Planet GT-80X Series User manual

10/100/1000Base-T to 1000Base-SX/LX
Gigabit Ethernet Media Converter
User’s Manual

Trademarks
Copyright © PLANET Technology Corp. 2007
Contents subject to revision without prior notice.
PLANET is a registered trademark of PLANET Technology
Corp. The information in this manual is subject to change
without notice. All other trademarks belong to their
respective owners.
Disclaimer
PLANET Technology does not warrant that the hardware
will work properly in all environments and applications,
and makes no warranty and representation, either implied
or expressed, with respect to the quality, performance,
merchantability, or tness for a particular purpose.
PLANET has made every effort to ensure that this User’s
Manual is accurate; PLANET disclaims liability for any
inaccuracies or omissions that may have occurred.
Information in this User’s Manual is subject to change
without notice and does not represent a commitment on the
part of PLANET. PLANET assumes no responsibility for any
inaccuracies that may be contained in this User’s Manual.
PLANET makes no commitment to update or keep current
the information in this User’s Manual, and reserves the
right to make improvements to this User’s Manual and/or
to the products described in this User’s Manual, at any time
without notice.

If you nd information in this manual that is incorrect,
misleading, or incomplete, we would appreciate your
comments and suggestions.
FCC Warning
This equipment has been tested and found to comply with
the regulations for a Class A digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with
this user’s guide, may cause harmful interference to radio
communications. Operation of this equipment in a residential
area is likely to cause harmful interference, in which case
the user will be required to correct the interference at his
own expense.
CE Mark Warning
This is a Class A product. In a domestic environment, this
product may cause radio interference, in which case the
user may be required to take adequate measures.

WEEE Warning
To avoid the potential effects on the
environment and human health as a result
of the presence of hazardous substances
in electrical and electronic equipment, end
users of electrical and electronic equipment
should understand the meaning of the
crossed-out wheeled bin symbol. Do not dispose of WEEE
as unsorted municipal waste and have to collect such WEEE
separately.
Revision
User’s manual for PLANET Gigabit Ethernet Converter
For Models: GT-802, GT-802S, GT-805A, GT-806A15, GT-
806B15, GT-806A60, GT-806B60
Rev 1.0 (August. 2007)
Part No: 2010-AA4230-000

Table of Contents
Chapter 1 OVERVIEW......................................................6
About the Gigabit Ethernet Media Converter ................6
Chapter 2 PRODUCT FEATURES........................................7
Chapter 3 MODEL LIST ...................................................9
Chapter 4 CHECKLIST ...................................................10
Chapter 5 PRODUCT OUTLOOK ...................................... 11
Chapter 6 INSTALLING THE CONVERTER......................... 13
6.1 Stand-alone Installation .....................................13
6.2 Chassis Installation and Rack Mounting ...............16
Chapter 7 DUPLEX MODE SUPPORT................................ 18
Chapter 8 LED INDICATION ........................................... 19
Chapter 9 CABLE CONNECTION PARAMETER ...................20
Chapter 10 PRODUCT SPECIFICATION ............................22
Chapter 11 POWER INFORMATION .................................24

6
Chapter 1 OVERVIEW
Thank you for purchasing PLANET GT-80X family Gigabit
Ethernet Media Converter products. This Gigabit Ethernet
Media Converter is used to convert one type media signal to
other type equivalent that allows two type segments connect
easily, efciently and inexpensively. The Gigabit Ethernet
Media Converter introduced here provides one channel
media conversion between the 10/100/1000Base-T and
1000Base-SX/LX,1000Base-SX/LX through SFP Mini-GBIC
(GT-805A only) or the 1000Base-LX WDM (GT-806A15/B15
and GT-806A60/B60 only).
This Gigabit Ethernet Media Converter can be used as a
standalone unit or as a slide-in module to the 10”/19”
media chassis (up to 15 units) for a multi-mode and single-
mode Fiber combined networks at a central wiring closet.
Please contact with your sales representative for more about
the 10”/19” media chassis.
About the Gigabit Ethernet Media Converter
This Gigabit Ethernet Media Converter utilizes a netrwork
technology specied by IEEE 802.3 10Base-T, IEEE 802.3u
100Base-TX, IEEE 802.3ab 1000Base-T and IEEE 802.3z
1000Base-SX/LX standards. The Gigabit Ethernet Media
Converter is used to converter one type media signal
to other type equivalent that allows two type segments
connect easily, effciently and inexpensively.

7
Chapter 2 PRODUCT FEATURES
● Comply with IEEE 802.3 10Base-T, IEEE 802.3u 100Base-
TX, IEEE 802.3ab 1000Base-T, IEEE 802.3z 1000Base-SX/
LX Ethernet standard
● Bridge mode media converter with TP port supports
10/100/1000Base-T auto-negotiation and auto-MDIX
● Auto-Negotiation for 10/100/1000Base-T; Half-Duplex or
Full-duplex for 100Mbps and 10Mbps
● LED indicators for simple diagnostics and management
● Fiber Interface
● Compact in size, easy installation
● Can be installed on PLANET’s 10”/19” Media Converter
Chassis (MC-700/1000R/1500)
GT-802
1000Base-SX interface for up to 550 meters (multi-mode
50/125µm ber) and 220 meters (multi-mode 62.5 /125µm
ber)
GT-802S
1000Base-LX interface for up to 10km (single mode
9/125µm ber) and up to 550m (multi-mode ber cable)
GT-805A
One SFP (Mini-GBIC) slot supporting either multi-mode or
single mode ber, exibility in Gigabit Ethernet ber-optic
wiring with different Mini-GBIC module installed

8
GT-806A15 / GT-806B15
1000Base-LX WDM interface for up to 15km (single mode
9/125µm ber)
GT-806A60 / GT-806B60
1000Base-LX WDM interface for up to 60km (single mode
9/125µm ber)

9
Chapter 3 MODEL LIST
Your Gigabit Ethernet Converter comes with one of the
following models.
• GT-802: 10/100/1000Base-T to 1000Base-SX(SC)
• GT-802S: 10/100/1000Base-T to 1000Base-LX(SC)
• GT-805A: 10/100/1000Base-T to 1000Base-SX/LX(LC)
• GT-806A15: 10/100/1000Base-T to 1000Base-LX(WDM)
• GT-806B15: 10/100/1000Base-T to 1000Base-LX(WDM)
• GT-806A60: 10/100/1000Base-T to 1000Base-LX(WDM)
• GT-806B60: 10/100/1000Base-T to 1000Base-LX(WDM)
In the following sections, the term “GT-80X” indicates the
product family above, the term “MM” and “SM” represent
Multi-Mode and Single Mode ber-optic mode.
Notice:
Please note GT-806A15/806B15 and GT-
806A60/806B60 is designed to work
together. It means you must connect GT-
806A15 to GT-806B15 or GT-806A60 to
GT-806B60 from them to work normally.
If both ends are GT-806A15 or GT-806A60
and GT806B15 or GT-806B60, they can’t
work normally and may damage the fiber
connectors.

10
Chapter 4 CHECKLIST
Your GT-80X carton should contain the following items:
• The Gigabit Ethernet Converter
• AC-DC Power Adapter (Output: 5VDC, 2A max.)
• This user’s manual
If any item is missing or damaged, please consult the dealer
from whom you purchased your Gigabit Ethernet Converter.
Notice:
GT-805A is with one vacant SFP module
slot. The mini GBIC SFP module is not
bundled with in the package.

11
Chapter 5 PRODUCT OUTLOOK
Right View (GT-80X)
GT-802/GT-802S
GT-805A
GT-806A15/B15/A60/B60
Left: Fiber-optic connector, Right: TP connector.
Two LED indicators per TP, ber port.

12
Rear View (GT-80X)
One DC jack for DC power input.

13
Chapter 6 INSTALLING THE CONVERTER
6.1 Stand-alone Installation
To install a GT-80X stand-alone, on a desktop or shelf,
simply complete the following steps:
Step 1: Turn off the power of the device/station in a
network to which the GT-80X will be attached.
Step 2: Ensure that there is no activity in the network.
Step 3: Attach ber cable from the GT-80X to the ber
network. TX, RX must be paired at both ends.
Step 4: Connect the 5VDC power adapter to the GT-80X
and verify that the Power LED lights up.
Step 5: Turn on the power of the device/station; the PWR
LEDs should light when all cables are attached.

14
Figure 6-1 GT-80X installation
Notice:
Please refer to Section 9 for detailed wiring
information of the GT-80X.
To prevent from optic acceptor malfunction,
check the both wires / transmitter before
power on the converter.

15
GT-805A Installation
Step 1: Connect the ber cable. Attach the duplex LC
connector on the network cable into the SFP
transceiver.
Step 2: Attach ber cable from the GT-805A to the ber
network. TX, RX must be paired at both ends.
Step 3: Connect the 5VDC power adapter to the GT-805A
and verify that the Power LED lights up.
Step 7: Turn on the power of the device/station; the PWR
LEDs should light when all cables are attached.
Figure 6-2 GT-805A installation
Notice:
It recommends using PLANET MGB-SX /
MGB-LX series 1000Base-SX/LX SFP on the
converter. If you insert a SFP transceiver
that is not supported, the converter will
not recognize it.

16
6.2 Chassis Installation and Rack Mounting
To install the media converter in a 10-inch or 19-inch with
standard rack, follow the instructions described below.
Step 1: Place your GT-80X on a hard at surface, with the
front panel positioned towards your front side.
Step 2: Carefully slide in the module until it is fully and
rmly tted into the slot of the chassis.
Figure 6-3: Insert a media converter into an available slot
Step 3: Attach a rack-mount bracket to each side of the
Chassis with supplied screws attached to the
package.
Step 4: After the brackets are attached to the chassis, use
suitable screws to securely attach the brackets to
the rack, as shown in Figure 6-3.
Step 5: Proceed with the steps 4 and steps 5 of session
6.1 Stand-alone Installation to connect the
network cabling and supply power to your switch.

17
Caution:
You must use the screws supplied with
the mounting brackets. Damage caused to
the parts by using incorrect screws would
invalidate your warranty.

18
Chapter 7 DUPLEX MODE SUPPORT
The GT-80X is one-channel media conversion between
10/100/1000Base-T and 1000Base-SX/LX. 10/100/1000Base-
T port can work under Auto-negotiation mode. 1000Base-
SX/LX ber port only allow to work under xed 1000Mbps
full duplex mode.

19
Chapter 8 LED INDICATION
LED Color Description
PWR Green Lit: When +5VDC power
detected.
Fiber
LNK/ACT Green
Lit: To indicate the link through
that ber port is successfully
established.
Blink: Indicate that the Fiber
port is actively sending or
receiving data over that port.
TP
LNK/ACT Green
Lit: To indicate the link through
that port is successfully
established.
Blink: Indicate that the port is
actively sending or receiving
data over that port.
TP
1000 Green
Lit: When the port runs in
1000Mbps Full duplex.
Blink: When the port runs in
100Mbps Full duplex.
Off: When the port runs in
10Mbps Full duplex.
Table 8-1: LED indication of GT-80x

20
Chapter 9
CABLE CONNECTION PARAMETER
The wiring details are as below:
Cables:
Standard Fiber Type Cable Specication
1000Base-SX
(850nm) Multi-mode 50/125μm or 62.5/125μm
1000Base-LX
(1300nm)
Multi-mode 50/125μm or 62.5/125μm
Single-mode 9/125μm
Wiring Distances:
Standard Fiber Diameter
(micron)
Modal
Bandwidth
(MHz * km)
Max.
Distance
(meters)
1000Base-SX MM
62.5
62.5
50
50
100
200
400
500
220
275
500
550
1000Base-LX
MM
62.5
50
50
5
4
5
550
SM 9 N/A 5000*
