Planet IGSW-24040T User manual

Industrial 24-Port 10/100/1000Mbps
with 4 Shared SFP Managed Gigabit Switch
IGSW-24040T
Quick Installation Guide

Table of Contents
1. Package Content.......................................................................................... 3
2. Requirements .............................................................................................. 3
3. Wiring DC Power Inputs ............................................................................... 4
4. Terminal Setup ............................................................................................ 5
5. Logon to the Console ................................................................................... 6
6. Congure IP Address ................................................................................... 7
7. Start Web Management................................................................................ 9
8. Customer Support .....................................................................................12

3
1. Package Content
Thank you for purchasing PLANET Industrial Layer 2 Managed Switch, IGSW-
24040T. Terms of “Managed Switch” means the Switch mentioned titled in the
cover page of this Quick installation guide, i.e. IGSW-24040T.
Open the box of the Managed Switch and carefully unpack it. The box should
contain the following items:
 The IGSW-24040T Switch x 1
User’s Manual CD x 1
 Quick Installation Guide x 1
RS232 Cable x 1
Rubber Feets x 4
 Two Rack-mounting Brackets with Attachment Screw x 1 (set)
 Power Cord x 1
If any item is found missing or damaged, please contact your local reseller for
replacement.
2. Requirements
 Workstations of subscribers running Windows XP/2003/Vista/7/2008, MAC OS9
or later, Linux, UNIX or other platform compatible with TCP/IP protocols.
 Workstation installed with Ethernet NIC (Network Interface Card)
Serial Port connect (Terminal)
 Above PC with COM Port (DB9)
Ethernet Port connect
 Network cables - Use standard network (UTP) cables with RJ-45 connectors.
 Above PC installed with WEB Browser and JAVA runtime environment Plug-in.
Note
It is recommended to use Internet Explore 7.0 or above to access
the Managed Switch.

4
3. Wiring DC Power Inputs
The 6-contact terminal block connector on the rear panel of IGSW-24040T is used
for two DC redundant powers input. Please follow the steps below to insert the
power wire.
1. Insert positive / negative DC power wires into the contacts 1 and 2 for DC
POWER 1, or 5 and 6 for DC POWER 2.
ON
OFF
Fault
N/AGNDDO 1DO 0DI 1DI 0
DC 2DC 1
AC POWER 100~240V AC
50/60Hz
Please refer to user’s manual before
connect the DC wire.
DC Input Range: 36V~72V DC
CAUTION
2. Tighten the wire-clamp screws for preventing the wires from loosing.
123456
DC 1 Fault Alarm DC 2
+-+-
Note
The wire gauge for the terminal block should be in the range
between 12 ~ 24 AWG.

5
4. Terminal Setup
To congure the system, connect a serial cable to a COM port on a PC or
notebook computer and to serial (console) port of the Managed Switch. The console
port of the Managed Switch is DCE already, so that you can connect the console
port directly through PC without the need of Null Modem.
PC / Workstation
with
Terminal emulation software
RS-232
Serial Port Serial Port
115200,8,n,1
PLANET Managed Switch
A terminal program is required to make the software connection to the Managed
Switch. Windows’ Hyper Terminal program may be a good choice. The Hyper
Terminal can be accessed from the Start menu.
1. Click START, then Programs, Accessories and then Hyper Terminal.
2. When the following screen appears, make sure that the COM port should be
congured as:
♦ Baud: 115200
♦Data bits : 8
♦ Parity : None
♦Stop bits : 1
♦ Flow Control : None

6
5. Logon to the Console
Once the terminal has connected to the device, power on the Managed Switch, the
terminal will display that it is running testing procedures.
Then, the following message asks the login username and password. The factory
default username and password as following and the login screen in Figure 5-1
appears.
Username: admin
Password: admin
Figure 5-1: IGSW-24040T Managed Switch Console Login Screen
Note
1. For security reason, please change and memorize the new pass-
word after this first setup.
2. Only accept command in lowercase letter under console inter-
face.

7
6. Congure IP Address
The Managed Switch is shipped with default IP address as following.
IP Address: 192.168.0.100
Subnet Mask: 255.255.255.0
To check the current IP address or modify a new IP address for the Switch, please
use the procedures as follow:
Show the current IP address
1. On “Switch/>” prompt, enter “show ip”.
2. The screen displays the current IP address, Subnet Mask and Gateway. As show
in Figure 6-1.
Figure 6-1: Show IP Information Screen

8
 Congure IP address
3. On “Switch/> ” prompt, enter the following command and press <Enter>. As
show in Figure 6-2.
Switch/> ip setup 192.168.1.100 255.255.255.0 192.168.1.1
The previous command would apply the follow settings for the Switch.
IP Address: 192.168.1.100
Subnet Mask: 255.255.255.0
Gateway: 192.168.1.1
Figure 6-2: Set IP Address Screen
4. Repeat Step 1 to check if the IP address is changed.
If the IP is successfully congured, the Managed Switch will apply the new IP
address setting immediately. You can access the Web interface of the Managed
Switch through the new IP address.
Note
If you do not familiar with console command or the related param-
eter, enter “help” anytime in console to get the help description.

9
7. Start Web Management
The following shows how to start up the Web Management of the Managed
Switch. Note the Managed Switch is congured through an Ethernet connection,
please make sure the manager PC must be set on the same IP subnet address.
For example, the default IP address of the Managed Switch is 192.168.0.100,
then the manager PC should be set at 192.168.0.x (where x is a number between
1 and 254, except 100), and the default subnet mask is 255.255.255.0.
PLANET Managed Switch
RJ-45/UTP-Cable
PC / Workstation
with
IE Browser
IP Address:
192.168.0.x
IP Address:
192.168.0.100
Figure 7-1: IP Management Diagram
Login the Managed Switch
1. Use Internet Explorer 7.0 or above Web browser, enter IP address
http://192.168.0.100 (the factory-default IP address or that you have just
changed in console) to access the Web interface.
2. When the following dialog box appears, please enter the default username and
password “admin” (or the password you have changed via console). The login
screen in Figure 7-2 appears.
Default Username: admin
Default Password: admin
Figure 7-2: Login Screen

10
3. After entering the password, the main screen appears as Figure 7-3.
Figure 7-3: Web Main Screen of the Managed Switch
4. The Switch Menu on the left of the Web page let you access all the commands
and statistics the Switch provides.
Figure 7-4: Switch Menu
Note
If you do not familiar with Switch functions or the related param-
eter, press “Help” button anytime at left of the Web page to get
the help description.

11
Now, you can use the Web management interface to continue the Switch
management or manage the Switch by console interface.
Please refer to the user manual for more.
While IP Address be changed or forgotten admin password –
To reset the IP address to the default IP Address “192.168.0.100” or reset
the login password to default value. Press the hardware reset button at the
front panel over 5 seconds. After the device is rebooted, you can login to the
management Web interface within the same subnet of 192.168.0.xx.
Reset

12
8. Customer Support
Thank you for purchase PLANET products. You can browse our online FAQ resource
at the PLANET website rst to check if it could solve your issue. If you need more
support information, please contact with PLANET switch support team.
PLANET online FAQ :
http://www.planet.com.tw/en/support/faq.php?mt=menu_support_1
Switch support team mail address :
[email protected]w
Copyright  PLANET Technology Corp. 2011.
Contents subject to revision without prior notice.
PLANET is a registered trademark of PLANET Technology Corp.
All other trademarks belong to their respective owners.
