Planet ICA-210 User manual

Internet Camera
ICA-210 / ICA-210W
User’s Manual
Version 1.0

1
Copyright
Copyright (C) 2006 PLANET Technology Corp. All rights reserved.
The products and programs described in this User’s Manual are licensed
products of PLANET Technology, This User’s Manual contains
proprietary information protected by copyright, and this User’s Manual
and all accompanying hardware, software, and documentation are
copyrighted.
No part of this User’s Manual may be copied, photocopied, reproduced,
translated, or reduced to any electronic medium or machine-readable
form by any means by electronic or mechanical. Including photocopying,
recording, or information storage and retrieval systems, for any purpose
other than the purchaser's personal use, and without the prior express
written permission of PLANET Technology.
Disclaimer
PLANET Technology does not warrant that the hardware will work
properly in all environments and applications, and makes no warranty
and representation, either implied or expressed, with respect to the
quality, performance, merchantability, or fitness for a particular purpose.
PLANET has made every effort to ensure that this User’s Manual is
accurate; PLANET disclaims liability for any inaccuracies or omissions
that may have occurred.
Information in this User’s Manual is subject to change without notice and
does not represent a commitment on the part of PLANET. PLANET
assumes no responsibility for any inaccuracies that may be contained in
this User’s Manual. PLANET makes no commitment to update or keep
current the information in this User’s Manual, and reserves the right to
make improvements to this User’s Manual and/or to the products
described in this User’s Manual, at any time without notice.
If you find information in this manual that is incorrect, misleading, or
incomplete, we would appreciate your comments and suggestions.
CE mark Warning
The is a class B device, In a domestic environment, this product may
cause radio interference, in which case the user may be required to take
adequate measures.

WEEE Notice
To avoid the potential effects on the environment and human
health as a result of the presence of hazardous substances
in electrical and electronic equipment, end users of electrical
and electronic equipment should understand the meaning of
the crossed-out wheeled bin symbol. Do not dispose of
WEEE as unsorted municipal waste and have to collect such
WEEE separately.
Trademarks
The PLANET logo is a trademark of PLANET Technology. This
documentation may refer to numerous hardware and software products
by their trade names. In most, if not all cases, their respective companies
claim these designations as trademarks or registered trademarks.
Revision
User’s Manual for PLANET Internet Camera
Model: ICA-210/ICA210W
Rev: 1.0 (Mar. 2006)
Part No.EM-ICA210WV1
2

3
TABLE OF CONTENTS
ABOUT THIS GUIDE...................................................5
INTRODUCTION............................................................6
GENERAL FEATURES AND BENEFITS ...................................................7
UNPACKING THE PACKAGE .................................................................9
SYSTEM REQUIREMENT.....................................................................10
PHYSICAL DESCRIPTION....................................................................11
HARDWARE INSTALLATION ................................16
CONNECTING TO LAN AND POWER...................................................16
I NSTALLING THE C AMERA S TAND ......................................................17
SECURITY......................................................................18
APPLICATIONS ...........................................................19
APPLICATIONS OF THE CAMERA........................................................20
APPLICATION DIAGRAMS OF THE CAMERA .......................................21
USING THE CAMERA ...............................................23
WEB CONFIGURATION.......................................................................23
CONTROLLING AND VIEWING VIDEO.................................................25
BASIC CONFIGURATION.....................................................................30
ADVANCED CONFIGURATION ............................................................31
IPVIEW PRO..................................................................54
INSTALLATION...................................................................................54
GETTING STARTED ............................................................................58
USING IPVIEW PRO...........................................................................61
CONFIGURING THE SYSTEM...............................................................66
APPENDIX .....................................................................79
A. FREQUENTLY ASKED QUESTIONS.................................................79
B. PING YOUR IP ADDRESS..............................................................81
C. TROUBLESHOOTING ......................................................................82
D. TIME ZONE TABLE........................................................................85

4
E. ADJUSTING THE CAMERA FOCUS ..................................................87
F. SPECIFICATION..............................................................................88
G. GLOSSARY OF TERMS ...................................................................90

5
ABOUT THIS GUIDE
This manual provides instructions and illustrations on how to use
your Pan/Tilt Wireless Internet Camera, includes:
zChapter 1, Introduction, provides the general information
on the camera.
zChapter 2, Hardware Installation, describes the hardware
installation procedure for the camera.
zChapter 3, Security, explains the security feature of the
camera.
zChapter 4, Application of the Camera, provides the
illustrations of the camera’s applications.
zChapter 5, Using the Camera, guides you through the
configuration using the web browser.
zChapter 6, IPView Pro, helps you to install and use the
software.
zChapter 7, Appendix.
Please note that the illustrations or setting values in this manual
are FOR YOUR REFERENCE ONLY. The actual settings and
values depend on your system and network. If you are not sure
about the respective information, please ask your network
administrator or MIS staff for help.

6
1
INTRODUCTION
Thank you for purchasing the ICA-210/ICA-210W Wired
/Wireless Internet Camera, a camera device that can be connected
directly to an Ethernet or Fast Ethernet network and also
supported by the wireless transmission based on the IEEE
802.11g standard. Compared to the conventional PC camera, the
Internet Camera features a built-in CPU (central processing unit)
and web-based solutions that can provide a cost-effective solution
to transmit the real-time high-quality video images for monitoring.
In addition, the built-in microphone provides you with the audio
function, allowing you to “watch” and “listen” from the camera.
The Internet Camera can be managed remotely, so that you can
use a web browser to access and control it from any
notebook/desktop PC over the Intranet or Internet. The simple
installation procedures and web-based interface allow you to
integrate it into your network easily. With comprehensive
applications supported, the Internet camera is your best solution
of high quality, and high performance remote video viewing.

7
General Features and Benefits
Simple to Use
The ICA-210/ICA-210W is a standalone system with built-in
CPU requiring no special hardware or software such as PC frame
grabber cards. Allows remote access from web browser for live
image/Audio viewing and listen.
Use Internet Explorer 5.0 or above to view image online. Just
plug and view the picture from your ICA-210/ICA-210W with a
valid IP Address.
Support Variety of Network usage
The ICA-210/ICA-210W supports TCP/IP networking, UPnP,
SMTP e-mail, FTP, DDNS, HTTP and other Internet related
protocols for various applications. It can be utilized in a mixed
operating system environment, including Windows 98SE/ME/
2000/XP and Windows NT 4.0. It can be integrated easily into
other www/Intranet applications.
Web Configuration
Applying a standard web browser, the administrator can configure
and manage the ICA-210/ICA-210W directly from web page via
the Intranet or Internet. Built-in wide angle Pan/Tilt device and
allows remote control from web browser. View multiple video
windows simultaneously on the web page.

8
Remote Utility
The powerful IPView Pro application allows the administrator to
modify the ICA-210/ICA-210W settings from the remote site via
Intranet or Internet. When new firmware is available, you can
also upgrade remotely over the network for added convenience.
Users are also allowed to monitor the image, and take snapshots /
motion detection with alert and e-mail sending / recording
triggered by Motion Detection, Schedule, and Manual.
Broad Range of Applications
With today’s high-speed Internet services, the ICA-210/ICA-
210W can provide the ideal solution for live video images over
the Intranet and Internet for remote monitoring. The ICA-
210/ICA-210W allows remote access from a web browser for live
image viewing and allows administrator to manage and control
the ICA-210/ICA-210W anywhere and any time in the world.
Apply the ICA-210/ICA-210W to monitor various objects and
places such as homes, offices, banks, hospitals, child-care centers,
amusement parks and other varieties of industrial and public
monitoring.
With built-in Pyroelectricity Passive Infrared Sensor for motion
detection, the ICA-210/ICA-210W can be used for intruder
detection; in addition, it can capture still images for archiving.
802.11g / 802.11b compliant
To avoid wire burden ICA-210W supports wireless LAN and
security protection WEP (64/128bit) and WPA-PSK.

9
Unpacking the Package
Unpack the package and check all the items carefully. Be certain
that you have:
One ICA-210 or ICA-210W Internet Camera.
One RJ-45 Ethernet Cable
One Camera Stand
One AC power adapter
One Installation CD-ROM
One Quick Installation Guide
If any item contained is damaged or missing, please contact your
local dealer immediately. Also, keep the packing materials and
box in case you need to ship the units in the future.

10
System Requirement
Networking
LAN: 10Base-T Ethernet or 100Base-TX Fast Ethernet.
WLAN: IEEE 802.11g Wireless LAN with internal chip
antenna.(ICA-210W)
Accessing the Camera
For Web Browser Users
OS: Microsoft® Windows® 98SE/ME/2000/XP
CPU: Intel Pentium III 350MHz or above
Memory Size: 128MB
Resolution: 800x600 or above
Microsoft® Internet Explorer 5.0 or above
For IPView Pro Application Users
OS: Microsoft® Windows® 98SE/ME/2000/XP.
CPU: Intel Pentium III 650MHz or above (Pentium 4 is
preferred)
Memory Size: 256MB
Resolution: 1024x768 or above
NOTE: When you connect multiple cameras and monitor their images
synchronously, it is recommended to use a high performance system, such
as a Pentium 4, 2.4GHz, 512MB RAM computer.

Physical Description
This section provides the illustration of the camera and explains
the function of each component.
Front and Side View
11
7.
6.
1.
2. 8.
9.
10.
3.
11.
4. 12.
5.
1. Internal MIC
The built-in omni-directional microphone allows the camera to
receive sound and voice.

12
2. ACCESS LED
The ACCESS LED indicates the system status by:
-Green light on: The camera is powered on.
-Green light flashing: The camera is receiving/sending data
from/to the LAN.
-Orange light flashing slowly: The camera is in Privacy
mode.
3. PIR Sensor
The PIR Sensor allows you to monitor the target area dynamically.
To use this motion detection function, you have to enable this
sensor from the web configuration page.
4. Camera Lens
5. Compensative Flash LED
This Flash LED allows you to capture video images even in a
dark environment. You can turn on the flash light from the web
configuration page.
6. Internal Antenna for ICA-210W
7. USB Port
The USB port allows you to expand the camera’s function, such
as connecting a large storage device. To connect the USB device,
simply plug the USB device into the USB port. Alternately, you
can connect the USB device through a USB cable.

13
8. STATUS LED
The STATUS LED indicates the configuration status by:
-Green light flashing: The camera is powered on and works
in normal mode.
-Orange-Red light flashing: Indicates the camera cannot
access DHCP within the network.
9. Privacy Mode Button
Press this button to enter the camera’s privacy mode; this makes
the camera stop monitoring temporarily until it releases from the
privacy mode.
10. Network Cable Connector
This RJ-45 connector is used to connect the 10Base-T Ethernet or
100Base-TX Fast Ethernet network (which should be Category 5
twisted-pair cable). The port supports the NWay protocol,
allowing the camera to automatically detect or negotiate the
transmission speed of the network.
11. DC Power Connector
The DC power input connector is located on the camera’s side
panel, and is labeled DC 5V with a single jack socket to supply
power to the camera. Power will be generated when the power
supply is connected to a wall outlet.
12. Camera Stand
The camera stand allows you to place the camera on a flat surface,
instead of hanging on the wall or installing on a tripod.

Rear and Bottom View (without the
Camera Stand)
3.
1.
2.
1. Screw Hole
The screw hole can be used to attach the camera stand or a tripod.
2. Reset Button
Press the button to reboot the camera; press and hold the button
for 5 second will reload the factory default settings for the camera.
The button works as the function in Web Configuration Utility
> Setting menu > Maintenance > Reboot or Factory reset.
14
When you perform a factory reset and try to re-login into the
camera, the default password is re-loaded as “admin.” Use the
factory default setting for password to login, and then the system
will ask you to change the password.

15
3. Hanging Hole
The two holes on the rear panel of the camera allow you to place
the camera on the wall.

16
2
HARDWARE
INSTALLATION
Connecting to LAN and Power
To connect the camera to your network, connect an Ethernet cable
to the LAN connector located on the camera’s side panel, and
then attach it to the network device.
To provide power to the camera, connect the AC power adapter to
the DC power input connector located on the camera’s side panel,
and then plug it to the electrical outlet.
Connect to LAN
Connect to power

Installing the Camera Stand
If you want to place the camera on the flat surface, instead of
hanging on the wall, you have to install the camera stand onto the
bottom part of the camera.
The following describe the installation procedure of the camera
stand:
1. Align the camera stand with the bottom part of the camera.
Then, secure the camera stand with the screw.
2. Place the camera on a flat surface, and connect the Ethernet
cable and AC power adapter as described in the previous
section.
17

18
3
SECURITY
To ensure the highest security and prevent unauthorized usage of
the camera, the administrator has the exclusive privilege to access
the System Administration for settings and control requirements
to allow users the level of entry and authorize the privileges for
all users. The camera supports multi-level password protection.
Accessing to the camera is strictly restricted to defined users with
a "User Name" and "User Password", which are assigned by the
administrator.
The administrator can release a public user name and password.
Therefore, when remote users access the camera, they will have
the right to view the image transmitted by the camera.
NOTE: Since the default settings are Null String, it is highly recommended to
set the "Admin Password" when you are the first time to use the camera.
Once the password is defined, only the administrator is permitted to manage
the camera. The security feature of the camera will not be enabled until the
"Admin Password" is defined; therefore, you have to complete this procedure
as soon as possible.

19
4
APPLICATIONS
The ICA-210/ICA-210W can be applied in wide variety of
applications. With the built-in CPU, it can work as a standalone
system that provides a web-based solution transmitting high
quality video images and sounds for monitoring purposes. It can
be managed remotely, accessed and controlled from any PC
desktop over the Intranet or Internet via a web browser. With the
easy installation procedure, real-time live images will be available.
In addition, once the ICA-210/ICA-210W is installed coupled
with the IPView Pro application, you can further expand the
scope of the ICA-210/ICA-210W.
The following section provides the example applications for your
camera with the IPView Pro application, and also includes some
basic knowledge to assist in the installation and configuration of
the camera.
