Plantronics .Audio™995
User Guide

ii
Welcome
Congratulations on purchasing your new Plantronics .Audio™995.
This User Guide contains instructions for setting up and using the
.Audio 995. Please refer to the separate For Your Safety guide for
important safety, charging, battery, and regulatory information prior
to installation or use.
Getting Assistance
The Plantronics Technical Assistance Center is ready to assist
you. You can find answers to frequently asked questions, ask
a question using e-mail, receive service over the Internet, or speak
directly with a representative.Visit www.plantronics.com/support or call
your country support line mentioned at the back of this user guide.
Registering Your Product
Visit www.plantronics.com/productregistration to register your
product online so we can provide you with the best service and
technical support.

iii
Contents
Range ...............................................................................................iv
Package Contents and Features...................................................... 1
Charging Your Headset Using the USB Charger.............................. 2
Using Your Headset.......................................................................... 3
Pairing Your Headset........................................................................ 4
How to Manually Pair Your Headset and Adapter................... 4
Headset Controls.............................................................................. 5
Operating Systerms Configuration................................................... 6
Indicator Lights................................................................................. 8
Product Specifications ..................................................................... 9
Troubleshooting ............................................................................. 10

iv
Important Note on Wireless Range
The .Audio 995 headset has a wireless range of
up to 12 meters. However, wireless performance
may be affected by nearby objects including walls,
metal items, and other wireless devices. When you
move the headset to the edge of its wireless range,
audio may become distorted and will eventually cut
out. Move closer to the wireless adapter to restore
clear audio.

1
Package Contents and Features
Volume Up
Indicator Light
Play/Pause
Microphone
Volume Down
Track Skip Forward/
Fast Forward
Power On/Off
Connect/Pair
Indicator Light
Wireless Adapter
Mute Microphone

2
Charging Your Headset Using the USB Charger
Before using your headset for the first time,
charge it for at least one hour. A full charge takes
approximately three hours.
1 Connect the charger cable to the headset.
2 Plug the charger into the USB port on your
computer.
While your headset is charging the indicator glows
red. When your headset is fully charged, the indicator
turns off.
NOTE Charging time depends on the amount of
power your USB device provides.
CHARGING TIME
3-4 hours ................
Full charge
1 hour .....................
Minimum charge
before first use

3
Using Your Headset
Congratulations, you can now listen to your favorite music or talk with friends and family using your new
wireless headset.
Using Your Headset
1 Make sure that your headset is fully charged. When fully charged, the red indicator light
turns off.
Do not use your headset while it is connected to the charger.
2 Plug the wireless adapter into a USB port on your computer.
Your computer and USB hub (if using) should be turned on.
NOTE When not using the headset and adapter, you can remove the adapter safely by just unplugging
it from the USB port.
3 After removing your headset from the charger, press the Power button for two seconds to
turn the headset on.
The headset and the adapter should connect immediately, and the indicator lights on both headset and
wireless adapter will be solid blue. If you cannot hear anything through your headset, try adjusting the
volume up or restarting the media application.
NOTE If steps 1 through 3 do not work, refer to “Pairing Your Headset” on page 4 to manually pair your
headset and adapter.

4
Pairing Your Headset
How to Manually Pair Your Headset and
Adapter
Your headset and adapter are factory pre-paired,
and should automatically connect with each
other. Should your headset and adapter become
unpaired, you can initiate pairing manually:
1 Press and hold the Power button on the
headset and the Connect button on the
adapter for 4 seconds.
The indicator lights on the headset and adapter
will rapidly flash blue.
2 The headset and adapter will automatically
attempt to pair.
If the pairing is successful the indicator lights
will glow solid blue; if unsuccessful, both
headset and adapter will stay in pairing mode.
If manual pairing was unsuccessful, and you want
to re-attempt the pairing process, you must first
take your headset and adapter out of pairing
mode.
3 Turn headset off.
4 Single press the Connect/Pair button on
the adapter, then repeat steps 1 and 2.
NOTE If your headset and adapter are separated
and lose their connection after being successfully
paired, they will automatically reconnect when
they come back into range of each other. If they
remain out of range for more than 30 seconds, the
headset will go into sleep mode, but will reconnect
automatically with the adapter once it is back in
range. If the headset is out of range for more than
15 minutes, it automatically shuts off.

5
Headset Controls
Turn the headset
on/off
Press Power button for 2 seconds
Adjust volume Increase: Press +
Decrease: Press -
Minimum volume: Continually press -
Pause music: Press
WARNING Do not use headsets at high volumes for an extended period of time.
Doing so can cause hearing loss. Always listen at moderate levels.
See www.plantronics.com/healthandsafety for more information on headsets
and hearing.
Muting the
microphone
Mute: Lift the boom to full stop.
Unmute: Lower the boom.
CAUTION Do not force the boom past its upper or lower limits.
Music controls Press to Play or Pause music.
Press to skip track forward.
Press and hold to fast forward.
NOTE Some applications, such as iTunes, must be the active window in order for
play, pause and skip to work properly.

6
Operating Systems Configuration
Your .Audio 995 headset works with any USB-
compliant computer. The headset will automatically
be set as the active audio device once the wireless
USB Adapter is plugged in. Below are details on
how to set the audio device for the most popular
operating systems.
NOTE On-ear controls may not function properly
with operating systerms earlier than Windows XP.
Windows XP®
1 Go to Start > Control Panel > Sounds and
Audio Devices.
2 On the Audio tab, select “Plantronics
Wireless Audio” as the Sound Playback
and Sound Recording device.
3 On the Voice tab, select the “Plantronics
Wireless Audio” as the Voice Playback and
Voice Recording device.
4 On the Volume tab, adjust the Volume
Slider as necessary. Do not select the
Mute option.
5 Select OK.

7
Operating Systems Configuration
Windows Vista
1 Go to Start > Control Panel > Classic View
> Sounds.
2 On the Playback tab, select the
“Plantronics Wireless Audio” as the Sound
Playback device.
3 Select Properties, and on the Levels tab,
adjust the Volume Slider as necessary. Do
not select the mute option. Select OK.
4 On the Recording tab, select the
“Plantronics Wireless Audio” headset as
the Sound Recording device.
5 Select Properties, and on the Levels tab,
adjust the Volume Slider as necessary. Do
not select the mute option. Select OK.
6 Select OK.
Mac®OS X
1 Go to System Preferences > Sound.
2 On the Output tab, select the “Plantronics
Wireless Audio” headset as the Sound
Output device.
3 Adjust the Output Volume Slider as
necessary. Do not select the mute option.
4 On the Input tab, select the “Plantronics
Wireless Audio” headset as the Sound
Input device.
5 Adjust the Input Volume Slider as
necessary.
6 Select OK

8
Status Indicator
Power On/Off On: Steady blue glow
Off: Steady red glow, then off
Out of Range Flashing blue
Charging Solid red until charging complete
Connected to Adapter Solid blue glow
Standby/Battery Save Mode
(Sleep)
Intermittent breathing or pulsing
blue glow
Pairing Headset and adapter will rapidly flash
blue when in pairing mode
Indicator Lights—Headset and Wireless USB Adapter

9
Product Specifications
Technology Digital wireless
Full range stereo Stereo headset
Wearing style Over the head
Cable length Wireless
Ear cushion material Non-allergenic
Ear cushion design Closed ear
Noise cancelling mic Yes
Microphone boom Rotates/bends
Mic mute FastMic mute
Volume controls On ear
Wireless technolgy 2.4GHz
Speaker driver
size
40mm diameter
Speaker frequency
response
20Hz—20kHz
Microphone
frequency
response
100Hz—10kHz
Wireless range Up to 12 meters
Battery Type Lithium ion polymer
(embedded, non-replaceable)

10
The headset did not connect
to the wireless USB adapter
on first use.
Ensure the headset is fully charged and powered on.
Ensure that the wireless USB adapter is plugged into a powered USB
port. If the port is powered, the LED on the wireless USB adapter will
be lit.
If the wireless USB adapter is plugged into a USB hub, ensure that the
USB hub is turned on.
If all of the above fails, then follow the steps to pair the headset to the
wireless USB adapter.
The headset did not
re-connect to the wireless
USB adapter after coming
back into range.
Power off the headset and then power it back on. The headset should
then automatically re-connect to the wireless USB adapter.
The headset is paired to the
adapter, but I cannot hear
audio from the headset.
Ensure that both the headset and adapter are powered on and paired.
Restart any running applications. Some applications need to be restarted
in order to recognize a new audio device.
In the Control Panel, check sound and audio settings to ensure that the
chosen device is “Plantronics Wireless Device.”
Troubleshooting

11
The play/pause and/or track
skip function is not working for
my application.
Some applications, such as iTunes, require that they be the active
appliction (i.e., not minimized) in order to be controlled by a 3rd party
audio device.
Some media applications, when embedded in a web page, do not
recognize standard Windows audio commands for play/pause and/or
track skip.
When using the internet to
make calls (i.e., using VoIP),
callers cannot hear me.
Check that the application being used has “Plantronics Wireless Device”
listed as the active device for listening and speaking.
Some applictions need to be set manually or restarted before they will
recognize a new audio device.
NOTE: In unusual circumstances the headset may switch off. Switch the headset back on to resume
normal operation.
Troubleshooting

12
For safety information, see the separate “For Your Safety” booklet.
For warranty information, see the “Getting Started” guide or visit www.plantronics.com
Plantronics Ltd
Wootton Bassett, UK
Tel: [phone]
www.plantronics.com
Czech Republic
www.plantronics.com
Danmark
Tel: [phone]
Plantronics GmbH
Hürth, Deutschland
Kundenservice:
Deutschland 0800 9323 400
Österreich 0800 242 500
Schweiz 0800 932 340
Για περισσότερες
πληροφορίες:
www.plantronics.com
Plantronics Iberia, S.L.
Madrid, España
Tel: [phone]
Finland
Tel: [phone]
Plantronics Sarl
Noisy-le-Grand
France
Plantronics BV
Regus House
Harcourt Centre
Harcourt Road
Dublin 2
Ireland
Service ROI: 1800 551 896
:רתאב רקב ,ףסונ עדימל
www.plantronics.com
További információk:
www.plantronics.com
Plantronics Acoustics
Italia Srl
Milano, Italia
Numero Verde: 800 950934
Plantronics B.V.
Hoofddorp, Nederland
Tel: (0)0800 Plantronics
0800 7526876 (NL)
00800 75268766 (BE/LUX)
Norge
Tel: [phone]
Aby uzyskać więcej
informacji:
www.plantronics.com
Portugal
Tel: [phone]
Pentru informaţii
www.plantronics.com
Дополнительная
информация:
www.plantronics.com
Sverige
Tel: [phone]
Daha fazla bilgi için:
www.plantronics.com
en
cs
da
de
el
es
fi
fr
ga
he
hu
it
nl
ar
no
pl
pt
ro
sv
tr
ru

Plantronics B.V.
Scorpius 140
2132 LR Hoofddorp
Netherlands
www.plantronics.com
©2009 Plantronics, Inc. All rights reserved. Plantronics, the logo design, .Audio, and Sound Innovation are trademarks or registered
trademarks of Plantronics, Inc. Windows XP and Windows Vista are either trademarks or registered trademarks of Microsoft
Corporation in the United States and/or other countries. Mac OS X and iTunes are trademarks of Apple, Inc. registered in the US and
other countries. All other trademarks appearing herein are the property of their respective owners.
81182-03 Rev A
МЛ05
