Planet NVR-810 User manual

8/16-Channel
Network Video Recorder
NVR-810 / NVR-1610
User’s Manual
Version 1.1

Copyright
Copyright ©2010 by PLANET Technology Corp. All rights reserved. No part of this publication may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer
language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or
otherwise, without the prior written permission of PLANET.
PLANET makes no representations or warranties, either expressed or implied, with respect to the contents
hereof and specifically disclaims any warranties, merchantability or fitness for any particular purpose. Any
software described in this manual is sold or licensed "as is". Should the programs prove defective following
their purchase, the buyer (and not PLANET, its distributor, or its dealer) assumes the entire cost of all
necessary servicing, repair, and any incidental or consequential damages resulting from any defect in the
software. Further, PLANET reserves the right to revise this publication and to make changes from time to time
in the contents hereof without obligation to notify any person of such revision or changes.
All brand and product names mentioned in this manual are trademarks and/or registered
trademarks of their respective holders.
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
4. Consult the dealer or an experienced radio technician for help.
FCC Caution
To assure continued compliance. (example-use only shielded interface cables when connecting to computer or
peripheral devices). Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the Following two conditions: ( 1 )
This device may not cause harmful interference, and ( 2 ) this Device must accept any interference received,
including interference that may cause undesired operation.
Federal Communication Commission (FCC) Radiation Exposure Statement
This equipment complies with FCC radiation exposure set forth for an uncontrolled environment. In order to
avoid the possibility of exceeding the FCC radio frequency exposure limits, human proximity to the antenna
shall not be less than 20 cm (8 inches) during normal operation.
Safety
This equipment is designed with the utmost care for the safety of those who install and use it. However,
special attention must be paid to the dangers of electric shock and static electricity when working with
electrical equipment. All guidelines of this and of the computer manufacture must therefore be allowed at all
times to ensure the safe use of the equipment
.
CE Mark Warning
This is a Class B product. In a domestic environment, this product may cause radio interference, in which
case the user may be required to take adequate measures.

WEEE Regulation
To avoid the potential effects on the environment and human health as a result of the presence of
hazardous substances in electrical and electronic equipment, end users of electrical and electronic
equipment should understand the meaning of the crossed-out wheeled bin symbol. Do not dispose
of WEEE as unsorted municipal waste and have to collect such WEEE separately.
Energy Saving Note of the Device
This power required device does not support Stand by mode operation.
For energy saving, please remove the DC-plug or push the hardware Power Switch to OFF position to
disconnect the device from the power circuit.
Without remove the DC-plug or switch off the device, the device will still consuming power from the power circuit.
In the view of Saving the Energy and reduce the unnecessary power consuming, it is strongly suggested to
switch off or remove the DC-plug for the device if this device is not intended to be active.
Revision
User’s Manual for PLANET 8/16-ch Network Video Recorder
Model: NVR-810 / NVR-1610
Rev: 1.1 (March, 2010)
Part No. EM-NVRx10v1.1

Table of Contents
1. Product Description ................................................................................................................. 5
1.1 Product Features............................................................................................................. 5
1.2 System Requirements..................................................................................................... 6
1.3 Packet Content ............................................................................................................... 6
1.4 Specification .................................................................................................................. 7
1.5 Front Panel..................................................................................................................... 8
1.6 LEDs Definition............................................................................................................. 8
1.7 I/O Ports......................................................................................................................... 9
2. Install Hard Disk.................................................................................................................... 11
3. Connect to the NVR............................................................................................................... 13
3.1 Use Device Search Utility............................................................................................ 13
3.2 Access NVR with its default IP address....................................................................... 17
4. Live View............................................................................................................................... 18
4.1 Retrieve camera’s video stream ................................................................................... 19
4.2 Retrieve camera’s status............................................................................................... 19
4.3 Perform Sequence Viewing.......................................................................................... 19
4.4 PTZ Control ................................................................................................................. 20
4.5 Perform PTZ Preset Viewing ....................................................................................... 21
4.6 Live Video Control Buttons ......................................................................................... 23
4.7 Change Web UI Display Language.............................................................................. 26
5. Playback................................................................................................................................. 27
5.1 Methods to Search Playback Videos............................................................................ 28
5.2 Export Playback Videos to AVI Files........................................................................... 33
6. System Setup.......................................................................................................................... 35
6.1 System Configurations................................................................................................. 35
6.1.1 Network Settings............................................................................................... 35
6.1.2 Time and Date................................................................................................... 37
6.1.3 User Account .................................................................................................... 38
6.1.4 Group Privilege................................................................................................. 39
6.1.5 Disk Setup......................................................................................................... 40
6.2 Channel Configurations ............................................................................................... 41
6.2.1 Add a Camera ................................................................................................... 41
6.2.2 OSD Settings..................................................................................................... 44
6.2.3 PTZ Preset Settings........................................................................................... 45
6.2.4 PTZ Preset Sequence ........................................................................................ 46
6.2.5 E-Map Monitor ................................................................................................. 47
6.3 Event Configurations ................................................................................................... 49
6.3.1 General Settings................................................................................................ 49
6.3.2 I/O Settings ....................................................................................................... 50
6.3.3 Event Servers .................................................................................................... 51
6.3.4 Event Triggers................................................................................................... 54
6.4 Recording Configurations............................................................................................ 55
6.4.1 General Settings................................................................................................ 55
6.4.2 Schedule Recording .......................................................................................... 56
6.5 System Options ............................................................................................................ 57
6.5.1 Device Information ........................................................................................... 57
6.5.2 Logs and Reports .............................................................................................. 58
6.5.3 Maintenance...................................................................................................... 58
6.5.4 DO Status.......................................................................................................... 61
6.5.5 Disk Status ........................................................................................................ 61
6.5.6 UPS Configuration ........................................................................................... 62

5
1. Product Description
The Network Video Recorder is designed for use within a surveillance system,
and performs recordings and playbacks pictures from network cameras in the
system. It is a recording device using a hard disk drive to record camera pictures
instead of using video tapes so that pictures recorded by repeated overwriting
will not experience deterioration of the recorded picture quality. Up to 8 (for NVR-
810) or 16 (for NVR-1610) cameras can be connected via a net- work and it is
possible to record their camera pictures. It is possible to perform the settings or
operate the NVR using a web browser installed on a PC connected to a network,
or remote controller. Recorded video can be played back from remote site by a PC.
Up to 4 PCs (web browsers) can access this unit concurrently and it is possible to
perform the settings and operate this unit. The NVR is compatible with most major
brand cameras and its ability to automatically search and find the available
cameras on the network can greatly reduce the user effort when expanding the
system.
1.1 Product Features
Simultaneous Record and Live Video Streams
Manual or Schedule Recording of 8/16 IP Cameras simultaneously.
Supports M-JPEG / MPEG-4 / H.264 compression
Web-Based and manage utility for Easy Configuration
Video resolution up to HD (1920 * 1080)
Support up to 16 NVR, max. 256 channel with the manage software
Auto power on auto recover and recording
Supports Real Time Clock (RTC)
Gigabit Ethernet port
Two-way Audio function
Video recycle function makes the video keep recording in 7/24
E-map interface in web and utility configuration
Auto discover by management software
Supports external UPS
Smart IP camera search
Export record video file to AVI format
Compliant with major brands. Axis, Panasonic, Sony, Planet, Canon and more
Support mobile phone remote view with WinCE 6.1, Android, Symbian S60,
iPhone, Blackberry 4.6
LED indicators to display the status of connected IP camera
 DI/DO/RS-232/RS-485 interfaces supported

Multiple Languages support

6
1.2 System Requirements
The following are minimum system requirements for the system to op- erate
Network Video Recorder (NVR):
Operating System
Microsoft® Windows® 2000 Professional, Windows® XP Professional
(32 bit) or Windows® Server 2003 (32 bit)
Browser
Microsoft Internet Explorer 6 or above
CPU
Minimum Intel® Core2 Duo E6300 2.8GHz or higher (Core2 Quad is
recommended)
RAM
Minimum 1 GB of RAM, 2GB or above is recommended
Network
Minimum 10/100 Ethernet (Gigabit Ethernet is recommended)
Graphics Adapter
Standalone AGP or PCI-Express, 128MB Ram, minimum 1024x768, 16 bit
colors. (256MB is recommended, we highly recommend to work above the
1024 x 768 resolution to get the full experience of the software)
. Make sure your display DPI setting is set to default at 96DPI
. To set DPI value, right-click on desktop, choose “Settings” tab >>
“Advanced” >> “General”
1.3 Packet Content
1 x NVR
1 x Power Cord
1 x RJ-45 Cable
1 x CD-ROM
1 x Quick Installation Guide
English

7
1.4 Specification
Product NVR-810 NVR-1610
General
OS Embedded Linux
Ethernet 1 x RJ-45, 10/100/1000 Base-TX
USB Interface 2 x USB2.0 for backup device and firmware upgrade
Storage Device 2 x 3.5” SATA hard disk
Button Power, Reset, Buzzer
LED Display
1 x Power
1 x Status
1 x LAN
2 x HDD
1 x alarm
8 x IP camera
1 x Power
1 x Status
1 x LAN
2 x HDD
1 x alarm
16 x IP camera
Video Input 8 channel IP cameras 16 channel IP cameras
Recording Mode Manual, Schedule, Event
E-Map Web Browser, CMS utility
Network Service TCP/IP, DHCP, DNS, HTTP, FTP, NTP, SMTP, UPnP
Network File Protocol Microsoft Networks (CIFS/SMB), Internet (HTTP), FTP
Management
Web-based administration
Network Time Protocol
Multiple users account
E-mail notification
System log
Firmware upgrade
User Interface Web browser
CMS utility
Multiple Language English, Italian, Japanese, Portuguese, Spanish,
Traditional Chinese, Simplified Chinese
Power 100~240V AC, 1.4A / Max. 50/60Hz
Consumption 90W
Operating Temperature 0~45 Degree C
Storage Temperature -40~70 Degree C
Humidity 0~90% (non-condition)
Weight 2.98 kg
Dimension (W x D x H) 240 x 218 x 72 mm

8
1.5 Front Panel
NVR-810
NVR-1610
1.6 LEDs Definition
Green Solid green when the hard disk is mounted
and being accessed
Red Solid red for disk fail
HDD x 2
Amber Solid
amber when disk is full
Blinkin
g
when rec
y
clin
g
Amber Solid amber for activity on a 1G bps network.
Network
Green Solid
g
reen for activity on a 10/100 Mbps
network.
Amber Blinking during firmware upgrade
Green
Shows solid green for normal operation.
Blinking green when firmware upgrade is
done
Status
Red Flashes red for failed firmware upgrade.
Green Normal operation

Red System off (power adapter remains plugged
in)
Amber Blinking amber indicating device is initializing
Red Blinking when an alarm occurs
Alarm
None When alarm is reset
Green Solid green, live connected with no event or
recording activity
Amber Blinking amber, manual or event recording is
being performed
Amber Solid amber, schedule or continuous recording
is being performed
Camera
LEDs
Red Recording is set but no video from camera
1.7 I/O Ports
English
9

Pin Signal
1DC IN
2GND
3 Alarm Input 1
4 Alarm Input 2
5 Alarm Input 3
6 Alarm Input 4
7 Alarm Input 5
8 Alarm Input 6
9 Alarm Input 7
10 Alarm Input 8
11 Alarm Out 1
12 Alarm Out 2
13
A
larm Out 3
14 Alarm Out 4
15 RS-485+
16 RS-485-
10

2. Install Hard Disk
1. Removing the screws on the side.
2. Push the top housing forward, then lift it up.
3. Insert the HDD to HDD tray. Please push the HDD until the SATA connect
is connected properly.
• The NVR supports SATA I or SATA II hard disks
• The NVR supports max. 1.5TB per hard disk and it supports total of 2 hard disks (3TB)

4. Lock the HDD with HDD screw.
5. Place the top housing back and secure it with the bottom
housing.

3. Connect to the NVR
There are various ways you can connect to the NVR and below are the
suggested methods for different network setup:
. The NVR is placed in a network with a DHCP server: Connect to the NVR
by using “Device Search” Utility.
. The NVR is placed in a network without DHCP server (or you are
connecting to it directly): Access NVR with its default IP (192.168.0.20).
3.1 Use Device Search Utility
If the NVR is placed in a corporate network or a local area network where a
DHCP server is already presented, please install the “Device Search” utility from
the bundled CD disk.
To begin, launch the “Device Search” utility from the CD and proceed with the
installation.

Please click “Next” to continue.
Please click “Install” to start the installation.
Once the installation is complete, please check the “Finish”.

Please go to Start => Programs => NVR => Search NVR to run the search tool.
Then you will see the utility start search the network.
The NVR should be located and its IP address should be displayed: Double-click
on it and the program should automatically access the NVR’s web
administration page from your default browser.

You may change NVR’s IP address by click on the button highlighted below.
You will be prompted for the NVR’s login information before proceeding to
change device’s IP address.
You may click on the button highlighted below to perform search again. Or
double-click on any of the search results to access NVR’s web ad- ministration
page.
Perform search again Access NVR’s web administration page
You should be prompted for the NVR’s username and password. Enter its
default username “admin” and password “admin” and then click ”OK” to
enter the system.

3.2 Access NVR with its default IP address
The NVR comes with a pre-configured static IP address “192.168.0.100”.
However, it is only used when there is no DHCP server presented in the
network. Connect the NVR and PC to your switch or hub, or connect the PC
directly to the NVR using a crossover CAT5 Ethernet cable.
The PC that is connected directly to the NVR (or within the same local area
network) should receive an IP from it. Simply access the NVR from your web
browser with NVR default IP address.
You should be prompted for the user name and password. Enter its default
username “admin” and password “admin” and then click” OK” to enter the
system.

4. Live View
The 8 channel NVR comes with a 8-video split window view with one
video displays on a larger window. Select a channel from the drop-down
menu to display its video on the larger split window. You can also double-
click on any of the smaller one to display its video to the larger window.
The “Live View” page provides the following functions:
. Retrieve camera’s video stream
. Retrieve camera’s status
. Perform Live Sequence Viewing
. PTZ Control
. Perform PTZ Preset Sequence viewing
. Perform manual recording
. Take snapshot
. Receive audio of a video stream
. Send audio
. Control “Buzzer”
. Change web UI display language

4.1 Retrieve camera’s video stream
The camera list is expanded and
displayed on the Live View page.
. Click “All” to display videos in
the
8-video mode (NVR-810) or
16- video mode (NVR-1610).
. Click on a “Group” (ex. Group
1) to display videos from
cameras under that group in
quad view.
. Click on any camera to
display video in single-view
mode.
4.2 Retrieve camera’s status
The camera list can show each camera’s current status. Each
status is represented with different colors and their meanings are
explained on the left.
Camera is connected
Camera is NOT connected
Camera is current performing recording
4.3 Perform Sequence Viewing
Sequence view is a function that allows you to view multiple video
streams from certain cameras in sequence automatically with having to
select them one by one.
To perform sequence view, select “Sequence” from the upper-left hand
corner. Then select one or more camera(s) or camera group(s) for sequence
viewing

Then select dwell interval from the drop-down menu
Finally click “Start” to start sequence viewing
Click “All Channels” to quickly select all available channels and start
sequence view in single-view mode.
Click “All Groups” to quick select all available groups and start
sequence view in quad-view mode.
Or simply select the desired channels and press “Start” to start sequence
view.
4.4 PTZ Control
PTZ control provides functions to pan, tilt, zoom a PTZ camera as well
as the ability to adjust camera focus and iris.
Camera(s) that are currently being selected for live viewing will be listed
in the PTZ drop-down menu. Simply select a camera then use the PTZ
control panel to control the camera.
The bar shown below allows you to control the pan/tilt speed.
