Planika Misty User manual

Misty
Copyright Planika Sp. z o.o. www.planikafires.com IP0006#0004.12.2023
EN Installation manual
WARNING / WARNUNG / ADVERTENCIA / AVERTISSEMENT / ATTENZIONE / OSTRZEŻENIE / ВНИМАНИЕ
EN This Manual only applies to the installation of Misty only.
DE Dieses Handbuch gilt nur für die Installation von Misty
ES Este manual sólo es aplicable a la instalación de Misty
FR Ce manuel s'applique uniquement à l'installation des Misty
IT Il presente manuale si applica solo all'installazione di Misty
PL Niniejsza instrukcja dotyczy wyłącznie instalacji urządzeń Misty
RU Данное руководство относится только кустановке Misty
This product complies with all the required Product Safety, Electromagnetic Compatibility and Environmental Standards. This product is fully compliant with the LVD, EMC, RoHS and Eco Design
Directives.

2
TABLE OF CONTENTS
1. INTRODUCTION .............................................................................................................................................................3
2. IMPORTANT SAFETY ADVICE .........................................................................................................................................3
3. GENERAL INFORMATION...............................................................................................................................................4
4. INSTALLATION INSTRUCTIONS ......................................................................................................................................5
5. OPERATING THE FIRE ....................................................................................................................................................5
6. MAINTENANCE................................................................................................................................................................6
7. CLEANING ......................................................................................................................................................................7
8. ADDITIONAL INFORMATION .........................................................................................................................................7
9. PATENT / PATENT APPLICATION ...................................................................................................................................8
10. TROUBLESHOOTING ......................................................................................................................................................8
11. APPENDIX ......................................................................................................................................................................9

3
1. INTRODUCTION
Thank you for choosing this Planika electric fire. Please read this information guide carefully to be able to safely install, use and
maintain your product.
2. IMPORTANT SAFETY ADVICE
When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electrical shock and injury
to persons, including the following:
WARNING
Do not place material or garments on, or obstruct the air circulation around the appliance.
This appliance carries a DO NOT COVER warning
DAMAGE
Do not use this appliance if it has been dropped
If the appliance is damaged, check with the supplier before installation and operation.
If the supply cord is damaged it must be replaced by the manufacturer or service agent or a similarly qualified person in order to
avoid a hazard.
LOCATION
Do not use outdoors.
Do not use in the immediate surroundings of a bath, shower or swimming pool.
Do not locate the fire immediately below a fixed socket outlet or connection box.
Ensure that furniture, curtains or other combustible material are positioned no closer than 1 metre from the appliance.
Use this appliance on a horizontal and stable surface.
PLUG POSITIONING
The appliance must be positioned so that the plug or point of isolation is accessible. Keep the supply cord away from the front of
the appliance.
UNPLUGGING
In the event of a fault unplug or isolate the device.
Unplug or isolate the device when not required for long periods.
OWNER/USER
This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall
not be made by Children without supervision.
Children of less than 3 years should be kept away unless continuously supervised. Children aged from 3 years and less than 8 years
shall only switch on/off the appliance provided that it has been placed or installed in its intended normal operating position and
they have been given supervision or instruction concerning use of the appliance in a safe way and understanding the hazards
involved. Children aged from 3 years and less than 8 years shall not plug in, regulate and clean the appliance or perform user
maintenance.
ELECTRCITY
WARNING - THIS APPLIANCE MUST BE EARTHED.
This appliance must be used on an AC ~ supply only and the voltage marked on the appliance must correspond to the supply
voltage. Before switching on, please read the safety advice and operating instructions.
CAUTION - Some parts of this product can become very hot and cause burns. Particular attention has to be given where children
and vulnerable people are present.
WARNING - In order to avoid overheating, do not cover the appliance.

4
WARNING: KEEP BATTERIES OUT OF REACH OF CHILDREN
1. Swallowing may lead to serious injury in as little as 2 hours or death, due to chemical burns and potential perforation of the
oesophagus.
2. If you think batteries might have been swallowed or placed inside any part of the body seek
immediate medical attention
3. Examine devices and make sure the battery compartment is correctly secured, e.g. that the
screw or other mechanical fastener is tightened. Do not use if the compartment is not secure.
4. Dispose of used button batteries immediately and safely. Flat batteries can still be dangerous.
CAUTION: No obvious symptoms
Unfortunately, it is not obvious when a button or coin battery is stuck in a child’s oesophagus (food pipe). There are no
specific symptoms associated with this. The child might:
•cough, gag or drool a lot;
•appear to have a stomach upset or a virus;
•be sick;
•point to their throat or stomach;
•have a pain in their abdomen, chest or throat;
•be tired or lethargic;
•be quieter or more clingy than usual or otherwise “not themselves”;
•lose their appetite or have a reduced appetite; and
•does not want to eat solid food/be unable to eat solid food.
These sorts of symptoms vary or fluctuate, with the pain increasing and then subsiding.
A specific symptom to button and coin battery ingestion is vomiting fresh (bright red) blood. If the child does this seek immediate
medical help.
The lack of clear symptoms is why it is important to be vigilant with “flat” or spare button or coin batteries in the home and the
products that contain them.
3. GENERAL INFORMATION
Only use filtered water in this appliance.
This model is designed to be free standing and is normally positioned near a wall.
Always ensure that the appliance is sitting on a level surface.
PLEASE NOTE: Used in an environment where background noise is very low, it may be possible to hear a sound which is related to
the operation of the flame effect. This is normal and should not be a cause for concern.
If this product experiences a power surge for whatever reason the product may cut-out. This is a normal safety feature and the
product will resume operation after 30 seconds.
Once installed, never move this appliance or lay on its back, without draining the water from sump and water tank.
If you intend not using the appliance for longer than 2 weeks, drain the water from sump and water tank and dry the sump.
The water tank, sump, sump lid, tank cap and air filters must be cleaned once every two weeks, particularly in hard water areas.
The sump and the water tank in this product are treated with a biocidal product.

5
4. INSTALLATION INSTRUCTIONS
BEFORE YOU START
1. Ensure that all packing items are removed (read any warning labels carefully) and retain all packing for possible future use e.g.
in the event of moving house or returning the appliance to your supplier.
2. Before connecting to the mains supply, check that the supply voltage is the same as that stated on the appliance.
INSTALLATION
This appliance has been designed to be placed in front of the wall. Make sure to follow with these guidelines:
ESSENTIAL VENTING
A suitable air vent is essential to ensure that air can circulate into the appliance - otherwise the Opti-myst flame effect will not
operate correctly. Bottom section pathway for air must not be obstructed. The air vent should be free from drafts.
3. Ensure that there is sufficient room to thread through the mains cable
4. Assemble the side legs as well as back stand to the Misty using screws (fig 9)
5. Install assemble profile on the wall dedicated for installation (fig 9)
6. Locate the product in dedicated space
7. Set the ceramic logs added to the product
8. Set the glass on top of the device (20mm from the rail)
5. OPERATING THE FIRE
This section describes how to activate your fire using either the manual controls or remote control.
MANUAL CONTROLS
The manual controls are located beneath the fuelbed
(See Fig.4 for Manual Control layout)
Switch ‘A’ – Controls the electricity supply to the Fire.
Note: This switch must be in the ‘ON’ (I) position for the Fire to operate
Switch ‘B’ – Press to turn on the flame effect. This will be indicated by an audible beep. Although the main lights operate
immediately it will take a further 45 seconds before the flame effect starts.
Press to put fire in to standby mode. This will be indicated by one beep.
REMOTE CONTROL OPERATION
The remote control comes with batteries fitted. Pull out the plastic pull tabs completely in order to engage the batteries.
1. Remove battery cover of the remote control using a Philips screwdriver. (See below)
2. Correctly install two 3 Volt (CR2032 or similar) battery in the battery holder with the + side facing up.
3. Secure the battery cover using the previously removed screw.
Batteries must be recycled or disposed of properly. Check with your Local Authority or Retailer for recycling advice in your
area.
Frequency band(s) this product operates in: 2.4 GHz.
Maximum radio- frequency power transmitter in the frequency band(s) this product operates in: 2.71 dBm

6
This section describes how to active your fire using the remote control
Standby
Press to turn on the unit or put it in standby mode. There is a brief delay after pressing
before the unit turns on.
When the unit is turned on, there is a 45-second warm-up sequence before the flame effect
starts.
Timer
Press repeatedly to set the timer. The fireplace goes into standby after the time has
elapsed. The timer can be set from 1 hour to 3 hours. Pressing timer 1 beep indicates
time set for 1 hour, press again 2 beeps indicates timer set for 2 hours and press again 3
beeps for 3 hours, press again to turn off the timer (no beeps)
Increase Flame Intensity
Press to increase the flame intensity. Flame intensity range F1-F6
Decrease Flame Intensity
Press to decrease the flame intensity. Flame intensity range F1-F6
Increase Volume Press repeatedly (or press and hold) to increase the volume level of the crackling sound
effect. Sound control range OFF- VOL6
Decrease Volume Press repeatedly (or press and hold) to decrease the volume level of the crackling sound
effect. Sound control range OFF- VOL6
6. MAINTENANCE
GENERAL TIPS
Only use filtered tap water in this appliance.
Always ensure that the appliance is sitting on a level surface.
If you intend not using the appliance for longer than 2 weeks, remove and empty the sump and water tank.
Once installed, never move this appliance or lay on its back, without draining the water from sump and water tank.
FILLING THE WATER TANK
When the water tank is empty, the flame and smoke effect shuts off and you will hear two audible beeps, the LED’s will double
blink indicates low water.
Follow the steps below to refill your product with water.
1. Unplug the device from the electricity
2. Take off the glass from the product (fig 10)
3. Take off the top plate from the device to get inside the product (fig 10)
4. Take out the device from the firebox
5. Press Switch ‘A’ to (0) (See Fig.4)
6. Gently lift out the fuelbed and carefully set aside.
7. Remove the water tank by lifting upwards and outwards.
8. Place the water tank in sink and remove cap, turn anti-clockwise to open.
9. Fill tank with filtered tap water only. This is necessary to prolong the life of the flame and smoke producing unit. The water
should be filtered through a conventional domestic water filter unit and the filter should be replaced regularly.
10. Screw the cap back on, do not over tighten.
11. Return the tank to the sump, with the tank cap facing down
12. Gently place the fuelbed back into position.
13. Press Switch ‘A’ to ‘ON’ (I) position (See Fig.4)
14. Put the device back and plug it into electricity
15. Connect the power cable to the appropriate power connector at the back of the appliance and Plug the power cable into a
13amp/240volt outlet. The appliance is now ready for use.
16. When the sump has been refilled the blinking lights will stop and product will start up as normal.

7
7. CLEANING
Warning – Always press Switch ‘A’ to the ‘OFF’ (0) position (See Fig.4) and disconnect from the power supply before cleaning the
fire.
We recommend cleaning the following components once every 2 weeks, particularly in hard water areas: Water
Tank, Sump, Nozzle, Tank cap and seal, Air filter.
For general cleaning use a soft clean duster – never use abrasive cleaners.
To remove any accumulation of dust or fluff, the soft brush attachment of a vacuum cleaner should occasionally be used.
WATER TANK
1. Remove water tank, as described earlier, put into sink and empty water.
2. Using the supplied brush gently rub the inside surfaces of the cap paying particular attention to the rubber ring in the outer
groove and the center rubber seal.
3. Put a small quantity of washing up liquid into the tank, refit the cap and shake well, rinse out until all traces of washing up
liquid are gone.
4. Refill with filtered tap water only, replace the cap, do not overtighten.
SUMP
1. Unplug the device from the electricity
2. Take off the glass from the product (fig 10)
3. Take off the top plate from the device to get inside the product (fig. 10)
4. Take out the device from the firebox
5. Gently lift out the fuelbed and place carefully on the ground.
6. Press Switch ‘A’ to the ‘OFF’ (0) position
7. Remove the water tank by lifting upwards.
8. Disconnect the electrical connector, located on the back of the product under the rating label. (See Fig.5) .
9. Pinch open the red clips.
10. Gently lift up the orange nozzle and set aside.
11. Lift out the sump being careful not to spill any water left inside it.
12. The transducer is secured in the sump by a small clip. Pull back the clip to allow the transducer to be removed from the sump.
Carefully tilt, so that the liquid drains out of the sump.
13. Put a small amount of washing up liquid into the sump, and using the supplied brush, gently clean all surfaces in the sump
and gently clean the transducer including the metal discs located in the top grooved surface. (See Fig.7)
14. When cleaned, thoroughly rinse the sump with clean water to remove all traces of washing up liquid.
15. Clean the Nozzle with the brush and flush out thoroughly with water. (See Fig.8)
16. Reverse the above steps to reassemble.
AIR FILTER
1. Gently lift out the fuelbed and place carefully on the ground.
2. Gently slide the air filter upwards out of its plastic holder. (See Fig.9)
3. Gently rinse with water in the sink and dry with fabric towel before returning.
4. Replace the filter making sure that the coarse black filter is facing the front of the fire.
5. Replace the fuelbed.
8. ADDITIONAL INFORMATION
AFTER SALES SERVICE
Your product is guaranteed for two years from the date of purchase. Within this period, we undertake to repair or exchange this
product free of charge (excluding lamps & subject to availability) provided it has been installed and operated in accordance with
these instructions. Your rights under this guarantee are additional to your statutory rights, which in turn are not affected by this
guarantee.

8
RECYCLING
For electrical products sold within the European Community - At the end of the electrical products useful life it not
be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer
for recycling advice in your country.
9. PATENT / PATENT APPLICATION
Products within the Planika range are protected by one or more of the following patents and patent applications:
Great Britain GB 2402206, GB 2460259, GB 2460453 , GB 2418014, GB 2465738, GB 2449925, GB 2465537 , GB
2455277 , GB1020534.2, GB1020537.5, GB1110987.3
United States US 7967690, US 2010299980, US 2011062250, US 2008028648, US 13/167,042
Russia RU2008140317
European EP 2029941, EP 2201301, EP 2315976, EP 1787063, EP07723217.1 , EP11170434.2, EP 11170435.9
China CN 101883953, CN 200980128666.2, CN 101057105, CN 101438104
Australia AU 2009248743, AU 2007224634
Canada CA 2725214, CA 2579444, CA 2645939
International Patent Application WO 2006027272
South Africa ZA 200808702
Mexico MX 2008011712
Korea KR 20080113235
Japan JP 2009529649
Brazil BR P10708894-9
India IN 4122/KOLNP/2008
New Zealand NZ 571900
10. TROUBLESHOOTING
Symptom
Cause
Correc�ve Ac�on

will not start.
Mains plug is not plugged in.
Low voltage connector not connected
properly. (See Fig.5)

correctly in the sump
Check plug is connected to wall socket correctly.
Check that the connector is inserted correctly. (See Fig.6)
 the moulded recess in the sump
Product will not
operate. LEDs

Low water level. Check that the water tank is full and there is water in the sump.


too low

The metal Disc in the transducer might
be dirty.
The wire from the Transducer Unit is


 7) See “Maintence” for a step by
step procedure.
Direct the wire to the back of 
the sump.
Unpleasant smell
when unit is used.
Dirty or stale water.

Clean the unit as described under maintenance.


has too much
smoke
 

There are no
 There is no water in the water tank

Maintenance, “Filling the water tank”
4
is in ‘ON’


9
11. APPENDIX
Fig 1
Fig 2
Fig 3
Fig 4
Fig 5
650 240
370
407318
725

10
Fig 6
Fig 7
Fig 8
Fig 9
Fig 10
