Pinell Go radio User manual

Thank you
of Norway

Menu / Back
Previous
Power
on / off
Toggle DAB / FM
( press & hold )
Next
OK

As a user of our product, you are the most
important person at Pinell.
We strive to make high quality audio products for
the most demanding users. Imagined, designed
and developed at our headquarter in Norway.
It’s for people like you we work hard every day to
keep improving the quality and user friendliness
of our products.
We sincerely hope you will get much joy and
entertainment from your new radio.
Thank you for choosing a Pinell.
The Pinell Team
Oslo, Norway

4
The Pinell Go radio works in three modes:
DAB radio, FM radio and line input ( AUX ).
When you plug an audio cable into the audio
input, the Go automatically switches to AUX
mode. Unplug the cable to go back to radio.
When no audio cable is connected, hold the
PINELL button to switch between DAB and FM.
Each mode has a dedicated menu called a Mode
Menu. Press MENU to access this.
While navigating any menu, press MENU to
move one step back or exit.
General settings that apply to all modes can be
adjusted in the System Menu. You can reach the
System Menu from any Mode Menu.
General operation
Note: To reduce your power consumption, the Pinell Go will
automatically power off after 4 hours of uninterupted playback.
Press any button or the volume control to extend this period.

5
4 steps to get you started
Mount the appropriate plug for your
country to the power adapter.
Plug the power cord
into the Pinell Go.
Press PINELL
Follow the on-screen instructions to set up the
radio. See next page for details.
1
2
3
4
10 V DC (1.6A)

In the box you will find a power adapter and
3 international power plugs. Mount the plug
appropriate for your country and connect the
power cord to the Pinell Go.
When you start the radio for the first time, you
will be asked to choose your preferred language.
Use the left and right buttons to find your
language and press OK (center) to continue.
The radio will now automatically scan for all
available DAB and FM stations. We recommend
to extend the aerial before this scan, to allow
optimal reception for the Pinell Go to find all
available stations in your area.
That’s it! Happy listening.
6First time startup

1
2 3
4 5
6

8A few words about the battery
The Pinell Go is equipped with a powerful
battery which should give you at least 24 hours
of real playback time. In some cases more.
Feel free to leave the radio plugged into
your power outlet at all times. We’ve built
in intelligent battery management that
automatically stops charging when the battery
is full. The radio will thereafter run directly from
wall power.
If your battery is completely exhausted, it’ll
take about 2-3 hours to reach a 75% charge. To
protect your battery and to optimize its total
lifespan, it’ll take longer to fill the remaining
quarter of your battery. A total of 12 hours is
usually needed to charge the battery from empty
to completely full.

If the internal battery has been removed, a
battery icon with an “X” will be displayed.
When the battery is emtpy, the icon
will blink for a few minutes before
the radio shuts off.
The power cord icon is always
displayed when the radio is
connected to a power outlet.
During playback, the
battery indicator shows
remaining power.
Each of the four bars
represent approx. 25%
of battery life.
0 % 50 % 75 % 100 % 25 %
A filled battery symbol
is displayed when a
complete charge has
been reached. This
means charging has
stopped.

10 External audio
Connect your music player to the Pinell Go to
listen to your favourite music through the radio.
When you connect a standard “mini-jack” audio
cable the radio automatically switches to AUX
for immediate playback from your device.
Remove the cable to listen to
DAB or FM radio again.
AUX
AUX mode is auto-
matically activated
when an audio cable
is connected.
Sleep timer
with countdown
Battery level indicator
AUX Mode indicator
Power cord is
connected

AUX MODE MENU
System menu: From all Mode
Menus, this item will take you to
the System Menu. See page 16 for
more details.
Sleep: The sleep function will
power off the radio after a chosen
period of time. Options are 15, 30,
45, 60 and 75 minutes.

12 DAB Radio
DAB
Sleep timer
with countdown
Battery level
Mode
DAB strength
Station info Station name
Power cord is
connected
DAB means digital radio, and in several countries
it’s replacing the FM broadcast system. If you
don’t have DAB reception where you live right
now, chances are you soon will.
The first time you start the radio, all available
stations will be stored in your station list in
alphabetical order. No manual searching
is required.
Switch between DAB
and FM by holding the
“PINELL” button.

Rescan all stations: DAB stations
are available in certain areas. So
if you bring your Go to a new
location, the stored list of stations
may not be accurate. To fix this,
choose “Rescan all stations” to
refresh your station list to include
any newly available stations and
remove all unavailable stations.
Sleep: The sleep function will
power off the radio after the period
of time you choose. Options are: 15,
30, 45, 60 and 75 minutes.
Menu
Previous
station
Power
on / off
Toggle DAB / FM
( press + hold ) Next station
Station info
DAB MODE MENU

14
There are two ways to operate the radio in FM
Mode: Preset Mode and Search Mode. Preset
Mode is the default way: With LEFT and RIGHT,
you can easily cycle through the list of stored
stations. Search Mode is for when you want to
do manual frequency searches.
To store a new station: press and hold the center
button until “Station stored” is shown. To delete
a station from the list, press and hold the center
button and confirm when prompted.
FM Radio
FM
Sleep timer
with countdown
Battery level
Mode
Frequency
This icon is shown
when in Search Mode
Unstored stations
are shown with brackets
Power cord is
connected
Switch between DAB
and FM by holding the
“PINELL” button.

Frequency down
(hold to scan) Frequency up (hold to scan)
Toggle Preset /
Scan Mode
Rescan all stations: FM stations are
available in certain areas. So if you
bring your Go to a new location, the
stored list of stations may not be
accurate. To fix this, choose “Rescan
all stations” to refresh your station
list to include any newly available
stations and remove all unavailable
stations.
Sleep: The sleep function will
power off the radio after the period
of time you choose. Options are: 15,
30, 45, 60 and 75 minutes.
PRESET MODE
SEARCH MODE
Menu
Previous
station
Power on / off
Toggle DAB / FM
( press + hold )
Next
station
Battery level
FM MODE MENU

16
Bass: For the bass hungry, adjust
the bass level up to achieve more
punch. For the easily scared: adjust
it down to reduce bass power.
Treble: Adjust the treble to control
the clarity of the sound. For
example will more treble usually
increase the clarity of voices.
In the Display panel, the properties
of the display are adjusted. There
are two sections: Brightness adjusts
the screen brightness between low,
medium and high. Timeout adjusts
how quickly the display turns off
when no button has been pressed
for a while: Off, 10 sec, 20 sec, 30
sec, 1 min, 2 min and 3 min.
System menu

Language: Choose your preference
among the 10 built-in languages:
English, Nowegian, Danish, Swedish,
Finnish, French, German, Spanish,
Italian and Dutch.
Factory reset: This option will erase
all settings and stored stations,
and reset the radio to the standard
factory settings. After factory
settings are restored, you’ll be taken
to the first-time startup sequence as
described on page 6.
SW version: For service and
troubleshooting, here you can see
the currently installed software
versions on the radio.

Safety precautions
& recommendations
We recommend to switch off
the radio when not in use.
Don’t leave the radio within
the reach of small children.
Only use the power supply that came with your radio – or an
original replacement provided by your Pinell dealer. To prevent
damage to your radio and avoid the risk of electric shock, make
sure the power supply is not damaged and is connected according
to the information given in this manual and on the power supply.
You should also make sure the power supply is plugged into an
outlet that’s easy to reach. If your radio is damaged, please unplug
it from the mains power.
Make sure to place the radio
more than 1.5m away from
any water source.
The apparatus1shall not
be exposed to dripping or
splashing and no objects
filled with liquids, such as
vases, shall be placed on the
apparatus.
1 We’re sorry for using such complicated
language. Unfortunately, it’s mandatory by
law. It’s just a fancy way of saying ‘Radio’.
Don’t use your radio in very
damp conditions, such as in
a small bathroom with poor
ventilation. Make sure the radio
is not directly subjected to
water. Any contact with liquid
may cause irreparable damage.
If liquid enters the radio,
immediately disconnect it from
the power outlet and contact
your Pinell dealer.
Keep the radio away
from heat sources such as
radiators, candles, lamps, etc.
To avoid overheating, do not
place the radio in a tightly
confined space. Make sure to
leave at least 10cm of free air
on all sides.
Power supply: Pinell of Norway - Model:
Y18DE-100-1600 – Input: 100-240V ~ 50-60Hz
0.5A – Output: 10V DC 1600mA

Declaration of Conformity
We declare Pinell Go is in
conformity with directives
1999/5/EC & 2011/65/EU with
reference to these standards:
EN 5013:2001 + A1:2003 + A2:2006, EN
55020:2007 + A11:2011, EN 61000-3-2:2006
+ A1:2009 + A2:2009, EN 61000-3-3:2008, EN
60065:2002 + A1:2006 + A11:2008 + A2:2010
+ A12:2011, IEC 62133
The latest full version of our
declaration of conformity may
be found at: www.pinell.com/
declarations
Ole Morten Skymoen
CEO
Pinell
Postboks 150
0619 Oslo
Norway
Disposal of Waste Electrical & Electronic Equipment
This symbol on the product or on its packaging indicates
that this product should not be treated as household waste.
Instead it should be handed over to a suitable collection
point for the recycling of electrical and electronic equipment. By
ensuring this product is disposed of correctly, you will help prevent
potential negative consequences for the environment and human
health, which could otherwise be caused by inappropriate waste
handling of this product. The recycling of materials will help to
conserve natural resources. For more detailed information about
recycling of this product, please contact your local council office,
your household waste disposal service or the shop where you
purchased the product.
The use of headphones at high volume can
cause hearing damage. Sound perception can
be misleading. Over time, your hearing “comfort
level” gets used to higher volumes. After prolonged
listening, what may seem a “normal” volume to you, may in fact
be too high and harmful to your hearing. To protect yourself from
this risk, set the volume to a safe level and do not increase it
subsequently. To prevent possible hearing damage, do not listen
at high volume levels for long periods.
To prevent damage to your radio and avoid the risk of explosion,
only use the battery pack supplied with your radio. Or an
original replacement battery provided by your Pinell dealer.
We provide 6 months warranty on the built-in battery.
For optimal audio quality,
use your radio at ambient
temperatures between +5°C
and +40°C.
Never open the radio. It
contains no user-replaceable
or -repairable parts, and you
run the risk of electric shock.

www.pinell.com
Postboks 150, Oppsal
0619 Oslo
Norway
1.1
