Pitco SG18S User manual

Pitco Frialator, Inc.,P.O. Box 501, Concord, NH 03302-0501 x1509 Route 3A, Bow NH 03304, USA
Phone [phone]xFax(603)225-8472xwww.pitco.com
L10-126 Rev 5(02/07)
Model SG18S with Options
Tube Fired Gas Fryer
Project __________________________
Item number _____________________
Quantity _________________________
Model SG18S w/Options
APPROVALS
CSA Certified
(AGA, CGA)
NSF Listed
MEA Approved
CE Certified
Australian Gas Assoc.
Certified (AuGA)
Patent Pending
STANDARDACCESSORIES
Choice of basket options
Two nickel-plated, oblong, wire mesh baskets
One nickel-plated, square, wire mesh basket
One nickel-plated tube rack
One drain extension
One drain line clean-out rod
Fryer cleaner sample
Rear gas connection
Manual gas shutoff
11/4” (3.2 cm) full port drain valve
Built-in integrated flue deflector
Removable basket hanger for easy cleaning
9” (22.9 cm) adjustable legs
Cabinet - stainless steel front, door, and sides
AVAILABLE OPTIONS & ACCESSORIES
Stainless steel back
Basket Lift*
Solid State Thermostat**
Digital controller**
Triple baskets
Covers
Intellifry computer control**
Computer back-up thermostat
9” (22.9 cm) adjustable casters
*Only available with digital or computer controls.
**Includes matchless ignition, melt cycle, and drain valve
interlock switch.
STANDARD SPECIFICATIONS
CONSTRUCTION
Welded tank with an extra smooth peened finish en-
sures easy cleaning.
Long-lasting, high-temperature alloy stainless steel heat
baffles are mounted in the heat exchanger tubes to
provide maximum heating and combustion efficiency.
Standing pilot light design provides a ready flame when
heat is required.
Stainless steel front, door, side, and splashback.
Heavy duty 3/16” (.48 cm) door hinge.
CONTROLS
Millivolt thermostat maintains selected temperature
automatically between 200qF (93qC) and 400qF (190qC-
CE).
Integrated gas control valve acts as a manual and pilot
valve, automatic pilot valve, gas filter, pressure regulator,
and automatic main valve.
Gas control valve prevents gas flow to the main burner
until pilot is established and shuts off all gas flow
automatically if the pilot flame goes out.
Temperature limit switch safely shuts off all gas flow if
the fryer temperature exceeds the upper limit.
New Solstice burner/baffle design.***
-Increases cooking production.
-Lowers flue temperature.
-Improves working environment.
-Generates more production per BTU.
***Compared to previous models.
OPERATIONS
Front 1 1/4” (3.2 cm) full port drain for quick draining.
9” (22.9 cm) clearance allows for ease of cleaning.
Reversible tube rack converts fry depth from basket
operation to cooking free floating products.

Model SG18S with Options - Tube Fired Gas Fryer
Pitco Frialator, Inc.,P.O. Box 501, Concord, NH 03302-0501 x1509 Route 3A, Bow NH 03304, USA
Phone [phone]xFax(603)225-8472xwww.pitco.comL10-126Rev5(02/07)PrintedintheUSA
We reserve the right to change specifications without notice and without incurring any obligation for equipment previously or subsequently sold.
Model SG18S w/Options
GAS REQUIREMENTS
Gas Input Per Hour
140,000 BTUs / 40 kW (CE) / 145 megajoules (AuGA)
Gas Type*
Recommended Minimum
Store Manifold Pressure Burner Manifold Pressure
*For other gas types, contact
your Dealer/Distributor.
Natural Gas 7” W.C. / 17.4 mbars / 1.75 kPa 4” W.C. / 10 mbars / 1 kPa
L.P. Gas 13” W.C. / 32.4 mbars / 3.25 kPa 10” W.C. / 25 mbars / 2.5 kPa
Check plumbing/gas codes for
proper gas supply line sizing.
Clearance Information Fryer Front
Fryer Sides, Rear, Bottom to
any combustible material Fryer Flue Area
All Models 30” (76.2 cm) min. 6” (15.2 cm)
Do not Curb Mount
Do not block or restrict the flue
gasses from flowing into the
ventilation system.
ELECTRICAL OIL CAPACITY
Control Type Voltage / Phase / Frequency Amps
70 - 90 pounds
(32 – 41 kg)
Millivolt Not required 0 PERFORMANCE CHARACTERISTICS
115 / 1 / 60 1.7
Upgraded controls
(solid state, digital,
computer, basket lift) 220-230-240 / 1 / 50 0.9
Upgraded controls options include matchless ignition, melt cycle and
drain valve interlock at no additional amps.
Cooks 120 lbs (54kg) of fries per hour
Frying Area 18 x 18 x 4 ~ 4 ¾ in
(47.7 x 45.7 x 10.2 ~ 12.1 cm)
SHIPPING INFORMATION
Model Shipping Weight Shipping Cube Shipping H x W x L
Single Millivolt 216 lbs
98 kg
23 ft.È.65 mÈ45 ¼ x 22 Ëx 38 Éin
114.9 x 57.8 x 97.8 cm
Single Upgraded Controls 226 lbs
103 kg
33 ft.È.93 mÈ58 x 22 Éx 43 Éin
147.3 x 57.2 x 110.5 cm
2Add 50 lbs (23 kg) for Basket Lifts
SHORT FORM SPECIFICATION
Provide Pitco Model SG18S tube fired gas fryer. Fryer shall have an atmospheric burner system combined with five stainless steel
heat tubes utilizing high temperature alloy stainless steel baffles. Fryer shall have a deep cool zone; minimum 16% of total oil
capacity to trap burnt particles, crumbs and black specks. Fryer cooking area shall be 18” x 18” (45.7 cm x 45.7 cm) with a cooking
depth of 4” (10.2 cm) and 4 Ë” (12.1 cm). Heat transfer area shall be a minimum of 948 sq. inches (6116 sq. cm). Provide
accessories as follows:
TYPICAL APPLICATION
Frying a wide variety of foods in a limited amount of space. Frying that requires a high volume production rate.
