EASY REACH STEAM MOP
P29006
www.pifco.co
GUARANTEE
YEAR
*
3
GUARANTEE
YEAR
*
3

PARTS IDENTIFICATION
TECHNICAL DATA
Specication
Model No. P29006
Rated Voltage & Frequency
220V-240V 50Hz
Power consumption
800W (IPX4)
Sutton House,
Berryhill Road,
Fenton
Stoke on Trent
Staordshire,
ST4 2NL.
A. Base Of Main Unit
B. Water Tank
C1. Top Handle Sha
C2. Middle Handle Sha
C3. Bottom Handle Sha
D. Power ON/OFF Indicator Light
E. Water Tank Alert Light
F. Foot Switch
G. Handle
H. Stopper
I. Cleaning Pad (see Page 10)
J. Carpet Glider
K. Sha Adjustment Switch
L. Reset Button
A
F
K
G
B
D
E
L
H
C3
C2
C1
J
IIII
ASSEMBLING THE HANDLE AND SHAFT
Note: e three sha sections (C1,C2 & C3) are dierent.
e handle section (C1) with its plastic locating lug at its base should be inserted into
the top of the sha middle section
(C2). e locating lugs on the bottom of the handle section
(C1) will click into position.
Next locate this joined section of the sha into the top of the bottom section (C3)
in the same way as previously described.
e assembled sha should then be inserted into the main unit as shown in the two
photographs below.
Note: If the handle does not go right into its location, it is the wrong way round, please
do not force.
C3C2 C1 C2
NOTE:
When inserting the Bottom Handle Sha C3 in the main unit slide the sha
down to locate the plastic lug (1) in the hole (2).
To remove press on the lug
(1) at the same time pulling the sha upwards. Do NOT press on the cord cleat (3)
as it may break.
AB
2
3
1
1
1
*
2

1.FILLING THE WATER TANK (B)
Caution: Do not overll. Max water capacity 450ml. e Water Tank (B) can be lled at
anytime aer the pressure and temperature has been release suciently.
• Remove the Filler Cap (H) by turning anti-clockwise.
• Fill the Water Tank with so or distilled water. e Home-tek Water Soener Bottle
is designed and recommended for this purpose. However, any clean jug can be used
to ll the Water Tank
- but please NOTE - only soened or distilled water must be used in this product.
Aer lling replace the Filler Cap by turning it clockwise.
• Your Steam mop has a built in safety feature which ensures that if the unit is le
without water and the tank boils dry then the unit will automatically cut o the
power to the heater. If this occurs then before the product can be used again it has to
be le for approximately 10 minutes to cool down aer which the Reset Button (L )
can be pressed and the unit will reset.
• e Steam mop has a safety Filler Cap (H ) which can only be released when there
is no pressure in the boiler. e Filler Cap can only be unscrewed aer the unit has
cooled down and there is no pressure in the boiler.
3.POWER CABLE
Before using the appliance, completely release the full length of the power cable.
CAUTION: Do not leave the appliance in one area when hot as this may damage the
oor surface.
4. RED POWER ON / OFF INDICATOR LIGHT (D) / GREEN WATER TANK
ALERT LIGHT (E)
When the handle sha is placed securely and the tank lled with water, plug
the appliance into a mains electricity supply, at this point the Red Indicator Light (D )
will illuminate.
When you are ready to start cleaning press the Foot Switch (F) this activates the heater.
At this point the green
indicator light (E ) will illuminate. e Green Water Tank Alert Light (E) will go out if
the Water Tank needs re-lling.
IMPORTANT: Never use more than 5 pounds force on the foot switch. Excessive force
willdamage the switch.
CAUTION: Always turn o all the switches when relling with water and always
unplug the
product aer use.
5. REFILLING THE STEAM MOP
Always make sure that your Steam Mop has cooled before attempting to unscrew the
Safety Filler
Cap ( ) to rell your mop. Aer relling with distilled or soened water, plug
the appliance into a
mains electricity ssupply socket andthe Red Indicator Light (D) will illuminate
as described above.
en press the foot operated Foot Switch (F) this activates the heater and the Green
Water Tank
Alert Light (E) will illuminate. When both lights are ON steam will start to come from
the base of
the product and you are now ready to start cleaning the oor.
Note: It may initially take a few minutes before steam is produced aer both lights
illuminate.
IMPORTANT: Never execute more than 5 pounds force on the Pump Switch (F),
excessive force will damage the switch.
CAUTION: Always turn o all the switches aer usage and when relling with water.
6. CLEANING PAD (I)
e cleaning pad is held in position by special gripping strips which grip the main base
unit (A).
Align these with the grippers on the main base and press into place smoothing the
whole surface to remove any wrinkles.
To remove the pad for cleaning, just peel o. To clean the cloth, just machine wash,
(MAX. TEMP. Setting 60º C) or hand wash in hot soapy water and rinse. Should you
experience stubborn stains on your oor, it is possible to dampen the stain
with detergent before steaming it with your mop, but do ensure that the detergent
is compatible with the surface being cleaned.
NOTE: We only recommend the use of genuine accessories (ese can be purchased
from the web site).
3 4

7. CARPET GLIDER (J)
e Carpet Glider is only required when cleaning
and sanitizing your carpets or rough surfaces.
Place the Carpet Glider on the oor and place
the steam mop with the cleaning pad attached
into it. Note: Carpet Glider(J) does not clip onto
the steam mop.
e mop simply sits in the Carpet Glider.
CAUTION: e steam mop must be switched o before placing into the Carpet Glider.
It is recommended to test a small area of carpet in an unseen area for compatibility
with a steam process, do not allow the steam mop to stand stationary on one spot, the
heat may damage bres or polished surfaces.
8. USING THE STEAM MOP
Once the Steam Mop is generating steam, operate it by passing it slowly over
the surface to be cleaned. is is the ideal method to thoroughly clean your oor.
On some rough surfaces it may only be possible to pull the appliance backwards.
10. STORAGE
• Turn o all the controls and unplug the appliance from the electrical outlet.
• Wind the power cord around cord holder.
• Store the Steam Mop indoors in a cool, dry area.
CAUTION: Always empty water from the tank before storage.
5
IMPORTANT SAFEGUARDS
When using an electrical appliance, basic precautions should always be observed,
including the following:
To reduce the risk of re, electric shock, or injury read all safeguards and instructions
carefully before using this product and retain for future reference.
• Do not leave the appliance connected to an electrical outlet when it is not in use.
• Before using, make sure the appliance is lled with water.
• Do not operate this appliance if the cord or plug has been damaged or aer the
appliance has malfunctioned in any manner.
• Never disconnect the cord by pulling it from the outlet; grasp the plug and pull to
disconnect.
• Do not pull or carry by the cord, use the cord as a handle, close a door on the cord
or pull the cord around sharp corners or edges.
• Do not allow the cord to make contact with hot surfaces.
• Do not use extension cords or outlets with inadequate current rating. Care should
be taken to arrange the cord so that it can not be pulled or tripped over.
• e appliance must not be immersed for cleaning.
• Do not immerse the cord, plug or main unit into water or other liquids.
• Do not handle the plug or steam cleaner with wet hands or operate it without suitable
footwear.
• Use only as described in this manual. Use only the manufacturer’s recommended
accessories.
• Do not treat it as a toy.
• Close attention is necessary when used near children, pets or plants.
• Close supervision is recommended as children should not play with the appliance.
• is appliance is not intended for use by children or the inrm unless they have
been given supervision or instruction concerning use of the appliance by the person
responsible for their safety.
• Fill the tank with distilled water or water that has been soened with an appropriate
water soener to prevent lime scale build-up which will prolong the life
of the appliance. Do not use ordinary tap water in this appliance even in a so water
area.
• Never put products containing perfumes, alcohol or detergent into the
appliance, this will cause damage, make it unsafe and invalidate your warranty.
• Never turn the appliance over on its side when using steam. Never
direct steam towards people, animals or plants.
• Do not use the appliance in an enclosed space lled with vapours given o by oil
based paint, paint thinner, some moth proong substances, ammable dust, or other
explosive and toxic vapours.
• Do not touch the hot surface or steam. ere is a danger of scalding.
• Do not block the appliance’s openings.
• Steam must not be directed towards equipment containing electrical components.
6

IMPORTANT SAFEGUARDS
• Do not touch the hot surface or the steam. ere is a danger of scalding.
• Do not block the appliance’s ventilation openings.
• Steam must not be directed towards equipment containing electrical
components.
• Do not use on wax polished oors or other delicate, steam sensitive
materials. DO NOT USE on unsealed wood oors.
• Turn o and allow all the steam to escape before unplugging from the
electrical outlet.
• Unplug the appliance from the electrical outlet before relling the
water tank, adding or removing components or cleaning.
• Allow the appliance to cool down completely before storing. Loop the
cord loosely around the cable hooks when storing.
• Store indoors. Do not expose the appliance to rain or a damp atmospheres.
• Carpet Glider attachment is for use on carpets only. Do not use the
Carpet Glider on hard oor surfaces.
• Do not operate the appliance if the main cord or plug is damaged, in order to avoid
a hazard it must only be replaced by a qualied person
• is unit is for household use only.
Declaration of Conformity
We PFD Ltd Declare that this product conforms to all the following
product legislation
In accordance with the following directive(s):
2004/108/EEC. e Electromagnetic compatibility Directive
2006/95EC. e LVD directive (Low Voltage Directive)
2002/95/EC. e RoHS. Directive. (Restriction of Hazardous substances Directive)
Peter Bowden
Quality Assurance Manager
Sutton House, Berryhill Road, Fenton, Stoke-On-Trent,
Staordshire, ST4 2NL.
87
GUARANTEE
is product is guaranteed for 12 months from the date of original purchase.
If any defect arises due to faulty materials of workmanship the faulty products must be
returned to the place of purchase. Refunds or replacement is at the discretion
of the Retailer.
e following conditions apply:
e product must be returned to the retailer with proof of purchase.
e product must be installed and used in accordance with the instructions contained
in this instruction guide.
It must be used only for domestic purposes.
It does not cover wear and tear, damage, misuse or consumable parts.
PFD has limited liability for incidental or consequential loss or damage.
is guarantee is only Valid in the UK and Eire Only.
DISPOSAL OF UNIT
Disposal instructions for Pifco items in accordance with the WEEE directive.
Appliances bearing the symbol shown here may not be disposed of in domestic
rubbish. You are required to dispose of old electrical and electronic appliances like this
separately. Please visit www.recyclemore.co.uk, or www.recylcenow.co.uk for
access to information about the recycling of electrical items.
Please visit www.weeeireland.ie for access to information about the recycling of
electrical items purchased in Ireland.
e WEEE directive, introduced in August 2006, states that all electrical items must
be recycled, rather than taken to landll. Please arrange to take this appliance to your
local Civic Amenity site for recycling, once it has reached the end of its life.

AVAILABLE ACCESSORIES
TO PURCHASE THE ABOVE PRODUCTS.
PLEASE USE THE WEB ADDRESS BELOW
Made by or on behalf of R K Wholesale Limited under licence from
Spectrum Brands (UK) Limited. Pifco is the registered trade mark
of Spectrum Brands (UK) Limited
Product Helpline. 0871 221 3615 For all your product needs.
www.pifco-products.co.uk
WATER SOFTNER
Code: P29006002
CLEANING PADS
Code: P29006001
9 10
ELECTRICAL SAFETY
Class 1 Conguration
e wires in the mains lead are coloured in accordance with the following code:
GREEN/YELLOW: EARTH (E)
BLUE: NEUTRAL (N)
BROWN: LIVE (L)
Class 1 Conguration
As the colours of the wires in the mains lead of this appliance may not correspond with the coloured mark-
ings identifying the terminals in your plug, proceed as follows:
e wire which is coloured GREEN & YELLOW (or coloured GREEN) must be connected to the terminal in
the plug which is marked with the letter “E” or by the earth symbol .
e wire which is coloured BLUE (or coloured BLACK) must be connected to the NEUTRAL terminal
which is marked with the letter “N”.
e wire which is coloured BROWN (or coloured RED) must be connected to the LIVE terminal which is
marked with the letter “L”.
Always ensure that the Mains Cord is xed into the plug through the Cord Guard or Cable Clamp, (plug wir-
ing diagram above), and that the Cord Guard screws are tightened to clamp the cord (outer sheath and inner
coloured wires) into position in the plug. Make sure that the plug top is also tted securely.
is appliance must be protected by a 13Amp fuse in a 13 Amp type (BS1363) plug. Should you need to
replace the fuse, use only a 13Amp ASTA approved BS1362 fuse (13A).
OPERATIONAL GUIDELINES
It is important to ensure the correct Plug Adaptor is used when operating in a country not using the UK 13
Amp socket system. If in doubt, consult a qualied electrician.
