Pixio PX5 HAYABUSA Series User manual

The color and the appearance may differ depending on the product, and the specifications are subject to change without prior
notice to improve the performance.
The contents of this manual are subject to change without notice to improve quality.
Copyright © 2020 Pixio USA Inc. I Pixio is a registered trademark of Pixio USA Inc. I All Rights Reserved.
Use or reproduction of this manual in parts or entirety without the authorization of Pixio USA Inc is prohibited.
All other trademarks are owned by their respective owners. Rev.1.01Copyright © 2019 Pixio USA Inc. I Pixio is a registered trademark of Pixio USA Inc.
All Rights Reserved.

PX5H2
CTB191227039EX

RISK OF ELECTRIC SHOCK DO NOT OPEN THE MONITOR.
OPENING MONITOR BACK COVER WILL VOID YOUR WARRANTY.
This symbol indicates that high voltage is present inside.
It is dangerous to make any kind of contact with any internal part of
this product.
This symbol alerts you that important literature concerning operation
and maintenance has been included with this product.

Before Using the Product.
Do not place the monitor near heat sources, such as radiators, and do not expose the monitor to direct sunlight
for an extended period of time.
Make sure to keep the original packaging material. If there are any needs to transport the monitor, the packaging
material will be the best method for successful delivery.
Make sure to use a soft, non-abrasive cloth when cleaning the monitor. Do not use corrosive or strong detergents
to clean the monitor. They may result in permanent damage to the panel and will void the warranty.
Always check to make sure the power cord is unplugged before cleaning the monitor.
Be careful when handling liquids while cleaning as it may cause irreparable damage to the electrical components
in the monitor.
Installation Space
Ensure some space around the product for ventilation. An internal temperature rise may cause fire and damage the product.
Make sure to allow some space. Do not install near heater or any other high temperature product or humidifier.

Make sure the monitor is not placed near any source of water, such as the bathroom, kitchen, or humid areas.
Do not place the monitor on an unstable, or uneven surface. If dropped, the monitor may cause bodily injuries.
When transporting the monitor, make sure it is secured in an upright position or preferably in its original packaging
for best results. When mounting the monitor, make sure to follow the instructions of the respective mounting provider
for best results.
The openings in the monitor are for ventilation. For best results, make sure the ventilation holes are not covered up.
Avoid confined spaces like a bookcase for proper functionality.
If the monitor will not be used for an extended period of time, make sure to unplug the power cord to prevent the risk
of damage from lighting strikes or other abnormal voltage incidents.
Do not overburden any socket to prevent risk of fire or shock.
Do not stick any foreign objects into the monitor to prevent risk of fire or shock.
Please do not try to take off the back panel to repair the monitor yourself. You may run the risk of shock and void the
warranty as well. Contract Pixio directly for all RMA issues.
Take note of elevation and temperature zone warnings on the adapters.
The icon indicates that the adapter is suited for areas under 2000 meters.
The icon indicates that the adapter is suited for non-tropical areas.

Take the following steps when cleaning.
1 Power off the product and computer.
2 Disconnect the power cord from the product.
Hold the power cable by the plug and do not touch the cable with wet hands. Otherwise, an electric shock
may result.
3 Wipe the monitor with a clean, soft and dry cloth.
Do not apply a cleaning agent that contains alcohol, solvent, or surfactant to the monitor.
Do not spray water or detergent directly on the product.
4 Wet a soft and dry cloth in water and wring thoroughly to clean the exterior of the product.
5 Connect the power cord to the product when cleaning is finished.
6 Power on the product and computer.
Cleaning the Product.

Notice.

Product Includes:
Preperation.

Align stand base and the stand
*insert marked pin into the marked hole above picture.
Use included screw to assemble the base.
Product Assembly:

327mm / 12.9inch
555mm / 21.8inch
415mm / 16.3inch
415mm~510mm / 16.3inch~20inch
175.5mm / 6.9inch
Weight : 4.23kg = 9.3lb
Dimension & Weight.

DC
HDMI2 HDMI 1.4, 144Hz, FreeSync
HDMI1 HDMI 2.0, 240Hz, FreeSync, HDR
DP DisplayPort 1.2, 240Hz, FreeSync, HDR
USB Firmware Update
AUDIO OUT
Monitor Inputs.
*WARNING:
Always use the appropriate power cord.

Main OSD Navigation
Menu Short Cut
Button Press
To turn ON, click the Jog Button.
To turn OFF, Press (Enter) the Jog Button for 2 seconds.
Move the OSD Menu
Up Select Input from Auto Source, DP, HDMI1(2.0), HDMI2(1.4)
Adjust Brightness
Choose Preset Colors (FPS / RTS / Standard)
Choose Crooshairs
Down
Left
Right
Up
UP
DOWN
RIGHTLEFT
Down
Left
Right
Press
Move up on the OSD Menu
Move down on the OSD Menu
Move left on the OSD Menu/Decrease value of selected item/Exit OSD Menu
Increase value of selected item
Select menu / Select item
Control Panel.
Jog Button
Multi directional
button that helps
navigate.

45˚45˚
Swivel Tilt

90˚
90mm
Elevate Pivot

DP Resolution: 1920x1080@240Hz
Input Source
Brightness/Contrast
Picture Quality Setting
Display Setting
Audio Setting
OSD Setting
User Setup
Other Setting
HDMI1 [2.0]
Color Setting
HDMI2 [1.4]
DP
Auto Source
V1.0
Switch the signal input to AUTO, DP, HDMI1 or HDMI2.
OSD Menu.

BRIGHTNESS: Adjust the display brightness value from 0 to 100.
CONTRAST: Adjust the display contrast value from 0 th 100.
DCR: Select Dynamic Contrast Ration feature ON or OFF.
Input Source
Color Setting
Brightness/Contrast
Picture Quality Setting
Brightness
Contrast
DCR
80
50
Off
Display Setting
Audio Setting
OSD Setting
User Setup
Other Setting
V1.0
DP Resolution: 1920x1080@240Hz

Input Source
Color Setting
Gamma
Color Temperature
2.2
Brightness/Contrast Picture Mode Standard
Normal
Picture Quality Setting Hue
Saturation
50
50
OFF
Low Blue Light
Display Setting
Audio Setting
OSD Setting
User Setup
Other Setting
V1.0
Gamma: Change the display Gamma Value to: 1.8-2.6
Picture Mode: Change the picture mode to Standard, FPS, or RTS.
Color Temperature: Change the display color temperature value to
Normal, Warm, Cool, DCI-P3 or User.
When User mode is selected, change the Red,
Green, and Blue values from 0 to 100.
Hue: Changes the display Hue value from 0 to 100.
Saturation: Change the display saturation value from 0 to 100.
Low Blue Light: Select the Low Bluelight from LOW BLUE1,
LOW BLUE2, LOW BLUE3 or turn it off.
DP Resolution: 1920x1080@240Hz

Input Source
Color Setting
Sharpness
Black Balance
50
Brightness/Contrast Response Time Off
0
Picture Quality Setting
Display Setting
Audio Setting
OSD Setting
User Setup
Other Setting
V1.0
Sharpness: Change the display Sharpness value from 0 to 100.
Response Time: Select the Response Time feature from Low, Middle,
High, or turn it off.
Black Balance: Change Black balance Level 0 to 20.
DP Resolution: 1920x1080@240Hz

Aspect Ratio: Change the display aspect ration to Wide Screen,
4:3, 1:1, or Auto.
Input Source
Color Setting
Aspect Ratio Wide Screen
Brightness/Contrast
Picture Quality Setting
Display Setting
Audio Setting
OSD Setting
User Setup
Other Setting
V1.0
DP Resolution: 1920x1080@240Hz
