PICOTE SMART MIXER 2.0 Use and care manual

These instrucons are for your personal safety. Always ensure that you
have read and understood these instrucons before using the machinery.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
OPERATION & SAFETY MANUAL
Smart Mixer 2.0

Picote Soluons Oy Ltd 2www.picoteinstute.com
To watch practical demonstration videos, take a course, or to download an electronic copy of these Instructions, please visit
www.picoteinstitute.com. Please note that videos and courses are not intended as a replacement or alternative to this operating and
safety manual, but only as an additional learning tool.
TOPIC PAGE
Safety Informaon 3
General Machine Safety Informaon 4
Environment, Transport, Storage & Disposal 5
General Informaon 6
CE Declaraon of Conformity 7
Operang Instrucons 8
Troubleshoong Guide 13
Warranty Policy & Procedure 14
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE
TABLE OF CONTENTS

Picote Soluons Oy Ltd 3www.picoteinstute.com
Personal Protecve Equipment (PPE)
Always use Personal Protecve Equipment including suitable protecve clothing, footwear, plus:
Suitable eye protecon to protect against chemicals from irritang eyes.
Suitable gloves to help prevent any contact with chemicals. Do not use gloves which
can become entangled.
Suitable respirator to prevent any dust or fumes being inhaled or consumed, which
could cause occupaonal asthma or dermas.
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE
SAFETY INFORMATION
This secon contains important safety informaon. Failure
to comply could result in serious injury.
Safety Symbols
Safety symbols are used throughout this manual to draw aenon to potenal hazards.
Danger risk of serious injury, follow instrucons.
Danger risk of serious injury from rotang parts, follow instrucons.
Danger risk of entanglement.
Do not operate this machine unless long hair has been conned. Do not wear loose clothing,
gloves, jewelry or other items which can become entangled.

Picote Soluons Oy Ltd 4www.picoteinstute.com
1. Always wear eye and chemical resistant gloves.
Other personal protecve equipment, such as dust mask, gloves and overalls should be
worn when necessary. Do not wear loose clothing when using the machine. Always
wear appropriate personal protecve equipment.
2. Always ensure that the machine is fully turned o before inspecon, maintenance, or installing any accessories to
the machine. Always follow the instrucons in the manufacturer’s manual.
3. Before each use inspect the machine carefully for any potenal break or damage. Change damaged parts
immediately.
4. Do not place hand or nger in front of plungers while baery is aached. This could result in injury to operator.
5. When not in use, turn speed control to its minimum seng and remove baery pack. This prevents tool from starng
unintenonally.
6. Only use this machine with the accessories and spare parts oered by Picote Soluons. Accessories and spare parts
should only be used in the manner intended and as described by Picote Soluons.
Always read all safety warnings and instrucons. Failure to follow warnings and instrucons may result in electric
shock, re and/or serious injury.
This secon contains important safety informaon. Failure to comply could result in serious injury or death.
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE
GENERAL MACHINE SAFETY INFORMATION

Picote Soluons Oy Ltd 5www.picoteinstute.com
TRANSPORT
The Smart Mixer 2.0 should be transported in it’s carrying bag baery detached. Always use a suitable cover to protect
the unit from the elements.
STORAGE
The Smart Mixer 2.0 should be stored indoors to protect it from rain and sunlight and somewhere with a constant
ambient
temperature. The best way to store the machine is to use the bag it was delivered with.
If the machine has been stored in an environment colder than +10 oC or +50 oF, the machine should be stood at room
temperature for 24 hours before use.
If the machine has been stored for long periods of me (over 2-3 months), it should be checked and tested according to
the maintenance programme before use.
Charge the machine baery to around 80% capacity before storing for long periods.
DISPOSAL
Baery charger and the dispenser unit can be disposed of in Europe at Waste Electrical and Electronic Equipment
(WEEE) collecon points.
Always follow local waste handling rules and regulaons.
Recycle Li-ion baeries according to local regulaons.
PLEASE NOTE! Do not dispose of in re! Do not puncture!
ENVIRONMENTAL
Operaonal Ambient Temperature Range: -20 oC to +60 oC (-4 oF to +140 oF) frost and condensaon free
Charge Ambient Temperature Range: 0 oC to +45 oC (32 oF to +113 oF) frost and condensaon free
Storage Ambient Temperature Range: -20 oC to +45 oC (-4 oF to +113 oF) frost and condensaon free
Maximum Altude: 2000m or 6500 . Derate above 1000m or 3280: 1% / 100m or
328
Maximum Humidity: 95% non-condensing
This secon contains important safety informaon. Failure to comply could result in serious injury or death
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE
ENVIRONMENT, TRANSPORT, STORAGE & DISPOSAL

Picote Soluons Oy Ltd 6www.picoteinstute.com
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE
GENERAL INFORMATION
GENERAL DESCRIPTION
For more details about the funcon-
al descripon, please see page 8.
INTENDED USE
This Smart Mixer 2.0 is intended for the following use;
Mixing Picote Dual Coat 100% Solids Epoxy and Masc for the Picote Brush Coang™ Systems.
The Smart Mixer 2.0 is specically calibrated for Picote products.
Use Picote Mini Miller and Mini Coang Pump or Maxi Miller and Maxi Coang Pump to apply the resin. Always follow
the Picote Soluons instrucons when installing and using the machine with accessories.
VOLTAGE
Smart Mixer baery charger
Charger capability - 100 - 240 VAC power source.
A BATTERY OPERATED
2-COMPONENT DISPENSER

Picote Soluons Oy Ltd 7www.picoteinstute.com
We Picote Soluons Oy Ltd as the responsible manufacturer, declare that the following Picote Soluons Oy Ltd
dispensing machine:
Picote Smart Mixer
Model No: Smart Mixer 2.0
are of series producon and
Conform to the following EU Direcve:
2006/42/EY
2014/30/EU
2014/35/EU
And is manufactured in accordance with the following standards or standardised documents:
EN 62841-1:2014
The technical documentaon is kept by our authorised representave in Europe who is:
Picote Soluons Oy Ltd, Pienteollisuuse 24
06450 Porvoo, Finland
22th March 2022
8
Katja Lindy-Wilkinson
C.E.O.
Picote Soluons Oy Ltd
Pienteollisuuse 24, 06450 Porvoo, Finland
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE
CE DECLARATION OF CONFORMITY

Picote Soluons Oy Ltd 8www.picoteinstute.com
STARTING & USING THE MACHINE
Before operaon:
- Before installing Picote tools, always make sure that the machine is fully turned o and the
baery charger unplugged.
- Consult accessory operang manuals (Picote Millers and Coang Pumps) for detailed
informaon.
This secon contains important safety informaon. Failure to comply could result in serious injury
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE
OPERATING INSTRUCTIONS
Trigger
“ON”/“OFF” mechanism
Speed Control Knob  - SPEED + →
The speed feature allows you to speed up or slow down the ow of resin. To use this feature, turn the speed control knob to the
ow that is applicable to the applicaon.
Changing the speed while using the dosing feature will reduce or increase the amount of resin dispensed.

Picote Soluons Oy Ltd 9www.picoteinstute.com
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE
OPERATING INSTRUCTIONS
Dose Control Knob  -DOSE + →
The dose control knob has been disabled.
Baery Pack
To remove baery pack, squeeze both release buons and slide the baery pack forward.
To insert baery pack, slide baery pack fully onto the base of the handle.
Rack Handle
To reposion the pistons, open the clutch lever and push or pull the rack handle, as needed.
Cartridge Nozzle Opening
Line up the cartridge in the opening to ensure accurate cartridge alignment and proper engagement of pistons.

Picote Soluons Oy Ltd 10 www.picoteinstute.com
12
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE
OPERATING INSTRUCTIONS
13
Step 1. Open clutch lever to allow free movement of rack.
Step 3. Remove cartridge and replace with new one. Add the stac mixer to
new cartridge before inserng into Smart Mixer 2.0.
Step 2. Pull the rack fully open.

Picote Soluons Oy Ltd 11 www.picoteinstute.com
12
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE
OPERATING INSTRUCTIONS
13
Step 4. Push rack against the cartridge.
Step 5. Close rack lever.

Picote Soluons Oy Ltd 12 www.picoteinstute.com
12
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE
OPERATING INSTRUCTIONS
13
Step 6. Open Index Plungers of Coang Pump plaorm. Align the Smart Mixer 2.0 holes with Index Plungers.
Step 7. Release Index Plungers to lock Smart Mixer 2.0 into the plaorm. Check that both Index Plungers have
been locked to the Smart Mixer 2.0. Add resin cup to holder underneath the Smart Mixer 2.0 and start
dispensing the resin.

Picote Soluons Oy Ltd 13 www.picoteinstute.com
If there is problem that you cannot resolve with this manual, please consult your Picote
Reseller or Picote Solutions at [email protected]om.
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE
TROUBLESHOOTING GUIDE
SYMPTOM CAUSE REMEDY
Motor does not
start.
Trigger not depressed
Discharged baery
Speed seng too low
Baery pack not fully inserted.
Cartridge fully dispensed (dispenser shuts o
automacally)
Press trigger.
Use charger to recharge baery.
Increase speed seng
Remove and reinstall baery pack.
Remove and replace cartridge.
Motor stops
suddenly while
running.
Baery pack not fully inserted.
Cartridge fully dispensed (dispenser shuts o
automacally)
Remove and reinstall baery pack.
Remove and replace cartridge.
Motor stops
gradually or slows
down.
Discharged baery
Speed seng too low
Use charger to recharge baery.
Increase speed seng
Motor runs, but
resin is not being
dispensed.
Clutch open
Cartridge p not removed
Resin too cold.
Cured resin clogging mixing tube
Cartridge failure (blow by)
Close clutch.
Remove p.
Warm the resin.
Replace mixing nozzle (mixing tube).
Remove cartridge. Clean pistons and teeth. Install
new cartridge.
Resin is dispensed
very slowly
Discharged Baery
Speed seng too low
Resin too cold.
Cured resin clogging mixing tube
Cartridge failure (blow by)
Use charger to recharge baery.
Increase speed seng
Warm the resin.
Replace mixing nozzle (mixing tube).
Remove cartridge. Clean pistons and teeth. Install
new cartridge.
Dispensed resin is
not uniformly
mixed.
Resin too cold.
Cured resin in mixing nozzle
Cartridge failure (blow by)
Warm the resin.
Replace mixing nozzle (mixing tube).
Remove cartridge. Clean pistons and teeth. Install
new cartridge.
Rack handle is
dicult to push or
pull.
Clutch closed
Resin built up on rack
teeth
Open clutch
Remove cartridge. Clean pistons
and teeth. Install new cartridge.

Picote Soluons Oy Ltd 14 www.picoteinstute.com
20
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE
WARRANTY POLICY & PROCEDURE
Limited Warranty:
Picote warrants to the original End User that the Product purchased by such End User will operate in
accordance with, and substanally conform to their published specicaons when shipped or otherwise
delivered to the End User and for a period of one (1) year, except electric motors and baeries for which the
warranty period shall be six (6) months, provided, however, that Picote does not warrant any claim or
damage under this Warranty if such claim or damage results from:
1. Consumable parts or normal wear and tear resulng from use of the Products,
2. Product overload or overheated motor,
3. Regular periodic maintenance of Products,
4. Misuse, neglect, or improper installaon or maintenance of the Products, or use of Products
not for their intended purpose,
5. Products that have been altered, modied, repaired, opened or tampered with by anyone
other than Picote or an authorized Picote Service Centre, or unsuitable or unauthorized spare
parts, accessories or third party products when using the Products or;
6. the use of the Products not in compliance with their respecve Documentaon, user manuals,
safety and maintenance instrucons, and any usage restricons contained therein, or
7. accident, re, power failure, power surge, or other hazard.
Otherwise, the Products are sold AS IS. End User is responsible for using the Products within
their specicaons and instrucons as contained in the Documentaon.
EXCEPT AS SPECIFIED IN THIS WARRANTY, ALL EXPRESS OR IMPLIED CONDITIONS,
REPRESENTATIONS, AND WARRANTIES INCLUDING, WITHOUT LIMITATION, ANY IMPLIED WARRANTY OR
CONDITION OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, NON INFRINGEMENT,
SATISFACTORY QUALITY OR ARISING FROM A COURSE OF DEALING, LAW, USAGE, OR TRADE PRACTICE,
ARE HEREBY EXCLUDED TO THE EXTENT ALLOWED BY APPLICABLE LAW. TO THE EXTENT AN IMPLIED
WARRANTY CANNOT BE EXCLUDED, SUCH WARRANTY IS LIMITED IN DURATION TO THE WARRANTY
PERIOD. BECAUSE SOME STATES OR JURISDICTIONS DO NOT ALLOW LIMITATIONS ON HOW LONG AN
IMPLIED WARRANTY LASTS, THE ABOVE LIMITATION MAY NOT APPLY. This disclaimer and exclusion shall
apply even if the express warranty set forth above fails of its essenal purpose.

Revision number: Rev. 1
Author: Ville Hukkanen
Accepted: Dawn Greig 22/3/22
Date: MAR 2022
Please Contact:
Your Reseller / Salesperson or Picote
www.picotegroup.com
Finland. United Kingdom. USA.
Authorised Resellers:
www.picotegroup.com/resellers
support@picotesoluons.com Pienteollisuuse 24
06450 Porvoo, Finland
support@picotesoluons.com
Producon & R&D
Internaonal Oces Technical Support
Claims
claims@picotesoluons.com
