Pit Boss PB1600PS1 User manual

MODEL/ MODÈLE/ MODELO/ MODELL/ MODELLO: PB1600PS1
PART/ PIÈCE/ PARTE/ TEIL/ PARTE: 10804
OWNER'S MANUAL | MANUEL DEL'UTILISATEUR
MANUAL DELPROPIETARIO | HANDBUCH | MANUALE DELL'UTENTE
WOOD PELLET
GRILL& SMOKER
IMPORTANT, READ CAREFULLY,RETAIN FOR
FUTURE REFERENCE.MANUAL MUST BE
READ BEFOREOPERATING!
FUMOIR ETGRILÀ
GRANULÉSDE BOIS
IMPORTANT, PRENEZ CONNAISSANCEDE
CEDOCUMENT ET CONSERVEZ-LEPOUR
RÉFÉRENCEULTÉRIEURE. VOUS DEVEZ LIRE
CEGUIDE AVANT D’UTILISER LE BARBECUE!
PARRILLAYAHUMADOR DE
PELLETSDEMADERA
IMPORTANTE, LEERDETENIDAMENTE,
CONSERVAR PARA REFERENCIAFUTURA.
LEA ELMANUAL ANTES DEL USO!
HOLZPELLET-GRILL
UND SMOKER
WICHTIG: AUFMERKSAM LESENUND GUT
AUFBEWAHREN BITTE UNBEDINGT VOR
GEBRAUCHDIE BEDIENUNGSANLEITUNG
SORGFÄLTIG DURCHLESEN!
GRIGLIA A PELLETDI
LEGNOCONAFFUMICATORE
IMPORTANTE: LEGGEREATTENTAMENTE E
CONSERVARE PER RIFERIMENTO FUTURO.
LEGGEREIL MANUALE PRIMA DELL'USO.
Foroutdoor and household useonly. Not for commercialuse.
Réservéà l'usageextérieur et résidentiel uniquement. Non destiné à un usage commercial.
Solopara uso doméstico y en el exterior. No apto para uso comercial.
Bitte nur im Freienund privat nutzen. Nicht für die gewerbliche Anwendung geeignet.
Solo per uso domestico ed esterno. Non per uso commerciale.
WARNING: PLEASE READ THE ENTIRE MANUAL BEFORE INSTALLATION
AND USE OF THIS ELECTRIC,PELLET FUEL-BURNING APPLIANCE. FAILURE TO
FOLLOW THESEINSTRUCTIONS COULDRESULTIN PROPERTYDAMAGE, BODILY
INJURY OREVEN DEATH. CONTACTLOCALBUILDING ORFIRE OFFICIALSABOUT
RESTRICTIONSAND INSTALLATION INSPECTIONREQUIREMENTSIN YOURAREA.
AVERTISSEMENT : VEUILLEZ LIRE L’INTÉGRALITÉ DU MANUEL AVANT
L’INSTALLATION ETL’UTILISATION DE CETAPPAREIL ÉLECTRIQUEÀ COMBUSTION
DEGRANULÉSDE BOIS. LENON-RESPECTDECESINSTRUCTIONSPEUT ENTRAÎNER
DES DOMMAGES MATÉRIELS, DES DOMMAGES CORPORELS OU MÊME LA
MORT. CONTACTEZ LES AUTORITÉS LOCALES COMPÉTENTES CONCERNANT LES
RESTRICTIONSETLESEXIGENCESD'INSPECTION ENVIGUEURDANSVOTRERÉGION.
ADVERTENCIA: LEATODO ELMANUAL ANTESDEINSTALARY USAR ESTAUNIDAD
QUE FUNCIONA CONELECTRICIDAD Y COMBUSTIÓN DE PELLETS.SINO SESIGUEN
ESTAS INSTRUCCIONES, PUEDEN PRODUCIRSE DAÑOS MATERIALES, LESIONES
CORPORALESO INCLUSO LA MUERTE. PARA CONSULTAR LAS RESTRICCIONES Y
REQUISITOS DE INSPECCIÓN DE LAS INSTALACIONES DE SU ZONA, PÓNGASE EN
CONTACTOCONLOSENCARGADOSDEEDIFICIO OELDEPARTAMENTO DEBOMBEROS.
ACHTUNG: BITTELESEN SIEDIEGESAMTEANLEITUNGSORGFÄLTIGDURCH, BEVOR
SIEDIESESELEKTRISCHE, PELLETBEFEUERTEGERÄTINSTALLIEREN UND BENUTZEN.
DIE NICHTBEACHTUNG DIESER ANWEISUNGEN KANN ZU SACHSCHÄDEN,
KÖRPERVERLETZUNGEN ODER SOGAR ZUM TOD FÜHREN. WENDEN SIE SICH
AN LOKALE BAU- ODER BRANDSCHUTZBEHÖRDEN,UM INFORMATIONEN ÜBER
EINSCHRÄNKUNGENUND ANFORDERUNGENAN DIE INSTALLATIONSINSPEKTION
IN IHRERNÄHEZU ERHALTEN.
AVVERTENZA: LEGGEREL'INTERO MANUALE PRIMA DELL'INSTALLAZIONE E
DELL'USO DI QUESTA APPARECCHIATURA ELETTRICA PER LA COMBUSTIONE DI
PELLET. LA MANCATA OSSERVANZA DELLE ISTRUZIONI PUÒ CAUSARE DANNI
ALLA PROPRIETÀ, LESIONI FISICHE O MORTE. CONTATTARE LE AUTORITÀ LOCALI
COMPETENTI PER L'EDILIZIA O I VIGILI DEL FUOCO PER INFORMAZIONI SULLE
RESTRIZIONIESUI REQUISITIDI ISPEZIONEDEGLIIMPIANTI NELLAPROPRIAZONA.

2
EN ENGLISH
SAFETYINFORMATION
MAJORCAUSESOFAPPLIANCEFIRESAREARESULTOFPOORMAINTENANCEAND
AFAILURETOMAINTAINREQUIREDCLEARANCETOCOMBUSTIBLEMATERIALS.IT
ISOFUTMOSTIMPORTANCETHATTHISPRODUCTBEUSEDONLYINACCORDANCE
WITHTHEFOLLOWINGINSTRUCTIONS.
Pleaseread and understand this entire manual before attempting to assemble,operate or install the product. This will ensure
you receivethe most enjoyable and trouble-free operation of your new wood pellet grill. We also advise you retain this manual
for future reference.
DANGERSAND WARNINGS
You must contact your local home association,building or fire officials, or authority having jurisdiction,
to obtain the necessarypermits, mission or information on any installation restrictions, suchas any grill
being installed on a combustible surface,inspection requirements or even ability to use, in your area.
1. A minimum clearanceof 914mm (36 inches)from combustible constructions to the sidesof the grill, and 914mm (36 inches)
from the back of the grill to combustible constructions must be maintained. Do not install appliance on combustible
floors, or floors protected with combustible surfaces unless proper permits and permissions are obtained by
authorities having jurisdiction. Do not use this appliance indoors, in an enclosed or unventilated area, inside homes,
vehicles,tents, garages. This wood pellet appliance must not be placed under overhead combustible ceiling or overhang.
Keepyour grill in an areaclear and free from combustible materials, gasoline and other ammable vapors and liquids.
Shoulda grease fire occur,turn the grill OFFand leave the lid closeduntil the fire is out. Unplug the power
cord.Do not throw water on the unit. Do not try to smother the fire. Useof an all-class(classABC)approved
fire extinguisher is valuable to keep on site. If an uncontrolled fire doesoccur,callthe FireDepartment.
2. Keep electrical supply cords and the fuel away from heated surfaces.Do not use your grill in the rain or around any water
source.If the supply cord is damaged,it must be replacedby the manufacturer, its serviceagent or similarly qualified persons
in order to avoid a hazard.
3. After aperiod of storage,or non-use,checkthe BurnPot for obstructions, the hopper for foreign objects,and any air blockage
around the fan intake or chimney. Cleanbefore use.Regularcareand maintenance is required to prolong the lifespan of your
unit. If the grill is stored outside during the rainy season or seasonsof high humidity, care should be taken to
insurethat water doesnot get into the hopper. When wet or exposedto high humidity, wood pellets will expandgreatly,
decompose,and may jam the feed system. Always disconnect the power, before performing any serviceor maintenance.
Do not transport your grill while in useor while the grill ishot. Ensurethe fire is completely out and that
the grill is completely coolto the touch before moving.
4. It is recommended to use heat-resistant barbecue mitts or gloves when operating the grill. Do not use accessoriesnot
specified for use with this appliance.Do not put a barbecue cover or anything flammable in the storage spacearea under
the barbecue.

3
EN
ENGLISH
5. To prevent fingers, clothing or other objects from coming in contact with the auger feed system,the applianceis equipped
with a metal safety screen,mounted to the interior of the hopper. This screenmust not be removed unlessdirected by
Customer Serviceor an authorized dealer.
Thisappliance can be used by children aged from 8 years and above and personswith reduced physical,
sensoryor mental capabilities or lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and understand the hazards involved.
Childrenshall not play with the appliance.Cleaningand user maintenance shallnot be made by children
without supervision.
6. Parts of the barbecue may be very hot, and serious injury may occur.Keepyoung children and pets away while in use.
7. Do not enlarge ignitor holes or Burn Pots.Failureto follow this warning could lead to a fire hazard and bodily harm and will
void your warranty.
8. Product may have sharp edges or points. Contact may result in injury. Handle with care.
DISPOSAL OF ASHES
Ashesshould be placed in a metal container with a tight-fitting lid. Theclosed container of ashesshould be placed on a non-
combustible floor or on the ground, well away from all combustible materials,pending final disposal.When ashesaredisposedby
burial in soil,or otherwise locally dispersed,they should be retained in a closedcontainer until all cindershave thoroughly cooled.
WOOD PELLETFUEL
Thispellet cooking applianceis designedand approved for pelletized,all natural, wood fuel only. Any other type of fuel burned in
this appliancewill void the warranty and safety listing. You must only useall natural wood pellets, designed for burning in pellet
barbecuegrills. Do not usefuel with additives. Wood pellets arehighly susceptibleto moisture and should always be stored in an
airtight container.If you arestoring your grill, without use,for an extended period, we recommendclearingall pellets from your
grill's hopper and auger,to prevent jams. The pellet fuel mean heating value in 8000-8770 BTU/LB,ashcontent < 1%.
Do not use spirit, petrol, gasoline, lighter-fluid or kerosene for lighting or refreshing a fire in your grill.
Keep all suchliquids well away from the appliance when in use.
At the time of printing, there isno industry standard for barbecuewood pellets,although most pellet millsuse the samestandards
to makewood pellets for domesticuse. Furtherinformation, canbe found at
www.pelletheat.org
or the
Pellet FuelInstitute
.
Contact your localdealer on the quality of pellets in your area,and for information on brand quality. Asthere is no control over
the quality of pellets used,moisture affected pellets,we assumeno responsibility to damage causedby poor quality of fuel.
CREOSOTE
Creosote,or soot, is a tar-like substance.When burning, it produces black smoke with a residue which is also black in color. Soot
or creosote is formed when the appliance is operated incorrectly, suchas:blockage of the combustion fan, failure to clean and
maintain the burn area,or poor air-to-fuel combustion.
It is dangerous to operate this applianceshould the flame become dark, sooty, or if the Burn Pot is overfilled with pellets. When
ignited, this creosotemakesan extremely hot and uncontrolled fire, similar to a greasefire. Shouldthis happen, turn the unit OFF,
let it cool completely, then inspect for maintenance and cleaning.It commonly accumulatesalong exhaust areas.
If creosotehasformed within the unit; allow the unit to warm up at a low temperature,turn off the appliance,then wipe away
any formation with a hand towel. Similarto tar, it is much easierto cleanwhen warm, as it becomesliquid.

4
EN ENGLISH
CARBONMONOXIDE(“the silent killer”)
Carbon monoxide is a colorless,odorless, tasteless gas produced by burning gas, wood, propane, charcoalor other fuel. Carbon
monoxide reduces the blood’s ability to carry oxygen. Low blood oxygen levels can result in headaches, dizziness,weakness,
nausea,vomiting, sleepiness,confusion, lossof consciousnessor death. Follow these guidelines to prevent this colorless,odorless
gas from poisoning you, your family, or others:
• Seea doctor if you or others develop cold or flu-like symptoms while cooking or in the vicinity of the appliance. Carbon
monoxide poisoning,which caneasilybe mistaken for a coldor flu, is often detected too late.
• Alcoholconsumption and drug use increasethe effects of carbon monoxide poisoning.
Carbonmonoxide is especiallytoxic to mother and child during pregnancy,infants, the elderly, smokers,and people with blood
or circulatory system problems, suchas anemia, or heart disease.
SAFETYLISTING
Conforms to EN 60335-2-102:2016, EN 60335-1:2012 + A11:2014+ A13:2017+ A1:2019 + A14: 2019 + A2: 2019,
EN62233: 2008, EN 55014-1:2017,ENIEC61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 55014-2:2015.
FCCCOMPLIANCE STATEMENT
This device complies with Part 15of FCCRules.Operation is subject to the following two conditions: (1)This
device may not causeharmful interference, and (2) Thisdevice must acceptany interference received,including
interference that may causeundesiredoperation.
This equipment has been tested and found to comply with the limits for a ClassBdigital device, pursuant to part 15of FCCRules.
Theselimits aredesigned to provide reasonableprotection against harmful interference in a residential installation. Thisequipment
generates, uses,and can radiate radio frequency energy and, if not installed and used in accordancewith the instructions, may
causeharmful interference to radio communications.However, there is no guarantee that interference will not occurin a particular
installation. If this equipment does causeharmful interference to radio or television reception,which canbe determined by turning
the equipment off and on, the useris encouragedto try to correctthe interferenceby one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increasethe separation between the equipment and receiver.
• Connectthe equipment into an outlet on a circuit different from that to which the receiveris connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution: The user is cautioned that changes or modifications not expressly approved by the party
responsiblefor compliancecouldvoid the user’sauthority to operate the equipment.
The Bluetooth® word mark and logo are registered trademarks owned by Bluetooth® SIG,Inc. and any use of such marks by
Espressifis under license.Other trademarks and tradenames are those of their respective owners.

5
EN
ENGLISH
TABLEOF CONTENTS
Safety Information .......................................................2
Parts & Specs......................................................................6
Assembly Preparation...................................................... 7
AssemblyInstructions
Mounting The LegsTo Main Barrel........................................7
Installing The Bottom Shelf ...................................................8
Adding Wheels To The Cart .......................................................8
Installing The Lid Handle...........................................................8
Assembling The Side Shelf.........................................................9
Mounting The Side Shelf.......................................................... 9
Securing The Chimney.................................................................9
Securing The Front Shelf Brackets .........................................10
Installing The Front Shelf .......................................................10
Placing The Diffuser Plate.......................................................10
Installing The Flame Broiler Components ......................... 11
Installing The Cooking Components ...................................12
Mounting The RackHanger....................................................12
Placing The Grease Bucket........................................................12
Installing The Power Cord ...................................................... 13
Connecting To A Power Source............................................... 13
Operating Instructions
Grill Environment....................................................................... 14
Grill Temperature Ranges........................................................15
Understanding The Control Board ...................................... 16
Control Board Functions..........................................................18
Connecting To The Smoke iT®App......................................... 19
Hopper Priming Procedure ....................................................20
First Use – Grill Burn-Off ......................................................... 20
Automatic Start-Up Procedure..............................................20
Shutting Off Your Grill ............................................................ 20
Care& Maintenance........................................................21
Tips & Techniques ..........................................................23
Troubleshooting ...........................................................24
Electrical Wire Diagram................................................26
Replacement Parts
Grill Replacement Parts ........................................................ 27
Hopper Replacement Parts.....................................................28
Warranty ...........................................................................29
COPYRIGHTNOTICE
Copyright 2021. All right reserved. No part of this manual
may be copied, transmitted, transcribed, stored in a retrieval
system, in any form or by any means without expressed
written permissionof,
Dansons
3411North 5th Avenue, Suite 500, Phoenix, AZ,USA85013
[e-mail] | [e-mail]
www.pitboss-grills.com
Customer Service
Monday through Sunday,4am - 8pm PST(EN/FR/ES)
Toll-Free: 1-877-303-3134, Fax: [phone]

6
EN ENGLISH
PARTS & SPECS
1
2
4
3
10
11 12
15
14
17
18
20
21
22
23 24 25
26
27
28
29
30
31
A D G J
B E H
C F I
19
16
8
6
79
5
Part# Description
1 Top Cooking Rack (x1)
2 Middle Cooking Rack(x1)
3 Griddle (x1)
4 Cooking Grids (x4)
5 Flame Broiler Slider (x1)
6 Flame Broiler Main Plate (x1)
7 Chimney Gasket (x1)
8 Chimney Cap (x1)
9 Chimney Stack (x1)
10 Rack Hanger (x1)
11 Lid Handle (x1)
12 Main Barrel / Hopper Assembly (x1)
13 Flame Broiler Adjusting Bar Handle (x1)
14 Flame Broiler Adjusting Bar (x1)
15 Meat Probe (x2)
16 GreaseBucket (x1)
17 Side Shelf (x1)
18 Diffuser Plate (x1)
19 Front Shelf Bracket / Left (x1)
20 Front Shelf Bracket / Right (x1)
21 Front Shelf (x1)
22 Left Support Leg - Front (x1)
23 Left Support Leg- Back (x1)
24 Right Support Leg - Front (x1)
25 Right Support Leg- Back (x1)
26 Bottom Shelf (x1)
27 Locking Caster Wheels (x2)
28 Wheel (x2)
29 Power Cord Clip (x1)
30 Power Cord - F Plug (x1)
31 Power Cord - GPlug (x1)
A Screw (x28)
B Washer (x24)
C Locking Washer (x22)
D Tool Hook (x3)
E Wheel Cotter Pin (x2)
F Wheel Washer (x2)
G Wheel Axle Pin (x2)
H Screw (x2)
I Nut (x2)
J Bushing (x2)
MODEL ASSEMBLED(WxDxH) WEIGHT COOKING AREA TEMPERATURE RANGE
PB
PB1600PS1 1,587.5MM x 813.5 MM x 1,400 MM /
62.50 IN. x 32.03 IN. x 55.12IN. 110.0 KG / 242.5 LB
TOPRACK- 2,474.8 CM² / 383.6 IN²
MIDDLE- 3,249.6 CM²/ 503.7IN²
MAIN - 4,587.1CM² / 711.0IN²
TOTAL- 10,311.5CM² / 1,598.3 IN²
82-260°C/ 180-500°F
13
NOTE:Dueto ongoing product development, parts are subject to changewithout notice. Contact
Customer Serviceif parts are missing when assembling the unit.
PB – ELECTRICREQUIREMENTS
220-240 V, 50 Hz, 275 W, 3-PRONGGROUNDEDPLUG

7
EN
ENGLISH
ASSEMBLYPREPARATION
Partsarelocated throughout the shipping carton,including underneath the grill. Inspectthe grill, parts, and hardwareblister pack
after removing from the protective shipping carton. Discardall packaging materials from inside and outside of the grill before
assembly,then review and inspect all parts by referencing the parts list. If any part is missing or damaged, do not attempt to
assemble.Shipping damage is not covered under warranty. Contact your dealer or Pit Boss®CustomerServicefor parts: Monday
through Sunday, 4am - 8pm PST(EN/FR/ES).
[e-mail] | Toll-Free: 1-877-303-3134 | Toll-Free Fax: [phone]
IMPORTANT:To ease installation, usingtwo people ishelpful (but not necessary)when assemblingthis unit.
Toolsrequired for assembly: screwdriver and level.
Toolsnot included.
ASSEMBLYINSTRUCTIONS
IMPORTANT: It is advised to read each step entirely before starting assemblyon instructions. Do not tighten screws
completely until all screwsfor that step have been installed. Hardware combination involving a locking washer and
washer should be installed with the locking washer closestto the head of the screw.
1. MOUNTING THE LEGSTOTHE MAIN BARREL
Parts Required:
1 x Main Barrel /Hopper Assembly (#12)
1 x Left Support Leg - Front (#22)
1 x Left Support Leg- Back (#23)
1 x Right Support Leg / Front (#24)
1 x Right Support Leg / Back(#25)
12 x Screw (#A)
12 x Washer (#B)
12 x Locking Washer (#C)
Installation:
• Placeapieceof cardboardon the floor to prevent scratchingthe unit and
parts during assembly.Lay the Main Barrel on its side on the cardboard,
hopper end pointed upward.
• Mount the Front-Right Support Legto the floor end of the Main Barrel
using three screws,locking washers,and washers,through the three pre-
drilled holes. Install screws from the inside of the Main Barrel. Repeat
installation for Back-RightSupport Leg.Note illustration 1A.
• Next, mount the Front-Left Support Legto the hopper end of the Main
Barrel using three screws, locking washers, and washers, through the
three pre-drilled holes.Install screwsfrom the inside of the Main Barrel.
Repeatinstallation for Back-Left Support Leg.Note illustration 1B.
IMPORTANT:Do not tighten screwscompletely until bottom shelf is
installed in next step.
1A
1B
25
24
22
23
BCA
BCA
BCA
BCA

8
EN ENGLISH
2. INSTALLING THE BOTTOM SHELF
Parts Required:
1 x Bottom Shelf (#26)
4 x Screw (#A)
4 x Washer (#B)
4 x Locking Washer (#C)
Installation:
• Mount the Bottom Shelf to each Support Leg using a screw, locking
washer, and washer. Ensure the at surface of the shelf is facing up
towards the Grill Barrel.
3. ADDING WHEELSTO THE CART
Parts Required:
2 x Locking Caster Wheels (#27)
2 x Wheel (#28)
2 x Wheel Cotter Pin (#E)
2 x Wheel Washer (#F)
2 x Wheel Axle Pin (#G)
Installation:
• Insert each Locking CasterWheel into the bottom of each Left Support
Leg by hand-tightening into the hole. Ensurethat each Locking Caster
Wheel is inserted completely. Note illustration 3A.
• Attach each Wheel to each Right Support Leg by inserting the Wheel
Axle Pin through the Wheel, Support Leg hole, Wheel Washer, then
secureusing the Wheel Cotter Pin.Note illustration 3B.
• Oncethe shelf issecure,carefully lift the grill into an upright position.
IMPORTANT: Re-tighten the support leg screwsto ensure they are
completely secureafter positioning the grill upright.
4. INSTALLINGTHELID HANDLE
Parts Required:
1 x Lid Handle (#11)
Installation:
• Remove the pre-installed screws from the Lid Handle. From inside
the barrel lid, insert one screw to protrude to the outside, then hand-
tighten the screw(from the inside)into the LidHandle.Repeatthe same
installation for the other end of LidHandle.
2
3A
3B
26
27
27
28
4
11
28
G
G
F
FE
E
23
22
ACB
ACB
BCA
BCA

9
EN
ENGLISH
5. ASSEMBLING THESIDE SHELF
Parts Required:
1 x Side Shelf (#17)
3 x Tool Hook (#D)
Installation:
• Turn the Side Shelf upside down. On the edge of the Side Shelf with
three holes,install the tool hooks into eachhole along the edge. The
tool hookswill secureto the nut that is pre-mounted on the inside.
6. MOUNTING THESIDESHELF
Parts Required:
4 x Screw (#A)
4 x Locking Washer (#C)
4 x Washer (#B)
Installation:
• From underneath, fasten the Side Chelf to the side panel of the Main
Barrel using four screws,locking washers, and washers.
NOTE:Do not tighten screwscompletely until all screwshave been
installed. Onceall screwsare installed, then tighten securely.
IMPORTANT: Avoid using the shelves to move or lift the grill. The
weight of the unit will cause the shelves to break, which is not
coveredby warranty.
7. SECURINGTHE CHIMNEY
Parts Required:
1 x Chimney Gasket (#7)
1 x Chimney Cap (#8)
1 x Chimney Stack (#9)
2 x Screw (#A)
2 x Locking Washer (#C)
2 x Washer (#B)
Installation:
• Locatethe chimney opening on the side of the Main Barrel.From the
outside, secure the Chimney Stack and Chimney Gasket to the side
panel using two screws,locking washers, and washers.The screw will
fasten to the pre-mounted nut on the inside of the barrel.
• Next, secure the Chimney Caponto the top of the Chimney Stack by
rotating the Chimney Capscrew into the Chimney Stack.
NOTE: Adjust the chimney cap to affect the airflow inside the Main
Grill.If cookingat low temperature, keep the cap more open. Ensure
the chimney cap allows for air to escape.
5
6
17D
BCA
BCA
BCA
BCA
D
D
7
8
9
BCA
7

10
EN ENGLISH
8. SECURINGTHE FRONT SHELFBRACKETS
Parts Required:
1 x Front Shelf Bracket / Left (#19)
1 x Front Shelf Bracket / Right (#20)
6 x Screw (#A)
Installation:
• Attach one Front Shelf Bracketto the front of the grill barrel by using
three screws. Install each screw halfway, then tighten completely
when all three screwsare mounted and aligned properly.
• Repeatthe same installation for the other Front ShelfBracket.
9. INSTALLING THE FRONT SHELF
Parts Required:
1 x Front Shelf (#21)
2 x Washer (#B)
2 x Screw (#H)
2 x Nut (#I)
2 x Bushing (#J)
Installation:
• From underneath, insert the screw (from the outside) into the Front
Shelf Bracket and the Front Shelf, then add the bushing onto the
screw,the washer,then the nut. Repeatinstallation for the other side
of the Front Shelf.
NOTE: When installed correctly, the Front Shelf can be raised (for
use)andlowered (for storage) with ease.
IMPORTANT: Avoid using the shelves to move or lift the grill. The
weight of the unit will cause the shelves to break, which is not
coveredby warranty.
10. PLACING THE DIFFUSERPLATE
Parts Required:
1 x Diffuser Plate (#18)
Installation:
• Placethe Diffuser plate into Main Barrel so the central opening aligns
directly with the circularBurn Pot on the baseof the Main Barrel.
NOTE:The Diffuser Plate does not require fastening.
10
8
9
18
B
J
HI
A
19
21
20

11
EN
ENGLISH
11. INSTALLING THE FLAME BROILERCOMPONENTS
Parts Required:
1 x Flame Broiler Slider (#5)
1 x Flame Broiler Main Plate (#6)
1 x Flame Broiler Adjusting Bar Handle (#13)
1 x Flame Broiler Adjusting Bar (#14)
Installation:
• Insert the FlameBroiler Main Plate into the Main Grill, right side first.
Rest the Flame Broiler Main Plate on the built-in ledge (on the inside
right) of the Main Grill that directs greasetowards the greasebucket.
Slidethe entire piece to the left side,and the two slots on the Flame
Broiler Main Plate will fit into the rounded ledge above the Burn Pot.
It will sit slightly at a downward angle.Note 11A.
IMPORTANT: If the Flame Broiler Main Plate is on the base of the
barrel, it isinstalled incorrectly.The Flame Broiler Main Plate should
sit at an angle, with the left sidesitting higher than the right. Poor
installation of this part may result in damage to your Main Grill
barrel.
• Placethe Flame Broiler Slider on top of the Flame Broiler Main Plate,
covering the slotted openings. Ensurethe raised tab is on the left,
to easily adjust for direct or indirect flame when cooking. Note
illustration 11B.BothFlame Broiler parts are lightly coated with oil to
avoid rusting when shipped.
• Next, remove the Flame Broiler Adjusting Bar Handle from the Flame
Broiler Adjusting Bar. Insert the Flame Broiler Adjusting Bar through
the opening hole on the left side of the Main Barrel. Add the Flame
Broiler Adjusting Bar Handle back onto the end outside the barrel.
Next, slide the notched end of the Adjusting Bar into the locking tab
on the Flame Broiler Slider,giving you adjustable accessto the Flame
Broiler Slider on the main plate. Note steps in 11C.
NOTE: When the Flame Broiler Slider isopen and direct flame is used,
do not leave the grill unattended for any period of time.
11A
11B
11C
B
B
A
A
6
5
6
13 14

12
EN ENGLISH
12. INSTALLING THE COOKINGCOMPONENTS
Parts Required:
1 x Top Cooking Rack (#1)
1 x Middle Cooking Rack(#2)
1 x Griddle (#3)
4 x Cooking Grids (#4)
Installation:
• Choosea desired main cooking surface: two Cooking Grids with the
Griddle (shown in 12A)or four Cooking Grids (shown in 12B).Placethe
chosencombination of cooking surfaceon the lower grid ledgesinside
the Main Grill.
• Next, place the Middle Cooking Rackon the middle ledges inside the
Main Grill. Place the Top Cooking Rack on the top ledges inside the
Main Grill.
NOTE: To maintain the searing and grilling performance of your
Cooking Grids and Cooking Racks, regular care and maintenance is
required.
13. MOUNTING THE RACKHANGER
Parts Required:
1 x Rack Hanger (#10)
Installation:
• Securethe Rack Hanger to the back panel of the Main Barrel using
the pre-assembly two screws.Cooking Rackscan be hung on the Rack
Hangerwhile not in use.
14. PLACING THE GREASEBUCKET
Parts Required:
1 x GreaseBucket (#16)
Installation:
• Place the Greasebucket on the spout hook on the end of the Main
Barrel. Ensureit is level to avoid grease spills.
• The unit is now completely assembled.
14
13
16
12A
12B
10
2
2
1
1
4,3,4
4,4,4,4

13
EN
ENGLISH
15. INSTALLING THE POWER CORD
NOTE:There are two Power Cords supplied. Select the Power Cord that is
required for your region.
Parts Required:
1 x Power Cord Clip (#29)
1 x Power Cord (#30 or #31)
Installation:
• Place the Power Cord Clip on the Power Cord. Then, insert the Power
Cordinto the groove at the bottom of the unit. Note 15A.
• Secure the Power Clip to the bottom panel using the pre-installed
screw, as shown. Note 15B.
16. CONNECTING TO APOWER SOURCE
• STANDARD OUTLET
This appliance requires 220-240 Volt, 50 Hz, 275 W. It must be a
grounded plug. Ensuregrounded end is not broken off before use.The
control usesa 220-240volt, fast-blow fuse to protect the board from
the ignitor.
IMPORTANT: Disconnectunit from power sourcewhen not in use.
15
15B
15A
29
30/31
16

14
EN ENGLISH
OPERATING INSTRUCTIONS
With today’s lifestyle of striving to eat healthy and nutritious foods, one factor to consideris the importance of reducing fat
intake. One of the best ways to cut down on fat in your diet is to use a low fat method of cooking, such as grilling. As a pellet
grill usesnatural wood pellets,the savory wood flavor is cookedinto the meats, reducing the need for high sugarcontent sauces.
Throughout this manual, you will notice the emphasison grilling food slowly at LOWor MEDIUMtemperature settings.
GRILLENVIRONMENT
1.
WHERETO SET-UP THE GRILL
With alloutdoor appliances,outsideweather conditions play a big part in the performanceof your grill and the cooking time
needed to perfect your meals.
All Pit Boss®units should keep a minimum clearanceof 914mm (36 inches)from combustible constructions, and this clearance
must be maintained while the grill is operational. This appliance must not be placed under overhead combustible ceiling or
overhang. Keepyour grill in an areaclearfrom combustible materials, gasolineand other ammable vapors and liquids.
2.
COLDWEATHERCOOKING
As it becomes cooler outside, that does not mean that grilling season is over! The crisp cool air and heavenly aroma of
smoked foods will help cureyour winter blues.
Follow these suggestionson how to enjoy your grill throughout the coolermonths:
• If smoking at low temperatures fails,increasethe temperature slightly to achievethe same results.
• Organize– Get everything you require ready in the kitchen before you head outdoors. During the winter, move your
grill to an area that is out of the wind and direct cold. Checklocal bylaws regarding the proximity of your grill in
relation to your home and/or other structures.Put everything you need on a tray, bundle up tight, and get it done!
• To help keep track of the outside temperature, placean outdoor thermometer closeto your cooking area.Keepa log
or history of what you cooked,the outdoor temperature,and the cookingtime. Thiswill helplater down the road to
help you determine what to cook and how long it will take.
• In very cold weather, increaseyour preheating time by at least 20 minutes.
• Avoid lifting the lid any more than necessary.Coldgusts of wind can completely cool your grill temperature. Be
flexible with your servingtime; add extra cooking time eachtime you open the lid.
• Have a heated platter or a dish cover ready to keep your food warm while making the trip back inside.
• Ideal foods for winter cooking are those that require little attention, suchasroasts,whole chickens,ribs,and turkey.
Make your meal preparation even easierby adding simple items suchasvegetables and potatoes.
3.
HOT WEATHERCOOKING
Asit becomeswarmer outdoors, the cooking time will decrease.
Followthese few suggestionson how to enjoy your grill throughout the hot months:
• Adjust your cooking temperatures downward. Thishelps to avoid unwanted flare-ups.
• Usea meat thermometer to determine the internal temperature of your foods. Thishelps in preventing your meat
from over cooking and drying out.
• Evenin hot weather it is still better to cook with the lid of your grill down.
• You can keep foods hot by wrapping them in foil, and placing them in an insulated cooler. Stuff crumpled up
newspaperaround the foil and this will keep food hot for 3 to 4 hours.

15
EN
ENGLISH
GRILLTEMPERATURE RANGES
Temperature readouts on the control board may not exactly match the thermometer. All temperatures listed below
are approximate and are affected by the following factors:outside ambient temperature, the amount and direction of
wind, the quality of pellet fuel being used,the lid being opened, and the quantity of food being cooked.
•
HIGH TEMPERATURE(205-260°C/ 401-500°F)
This range is best used to sear and grill at a high heat. Use in tandem with the Flame Broiler (slide plate) for indirect or
direct flame cooking. With the
Flame Broiler open
, direct flame is used to create those “blue” steaks, as well as flame-
kissed vegetables, garlic toast or s’mores! When the
Flame Broiler isclosed
,the air circulates around the barrel, resulting
in convection heat. High temperature is also used to preheat your grill, burn-off the cooking grids, and to achievehigh heat
in extreme cold weather conditions.
•
MEDIUM TEMPERATURE(135-180°C/ 275-356°F)
This range is best for baking, roasting, and finishing off that slow smoked creation. Cooking at these temperatures will
greatly reduce the chancesof a grease are-up. Ensurethat the Flame Broiler Slider in the closed position, covering the
slotted openings.Greatrange for cooking anything wrapped in bacon,or where you want versatility with control.
•
LOWTEMPERATURE(82-125°C/ 180-257°F)
This range is used to slow roast, increasesmoky avor, and to keep foods warm. Infuse more smoke avor and keep your
meats juicy by cooking longer at a lower temperature (alsoknown as
low and slow
).Highly recommendedfor the big turkey
at Thanksgiving,juicy ham at Easter,or the huge holiday feast.
Smoking is a variation on true barbecuing and is truly the main advantage of grilling on a wood pellet grill.
Hot smoking
,
another name for
low and slow
cooking, is generally done between 82-125oC/180-257oF.Hotsmoking works best when
longer cooking time is required, such as large cuts of meats, fish, or poultry.
TIP:Tointensify that savoryflavor, switchto a low temperature range immediately after putting your food on the
grill. Thisallowsthe smoke to penetrate the meats.
Thekeyisto experiment with the length of time you allow for smoking,before the mealisnished cooking.Someoutdoor chefs
prefer to smokeat the end of a cook,allowing the food to keep warm until ready to serve.Practicemakesperfect!

16
EN ENGLISH
UNDERSTANDING THE CONTROLBOARD
ThisP.I.D.(proportional-integral-derivative) digital Control Board is very much the sameasthe controls on your kitchen oven. The
main advantagesarethe ability to automatically compensatefor the different ambient conditions and fuel types.
IMPORTANT:Thetemperature insideof any grill will vary greatly from locationto location.Eveninstruments
calibratedtogether may not agree with eachother.
CONTROL DESCRIPTION
Pressthis button onceto Power On the unit. Thiswill begin the automatic start-up cycle.Pressandhold
this button for three secondsto Power-down the unit, activating the automatic cool-down cycle.The
button will light up solid white when connectedto a power sourceand when the unit is on.
The Smoke iT®icon indicates a connectivity with Wi-Fi. When searching for a connection by Wi-Fi or
via Bluetooth®, the SmokeiT®icon will blink. Oncea Wi-Fi connection has been established, the Smoke
iT®icon will stay solid. When connected, get live updates about the actual and set temperatures of
the grill, cooking time, and meat probe temperatures.It also allows you to adjust the settings of your
Control Board.
Thisbutton hastwo functions: Temperature Units Switch and Light.
1. Quickpush of this button to switch on and off the light insidethe grill barrel.
2. Pressand hold this button for three secondsto activate the Temperature Units Switch, changing
the temperature readout. Changebetween Celsius(ºC)and Fahrenheit (ºF),aspreferred. Default is
set to Celsius(ºC).
Thisbutton hastwo functions: Meat ProbeControl (MPC)and Prime Button.
1. Thequick pushof thisbutton activatesthe ProgrammableMeat Probe- which isthe first Meat Probe
plug-in port (MPC).Use the Controller Knob to set the Programmable Meat Probe temperature.
Pressthe Controller Knob again to confirm and exit the Programmable Meat Probe settings.
2. Pressand hold this button for three secondsto activate a manual continuous feeding of pellets to
the Burn Pot. Releasingthe button will stop the manual feeding of pellets.Thiscanbe usedto add
more fuel to the fire before opening the barrel lid, resulting in a quick heat recovery.It can also be
used while smoking, to increasethe intensity of clean smoke avor. This feature was requested
from competition cookers.
MP1 MP2 MP3MPC

17
EN
ENGLISH
TheController Knob is used to increase,decrease,and select a setting value. Rotate the Controller Knob
to selectthe time, temperature, or step in an active settings menu. Pushthe Controller Knob to confirm
the chosenvalue.
Thecentral readout displaysboth the Actualand Settemperatures. TheActual temperature isconstantly
displayed unlessthe Set temperature is being adjusted. The Actual temperature is the temperature
from inside the Main Barrel. The Actual temperature readout is taken by the grill probe (sensor)from
the inside of the grill barrel.
Toshow the Settemperature, pressthe Controller Knob.TheSettemperature is active when the readout
is blinking. To adjust the Set temperature, rotate the Controller Knob,as needed. Oncethe desired Set
temperature is reached,pressthe ControllerKnobto confirm the Settemperature, then the readout will
return back to the Actual Temperature.
Pressthe button once to activate the RecipeSteps.There are nine RecipeStepsavailable to set. Adjust
the settings of eachRecipeStepby using the Controller Knob.
Displays the current RecipeStep.
Displays the Time set during the RecipeStep. Pressthe RecipeButton to activate the Recipesettings.
Usethe Controller Knob to switch through the RecipeSteps,one being the Time.
Displays the Actual and Set temperature of the Programmable Meat Probe - which is the first Meat
Probe plug-in port (MPC).The Actual temperature is constantly displayed unless the Set temperature
is being adjusted. When the MPCButton is pressed,the selectedMeat Probe readout will blink and the
Settemperature canbe adjusted. When not in use,disconnectthe Meat Probefrom the connection port
and code"noP" will be displayed. Compatible with Pit Boss®Grillsbranded meat probes only.
Displays the Actual temperature of a Meat Probe. Thesethree Meat Probe readouts correspond with
the plug-in connectionport selected.When not in use,disconnectthe Meat Probefrom the connection
port and code "noP" will be displayed. Compatible with Pit Boss®Grillsbranded meat probes only.
This readout is displayed after Power-down has been selected. It indicates that the automatic cool-
down cycle has started. Oncethe cool-down cycle is completed, the readout will no longer be visible.
TheFANicon is visible when the fan is in operation. When the central readout hasthe FANicon blinking,
the Fanis not working. Seethe section on troubleshooting for assistance.
The AUGERicon is visible when the auger is turning. When the central readout has the AUGERicon
blinking, the auger isnot working. Seethe section on troubleshooting for assistance.
The IGNITORicon is visible when the ignitor is in use. When the central readout has the IGNITORicon
blinking, the ignitor is not working. Seethe section on troubleshooting for assistance.
When the central readout has the PELLETiconvisible, the re in the Burn Pot has gone out or the
hopper may be empty. Seethe section on troubleshooting for assistance.

18
EN ENGLISH
CONTROLBOARD FUNCTIONS
•
SETTINGTHEGRILL TEMPERATURE
The Grill Probe measuresthe internal temperature of the Main Barrel.When the Set temperature is adjusted, the Grill Probe
will read the Actual temperature inside the Main Barreland adjust to the desired Settemperature.
IMPORTANT:The temperature of your unit is highly dependent on ambient outdoor weather, quality of pellets
used,flavor of pellets, and the quantity of food being cooked.
SETTING/ADJUSTING THE SETTEMPERATURE
To adjust the desiredSettemperature of the grill, follow the stepsbelow:
1. Pressthe Controller Knob. Thiswill make the Set temperature readout blink, to show it is active.
2. Usethe Controller Knob again to adjust to your desired temperature.
3. Oncethe desired Set temperature is reached,pressthe Controller Knob to conrm the Set temperature,
then the readout will return backto the ActualTemperature.
•
USING THEPROGRAMMABLE MEAT PROBE
Themeat probe measuresthe internal temperature of the meat on the grill, similar to your indoor oven.Insert the stainless-
steel meat probe into the thickest portion of the meat. The internal temperature of the meat is shown on the Control
Board readout. Plug-in the Meat Probe adapter to the meat probe connection port and ensureit is inserted all the way
into the plug. Youwill feel and hear it snapin place.Not only will it cook the meat to your desiredtemperature, but it will
automatically reduce your grill temperature to low (82°C/ 180°F)to keep food warm until ready to serve. Just set it, then
relax while the Meat Probedoes the rest!
NOTE:When placing the meat probe into your meat, ensure the meat probe and meat probe wires avoid direct
contact with flame or excessheat. Thiscan result in damage to your meat probe. Run the excesswire out the rear
exhaust holes of the Main Barrel,the top of the Main Barrel (near the grill lid hinge), or through the front hole
near the hopper. When not in use,disconnectfrom the meat probe connectionport, and place in the holes on the
hopper handle to keep protected and clean.
SETTING/ADJUSTING THE PROGRAMMABLE MEAT PROBE
To program the desiredSettemperature of the ProgrammableMeat Probe,follow the steps below:
1. Quick pressthe MPC button to activate the Programmable Meat Probe.When active, the temperature
readout of the Meat Probewill blink.
2. Usethe Controller Knob to adjust to the desired Settemperature.
3. Once the desired Set temperature of your selected Meat Probe is reached, press the Controller Knob
again to confirm and exit the ProgrammableMeat Probesettings.

19
EN
ENGLISH
•
SETTINGUP A RECIPE
The Recipefunction allows the user to program cooking instructions, known as RecipeSteps,for the Control Board to follow
and automatically run. Thesecooking instructions are a combination between Cookingtemperature and Time.Starting from
the rst RecipeSteps(01),the Control Board will cycle through eachRecipeStepsto cook the meal. When all the RecipeSteps
are complete, the Control Board will automatically switch to a low temperature of 82°C/ 180°Fsothat the meal stays warm
until ready to serve.Thereare a total of nine RecipeStepsavailable to be programmed.
HOW TO PROGRAM ARECIPESTEP
To set one or more of the RecipeSteps,follow the steps below:
1. Pressand hold the RecipeButton. This will make the RecipeButton blink to show the Recipesettings are
active. Thiswill also activate the RecipeStepsand the letter 'S' will be on to show it is active.
• Usethe Controller Knob to select the RecipeStep.Start with the rst RecipeStep (01).
• When desired RecipeStep is reached,pressthe Controller Knob to go to next setting.
2. Setthe Timehours.Thehours of the Timereadout will blink, to show it is selected.
• Usethe Controller Knob to select the hours desired.
• When desired hours arereached,pressthe Controller Knob to go to next setting.
3. Setthe Time minutes. Theminutes of the Time readout will blink, to show it is selected.
• Usethe Controller Knob to select the minutes desired.
• When desired minutes are reached,pressthe Controller Knob to go to next setting.
4. Set the Temperature.Thecentral temperature readout will blink, to show it is selected.
• Usethe Controller Knob to select the desired temperature.
• When desired temperature is reached,pressand hold the RecipeButton to lock in all Recipesettings
for that RecipeStep.
• To set another Recipe Step, quick press the Recipe Button to select another Recipe Step,
programming a multiple RecipeStep cook. Repeat steps above, as desired.
Or,
• Pressand hold the RecipeButton a second time to exit the Recipesettings and run the Recipe.
The RecipeButton will stop blinking.
NOTE:The RecipeStepswill reset when the unit is shut-down / turned off.
CONNECTINGTO THESMOKE IT® APP
Follow these instructions on how to connect your grill to the SmokeiT®app with your Android™or iOS®device.Theapp will allow
you to control and monitor your grill and meat probe temperatures from your mobile device.Enjoythe benefits that SmokeIT®
mobile connectivity hasto offer!
1. Download the SmokeiT®app. Open the app and allow Bluetooth®to be enabled for setup. New userswill need to create
an accountand follow the prompts to login.
2. If you are within Bluetooth®range (9 m / 30 ft), the SmokeiT®app will automatically detect your grill. Selectyour grill
model. If you do not seeyour grill on the screen,ensureyour unit is connected to a power sourceand is turned on.
3. Name your grill model (ie. My Smoker) in the app and select "Connect" at the bottom of the screen.This will save your
grill model in the devicesmenu.
4. From the devices menu, click the grill model to connect. This will show you the control board screen.
5. Click the settings option (gear) in the top-right corner, enter your Wi-Fi credentials, then click the check mark at the
bottom of the screento connect.Now both Bluetooth®and Wi-Fi (cloud) iconswill show on the devicesmenu, showing
that the grill is connected.
While using the app, the screenwill shine bright when the grill is active and connected.If the app screenor grill goes
dark on the devices menu, checkyour wireless connection or power source.

20
EN ENGLISH
HOPPER PRIMING PROCEDURE
Theseinstructions should be followed the first time the grill is ignited, and eachtime the grill runs out of pellets in the hopper.
Theaugermust be primed to allow pelletsto travel through the length of the auger,and fill the feed system.If not primed, the
ignitor will timeout before the pellets are ignited, and no fire will start. Followthesestepsto prime the hopper:
1. Openthe Main Barrellid. Removeall cooking components from the interior of the grill. Locatethe BurnPot in the bottom
of the Main Barrel.Checkthe Burn Pot to ensurethere is no obstruction for proper ignition.
2. Plug the power cord into a power source.Pressthe Power button to Power On the unit. Checkthe following items:
• That you can hear the auger turning. Placeyour hand above the Burn Pot and feel for air movement. Do not place
your hand or ngers inside the Burn Pot. This can causeinjury.
• After approximately a minute, you shouldsmell the ignitor burning and begin to feel the air getting warmer in the
BurnPot.Theignitor tip doesnot glow red,but gets extremely hot and will burn. Do not touch the ignitor.
3. Onceverified that all electric components are working correctly,pressthe Power Button to turn the unit off.
4. Open the hopper lid. Ensurethere areno foreign objects in the hopper or auger feed system.Fill the hopper with dry, all
natural barbecuehardwood pellets.
5. Pressthe Power Button to turn the unit on again. The grill start-up cycle has a preset temperature of 176°C/ 350°F,soit
will begin to heat up. Pressandhold the PrimeButton until you seepellets on the inside of the grill from the auger tube.
Oncepellets begin to drop into the Burn Pot, releasethe Prime Button.
6. Pressthe Power Button to turn the unit off.
7. Re-install the cooking components into the Main Barrel.Thegrill is now ready to use.
FIRST USE– GRILLBURN-OFF
Onceyour hopper hasbeen primed and before cooking on your grill for the first time, it isimportant to complete a grill burn-off.
Start the grill and operate at any temperature over 176°C/ 350°F(with the lid down) for 30 to 40 minutes to burn-off the grill
and rid it of any foreign matter.
AUTOMATIC START-UP PROCEDURE
1. Plug the power cord into a grounded power source.Open the Main Barrel lid. Checkthe Burn Pot to ensure there is no
obstruction for proper ignition. Open the hopper lid. Ensurethere are no foreign objects in the hopper or auger feed
system.Fill the hopper with dry, all natural barbecuehardwood pellets.
2. Pressthe Power Button to turn the unit on. Thiswill activate the start-up cycle.Theauger feed system will begin to turn,
the ignitor will begin to glow and the fan will supply air to the Burn Pot. Thegrill will begin to producesmokewhile the
start-up cycleis taking place.Thebarrel lid must remain open during the start-up cycle.To confirm the start-up cyclehas
begun properly, listen for a torchy roar, and notice someheat being produced.
3. Oncethe heavy, white smoke has dissipated, the start-up cycle is complete and you are ready to enjoy your grill at your
desiredtemperature!
SHUTTING OFFYOUR GRILL
1. When finished cooking, with the Main Barrellid remaining closed,pressand hold the the Power Button for three seconds
to Power-down the unit. The grill will begin its automatic cool-down cycle.The auger system will stop feeding fuel, the
flame will burn out, and the fan will continue to run until the cool-down cycleis complete.
