Pitco 14R Programming manual

14R & 18 WKS
KENTUCKY FRIED CHICKEN
EQUIPPED WITH A FAST COOKING
COMPUTER: EM99 or VC210
FRONT PANEL SUPPLIED BY PITCO
PITCO FRIALATOR, INC
P.O. BOX 501
CONCORD, N.H. 03301
PHONE [phone]
SERVICE DEPT. 603-225-5688
L20-310 R1 (02/15)
TROUBLESHOOTING
MANUAL
IMPORTANT FOR FUTURE REFERENCE
Please complete this information and retain this
manual for the life of the equipment:
Model #:________________________
Serial #: ________________________
Date Purchased: _________________

CONTENTS
Section 1S Service Procedures
- Burner Flow Drawing
Section 2S Troubleshooting Charts
Section 3S Parts List
Section 4S Front Panel Bezel
- Orifice Tips & Burner Pressure
Section 5S Entrance Box
L20-310 R0(02/15)
SERVICE MANUAL
14R & 18 WKS
KENTUCKY FRIED CHICKEN

Pitco Frialator, Inc.
P.O. Box 501, Concord, New Hampshire
SECTION 1S SERVICE PROCEDURES
Parts can be identified from diagrams on Parts List page for each model.
1.1 TO REMOVE MAIN BURNER
a. Turn Unitrol knob to “OFF" position.
b. Loosen set screw in base of burner casting.
c. Unscrew and remove two hex head screws at top of burner.
d. Unscrew and remove air collar from burner.
e. Lift burner up to clear top of burner fitting and remove from fryer.
f. Reverse procedure to remount burner.
1.2 TO CHANGE MAIN BURNER ORIFICE
a. Follow procedure in Section 1.1.
b. After burner has been removed, unscrew orifice with 3/8” wrench.
c. Screw in new orifice – tighten gas tight.
d. Remount burner and air collar.
1.3 TO REPLACE HEAT TUBE BAFFLES
a. Remove main burners: follow procedure in Section 1.1.a. through e.
b. Baffles are fastened to the inside of the heat tube by a small tack weld on the right
hand front baffle support. Break leg away from weld with a chisel or solid steel bar.
c. Remove old baffles and insert new ones in tubes in original position.
d. Remount main burners.
1.4 TO REMOVE PILOT BURNER
a. Follow procedure in Section 1.1 and remove main burner to the right of the pilot
burner.
b. Unscrew and remove tubing nut from pilot tubing connection on Unitrol.
c. Unscrew and remove thermopile or thermocouple from connection on Unitrol.
d. Unscrew and remove the two screws holding the pilot to the bracket on the fry tank
and lift the entire pilot assembly out of the fryer.
1.5 TO CHANGE PILOT BURNER ORIFICE
a. Follow procedure in 1.4.
b. Unscrew tubing nut in fitting in base of pilot burner.
c. Unscrew fitting in the base of pilot burner and withdraw orifice from inside the fitting.
d. Insert new orifice and reverse procedure to re-assemble.
e. Tighten all screws and connections and test for gas leaks.

Pitco Frialator, Inc.
P.O. Box 501, Concord, New Hampshire 03301
SECTION 1S SERVICE PROCEDURES (Cont’d)
1.6 TO REPLACE THERMOPILE OR THERMOCOUPLE
a. Follow procedure in 1.4.
b. Unscrew and remove thermopile or thermocouple from pilot burner and bracket.
c. Replace with new thermopile or thermocouple.
d. Reverse procedure to re-assemble.
e. Tighten all screws and connections and test for gas leaks.
1.7 TO ADJUST PILOT FLAME
a. Make this adjustment with pilot burner lit.
b. Remove screw cap underneath pilot supply tubing connection to Unitrol valve.
c. Insert long handled screwdriver with 1/8” wide blade in adjusting screw slot inside this
pilot supply fitting.
d. Turn adjusting screw clockwise to decrease or counterclockwise to increase pilot
flame. Watch size of pilot flame while turning adjusting screw.
CAUTION DO NOT REMOVE ADJUSTING SCREW
e.Replace screw cap when desired flame size is obtained.
f. Replace pilot orifice if desired flame cannot be obtained by adjustment. See
procedure 1.5.
1.8 TO REPLACE LIMIT CONTROL
a. Turn Unitrol knob to “OFF.”
b. Drain all shortening from fry tank. Remove tube screen.
c. Unscrew and remove the two screws in the limit bulb clamp on the heat tube inside
the fry tank.
d. Take sensing bulb out of the clamp and straighten the capillary tubing.
e. Remove the two burners that are in front of the capillary connector fitting on the
bottom of the fry pot. See procedure 1.1.
f. Unscrew small hex nut in connector fitting of control to be replaced.
g. Unscrew large connector nut and withdraw capillary and bulb from fry tank.
h. Remove the two wires off the limit control terminals.
i. Unscrew and remove the two mounting screws in the limit control bracket and
remove the limit control from the fryer.
j. Unpack the new limit control and carefully unroll the capillary tubing and straighten it
out.
k. Install the new limit control by reversing the procedure. BE CAREFUL NOT TO
BEND, KINK OR TWIST THE CAPILLARY TUBING SHARPLY. THIS WILL
DESTROY THE LIMIT CONTROL.

PITCO Frialator, Inc.
P.O. Box 501, Concord, New Hampshire 03301
11
22
44
66
TROUBLE POSSIBLE CAUSE REMEDY
Pilot flame burning yellow.
8
Draft may be pulling flame off
thermopile or thermocouple.
7
Pressure at burner manifold
should be 4.0" w.c. for natural
gas and 10.0" w.c. for propane
with all equipment on line in
full operation. If this cannot be
maintained, consult gas
company.
Gas pressure too low. 8
7Eliminate the draft.
Check millivoltage as above;
increase size of flame with
Unitrol pilot adjusting screw.
Remove and clean pilot and
thermopile or thermocouple;
decrease size of flame with
Unitrol pilot adjusting screw if
over 450 mv. Reading should
be 500 +/-50 mv. for
thermopile. Reading should be
between 25 and 35 mv. for
thermocouple.
5
SECTION 2S TROUBLESHOOTING CHART
Thermopile or thermocouple
producing insufficient
millivoltage.
33
Pilot will light but Unitrol
pilot gas valve will not hold
open automatically.
Check all wire connections.Loose wire connection in
millivoltage circuit.
5
Hold Unitrol knob (in PILOT
position) depressed for 1
minute or longer. Make sure all
air has been purged from gas
line.
Pilot thermopile or
thermocouple not hot enough
to generate required
millivoltage.
Check voltage at Unitrol with
millivoltmeter, holding pilot
flame on manually as in No. 1
above. Reading should be 500
+/-50 mv. for thermopile.
Reading should be between 25
and 35 mv. for thermocouple.
Check continuity across limit
control terminals with meter. If
limit control has cut off, check
at what temperature it cut off.
Pilot flame too small.
High limit control may have cut
out.

PITCO Frialator, Inc.
P.O. Box 501, Concord, New Hampshire 03301
99
10 10
11
44
55
66
11
22
11
Fryer temperature recovery
too slow.
1
Replace thermopile or
thermocouple
Defective thermopile or
thermocouple
Reset
SECTION 2S TROUBLESHOOTING CHART (Cont'd)
Turn handle counter clockwise
as far as it will go.
Unitrol valve handle not turned
to ON.
Defective probe.
Defective thermopile or
thermocouple
Replace magnet
Clean.
Minimum operating pressure:
Natural Gas- 4.0" w.c.;
Propane Gas- 10.0" w.c.
1
Replace baffles.
TROUBLE POSSIBLE CAUSE REMEDY
Low gas pressure.
Pilot flame lit but burners will
not light.
Pilot flame and main
burners cut off while
cooking.
22
Pilot will light but Unitrol pilot
gas valve will not hold open
automatically.
Float switch bulb off or stuck
down.
Install float switch bulb and new
clip.
Check electric supply circuit
22
33
Supply cord may not be
plugged in or switch may not be
turned on.
55
Replace probe.
Defective computer. Replace Computer.
Defective Unitrol. Replace Unitrol.
Dirty burners.
Hi-Limit tripped
Baffles in heat tubes may be
burned out.
33
4
Call factory to learn proper
sizes.
Incorrect burner orifices.
Carbon build-up on heat tubes. Clean fry tank and tubes.
4
Pilot flame is yellow. Pilot flame too large. Adjust Unitrol pilot adjustment
screw.
Carbon build-up on thermopile
or thermocouple.
Remove and clean.

PITCO Frialator, Inc.
P.O. Box 501, Concord, New Hampshire 03301
11
22
33
44
11
11
44
11Howling or screeching noise
when burners are on.
Main burner flames are
yellow.
SECTION 2S TROUBLESHOOTING CHART
Gas pressure too high. Adjust pressure regulator.
Loosen burner mounting
screws and line up burners.
2
3
Burner flames will not enter
heat tubes.
Dirt or burr on burner orifice. Clean orifice or replace.
Defective Unitrol.
Clogged vent cap on Unitrol.
Orifices are too large.
2
Main burners dirty.
Improper gas pressure.
TROUBLE POSSIBLE CAUSE REMEDY
Improper air collar adjustment
Main burners will not shut
off automatically.
22
Replace Unitrol.
Remove and clean cap.
2
Call factory to learn proper
sizes.
Remove burners and clean.
On natural gas adjust Unitrol
pressure regulator to 4.0" w.c
operating pressure. On
propane gas have gas supplier
adjust tank pressure to provide
10.0" w.c. operating pressure
at the fryer. (See Orifice and
Burner pressure chart)
3
Gas pressure too high/low.
Burners out of alignment.
a. Turn Vent on.
Orifices may be incorrect size. Call factory to learn proper
sizes.
Protect flue opening from
downdrafts, breezes or air
flows from blowers.
Downdraft on fryer flue
opening, or vent not turned on.
Remove and clean cap.
On natural gas adjust Unitrol
pressure regulator to 4.0" w.c
operating pressure. On
propane gas have gas supplier
adjust tank pressure to provide
10.0" w.c. operating pressure
at the fryer. (See Orifice and
Burner pressure chart)
2

NOTES

SECTION 3S PARTS LIST MODEL 14R & 18 WKS

SECTION 3S PARTS LIST MODEL 14R & 18 WKS
ITEM # PART NUMBER ITEM DESCRIPTION
B3309902 Stainless Steel Fat Container (14R)
B3307201 Stainless Steel Fat Container (18)
3 P5047210 Hi limit Control
P5047541 Thermopile
P5047540 Thermocouple
P6071450 Pilot Burner Natural
P6071449 Pilot Burner Propane
6 B6779850 Unitrol Limit Wire
P5045650 Unitrol Natural 120V (Thermopile)
P5045652 Unitrol Propane 120V (Thermopile)
P5045638 Unitrol Natural 24V (Thermopile)
P5045639 Unitrol Propane 24V (Thermopile)
PP10777 Unitrol Natural 24V CE (Thermocouple)
PP10778 Unitrol Propane 24V CE (Thermocouple)
8 P6071269 Unitrol Knob
9 Contact Factory Data Plate
10 P6071051 Main Burners
P6071338 Burner Orifices Natural (14R)
P6071309 Burner Orifices Propane (14R)
P6071339 Burner Orifices Natural (18)
P6071353 Burner Orifices Propane (18)
See Orifice Chart See Section 3S Burner Orifices chart (CE)
12 A8001001 Air Collar
14 A8001101 Burner Fittings
15 B8005601 Manifold
17 PP10025 Main Burner Bolt
18 PP10368 Drain Valve 1 1/4"
B2301105 Door Assembly RH (14R)
B2301106 Door Assembly RH (18)
21 PP11006 Door Handle
22 P6071496 Snap Buttons
23 PP11261 Burner Mounting Bolts
24 P6071300 Magnetic Door Catch
26 A1400202 Probe and Limit Bulb Clamp
27 A3301001 Clean Out Rod
B1000601 Heat Tube Baffles (14R)
B1000801 Heat Tube Baffles (18)
A4500201 Tube Screen (14R)
P6072186 Tube Screen (18)
30 A2510101 Drain Extension
A1100108 Basket Hanger (14R)
A1100110 Basket Hanger (18)
32 P6072145 Basket (14R)
33 Front Bezel Assembly See Section 4S Front Bezel Assembly
PP10810 7" Caster-Swivel Non-Locking-Rear
B3900408 7" Leg-Front
B3901401 8" Caster/Leg Set-Swivel Non-Locking-Rear
38 A8000801 Manifold Bracket
39 Entrance Box Assembly See Section 5S Entrance Box
1
11
20
28
37
29
31
7
4
5

SECTION 3S PARTS LIST MODEL 14R & 18 WKS ORIFICE
TIPS & BURNER PRESSURE
GAS CATEGORY ORIFICE TIP
SIZE (mm)
GAS
CATEGORY
Supply Pressure
(mbars)
Governor on
Gas Valve?
ORIFICE TIP
SIZE (mm)
I2H,I2E 2.44 I3P 37 Yes 1.51
I2L 2.79 I3P 50 Yes 1.51
I2E+, I2ESI 1.17(4) I3P 37 No 1.4
I2ELL 2.44/2.79 I3P 50 No 1.32
I3B/P 50 No 1.25
GAS CATEGORY ORIFICE TIP
SIZE
(
mm
)
GAS
CATEGORY
Supply Pressure
(
mbars
)
Governor on
Gas Valve?
ORIFICE TIP
SIZE
(
mm
)
I2H, I2E, I2E+, I2ESI 2.38 I3P 50 No 1.15
I2L 2.58 I3P 37 No 1.25
I2ELL 2.38/2.58
GAS TYPE ORIFICE TIP
SIZE
BURNER
PRESSURE
(
in. WC
)
MIN. INLET
PRESSURE
(
in WC
)
Natura
l
#38 4.0 7.0
Propane 0.0625" 10.0 12.0
Natura
l
39 4.0 7.0
Propane 53 10.0 12.0
14R Natural
18 Natural
14R Propane
18 Propane
14R
18
MODEL
Domestic/International Operational Information

NOTES

SECTION 4S FRONT PANEL BEZEL ASSEMBLY MODEL 14R & 18 WKS
Back View of Front Panel Bezel Assembly
ITEM # Schematic
Symbol
Part
Number ITEM DESCRIPTION
See Schematic 700131 Schematic
2 DS2 P5045044 Lamp
S2 PP10093 Switch On/Off
S3 PP10559 Switch Start/On/Off DVI (drain switch)
4 K2 PP11124 Relay 24V SPDT DC
10 K3 P5046686 Relay 24V DPDT AC
B6711702 Harness
B6711703 Harness DVI (drain switch)
Fast Computer -EM99
Fast Computer -VC210 KFC
Contact FAST for
Replacement
Not Shown
3
Computer Type
Harness Not Shown

SECTION 4S FRONT PANEL BEZEL SCHEMATIC MODEL 14R & 18 WKS

SECTION 4S FRONT PANEL BEZEL SCHEMATIC MODEL 14R & 18 WKS

SECTION 5S ENTRANCE BOX ASSEMBLY MODEL 14R & 18 WKS
Item Numbe
r
Qty. Part Numbe
r
Description
B2904502 Entrance Box 115V
B2904504 Entrance Box 220-240V
1 P5045794 Fuseholder
PP10122 1 Amp Fuse - 115V
P5045717 2 Amp Fuse - 220-240V
1 P5045794 Fuseholder
1 PP10122 1 Amp Fuse - 115V
41 PP10210 40VA Transformer
B6713901 Wire Harness 115V
B6713902 Wire Harness 220-240V
NOTE 1: ITEM 3 NOT USED ON 220-240V MODELS
1
1
3
(See Note 1)
1
1
2
5

SECTION 5S ENTRANCE BOX ASSEMBLY MODEL 14R & 18 WKS
ENTRANCE BOX SCHEMATIC OF 700131

SECTION 5S ENTRANCE BOX ASSEMBLY MODEL 14R & 18 WKS
ENTRANCE BOX SCHEMATIC OF 700131

L20-310 R1 (02/15)
