Pifco P29002 User manual
Instruction Manual
Product may dier slightly from the one shown
P29002
For An Additional Two Year’s Guarantee
Please Register Your Appliance
At e Website Below
and enjoy the peace of mind
of a
HANDHELD STEAM CLEANER
P29002
www.pifco.co
Product Helpline. 0871 221 3615 For all your product needs.
product may dier slightly from the one shown
*
*
GUARANTEE
YEAR
*
3
GUARANTEE
YEAR
*
3
PARTS IDENTIFICATION
TECHNICAL DATA
Specication
Model No.
P29002
Rated Voltage & Frequency
220V-240V ~50Hz
Power consumption
1000W
Operating Pressure
300KPA
Sutton House,
Berryhill Road,
Fenton
Stoke on Trent
Staordshire,
ST4 2NL.
ACCESSORIES (SUPPLIED WITH THE PRODUCT)
1. Housing
2. Handle
3. Steam button
4. Accessory connection
5. Safety lid
6. Power control lamp
7. Mains cable
8. Rubber sealing
1
5
43
2
7
6
8
Brush. Extension Hose.
Nozzle. 90 Degree Nozzle.
Scrubbing Brush.
Window Cleaner.
Please Note
e product also comes with a cloth Filling jug and a funnel as we have tried to ensure
that you are prepared for almost any household task.
Please be aware when using this product, that steam is very hot and
will scald if it comes into contact with your skin use extreme care when
using this product and ensure that children, the inrm, and pets are kept
at a safe distance and children or the inrm, are not allowed to play with
or use this product.
Product Helpline. 0871 221 3615 For all your product needs.
IMPORTANT SAFETY INSTRUCTIONS:
1 2
During the use of electrical appliances, Please following the safety instructions.
Do not leave the appliance unattended while it is switched on.
Unplug the appliance from the mains supply socket before cleaning or maintenance
and before you ll or empty the water tank.
e appliance must be kept out of children’s reach.
is product is not recommended or intended for use by children or the inrm in any
circumstance, due to the nature of the product.
Use ONLY the accessories provided in the box.
Please ensure that the product is undamaged before use.
Do not use the power cord to carry the appliance.
Ensure that the power cord does not come into contact with hot surfaces.
Check the appliance and the mains power cord before each use.
Aer use unplug the appliance from the mains supply socket.
During the operation keep the openings and the air outlet free.
Do Not allow this product to tilt to 45oor above during operation.
When the appliance is in operation the nozzles should not be directed toward
humans, animals or plants.
Never immerse the appliance into water.
Only use water in the appliance. De scaler, Detergent etc. should not be added or used
When Filling the water tank :
1 Unplug the appliance from the mains supply socket.
2 Press the steam button to release the residual pressure.
3 Let the appliance cool down.
4 Press the steam button again to release the residual pressure.
5 Release the safety lid and remove it in about 5 minutes.
Warning! e appliance heats up in the operation therefore do not touch the hot sur-
face; use only the handles or buttons.
Always switch o at the wall socket and remove the plug then allow the appliance cool
down completely before removing or attaching accessories to the product.
If the power supply cord or product is damaged, it must be replaced or repaired by
the manufacture, service agent or a electrically qualied person in order to avoid an
electrical hazard.
Before any cleaning or maintenance unplug the appliance from the mains supply socket
and allow to cool down suciently.
is product is intended for household use only, is is not a commercial product.
Warning! Beware that the nozzle gets very hot during operation.
Danger of scalding! Do not come into contact with steam jet or nozzle.
Do not place the appliance directly onto so plastics or other non heat resistant materi-
als.
Where there is a need to sterilise or degrease area in the home this product is ideal and
will do it without, the need for harsh or dangerous chemicals. is product uses the
power of steam, which is over 100oCelsius and will kill most germs and mites in most
the household environment.
e Scrubbing brush this can be used for fabrics and clothes when used in
conjunction with the cloth and window wiper.
e Brush is used to remove hard stubborn stains in the kitchen
or Bathroom such as tiles or the cooker burned on spills.
e Hose can be used to extend the reach of the other attachments or this
hose can be used on its own.
e Window Wiper this is used on mirrors, windows.
Do Not use steam directly onto cold glass (outside window)it may shatter
the glass.
e Straight nozzle is ideal for tasks around the kitchen such as work top
joints and shelves.
e 90obend Nozzle can be used in dicult to reach areas such as the toilet
bowl or cooker ect.
HOW TO USE THE APPLIANCE
is appliance cleans by using steam under pressure and it is this, that removes the
grease, grim and it has numerous uses below are just a few.
e steam cleaner can be used in the bedroom to disinfect bedding curtains and
clothes.
e steam cleaner can be used in the kitchen to clean and sterilise the fridge.
e steam cleaner can be used in the bathroom to remove stubborn deposits.
e steam cleaner can be used on the car to remove oil grease and brake dust from
your alloy wheels.
ere are some surfaces and materials that this product is not recommended for.
cold glass. If the hot steam is used directly on to cold glass it may cause the glass to
shatter due to a process called thermal shock.
Treated wood. & Furniture where wood the steam can damage the surface if you
are contemplating cleaning with the steam cleaner it is always advisable to test it on a
area where if it is damaged by the steam it will not be seen.
WHAT TOOL FOR WHAT JOB?
WARNINGS AND SAFETY PRECAUTIONS
HOW YOUR APPLIANCE WORKS
3 4
Aer removing from the packaging you will need to follow some basic steps to 1.
Release the safety lid.
Fill appropriate water into the water tank. Please use the provided measuring cup and
the funnel. It is recommended that you ll the tank to Max 2/3 full.
Never use de scaler, perfume or detergent in the water tank, of the appliance. as this
may damage the heating element.
Close the safety lid again.
Attach the desired accessory (nozzle, hose, scrubbing brush etc.) on the appliance:
set the accessory on the connection and press it up to the rubber sealing.
Turn the accessory in the clockwise direction, until it locks into the position.
e brush and the curved nozzle:
e brush and the curved nozzle can be assembled on the hosing, with the hose or the
straight nozzle. (Figure)
Window wiper:
Warning! Do not operate this appliance directly on cold glass.
e window wiper must be attached to the scrubbing brush. Assemble the scrubbing
brush in the appliance or the hose at rst. Take o the cloth from the scrubbing brush
and connect with window wiper to the brush by the two hinges (gure). e window
wiper can be dismantles easily by loosening the hinges again.
Attach the appliance to the mains supply and the control lamp lights up.
As soon as the preheating (about 3-4 min) has terminated, the control lamp goes out.
Make sure that you do not switch the appliance on during the preheating process.
Switch the appliance on and move it slowly over the surface, which is to be cleaned. It
is recommended that the distance between the nozzle and the surface amount to 2-3
cm.
It is normal that the thermostat control light will cycle on and o during the process,
since the thermostat controls the heating element automatically.
Maintenance:
is appliance does not requires any special maintenance.
Do not try to repair the appliance. Repairs of electrical appliances must be carried our
by qualied electrician or other suitably trianed personnel.
HOW TO USE THE APPLIANCE HOW TO USE THE APPLIANCE
5 6
Possible cause
Appliance not plugged
correctly
Mains supply socket
damaged
Fuse blown
No water in tank
No water in tank
Too much water in the tank
Appliance overly tilted
Appliance not hot enough
Water tank still very hot
Accessory not correctly
attached
Appliance damaged
Advice
Attach the appliance
to mains supply socket again
Check the socket
Change the fuse
Fill water in tank
Fill water tank.
Empty water
Hold the appliance correctly.
Let the appliance heat up.
Let the appliance cool down
Use the funnel
Attach the accessory again
securely
Contact the customer service
Problem
Appliance does not
power up
No steam
Water runs our
from nozzle
Water boils while ll-
ing up the tank
Accessory comes
loose
Other problems
Class 1 Configuration
The wires in the mains lead are coloured in
accordance with the following code:
GREEN/YELLOW: EARTH (E)
BLUE: NEUTRAL (N)
BROWN: LIVE (L)
Class 1 Configuration
As the colours of the wires in the mains
lead of this appliance may not correspond
with the coloured markings identifying the
terminals in your plug, proceed as follows:
• ThewirewhichiscolouredGREEN&
YELLOW (or coloured GREEN) must
be connected to the terminal in the
plug which is marked with the letter “E”
or by the earth symbol .
• ThewirewhichiscolouredBLUE(or
coloured BLACK) must be connected
to the NEUTRAL terminal which is
marked with the letter “N”.
• ThewirewhichiscolouredBROWN(or
coloured RED) must be connected to
the LIVE terminal which is marked with
the letter “L”.
Always ensure that the Mains Cord is fixed
into the plug through the Cord Guard or
Cable
Clamp, (plug wiring diagram above),
and that the Cord Guard screws are
tightened to clamp the cord (outer
sheath and inner coloured wires) into
position in the plug. Make sure that the
plug top is also fitted securely.
This appliance must be protected by a
5 Amp fuse in a 13 Amp type (BS1363)
plug. Should you need to replace the
fuse, use only a 5Amp ASTA approved
BS1362 fuse (3A).
OPERATIONAL GUIDELINES
It is important to ensure the correct
Plug Adaptor is used when operating
in a country not using the UK 13 Amp
socket system. If in doubt, consult a
qualified electrician.
41mm O All
6mm Bare
15mm O All
6mm Bare
35mm O All
6mm Bare
41mm O All
6mm Bare
ELECTRICAL SAFETY TROUBLESHOOTING
7 8
Disposal instructions for Elgento items in accordance with the WEEE directive.
Appliances bearing the symbol shown here may not be disposed of in domestic
rubbish. You are required to dispose of old electrical and electronic appliances
like this separately. Please visit www.recyclemore.co.uk, or www.recylcenow.co.uk
for access to information about the recycling of electrical items.
Please visit www.weeeireland.ie for access to information about the recycling
of electrical items purchased in Ireland.
e WEEE directive, introduced in August 2006, states that all electrical items must
be recycled, rather than taken to landll. Please arrange to take this appliance to your
local Civic Amenity site for recycling, once it has reached the end of its life.
Declaration of Conformity
We PFD Ltd Declare that this product conforms to all the following
product legislation
In accordance with the following directive(s):
2004/108/EEC. e Electromagnetic compatibility Directive
2006/95EC. e LVD directive (Low Voltage Directive)
2002/95/EC. e RoHS. Directive. (Restriction of Hazardous substances Directive)
1935/2004/EC Materials & Articles in Contact with Food. (LFBG section 30, 31 & 35)
Peter Bowden
Quality Assurance Manager
Sutton House, Berryhill Road, Fenton, Stoke-On-Trent,
Staordshire, ST4 2NL.
Made by or on behalf of R K Wholesale Limited under licence from
Spectrum Brands (UK) Limited. Pifcois the registered trade mark
of Spectrum Brands (UK) Limited
is product is guaranteed for 12 months from the date of original purchase.
If any defect arises due to faulty materials of workmanship the faulty products must
be returned to the place of purchase. Refunds or replacement is at the discretion of the
store.
e following conditions apply:
e product must be returned to the retailer with proof of purchase.
e product must be installed and used in accordance with the instructions contained
in this instruction guide.
It must be used only for domestic purposes.
It does not cover wear and tear, damage, misuse or consumable parts.
PFD has limited liability for incidental or consequential loss or damage.
is guarantee is only Valid in the UK and Eire Only.
DISPOSAL OF UNIT
GUARANTEE
910
Table of contents
Other Pifco Steam Cleaner manuals
