Pintek DP-5205A User manual

DP-5205A/DP-5203A/DP-5201A
HIGH VOLTAGE DIFFERENTIAL PROBE
差 動 測 試 棒
Instruction Manual
TINSE56 Ver.01

TABLE OF CONTENTS
GENERAL SAFETY SUMMARY ----------------------------------------------------- 1
Safety Precautions -------------------------------------------------------------------------------------- 1
Explanation Symbols ------------------------------------------------------------------------------------2
Compliance Information-------------------------------------------------------------------------------- 2
PRODUCT INTRODUCTION --------------------------------------------------------- 3
Description of the Instrument and Accessories --------------------------------------------------- 4
Electrical Specifications -------------------------------------------------------------------------------- 5
General Specifications --------------------------------------------------------------------------------- 5
OPERATING INFORMATION ---------------------------------------------------------6
Connecting to the Instrument ------------------------------------------------------------------------- 6
Disconnecting from the Instrument ------------------------------------------------------------------ 7
Bandwidth Limit ------------------------------------------------------------------------------------------ 7
Twisting the Input Leads ------------------------------------------------------------------------------- 7
External Power Source --------------------------------------------------------------------------------- 8
Derating Curve ---------------------------------------------------------------------------------------- 8
MAINTENANCE-------------------------------------------------------------------------- 9
Cleaning --------------------------------------------------------------------------------------------------- 9
Warranty --------------------------------------------------------------------------------------------------- 9
Repair ------------------------------------------------------------------------------------------------------ 9
ATTACHED ( Standard accessories ) ------------------------------------------------ 19
目 次
⼀般安全概要 -----------------------------------------------------------------------------10
安全注意事項 ------------------------------------------------------------------------------------------- 10
符號說明
------------------------------------------------------------------------------------------------- 10
安規說明
-------------------------------------------------------------------------------------------------- 11
產品介紹- ----------------------------------------------------------------------------------12
儀器及附件說明 ---------------------------------------------------------------------------------------- 13
電氣規格
------------------------------------------------------------------------------------------------- 14
⼀般規格
------------------------------------------------------------------------------------------------- 14
操作說明 -----------------------------------------------------------------------------------15
連接到儀器 ---------------------------------------------------------------------------------------------- 15
斷開與儀器連接
---------------------------------------------------------------------------------------- 17
頻寬限制
------------------------------------------------------------------------------------------------- 17
輸入引線絞線
------------------------------------------------------------------------------------------- 17
外部電源
------------------------------------------------------------------------------------------------- 18
降額曲線
---------------------------------------------------------------------------------------------- 18
產品維護 -----------------------------------------------------------------------------------18
附圖 (標準附件示意圖) -----------------------------------------------------------------19

Differential voltage probes
1
GENERAL SAFETY SUMMARY
Review the following safety precautions to avoid injury and prevent damage to this product or any products
connected to it. To avoid potential hazards, use this product only as specified.
Only qualified personnel should perform service procedures.
Safety Precautions: to avoid fire or personal injury
Use proper power cord. Use only the power cord specified for this product and certified for the country of
use.
Connect and disconnect properly. Do not connect or disconnect probes or test leads while they are
connected to a voltage source.
Connect and disconnect properly. Connect the probe output to the measurement instrument before
connecting the probe to the circuit under test. Connect the probe reference led to the circuit under test before
connecting the probe input. Disconnect the probe input and the probe reference lead from the circuit under
test before disconnecting the probe from the measurement instrument.
Ground the product. This product is indirectly grounded through the grounding conductor of the mainframe
power cord. To avoid electric shock, the grounding conductor must be connected to earth ground. Before
making connections to the input or output terminals of the product, ensure that the product is properly
grounded.
Observe all terminal ratings. To avoid fire or shock hazard, observe all ratings and markings on the product.
Consult the product manual for further ratings information before making connections to the product.
Do not apply a potential to any terminal, including the common terminal, that exceeds the maximum rating of
that terminal.
Respect the max input voltages:
1. Max differential voltage: ±1300 V (DC + AC peak) or 1838 VRMS.
2. Max voltage between each input terminal and ground: 919 VRMS.
Power disconnects. The power cord disconnects the product from the power source. Do not block the power
cord; it must remain accessible to the user at all times.
Do not operate without covers. Do not operate this product with covers or panels removed.
Do not operate with suspected failures. If you suspect that there is damage to this product, have it
inspected by qualified service personnel.
Avoid exposed circuitry. Do not touch exposed connections and components when power is present.
Use proper AC adapter. Use only the AC adapter specified for this product.
Do not operate in wet/damp conditions.
Do not operate in an explosive atmosphere. Keep product surfaces clean and dry.

Differential voltage probes
2
Explanation Symbols
The following symbol(s) may appear on the product:
Attention refers to operation Instructions.
Dangerous voltage may be present at terminals.
This instrument has double insulation.
Compliance Information
This product complies with the following safety regulations:
Electrical Safety to IEC 61010-1:
Dual Insulation
Installation Category III
Pollution Degree 2. (Note: Rated for indoor use only)
Rated Voltage or Max Live-Earth: 919 VRMS
CE Mark: conforms to EN 50081-1 and 50082-1 standards.

Differential voltage probes
3
PRODUCT INTRODUCTION
The DP-5205A series differential voltage probes provide a safety means of measuring floating potentials for
all models of oscilloscopes incomplete safety.
It converts the high differential voltage (≦±1300 DC+AC peak) into a low voltage (≦±2.6 V) with reference
to the earth for display on the oscilloscopes.
The BNC output is designed to operate on an input with an impedance of 1 MΩ. It is 2 times of the 50Ω.
DP-5205A series are designed for high sensitivity modules and high dynamic range. Attenuation x50, x500
are multiple of 50, which is easy for calculation without mistake. Maximum voltage is 2.6 KVp-p. These are
designed for high voltage.
Model Bandwidth Attenuation Oscilloscope interface
DP-5205A 100 MHz X50 / X500 BNC
DP-5203A 70 MHz X50 / X500 BNC
DP-5201A 35 MHz X50 / X500 BNC

Differential voltage probes
4
Description of the Instrument and Accessories
Model: DP-5205A/ DP-5203A/ DP-5201A
○
1 Integral Input Leads ○ 2 Attenuation Function Switch
○
3 Bandwidth Function Switch ○ 4 Power On/Off Indication
○
5 Overrange Indication ○ 6 Output Connector/ BNC Cable
○
7 External Power Source [DC5V] ○ 8 USB Cable (USB-510) [L=100cm]
○
9 Extender Leads (ETL-2100) [L=100cm] ○
10 Hook Clips (BP-256A)
○
11 Test Probes (BP-286N) ○ 12 Alligator Clips (BP-276N)
○
13 AC adapter (ADP-51) [100~240V] ○ 14 Plug Convertor (PLUG-220) [100~240V]

Differential voltage probes
5
Electrical Specifications
Function/ Model DP-5205A DP-5203A DP-5201A
Bandwidth (-3dB) DC - to 100 MHz (X500)
DC - to 90 MHz
(
X50
)
DC - to 70 MHz DC - to 35 MHz
A
ttenuation X50 / X500
A
ccurac
y
≦ ±2%
Voltage Input
Ran
g
es
≦±130 V (DC + AC peak) for X50, (i.e about 183 VRMS)
≦±1300 V (DC + AC peak) for X500, (i.e about 1838 VRMS)
Permitted Max. Input
V
olta
g
e
Max differential voltage: ±1300 V (DC + AC peak)
Max volta
g
e between each input terminal and
g
round: 919 VRMS
Input Impedance 5 MΩ// 2 pF each side to
g
round
Output Volta
g
e ≦ ±2.6 V
Output Impedance 50 Ω
(
for 1 MΩinput oscilloscope
)
Rise Time
≈
4 nS ≈6 nS ≈12 nS
Rejection Rate on
Common Mode 60 Hz: ＞80 dB / 100 Hz: ＞60 dB / 1 MHz: ＞50 dB
5 MHZ Limit
Bandwidth Switchable: Full / 5MHz
General Specifications
Model DP-5205A DP-5203A DP-5201A
Power Suppl
y
External 5 V DC
(
USB Input
)
, consumption about 300 m
A
Dimensions 175 x 68 x 28 mm
W
ei
g
ht 285
g
T
emperature
Reference: +20 °C ~ +30 °C
Use: 0 °C ~ +50 °C
Stora
g
e: -30 °C ~ +70 °C
Relative Humidity
Reference: ≦70 %RH
Use: 10 % ~ 85 %RH
Stora
g
e: 10 % ~ 90 %RH
A
ccessories
Extender leads x 2pcs, Hook clips x 2pcs, Alligator clips x 2pcs,
Test probes x 2pcs, USB cable x 1pc, Plug convertor x 1pc,
A
C adapter x 1pc, Instruction manual

Differential voltage probes
6
OPERATING INFORMATION
Connecting to the Instrument
1. Connect to leads to the input and place the wire-grip on the circuit to be tested.
2. Connect the probe to the oscilloscope with the insulated BNC cable.
3. Adjust the vertical zero adjustment of the oscilloscope if necessary.
4. Select the attenuation ratio and the vertical deviation of the oscilloscope in accordance with the
conversion table1.
5. NB. The POWER light must come on.
table1. The conversion table gives the real vertical deviation:
A
ttenuation X500 X50
MAX Volta
g
e Input Ran
g
e
(
DC+AC Peak
)
± 1300 V ± 130 V
DC MAX INPUT ± 1300 V ± 130 V
A
C RMS MAX INPUT 1838Vrms 183Vrms
V
ertical deviation on the oscilloscope in V/div
Real Deviation In V/div
X500 Ran
g
e X50 Ran
g
e
1 500 50
0.5 250 25
0.2 100 10
0.1 50 5
50 m 25 2.5
20 m 10 1
10 m 5 0.5
5 m 2.5 0.25
2 m 1 0.1
Figure1.

Differential voltage probes
7
NOTE. The real vertical deviation in V/div is equal to the attenuation factor multiplied by the
range of vertical deviation selected on the oscilloscope. It will be doubled in the case of use of
a 50 Ωload.
Example:
With the probe on factor X50, the oscilloscope on 0.5 V/div,
the real vertical deviation is 50 x 0.5 = 25 V/div.
With a 50 Ωload on the input of the oscilloscope the deviation becomes 50 V/div
Disconnecting from the Instrument
WARNING. To avoid electrical shock, disconnect the probe inputs from the circuit before
disconnecting the probe from the instrument.
1. Turn the probe connector counterclockwise.
2. Pull straight out.
Bandwidth Limit
Slide the Bandwidth limit switch to limit the probe bandwidth to 5 MHz. The 5 MHz filter assists in the
characterization and testing of power supplies in switch mode by removing all high frequency content, noise
and harmonics from the measurement.
Twisting the input leads
Twisting the input leads helps to cancel noise from high-EMI environments that is induced into the input leads.
Figure2.
Figure3.

Differential voltage probes
8
External Power Source
Power consumption of the probe is about 500 mA,
thus it no suit for battery, please use the accessory
adapter only.
(Refer Figure4.)
If there are any damage on the adaptor, please
contact us and use the adaptor supply by us only.
If the input power over 12 VDC will caused to the
probe hard damage.
Derating Curve
The DP-5205A derating curve of the absolute maximum input voltage in common mode is shown as below.
Figure4.

Differential voltage probes
9
MAINTENANCE
For maintenance, only use specified spare parts.
The manufacturer can’t be held responsible for any accident arising following a repair made other than its
after sales service or approved repairers.
Cleaning
This probe does not require any particular cleaning. If necessary, clean the case with a cloth slightly
moistened with soapy water.
Warranty
Unless notified to the contrary, our instruments are guaranteed against any manufacturing defect or material
defect. They do not bear the specification known as the safety specification. Our guarantee, which may not
under any circumstances exceed the amount of the invoiced price, goes no further than the repair of our
faulty equipment, carriage paid to our workshops.
Repair
Maintenance, repairs under or out of guarantee. Please return to product to your distributor.

差動測試棒
10
⼀般安全概要
使用本產品前，請先查看以下安全預防措施，以避免受傷並防止損壞本產品或與其相連的設備。 為避免
潛在危險，請僅按規定使用本產品。
只有合格的人員才能執行維修程序。
安全注意事項：避免火災或人身傷害
使用合適的電源線。 僅使用為本產品指定並經使用國家/地區認證的電源線。
正確連接和斷開連接。 當測試棒或測試線連接到電壓源時，不要連接或斷開它們。
正確連接和斷開連接。 在將測試棒連接到被測電路之前，請先將測試棒輸出端連接到測量儀器。在連接測試
棒輸入之前，請將測試棒引線連接到被測電路。在將測試棒與測量儀器斷開連接之前，請將測試棒輸入端和
測試棒引線與被測電路斷開。
將產品接地。 本產品通過主機電源線的接地導體間接接地。為避免觸電，接地導體必須接地。 在連接產品的
輸入或輸出端子之前，請確保產品正確接地。
遵守所有端子額定值。為避免火災或電擊危險，請遵守產品上的所有額定值和標記。在連接到產品之前，請
查閱產品手冊以獲取更多額定值信息。
請勿對任何端子（包括公共端子）施加超過該端子最大額定值的電位。
遵守最大輸入電壓：
1. 最大差動電壓：±1300 V（DC + AC 峰值）或 1838 VRMS。
2. 輸入端與接地端之間的最大差動電壓：919 VRMS。
斷開電源。不要阻塞或遮蓋電源線，電源線必須隨時能斷開產品與電源的連接。
不要在沒有蓋子的情況下操作。 請勿在移除蓋板或面板的情況下操作本產品。
不要在疑似故障的情況下進行操作。 如果您懷疑本產品有損壞，請讓合格的維修人員對其進行檢查。
避免電路暴露。通電時請勿觸摸有裸露電路的連接物和組件。
使用合適的適配器。 僅使用為本產品指定的 AC 適配器。
請勿在潮濕/潮濕的環境條件下操作。
請勿在易爆炸的環境中操作。 請保持產品表面清潔乾燥。
符號說明
產品上可能會出現以下符號：
注意並參見操作說明。
接線端子上可能存在危險電壓。
本儀器具有雙重絕緣。

差動測試棒
11
安規說明
本產品符合以下安全規定：
符合 IEC 61010-1 的電氣安全:
雙重絕緣
安裝類目 III
污染等級 2（注：額定僅適用於室內使用) 。
額定電壓或最大接地電壓：: 919 VRMS
CE 標誌：符合 EN 50081-1 和 50082-1 標準

差動測試棒
12
產品介紹
DP-5205A 系列差動測試棒提供一個安全的絕緣儀器給所有的示波器使用，它可以轉換由高輸入的差動電壓
(≦±1300 DC+AC peak) 進入一個低電壓(≦±2.6 V) 並且顯示波形在示波器上，使用頻率高達 100 MHz (DP-
5205A) ，非常適合大電力測試、研發使用。
差動測試棒輸出標示是設計在操作示波器 1 MΩ的輸入阻抗的相對衰減量，當使用 50Ω匹配器時衰減量剛好
為2倍量。
DP-5205A 系列為一高靈敏度設計，衰減器 X50，X500 皆為 50 進位以方便使用者計算，且不容易出錯，其
最高電壓達到 2.6KVp-p，為一高電壓設計的機種。
產品型號 頻寬 衰減 示波器連接界面
DP-5205A 100 MHz X50 / X500 BNC
DP-5203A 70 MHz X50 / X500 BNC
DP-5201A 35 MHz X50 / X500 BNC

差動測試棒
13
儀器及附件說明
適用型號: DP-5205A/ DP-5203A/ DP-5201A
○
1 ⼀體式輸入引線 ○ 2 衰減量選擇開關
○
3 頻寬選擇開關 ○ 4 電源開/關指示燈
○
5 過載警示燈 ○ 6 輸出連接器/ BNC 電纜
○
7 外部電源輸入端 [DC5V] ○ 8 USB 傳輸線 (USB-510) [L=100cm]
○
9 延⻑線 (ETL-2100)[L=100cm] ○
10 鉤夾(BP-256A)
○
11 測試棒 (BP-286N) ○ 12 鱷魚夾 (BP-276N)
○
13 AC 轉換器(適配器)(ADP-51)[100~240V] ○ 14 插頭轉換器(PLUG-220)[100~240V]

差動測試棒
14
電氣規格
功能/ 型號 DP-5205A DP-5203A DP-5201A
頻寬(-3dB) DC - to 100 MHz (X500)
DC - to 90 MHz
(
X50
)
DC - to 70 MHz DC - to 35 MHz
衰減 X50 / X500
精確度 ≦ ±2%
輸入電壓範圍 ≦±130 V (DC + AC peak) X50 檔,(約183 VRMS)
≦±1300 V (DC + AC peak) X500 檔, (約1838 VRMS)
允許最高輸入電壓 最高差動電壓: ±1300 V (DC + AC peak)
輸入端及接地端間最高電壓: 919 VRMS
輸入阻抗 各單端到接地端間的輸入阻抗: 5 MΩ// 2 pF
輸出電壓 ≦ ±2.6 V
輸出阻抗 50 Ω(在1 MΩ輸入阻抗的示波器系統中)
上升時間
≈
4 nS ≈6 nS ≈12 nS
雜訊抑制率 60 Hz: ＞80 dB / 100 Hz: ＞60 dB / 1 MHz: ＞50 dB
5 MHz 限制頻寬 可切換: Full / 5MHz
⼀般規格
型號 DP-5205A DP-5203A DP-5201A
電源
指定外接 5 VDC 電源 (必須使用本公司指定品)
最大耗電量約 300 mA
尺寸(不含引線) 175 x 68 x 28 mm
重量 285 g
溫度
⼀般狀態: +20 °C ~ +30 °C
操作環境:0 °C ~ +50 °C
儲存環境: -30 °C ~ +70 °C
相對溼度
⼀般狀態: ≦70 %RH
操作環境: 10 % ~ 85 %RH
儲存環境: 10 % ~ 90 %RH
標準附件
延⻑線 x紅黑各 1, 鉤夾 x 紅黑各 1, 鱷魚夾 x 紅黑各 1,
測試棒 x 紅黑各 1, USB 連接線 x 1 條, 插頭轉換器 x 1 個,
AC 轉換器(適配器) x 1 個, 使用說明書

差動測試棒
15
操作說明
連接到儀器
1. 將鉤夾 BP-256A (或鱷魚夾 BP-276N) 插入差動測試棒的輸入端引線，並將鉤夾 BP-256A (或鱷魚夾 BP-
276N)與測量電路接觸。
2. 將差動測試棒的輸出端接上 BNC 電纜後連結到示波器。
3. 如有需要先調整示波器上的垂直開關。
4. 將示波器上的衰減率及垂直開關調整到⼀致的位置，如表格 1. 所示。
5. 注意! 電源必須打開。
表格 1. 垂直偏差換算表
衰減 X500 X50
最大輸入電壓(DC+AC Peak) ± 1300 V ± 130 V
DC 最大輸入值 ± 1300 V ± 130 V
A
C 最大輸入值 1838Vrms 183Vrms
示波器上的垂直偏向 V/div
換算實際偏向 V/div
X500 檔X50 檔
1 500 50
0.5 250 25
0.2 100 10
0.1 50 5
50 m 25 2.5
20 m 10 1
10 m 5 0.5
5 m 2.5 0.25
2 m 1 0.1
圖1.

差動測試棒
16
注意! 實際的垂直偏向是等於衰減乘上示波器上所選擇的垂直偏向，如果另外使用 50 Ω 負載
端子時，實際電壓值剛好是 2 倍量。
例如 :
測試棒是 X50, 示波器的垂直偏向在 0.5 V/div,
其實際的垂直偏向為 50 x 0.5 = 25 V/div
示波器輸入的負載是 50 Ω， 偏向就為 50 V/div
斷開與儀器連接
警告! 為避免電擊，在將測試棒與儀器斷開連接之前，請先將測試棒與電路斷開。
1. 逆時針轉動 BNC 接頭。
2. 直接拉出 BNC 接頭。.
頻寬限制
切換 Bandwidth Limit 開關，可以將輸出頻寬限制在 5 MHz。啟用頻寬過濾器後，可以有效去除所有的高頻內
容、諧振、 雜訊、簡化輸出波形。
輸入引線絞線
量測時將輸入線絞線，可以有效避免環境電磁干擾與雜訊。
圖2.
圖3.

差動測試棒
17
外部電源
測試棒的功耗約為 500 mA，因此不適合使用電池，
請僅使用附件轉換器(適配器)連接電源。
(圖4.)
如果電源轉換器(適配器)有任何損壞，請與我們聯
繫並僅使用我們提供的轉換器(適配器)。
注意! 如果輸入電源超過 12 VDC 會導致測試棒造
成硬損壞。
降額曲線
DP-5205A 高頻耐壓曲線是以最大共模輸入電壓為例:
圖4.
