Pifco PS012N User manual

12 IN 1
STEAM MOP
MODEL PS012N
YOUR SAFETY &
INSTRUCTION MANUAL
PLEASE READ CAREFULLY
www.pifco.co

2
CUSTOMER SUPPORT TEAM: [phone]
TECHNICAL DATA
Description: 12 in 1 Steam Mop
Model: PS012N
Rated Voltage: 220V-240V ~50/60Hz
Power Consumption: 1500 Watts
Water Capacity: 400ml
Waterproof Level: IPX4
DOCUMENTATION
We declare that this product conforms to the following product legislation in accordance with the
following directive(s):
2014/30/EU Electromagnetic Compatibility Directive.
2014/35/EU Low Voltage Directive.
2011/65/EU Restriction of Hazardous Substances Directive.
2009/125/EC Eco-Design of Energy Related Products.
RK Wholesale LTD Quality Assurance, United Kingdom
WARRANTY
This product is guaranteed for 12 months from the date of original purchase. If any defect arises due
to faulty materials of workmanship, the faulty products must be returned to the place of purchase.
Refund or replacement is at the discretion of the retailer.
The following conditions apply:
• The product must be returned to the retailer with proof of purchase.
• The product must be installed and used in accordance with the instructions contained in this
instruction guide.
• It must be used only for domestic purposes.
• It does not cover wear and tear, damage, misuse or consumable parts.
• RK Wholesale LTD has limited liability for incidental or consequential loss or damage.
• This guarantee is only Valid in the UK and Eire Only.
An extended warranty is available for this appliance.
See back page for details.

3
www.pifco.co
WIRING SAFETY FOR UK USE ONLY
IMPORTANT
As the colours in the
mains lead of this
appliance may not
correspond with the
coloured markings
identifying the terminals
in your plug, please
proceed as follows:
The wires in the mains lead are coloured in
accordance with the following code:
Blue neutral [N] Brown live [L]
Green/Yellow [EARTH]
Plug Fitting Details (Where Applicable).
The wire coloured blue is the neutral and must be
connected to the terminal marked [N] or coloured
black.
The wire coloured brown is the live wire and
must be connected to the terminal marked [L] or
coloured red.
The wire coloured green/yellow must be
connected to the terminal marked with the letter
[E] or marked .
On no account must either the brown or the blue
wire be connected to the [EARTH] terminal .
Always ensure that the cord grip is fastened
correctly.
The plug must be tted with a fuse of the same
rating already tted and conforming to BS 1362
and be ASTA approved.
If in doubt consult a qualied electrician who will
be pleased to do this for you.
Non-Rewireable Mains Plug
If your appliance is supplied with a non-
rewireable plug tted to the mains lead and
should the fuse need replacing, you must use an
ASTA approved one (conforming to BS 1362 of
the same rating).
If in doubt, consult a qualied electrician who will
be pleased to do this for you.
If you need to remove the plug – disconnect it
from the mains – and then cut it o of the mains
lead and immediately dispose of it in a safe
manner. Never attempt to reuse the plug or insert
it into a socket outlet as there is a danger of an
electric shock.
WARNING:
This Appliance MUST be Earthed
FUSE

4
CUSTOMER SUPPORT TEAM: [phone]
PRODUCT SAFETY
When using any electrical appliance, basic safety precautions should
always be followed including the following:
• Check that the voltage of the
main circuit corresponds with
the rating of the appliance
before operating.
• Please ensure that the
appliance is used on a stable,
level, and heat resistant
surface.
• DO NOT immerse cords,
plugs or any part of the
appliance in water or any
other liquid.
• DO NOT leave the appliance
unattended while it is
operating.
• Close supervision is
necessary when any
appliance is used by or near
children or pets.
• This appliance can be used
by children aged from 8 years
and above and persons with
reduced physical, sensory
or mental capabilities or
lack of experience and
knowledge if they have
been given supervision or
instruction concerning use of
the appliance in a safe way
and understand the hazards
involved.
• Children shall not play with
the appliance.
• Cleaning and user
maintenance shall not be
made by children without
supervision.
• Switch o at the wall socket
then remove the plug from
the socket when not in use or
before cleaning.
• If the supply cord or appliance
is damaged, stop using
the appliance immediately
and seek advice from the
manufacturer or its service
agent or a similarly qualied
person.
• DO NOT let the cord hang
over the edge of a table or
counter or let it come into
contact with any hot surfaces.
• The use of accessory
attachments is not
recommended by the
appliance manufacturer
apart from those supplied
with this product. DO NOT
use extension cords with the
appliance.
• DO NOT pull the plug out by
the cord as this may damage
the plug and/or the cable.
• DO NOT use this product
for anything other than its
intended use.

5
www.pifco.co
• This appliance is for
household use only.
• DO NOT carry the appliance
by the power cord.
• DO NOT use the appliance
outdoors.
• Never direct steam towards
people, animals or plants.
• DO NOT handle the plug
or the steam mop with wet
hands or operate without
shoes.
• DO NOT insert any objects
into openings in the unit
and DO NOT use with any
opening blocked including the
steam output.
• DO NOT use the mop head
without oor cloth or without
water in the water tank.
• Use extra caution when using
on stairs as the cable can
become a trip hazard.
• DO NOT use hot water or
chemicals in the water tank.
• The liquid or steam should not
be directed towards electrical
equipment.
• Stop using the steam mop if
water leakage is observed,
and contact a qualied
electrician to test and repair
the unit.
• DO NOT use the steam mop
in enclosed spaces that
are lled with ammable, or
explosive or toxic vapours.
• DO NOT use on heat sensitive
materials e.g., leather or
waxed ooring.
• DO NOT use for space
heating purposes.
• DO NOT touch hot surfaces
with the cable or the product
and allow to cool before
assembly or disassembly
occurs.
• In the unlikely event the
appliance develops a fault,
stop using it immediately
and seek advice from the
Customer Support Team.
HIGH VOLTAGE HOT SURFACE

6
CUSTOMER SUPPORT TEAM: [phone]
7
8
9
10
11
12
13
14
15
16
19
WHAT’S IN THE BOX
Instruction Manual
1. Handle
2. Cord hooks
3. Power switch
4. Water tank cover
5. Variable steam control
6. Triangle mop head
7. Cup
8. Funnel
9. Carpet glider
10. Microbre cloth
11. Metal brush tool
12. Nylon brush tool
13. Scraper tool
14. Angled nozzle
15. Brush tool
16. Steamer cloth
17. Steamer shelf
18. Squeegee attachment
19. Cone Steam Nozzle
20. Blind Attachment
21. Microbre cloth for Blind Attachment
BEFORE YOUR FIRST USE:
1. Remove the parts from the packaging.
2. Assemble as instructed in the assembly page.
3. Your appliance is now ready for normal use.
Dispose of the packaging in a responsible manner.
1
2
3
4
5
6
17
18
20
21

7
www.pifco.co
ASSEMBLY
Handle sections assembly:
Push tube into body ensuring the locking
spring assembly has locked.
To disassemble: push button and pull out tube
with some full force. (Fig.1)
Pad assembly:
Fit the pad on base and pull the draw string to
secure. (Fig.2)
Carpet Glider Assembly:
Place the carpet glider part onto the base with
its pad covering it. Then let the retaining clips
x it into position. To remove pull gently on the
outer rim of the glider until it is free. (Fig. 3)
FILLING THE UNIT
IMPORTANT: Always insure that the unit is
disconnected from the wall socket prior to initial
lling and before tting the bottom of the mop
head.
Never use the steam mop without the
microbre cleaning pad securely in place.
Filling the water tank:
Turn the cap anti-clockwise and then lift up to
remove from the water tank. (Fig, 4)
Using the lling cup and funnel, pour one cup
of water into the water tank. Do not overll the
tank. (400ml) (Fig, 4)
Replace the cap onto the water tank
After lling up the water tank, turn the power
button on. The light on button will show red
indicating that the boiler is beginning to heat
the water, the pump will also engage and the
steam will be produced from the base. To
switch o the steam mop set the power switch
to the o position then unplug from the main
supply and allow to cool.
Fig 1
Fig 2
Fig 3
Fig 4

8
CUSTOMER SUPPORT TEAM: [phone]
USING YOUR APPLIANCE
IMPORTANT: Never use the steam mop
without the microbre cleaning pad attached
to the mop head or without water in the water
tank.
Note: It’s better to sweep or vacuum oors
before using the steam mop.
1. Twist the quick release cord holder to
unwrap the power cord completely.
2. To turn on your steam mop, plug it
in and the steam mop will power on
automatically.
3. Turn on the steam switch and steam will
wet the microbre cloth. It is normal for
the pump to make a little noise and shake
when begins working.
4. Adjust the steam output according to your
preference.
5. When the water tank is empty, a noise will
come from the pump and it will shake.
Switch o the appliance immediately
and rell the water tank following the
instructions under the ‘Filling Your
Appliance’ section.
6. When you have nished using the steam
mop, unplug the unit from the electrical
outlet and carefully remove.
7. Never leave the microbre cleaning pad
on the steam mop head when you have
nished using the steam mop; as the
dirt deposits and other foreign objects
may cause unpleasant odours and in
some cases may damage the surface it is
resting on.
8. For the best results wash the pads
after each use (additional pads may be
purchased online from www.pifco.co)
The benets of using a Pifco Steam Mop are
as follows:
• It will remove stubborn stains and sanitise
your work surfaces or oors more
eciently than conventional cleaning
methods.
• The steam cleaner can be assembled and
disassembled easily from a long mop type
steamer to a hand held steamer.
• It can be used as a hand held steamer
for those awkward places where the
portability of the product allows you to
achieve the extra cleaning protection that
conventional methods or products just do
not achieve.
Hand-held steamer:
The hand held steamer is an ideal portable
cleaner for use on work surfaces, counter tops,
sinks, windows, mirrors, tiles and spot cleaning
on oors, carpets and rugs. Use it with the jet
nozzle, brass brush or nylon brush attachments
to spray away dirt, grease, mould and more.
Remove the power supply cord from the upper
cord wrap and cord holder, turn the lower cord
wrap to release the cord and
remove the power supply cord
from its channel as illustrated in
Fig 5.
Press the extension handle lock
button and remove the extension
handle and the curved handle
from the main body.
Press the lock button on main body and
remove the mop head.
Fig 5

9
www.pifco.co
To attach the Jet Nozzle:
Insert the Jet Nozzle into the designated hole
in the Main Body until it locks in place with the
Lock Button on the Main Body (You will hear a
clicking sound), as illustrated in Fig. 6.
To t all accessories:
All accessories that attach to the jet nozzle
end, x by clicking in place and turning slightly
clockwise to secure in position.
They can be used with soap or detergent to
clean dirty areas.
WARNING: Never use the round brass brush
on soft surfaces such as plastic or soft metals
as they are prone to scratching.
When changing any of the attachments it
is recommended the appliance is switched
o and allowed to cool before changing or
adding the attachments
Window cleaning/garment cleaning:
This attachment is used to clean windows and
at glass products such as mirrors also this
attachment can be used for cleaning garments.
Too Fit the Squeegee attachment: Clip onto the
steamer shelf.
Too clean clothing: attach the steamer cloth.
To Fit the cover: Pull the elasticated steamer
cloth (Attachment 16) over the steamer shelf
(Attachment 17) This is now ready for use.
Also there is a squeegee blade for use on
windows & mirrors (Attachment 18).
WARNING: Do not use on frozen windows,
as the thermal shock may cause the glass to
crack or shatter. When cleaning fabrics where
possible it is recommended that you check
the fabric label to ensure that the fabric will
withstand the temperatures generated by the
steam or for large items or items that are not
labelled use a test area that will not be visible. It
is always best to have the material hanging as
this will aid with the eradication of creases on
the fabric item or clothing.
Fabric will be hot after the steam has been
applied.
Always test on a small piece of fabric before
use.
CLEANING AND CARE
Limescale:
If you live in a particularly hard water area, we
recommend using bottled or distilled water.
Warning: never pour vinegar or other liquid
cleaners for eliminating calcium into water tank.
After using the steam mop:
Disconnect power supply, allow Steam Mop
to cool completely and empty the water left
in water tank. Let the Steam Mop completely
cool down, clean with a damp cloth or a non-
abrasive (liquid) cleaner.
Fig 6
WARNING:
DO NOT IMMERSE ANY ELECTRICAL PART
OF THE APPLIANCE IN WATER SUCH AS
MOTOR UNITS OR PLUGS.
PLEASE SEE CLEANING SECTION FOR
FURTHER INSTRUCTIONS.

10
CUSTOMER SUPPORT TEAM: [phone]
ACCESSORY FITTING & USAGE GUIDE:
Accessory Image Use Connect To
Triangle mop
head
Flooring (please use
Carpet Glider when
using on carpets or
rugs)
Steamer shelf &
Blind attachment
Work surfaces, counter
tops, sinks, windows,
mirrors, tiles and spot
cleaning on oors,
carpets and rugs,
blinds and garments
Squeegee
attachment
Windows, mirrors and
tiles.
Attach the steamer
shelf to the squeegee
tool to use as a
window steamer
Cone Steam
Nozzle
To connect smaller
accessories to the
steam unit
Metal & Large
Nylon Brush
Ovens, Hobs,
Showers, Bath
Tubs, Tiles, Toys,
Refrigerators etc
Angled Nozzle
Stove Tops, Taps,
Sinks, Hard to reach
areas
Brush Tool Cleaning grout lines,
sanded or non sanded
Scraper Tool
Scraping baked on
foods, grime & grease.
Removing residue or
other substances from
surfaces such as hobs
and ovens

11
www.pifco.co
NOTES
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here
may not be disposed of in domestic rubbish.
You are required to dispose of old electrical
and electronic appliances like this separately.
Please visit www.recycle-more.co.uk or
www.recyclenow.co.uk
for access to information about the recycling
of electrical items.
Please visit www.weeeireland.ie for access to
information about the recycling of electrical
items purchased in Ireland.
The WEEE directive, introduced in August
2006, states that all electrical items must be
recycled, rather than taken to landll.
Please arrange to take this appliance to your
local Civic Amenity site for recycling, once it
has reached the end of its life.

0119.V8
We hope you enjoy your appliance for many years.
As a thank you for purchasing one of our fantastic products,
we are oering you an extra 2 year peace of mind.
*To receive your extra guarantee period, register your appliance online
within 28 days of purchase by visiting:
www.pifco.co
Make sure to retain your original receipt.
Should you have a problem
with your appliance or need any spare parts please call our
Customer Support Team on:
[phone]
Distributed throughout the UK by RK Wholesale LTD
