Planet GEPON EPL-SPT-8 User manual

GEPON Splitter
EPL-SPT-8 / EPL-SPT-32 / EPL-SPT-64
Quick Installation Guide
Introduction
PLANET EPL-SPT-8 / EPL-SPT-32 / EPL-SPT-64 is a single-mode PLC splitter which can
divide a single optical input into multiple optical outputs uniformly. The splitter provides
high quality performance, such as Low Insertion Loss, Low PDL, High Return Loss, Wide
Wavelength Range from 1260nm to 1650nm and Wide Temperature Range from -40 to 85
degrees C.
PLANET EPL-SPT-8 / EPL-SPT-32 / EPL-SPT-64 is fully compliant with PLANET GEPON
technology, with high split ratio at 1:8 / 1:32 / 1:64 and supports the usage of PLANET
OLT (EPL-2000) and ONUs (EPN-102) / (EPN-103). Users can minimize the investment
cost and deploy the network easily. It provides the cost-effective solution, scalability and
exibility for optical network distribution.
Product Features
1 : 8 High Split Ratio (EPL-SPT-8)
1 : 32 High Split Ratio (EPL-SPT-32)
1 : 64 High Split Ratio (EPL-SPT-64)
Low Insertion Loss
Low PDL (Polarization Dependent Loss)
High Reliability and Stability
Wide Operating Wavelength 1260nm to 1650nm
Wide Operating Temperature -40 to 85 degrees C
Cassette size
Applications
Passive Optical Network
 FTTx Network
Optical LAN, WAN and Metro networks
CATV Network
IP Surveillance

Specications
Product GEPON Splitter
EPL-SPT-8 EPL-SPT-32 EPL-SPT-64
Optical Performance
Split Ratio 1 x 8 1 x 32 1 x 64
Operation Wavelength 1260 ~ 1650nm
Insertion Loss (max.) 10.2dB 16.5dB 20.5dB
Polarization Dependent Loss 0.25dB 0.3dB
Uniformity 0.8dB 1.5dB 2.5dB
Return Loss 55dB
Directivity 55dB
Environment Specications
Dimensions (W x D x H) 100 x 80 x 10 mm 120 x 80 x 18 mm 140 x 115 x 18 mm
Weight 112g 274g 515g
Temperature Operating temperature: -40 ~ 85 degrees C
Storage temperature: -40 ~ 85 degrees C
Pigtail Length ≥1.0m
Connector Type SC / APC Connector
RoHS RoHS Compliant
Connection
PON Port
1 x Input
64 x Output
Up to 64 ONU
ONU ONU
1:64 GEPON
Splitter EPL-SPT-64
GEPON OLT
EPL-2000
Applications IPTV
VoIP
Internet
GEPON OLT
1000Base-T UTP
100Base-TX UTP
PON
Passive Optical Network
Community
Highrise Buildings
PC
Camera
IPTV
IP Phone
EPN-102
EPN-102
PC
IPTV
PC
IPTV
IP Phone
IPTV
PON
PON
PON PON
PON
PON
FTTB FTTH
EPL-SPT-32
EPL-SPT-64
EPN-102
EPN-102
EPN-102
PON
1:64 Splitter
1:32 Splitter
