Plantronics CS10 User manual

12 3
1
2
3
4
5
6
7
8
9
0
A B
1
2
3
4
5
6
7
8
9
0
The CS10 Cordless Telephone Headset System converts
your desk telephone into a cordless headset system. It
includes a cordless remote unit, a base unit and a headset.
The remote unit and the headset allow hands free mobility
up to 150 feet away from the base depending on your
environmental conditions.
With the use of an optional handset lifter the user can
remotely receive the telephone's ring alert and can answer
the call by simply pushing the talk button.
Your CS10 System contains:
■This Quick Start Guide, the Product Information Booklet
and Product Registration Card
■Convertible Headset
■Remote Unit
■Base Unit
■AC Adapter
■Short Cord
For safety, alternate headset configurations
and more information see the Product
Information Booklet.
CONVERTIBLE HEADSET REMOTE UNIT BASE UNIT
Power
Charge
Tal k
Page
TAL K
Talk
(In-Use)
Indicator
Light
Battery
Charge
Light
Remote Unit
Charging
Well
Power
Indicator
Light
Page Button
Headset Holder/Antenna
Talk
Volume
Control
Talk
Button
Off On
Ringer
Ringer ON/OFF
(for use with optional
handset lifter) Battery
– +
VOLUME
CHANNEL MUTE
TALK
Talk (In-Use)
Indicator Light
Talk Button
Mute Indicator Light
Mute Button
Antenna
Listen Volume Controls
Headset
Jack
Channel
Button
Headset
Cord
Clip
COMPONENTS OF THE CS10 SYSTEM
ABOUT THE CS10
© 10.2000 Plantronics, Inc. All rights reserved.
Plantronics and the Plantronics Logo are registered trademarks of Plantronics, Inc.
Printed in USA. 47915-01
Power
Charge
Talk
Page
VOLUME
CHANNEL MUTE
TALK
TALK
Quick Start Guide
Cordless
Telephone
Headset
System
Transit Level
Switch
(1/2/3)
Manual
Channel
Settings Back of Base Unit
Configuration
Switch
(A/B)
Not shown
AC Adapter
P/N 45669-01
Short Cord
P/N 40974-01
Over-the-Head Configuration
Adjustable
Headband
Headset
Assembly
Voice
Boom
Ear Cushion
Assembly
Cord
Clothing
Clip
Over-the-Ear Configuration
see Product
Information
Booklet
Flexible
Earloop
Pivot
Ball
Ring
Hole for
Flexible
Earhook Pin
Cord
Retainers
Thumb
Loop
Pin for Pivot
Ball Ring Hole
2.5 mm Plug
345 Encinal Street
Santa Cruz, California 95060
[phone]
www.plantronics.com

CS10 CORDLESS TELEPHONE HEADSET SYSTEM
Off On
Ringer
– +
VOLUME
CHANNEL MUTE
TALK
3
4
5
Off On
Ringer
Off On
Ringer
If necessary, the
battery can be
separated from
remote unit and
reattached.
Charge remote unit
by firmly placing into
charging well.
Charging is complete
when battery charge
light goes off.
Note: The battery
may need to charge
overnight to get full
power.
The remote unit is
designed to clip on
a belt, pocket or a
an optional neck
strap by squeezing
the ends shown.
Remote
Unit Details
Plug headset into
remote unit. Slide
cord into the
headset cord clip.
2
Please read the important Safety Instructions in the Product Information Booklet.
1
Headset
Unpack all
components and
remove packing
materials from
workspace.
Identify the components
as shown on the other
side of this guide.
Use the Over-the-Head
configuration to quick
start and test your system.
For Over-the-Ear headset
configuration, see the Product
Information Booklet.
Quick Start
Operation
Put on the headset
and adjust the
headband for comfort.
Adjust boom to 1" from
side of mouth.
Press talk button on remote
or base unit (talk lights go on).
Remove telephone handset from
cradle (dial tone is heard).
Dial a co-worker or friend.
Talk normally and assess voice
quality. Adjustments can be
made according to the
Product Information Booklet
(page 5).
Press talk again to disconnect and return handset to telephone cradle.
Note: When properly configured your telephone handset will still function as normal.
For detailed operating instructions, headset re-configuration instructions, troubleshooting and other information see the Product Information Booklet.
Base Unit Setup
Connect the Base Unit as shown.
Note: The connection between
your telephone and the wall jack
remains unchanged.
Remote
Unit Setup
Pull out shipping
tab to activate
battery.
– +
VOLUME
CHANNEL MUTE
TALK
Over-the-Head
Configuration
LIFTER HANDSET TEL
CLASS 2
DC9V
Power
Charge
Tal k
Page
– +
VOLUME
CHANNEL MUTE
TALK
Power
Charge
Talk
TALK
– +
VOLUME
CHANNEL MUTE
TALK
battery
charge
light
AC
adaptor
(back
routed)
Underside of
Base Unit
For optional
handset lifter
accessory Telephone handset cord
(front routed)
Short cord to telephone
base handset jack (back routed)
TALK
