Planet GT-702 User manual

Trademarks
Copyright  PLANET Technology Corp. 2005
Contents subject to revision without prior notice.
PLANET is a registered trademark of PLANET Technol-
ogy Corp. The information in this manual is subject to
change without notice. All other trademarks belong to
their respective owners.
Disclaimer
PLANET Technology does not warrant that the hardware
will work properly in all environments and applications,
and makes no warranty and representation, either
implied or expressed, with respect to the quality, per-
formance, merchantability, or tness for a particular
purpose.
PLANET has made every effort to ensure that this User’s
Manual is accurate; PLANET disclaims liability for any
inaccuracies or omissions that may have occurred.
Information in this User’s Manual is subject to change
without notice and does not represent a commitment on
the part of PLANET. PLANET assumes no responsibility
for any inaccuracies that may be contained in this User’s
Manual. PLANET makes no commitment to update or
keep current the information in this User’s Manual, and
reserves the right to make improvements to this User’s
Manual and/or to the products described in this User’s
Manual, at any time without notice.
If you nd information in this manual that is incorrect,
misleading, or incomplete, we would appreciate your
comments and suggestions.
FCC Warning
This equipment has been tested and found to comply
with the regulations for a Class A digital device, pur-
suant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference when the equipment is operated in
a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not
2010-000006-004.indd 2005/1/14, �� 06:131

installed and used in accordance with this user’s guide,
may cause harmful interference to radio communica-
tions. Operation of this equipment in a residential area
is likely to cause harmful interference, in which case the
user will be required to correct the interference at his
own expense.
CE Mark Warning
This is a Class A product. In a domestic environment,
this product may cause radio interference, in which case
the user may be required to take adequate measures.
Revision
User's manual for PLANET Gigabit Ethernet Converter
For Models: GT-702, GT-702S, GT-705A, GT-706A15,
GT-706B15
Rev 4.0 (January. 2005)
Part No: 2010-000006-004
2010-000006-004.indd 2005/1/14, �� 06:132

Table of Contents
Chapter 1 Overview 1
Chapter 2 Product Features 2
Chapter 3 Model List 3
Chapter 4 Checklist 4
Chapter 5 Product Outlook 5
Chapter 6 Installing The Converter 6
Chapter 7 Duplex Mode Support 7
Chapter 8 Led Indication 8
Chapter 9 Cable Connection Parameter 9
Chapter 10 Product Specification 10
Chapter 11 Power Information 12
2010-000006-004.indd 2005/1/14, �� 06:133

This page is intentionally left blank
2010-000006-004.indd 2005/1/14, �� 06:134

1
Chapter 1
OVERVIEW
Thank you for purchasing PLANET GT-70X family Gigabit Ethernet
Media Converter products. This Gigabit Ethernet Media Converter
is used to convert one type media signal to other type equivalent
that allows two type segments connect easily, efciently and
inexpensively. The Giagbit Ethernet Media Converter introduced
here provides one channel media conversion between the
1000Base-T and 1000Base-SX/LX, 1000Base-SX/LX through SFP
Mini-GBIC(GT-705A only) or the 1000Base-LX WDM(GT-706A15/
B15 only).
This Gigabit Ethernet Media converter can be used as a standalone
unit or as a slide-in module to the 10”/19” media chassis (up
to 15 units) for a multi-mode and single-mode Fiber combined
networks at a central wiring closet. Please contact with your sales
representative for more about the 10”/19” media chassis.
About the Gigabit Ethernet Media Converter
This Gigabit Ethernet Media Converter utilizes a netrwork
technology specied by IEEE 802.3ab 1000Base-T and IEEE802.3z
1000Base-SX/LX standards. The Gigabit Ethernet Media Converter
is used to converter one type media signal to other type equivalent
that allows two type segments connect easily, effciently and
inexpensively.
2010-000006-004.indd 2005/1/14, �� 06:131

2
Chapter 2
PRODUCT FEATURES
• Comply with IEEE802.3ab 1000Base-T, IEEE802.3z
1000Base-SX/LX Ethernet standard
• Full-duplex supports for TP and fiber port
• Auto-negotiation on 1000Base-T port
• Auto-MDI/MDIX on TP port
• LED indicators for simple diagnostics and management
• Provides DIP switch to disable/ enable auto-negotiation
by-pass function
• 1000Base-SX interface for up to 550 meters (multi-
mode 50/125µm fiber) and 220 meters (multi-mode
62.5 /125µm fiber) on GT-702 and GT-705A
• 1000Base-LX interface for up to 10km (single mode
9/125µm fiber) on GT-702S and GT-705A
• 1000Base-LX WDM interface for up to 15km (single
mode 9/125µm fiber) on GT-706A15/B15
• One SFP (Mini-GBIC) slot supporting either multi-mode
or single mode fiber, flexibility in Gigabit Ethernet fiber-
optic wiring with different Mini-GBIC module installed
(GT-705A only)
• Compact in size, easy installation
• Can be installed on PLANET’s 10 /19 Media Converter
Chassis
2010-000006-004.indd 2005/1/14, �� 06:132

3
Chapter 3
MODEL LIST
Your Gigabit Ethernet Converter comes with one of the following
models.
ð GT-702: 1000Base-T to 1000Base-SX (SC)
ð GT-702S:1000Base-T to 1000Base-LX (SC)
ð GT-705A: 1000Base-T to 1000BaseSX/LX (LC)
ð GT-706A15: 1000Base-T to 1000Base-LX(WDM)
ð GT-706B15: 1000Base-T to 1000Base-LX(WDM)
In the following sections, the term “GT-70X” indicates the product
family above, the term “MM” and “SM” represent Multi-Mode and
Single Mode ber-optic mode.
 NOTE:
Please note GT-706A15/706B15 is designed
to work together. It means you must con-
nect GT-706A15 to GT-706B15 from them to
work normally. If both ends are GT-706A15
or GT-706B15, they can’t work normally and
may damage the fiber connectors.
2010-000006-004.indd 2005/1/14, �� 06:133

4
Chapter 4
CHECKLIST
Your GT-70X carton should contain the following items:
ð The Gigabit Ethernet Converter.
ð AC-DC Power Adapter (Output: 5VDC, 2A max.).
ð This user’s manual.
If any item is missing or damaged, please consult the dealer from
whom you purchased your Gigabit Ethernet Converter.
 Notice:
GT-705A is with one vacant SFP module slot.
The mini GBIC SFP module is not bundled
with in the package
2010-000006-004.indd 2005/1/14, �� 06:134

5
Chapter 5
PRODUCT OUTLOOK
Right View (GT-70X)
Left: Fiber-optic connector, Right: TP connector.
Three LED indicators per TP, ber port.
Rear View (GT-70X)
One DC jack for DC power input and DIP switch to disable/enable
Auto by pass function.
 Notice:
Please to note that if converter is connect
with switch which is Auto negotiation, must
enable the Auto by pass function.
If both devices are conveters must disable
the Auto by pass function.
2010-000006-004.indd 2005/1/14, �� 06:135

6
Chapter 6
INSTALLING THE CONVERTER
Please follow these steps to install the converter:
• Turn off the power of the device/station in a network to
which the GT-70X will be attached.
• Ensure that there is no activity in the network.
• Attach fiber cable from the GT-70X to the fiber network.
TX, RX must be paired at both ends.
• Connect the 5VDC power adapter to the GT-70X and
verify that the Power LED lights up.
• Turn on the power of the device/station; the PWR LEDs
should light when all cables are attached.
 Notice:
Please refers to section 9 for detailed wiring
information of the GT-70X.
To prevent from optic acceptor malfunction, check the both wires
/ transmitter before power on the converter.
2010-000006-004.indd 2005/1/14, �� 06:136

7
Chapter 7
DUPLEX MODE SUPPORT
The GT-70X is one-channel media conversion between 1000Base-
T and 1000Base-SX/LX/LX WDM. 1000Base-T port can work
under Auto-negotiation and xed 1000Mbps full duplex mode.
1000Base-SX/LX/LX WDM ber port only allow to work under
xed 1000Mbps full duplex mode.
 Notice:
It doesn’t support Auto-negotiation and can
not work with 1000Base-SX/LX interface
that can not configure to fixed 1000Mbps
full duplex.
2010-000006-004.indd 2005/1/14, �� 06:137

8
Chapter 8
LED INDICATION
LED Color Description
Fiber /
ACT
Green Lit: when the fiber port run in fix
1000Mbps and packet is travel-
ing.
TP/ ACT Green Lit: when the packet is traveling.
Fiber/
LNK
Green Lit: when fiber connection is good.
TP/LNK Green Lit: when TP connection is good.
FDX Green Lit: when the TP port runs in
1000Mbps Full duplex
PWR Green Lit: when +5VDC power detected
Table 8-1: LED indication of GT-70x
2010-000006-004.indd 2005/1/14, �� 06:138

9
Chapter 9
CABLE CONNECTION PARAMETER
The wiring details are as below:
Cables:
Standard Fiber Type Cable Specification
1000Base-SX
(850nm)
Multi-mode 50/125μm or 62.5/125μm
1000Base-LX
(1300nm)
Multi-mode 50/125μm or 62.5/125μm
Single-mode 9/125μm
Wiring Distances:
Standard Fiber Diameter
(micron)
Modal
Bandwidth
(MHz * km)
Max.
Distance
(meters)
1000Base-SX MM 62.5
62.5
50
50
100
200
400
500
220
275
500
550
1000Base-LX MM 62.5
50
50
5
4
5
550
SM 9 N/A 5000*
 Notice:
The Single-mode port (1000Base-LX port)
of GT-702S, GT-705A and GT-706A15/B15
is complied with LX 5 kilometers and pro-
vides additional margin allowing for a 10/15
kilometers Gigabit Ethernet link on single
mode fiber.
2010-000006-004.indd 2005/1/14, �� 06:139

10
Chapter 10
PRODUCT SPECIFICATION
The GT-70X comes with the following standard features:
Standards IEEE802.3ab 1000Base-T
IEEE802.3z 1000Base-SX/LX
Duplex Mode Full Duplex Mode
Transfer rate 1000Mbps
Media Interface RJ-45, SC, single SC(WDM)
LED indicators PWR, FDX, Fiber/LNK/ACT, TP/LNK/ACT
Cable 1000Base-T:
4 pair Cat. 5, EIA/TIA-568 100-ohm
screened twisted-pair (STP), up to
100m
1000Base-SX :
62.5/125μm multi-mode fiber optic
cable, up to 220m
50/125μm multi-mode fiber optic cable,
up to 550m
1000Base-LX :
9/125μm single-mode fiber optic cable,
up to 10km/15km
Dimensions 26 x 70 x 97mm (H x W x D)
Power External power adaptor 5V 2A max.
EMI
Compatibility
FCC Class A, CE Certification Class A
Temperature Storage: -40°C ~ 70°C
Operating: 0°C ~ 50°C
Humidity 5% ~90% non-condensing
2010-000006-004.indd 2005/1/14, �� 06:1310

11
 Notice:
Connecting to the Gigabit Ethernet prod-
ucts, please refer to the device s Technical
Manual.
2010-000006-004.indd 2005/1/14, �� 06:1311

12
Chapter 11
POWER INFORMATION
The power jack of GT-70X is with 2.5mm in the central post and
required +5VDC power input. It will conform to the bundled AC-
DC adapter and Planet’s Media Chassis. Should you have the
problem to make the power connection, please contact your local
sales representative.
Please keep the AC-DC adapter as spare parts when your GT-70X
is installed to a Media Chassis.
2010-000006-004.indd 2005/1/14, �� 06:1312

2010-000006-004.indd 2005/1/14, �� 06:1313

Part No.:2010-000006-004
2010-000006-004.indd 2005/1/14, �� 06:1314
