Pioneer X-HM76 User manual

X-HM76
XC-HM86
Language select / Sélection de la langue / Selección de idioma
English
Français
Español

> Before Start
> Part Names
> Install
> Initial Setup
> Playback
Advanced Setup | Firmware Update | Others
NETWORK CD RECEIVER SYSTEM
X-HM76
NETWORK CD RECEIVER
XC-HM86
Instruction
Manual
Before Start
What's in the box............................................................................2
Part Names
Front Panel......................................................................................4
Rear Panel ......................................................................................5
Remote Controller..........................................................................6
Display.............................................................................................7
Speakers System (X-HM76).........................................................8
Install
Connect the Speakers...................................................................9
Connecting the antennas and power cord, etc.........................10
Initial Setup
Power On & Initial Setup .............................................................11
Time settings.................................................................................14
Playback
Playing CDs ..................................................................................15
USB Storage Device/HDD ..........................................................17
Internet Radio ...............................................................................19
Spotify............................................................................................21
Listening Tothe FM/AM Radio ...................................................22
BLUETOOTH®..............................................................................24
AirPlay®.........................................................................................26
Playing audio from an external device ......................................27
Music Server.................................................................................28
Using the alarm to start play.......................................................30
Entering text, adjusting sound quality, etc.................................31
Advanced Setup
Advanced Settings.......................................................................32
Firmware Update
Firmware Update..........................................................................36
Others
Troubleshooting............................................................................38
General Specifications.................................................................41
License and Trademark Information..........................................43
E
N

> Before Start
> Part Names
> Install
> Initial Setup
> Playback
Advanced Setup | Firmware Update | Others
What's in the box
X-HM76 : 123456
XC-HM86 : 1234
Main unit (1)
Remote controller (RC-945S) (1), Batteries (AAA/R03) (2)
Indoor FM antenna (1)
Indoor AM antenna (1)
Speaker system (2)
2
E
N

> Before Start
> Part Names
> Install
> Initial Setup
> Playback
Advanced Setup | Firmware Update | Others
Speaker cable (1.5 m) (2)
0 The power cord must be connected only after all other cable connections are completed.
0 Connect speakers with 4 Ω to 16 Ω impedance.
0 We will not accept responsibility for damage arising from the connection of equipment
manufactured by other companies.
0 Functionality may be introduced by firmware updates and service providers may cease
services, meaning that some network services and content may become unavailablein
the future.
0 Specifications and appearance are subject to change without prior notice.
3
E
N

> Before Start
> Part Names
> Install
> Initial Setup
> Playback
Advanced Setup | Firmware Update | Others
Front Panel
1. Í STANDBY/ON button: Turns the unit onortostandbymode.
2. INPUT button: Switches the input to be played.
3. Play button:
:6 :Returntothebeginningofthetrackbeingplayed.Pressandholdtorewindthe
track quickly.(CD)
Move to the previous track. (USB, Music Server)
59 :Movetothenexttrack.Pressandholdtofast-forwardthroughthetrack.(CD)
Movetothenexttrack.(USB,MusicServer)
∫ : This button stops playback.
1 / ; : This button pauses the playback.
0 Depending on the input, the operation may not start.
4. <button: Open or close the disc tray.
5. Disc tray: Place discs here. 8-cm discs can also beused.
6. USBport:ConnectaUSBstoragedeviceorHDD(harddiskdrive)toplaymusicfiles.Youcan
also supplypower (maximum 5V/0.5A)toUSB deviceswithaUSB cable.
0 When connecting a HDD that requires more than 5 V/0.5 A, connect to the USB port
(maximum 5 V/1 A) on the rear of the unit.
7. PHONES jack: Connect stereo headphones with a miniplug.
8. Power indicator: This lights blue when the unit ison.
9. TIMER indicator: This lights when the alarm is set.
10. Remote control
sensor 11. Display(P7)
12. VOLUME dial: Adjust the volume. Adjust between 0 and 50.
4
E
N

> Before Start
> Part Names
> Install
> Initial Setup
> Playback
Advanced Setup | Firmware Update | Others
Rear Panel
1. Power cord
2. Wireless antenna: Used for Wi-Fi connection or when using a BLUETOOTHenabled
device. Adjust their angles according to the connectionstatus.
3. Speaker terminals: Connect speakers with speakercables.
0 You can connect banana plugs by removing the cap on the tip of the jack. When using
banana plugs, first tighten the speaker terminals and then insert the banana plugs.
4. FM ANTENNA jack: Connect the supplied indoor FMantenna.
5. LINE IN jack: Youcan play the audio from an external device such as a television
connected with an analogue audio cable.
6. SUBWOOFER PRE OUT jacks: Connect a subwoofer with built-inamplifier.
7. USB port: Connect a USB storage device or HDD (hard disk drive) to play music files. You
can also supply power (maximum 5 V/1 A) to USB devices with a USBcable.
8. NETWORK jack: Connect to the network with a Ethernet cable.
9. DIGITAL IN OPTICAL jack: You can play the digital audio from an external device such as
a television connected with a digital opticalcable.
10. AM ANTENNA jack: Connect the supplied AM loop antenna.
5
90°
180°
E
N

> Before Start
> Part Names
> Install
> Initial Setup
> Playback
Advanced Setup | Firmware Update | Others
30° 30°
Approx
(23 ft.)
Remote Controller
1. ÍSTANDBY/ON button:Turnsthe unitonorintostandbymode.
2. TIMER button: Used to set the time and set the alarm.
3. SLEEP button: Set the sleep timer. When the time set (30, 60, or 90 minutes)has
elapsed, the unit switches to standby. If SLEEP button is pressed after setting, the time
remaining until sleep is displayed.
4. INPUT SELECTOR buttons: Switches the input to be played.
5. Play buttons:
: : Return to the beginning of the track being played. (CD)
Move to the track before the one being played. (USB, Music Server)
 / ; : Play or pause play.
9 : Move to the next track.
22 : Rewind thetrack quickly. (CD only)
∫ : Stop playback.
11 : Fast-forward the track. (CD only)
0 Depending on the input, the operation may not start.
PRESET i / j buttons: Used to select stations that have been registered or to give names
to stations.
TUNE i / j buttons: Used to select radio stations.
6. MEMORY button: Used to register favorite radiostations.
7. SHUFFLE/REPEAT button: Set repeat play and shuffleplay.
8. MODE button: Used for program play of CDs.
9. Cursors, ENTER button: Select the item with the cursors and press ENTER to confirm.
10.SETUPbutton: Displays theSetup menu.
11. VOLUME i / j buttons: Adjust the volume. Adjust between 0 and 50.
12.SOUNDbutton:Adjustthesoundquality.
13. DIMMER button: Switch the display off or adjust the brightness of the display inthree
steps.
14. CLEAR button: Used when entering text, etc.
15. (NOW PLAYING) button: Switches the information onthe
display.
16. RETURN button: Returns the display to the previousstate.
17. MUTE button: Temporarily mutes audio. Press again tocancel
muting. .7 m
6
E
N

> Before Start
> Part Names
> Install
> Initial Setup
> Playback
Advanced Setup | Firmware Update | Others
USB Front
Song
Artist
Album
FLAC
44.1kHz/24bit
00:01:45 /00:03:23
Display
1. The input mode is displayed.
(USB Front / USB Rear / CD / Bluetooth / Network / Digital In / Line / Tuner AM / Tuner
FM)
2. The name of the file, artist, album, station, etc., isdisplayed.
3. Displays the play status.
4. Displays file format, sampling frequency, and quantization bitinformation.
5. The file play status is displayed. This may not be displayed depending on the input orfile.
6. This is displayed when muting is on.
7. Displayed when the sleep timer is set.
8. Lights in the following conditions.
:Whentheconnectionsettingontheunitis"Wired"andtheunitisconnectedtothenetwork.
:Whentheconnectionsettingontheunitis"Wired"andtheunitisnotconnectedtothenetwork.
:Whentheconnectionsettingontheunitis"Wi-Fi"andtheunitisconnectedtothenetwork.
:Whentheconnectionsettingontheunitis"Wi-Fi"andtheunitisnotconnectedtothenetwork.
9. If an album jacket is recorded for the file being played, it is displayedhere.
10. Lights in the following conditions.
: When all track repeat play is on
1 : When one track repeat play is on
: When shuffle play is on
0 When DIMMER is pressed to turn off the display, the unit may appear the same as if you
had unplugged the unit from the power outlet, but electricity is still being supplied to the
unit. To completely cut the unit off from the power supply, you need to unplug the power
plug (shutoff device) unit from the power outlet.
7
E
N

> Before Start
> Part Names
> Install
> Initial Setup
> Playback
Advanced Setup | Firmware Update | Others
Speakers System (X-HM76)
There is no distinction between left and right with the included speaker system. There will be
no difference in sound quality whichever side you choose to put each speaker.
1. Tweeter: Plays the mid range andtreble.
2. Woofer: Plays the bass.
3. Grill net fittings: Used to attach the grill nets.When removing the grill net, hold the bottom
of the grill net with both hands and pull gently forward, then gently pull the top of the grill
out to remove. Toattach again, attach the top first, then the bottom.
4. Speakercabinet
5. Bass ref duct: This releases the reverberations that occur within the cabinet toenhance
the reproductive capabilities of the bass range. Do not block theducts.
6. Speaker terminals: Connect speakers to the main unit with speakercables.
0 You can connect banana plugs by removing the cap on the tip of the jack. When using
banana plugs, first tighten the speaker terminals and then insert the banana plugs.
8
E
N
1
2
2
1

> Before Start
> Part Names
> Install
> Initial Setup
> Playback
Advanced Setup | Firmware Update | Others
Connect the Speakers
WhenconnectingthespeakersystemforX-HM76,connect
theincludedspeakercableswithendswiththeredtubing
attachedtothe i jacksonthemainunitandthespeaker.If
connectioniswrong,thephasereversesandthismakesit
hardertooutputbass.
For XC-HM86, use the illustration as a reference to connect
your own speakers.
Afterinsertingthespeakercables,tightentheterminalsfirmly
byturningtotheright.Alsomakesuretheexposedwiresofthe
speakers do not stick out of the speaker terminals when
connecting.Iftheexposedwiresofthespeakerstouchtherear
panel or the i and s wires touch each other, the protection
circuitmaybeactivatedandthepowermayturnoff.
You can also connect a subwoofer with a built-in amplifier to
boost bass playback even more. Use a subwoofer cable for
connection.
a Speaker cable
9
E
N
1
2
3
RED RED
RED
a
a
RED
