Phoenix Contact TRIO-PS-2G/1AC/24DC/10/B+D User manual

1Description
Power supply unit
TRIO-PS-2G/1AC/24DC/10/B+D
© PHOENIX CONTACT
Data sheet
TRIO POWER - power supplies with standard functionality
The power supplies of the TRIO POWER family convince
due to their slim and robust design. The dynamic boost (1.5
x INfor 5 seconds) absorbs starting currents and short
overload situations securely during operation and without a
drop in output voltage. The push-in connection technology
on the front enables fast and tool-free wiring of the devices.
Features
– Can be used on the bridge of a ship, thanks to optimized
EMC properties for supplying sensitive loads
– Tool-free connection via push-in connection
technology
– Safe operation, thanks to electrically and mechanically
robust design
– Especially slim design
– Worldwide use, thanks to wide-range input
– Reliable starting of heavy loads, thanks to dynamic
boost (1.5 x INfor 5 seconds)
– Simplified error diagnostics for remote signaling via DC-
OK signal contact
– OVP (Over Voltage Protection) limits surge voltages to
≤30VDC (EN61131-2)
Technical data (short form)
Input voltage range 100 V AC ... 240 V AC
-15 % ... +10 %
110 V DC ... 250 V DC
10 %
Mains buffering > 20 ms (120 V AC)
> 20 ms (230 V AC)
Nominal output voltage (UN) 24 V DC ±1%
Setting range of the output voltage
(USet)
24 V DC ... 28 V DC
Nominal output current (IN)
Dynamic Boost (IDyn.Boost)
10 A
15 A (5 s)
Output power (PN)
Output power (PDyn. Boost)
240 W
360 W
Efficiency typ. 90 % (120 V AC)
typ. 91.5 % (230 V AC)
Residual ripple < 20 mVPP
MTBF (IEC 61709, SN 29500) > 2200000 h (25 °C)
> 1300000 h (40 °C)
> 620000 h (60 °C)
Ambient temperature (operation) -25 °C ... 70 °C
-40°C (startup type tested)
> 60 °C Derating: 2.5 %/K
Dimensions W/H/D 42 mm / 130 mm / 160 mm
Weight 1 kg
Approved according to DNV GL (EMCB)
Make sure you always use the latest documentation.
It can be downloaded from the product at phoenixcontact.net/products.
105897_en_00 2017-07-27

TRIO-PS-2G/1AC/24DC/10/B+D
105897_en_00 PHOENIX CONTACT 2 / 26
2Tableofcontents
1 Description ..................................................................................................................................1
2 Table of contents.........................................................................................................................2
3 Ordering data ..............................................................................................................................4
4 Technical data.............................................................................................................................5
5 Safety regulations and installation notes ...................................................................................11
6 High-voltage test (HIPOT) .........................................................................................................12
6.1 High-voltage dielectric test (dielectric strength test) and why must it be performed?....................................12
6.2 High-voltage dielectric test during the manufacturing process......................................................................12
6.3 High-voltage dielectric test performed by the customer................................................................................12
6.4 Performing high-voltage testing ....................................................................................................................12
7 Basic circuit diagram ................................................................................................................. 13
8Structure.................................................................................................................................................................13
9 Cooling......................................................................................................................................14
10 Mounting position and dimensions ............................................................................................14
10.1 Mounting position .........................................................................................................................................14
10.2 Device dimensions .......................................................................................................................................15
11 Mounting/removal......................................................................................................................16
11.1 Assembly......................................................................................................................................................16
11.2 Removal .......................................................................................................................................................16
12 Device connection terminal blocks.................................................................................................................16
12.1 Push-in connection technology.....................................................................................................................16
13 Input ..........................................................................................................................................17
13.1 Position of input terminals.............................................................................................................................17
13.2 Protection of the primary side .......................................................................................................................17
14 Output .......................................................................................................................................18
14.1 Position of output terminals...........................................................................................................................18
14.2 Protection of the secondary side...................................................................................................................18
14.3 Output characteristic curve...........................................................................................................................18
15 Dynamic boost .......................................................................................................................... 19
16 Signaling.................................................................................................................................................................19
16.1 DC OK-LED ..................................................................................................................................................19
16.2 Floating signal contact..................................................................................................................................19

TRIO-PS-2G/1AC/24DC/10/B+D
105897_en_00 PHOENIX CONTACT 3 / 26
17 Derating .....................................................................................................................................20
17.1 Temperature-dependent derating................................................................................................................. 20
17.2 Installation height ......................................................................................................................................... 20
17.3 Position-dependent derating ........................................................................................................................ 20
18 Operating modes .......................................................................................................................24
18.1 Series operation ........................................................................................................................................... 24
18.2 Parallel operation ......................................................................................................................................... 24
18.3 Redundant operation.................................................................................................................................... 24
18.4 Increasing power.......................................................................................................................................... 25
19 Application example ..................................................................................................................26

TRIO-PS-2G/1AC/24DC/10/B+D
105897_en_00 PHOENIX CONTACT 4 / 26
Description Ty p e Order No. Pcs./Pkt.
Primary-switched TRIO POWER power supply with push-
in connection for DIN rail mounting, input: single phase,
output: 24VDC/10A
TRIO-PS-2G/1AC/24DC/10/
B+D
2903145 1
3Orderingdata
Accessories Ty p e Order No. Pcs./Pkt.
Redundancy module, 12 V - 24 V DC, 2 x 20 A, 1 x 40 A TRIO2-DIODE/12-24DC/
2X20/1X40
2907379 1
Redundancy module, 12 V - 24 V DC, 2 x 10 A, 1 x 20 A TRIO2-DIODE/12-24DC/
2X10/1X20
2907380 1
Multi-channel, electronic device circuit breaker with active
current limitation for protecting four loads at 24 V DC in the
event of overload and short circuit. With nominal current
assistant and electronic locking of the set nominal
currents. For installation on DIN rails.
CBM E4 24DC/0.5-10A NO-R 2905743 1
Multi-channel, electronic device circuit breaker with active
current limitation for protecting eight loads at 24 V DC in
the event of overload and short circuit. With nominal
current assistant and electronic locking of the set nominal
currents. For installation on DIN rails.
CBM E8 24DC/0.5-10A NO-R 2905744 1
VARIOFACE module, with two equipotential busbars (P1,
P2) for potential distribution, for mounting on NS 35 rails.
Module width: 70.4 mm
VIP-2/SC/PDM-2/24 2315269 1
VARIOFACE module with push-in connection and two
equipotential busbars (P1, P2) for potential distribution, for
mounting on NS 35 rails. Module width: 57.1 mm
VIP-3/PT/PDM-2/24 2903798 1
The range of accessories is being continuously extended. The current range of accessories can be found in
the download area for the product.

TRIO-PS-2G/1AC/24DC/10/B+D
105897_en_00 PHOENIX CONTACT 5 / 26
4 Technical data
Input data
Unless otherwise stated, all data applies for 25°Cambient temperature, 230VAC input voltage, and nominal
output current (IN).
Input voltage range 100 V AC ... 240 V AC -15 % ... +10 %
110 V DC ... 250 V DC 10 %
Extended input voltage range in operation > 88 V DC (Derating <99 V DC: 2%/V)
Switch-on voltage typ. 95 V DC
Shut-down voltage typ. 70 V DC
Electric strength, max. ≤300 V AC ( 15 s )
Network type Star network
Frequency range (fN)50 Hz ... 60 Hz 5Hz
Current consumption (for nominal values) typ. 3.1 A (100 V AC)
2.4 A (120 V AC)
1.4 A (230 V AC)
1.4 A (240 V AC)
2.5 A (110 V DC)
1.1 A (250 V DC)
Discharge current to PE
typ.
< 3.5 mA
< 0.8 mA (264 V AC, 60 Hz)
Mains buffering > 20 ms (120 V AC)
> 20 ms (230 V AC)
Inrush surge current I2t< 0.5 A2s
Switch-on current surge limitation typical after 1 ms 20 A
During the first few microseconds, the current flow into the filter capacitors is excluded.
Input fuse internal (device protection) 6.3 A
Choice of suitable circuit breakers 6 A ... 16 A (Characteristics B, C, D, K)
The external backup fuse must be approved for the (AC) supply voltage used and the voltage level.
Electric strength of the insulation
Insulation voltage input/output ( IEC/EN 60950-1 ) 3 kV AC (type test)
1.5 kV AC (routine test)
Production test 2.5 kV DC
