5543 Mirage User Guide 25/4/01 3:29 pm Page 1

User Guide
Brugsanvisning
Gebruiksaanwijzing
Notice d’utilisation
Benutzerhinweise
Manuale d’istruzioni
Brukerveiledning
Guia do Utilizador
Manual del usuario
Bruksanvisning
MIRAGE™
5543 Mirage User Guide 25/4/01 3:29 pm Page 2

Capsule
Ørekrog
Capsule
Capsule
Kapsel
Capsula
Kapsel
Cápsula
Cápsula
Bakstycke/stabilisator
Receiver
Modtager
Ontvanger
Récepteur
Empfänger
Ricevitore
Mottaker
Receptor Auricular
Receptor
Hörkapsel
Quick Disconnect™
Quick-stik (Hurtigfrakobling)
Quick Disconnect
(snelkoppeling)
Prise de déconnexion rapide
Quick Disconnect
Quick Disconnect
Schnellkupplung
Quick Disconnect
(scollegamento rapido)
Quick Disconnect
Ficha Ligar/Desligar Rápido
Quick Disconnect
Quick Disconnect
(snabbkoppling)
Clothing Clip
Tøjklips
Kledingklem
Pince
Kleidungs-Clip
Clip fermacavetto
Klesklype
Mola para Vestuário
Pinza de contacto con
la ropa
Klädesklämma
Voice Tube
Mikrofonrør
Spreekbuisje
Tube vocal
Sprechröhrchen
Tubo vocale
Talerør
Guia Vocal
Tubo de comunicación
Talrör
Glasses adapter
Brilleklips
Brilklem
Adaptateur pour lunettes
Brillenadapter
Fermaglio per occhiali
Brillefeste
Adaptador para óculos
Adaptador para gafas
Glasögonadapterk
Noise-Cancelling Microphone
Støjannulleringsmikrofon
Noise-Cancelling microfoon
Microphone directionnel
pour l'élimination des
bruits ambiants
Noise-Cancelling Mikrofon
Microfono a cancellazione
di rumore
Støydempingsmikrofon
Microfone Supressor
de Ruído
Micrófono con anulación
de ruidos
3
DIAGRAMS
1
1
2
3
4
5
6
7
6
7
5
4
3
2
1
5543 Mirage User Guide 25/4/01 3:29 pm Page 3

2
Fig. 1 Fig. 2 Fig. 3
Fig. 4 Fig. 5 Fig. 6a
Fig. 6b
Fig. 9
Fig. 7 Fig. 8
GB DIAGRAMS
5543 Mirage User Guide 25/4/01 3:29 pm Page 4

3
ADJUSTING THE EARPIECE
Fig. 1 Before you fit the headset onto your ear, move the receiver out
as far as possible.
Place the earhook over your ear and gently press the receiver
against your ear so it is ideally positioned for comfort and
call clarity.
ADJUSTING THE MOUTH PIECE
Standard Voice Tube Models
Fig. 2 The voice tube is adjustable in 2 ways. First it pivots at the metal
ball joint, and secondly the voice tube can be telescoped in
and out.
Hold the headset securely against your ear with one hand.
With your other hand, adjust the voice tube so that the tip sits
two finger-widths from the corner of your mouth. Your voice will
sound clearer if you avoid positioning the voice tube in front
of your mouth.
Noise-Cancelling Models
Fig. 3 Carefully shape the boom with both hands as shown. Do not
bend or twist the boom within 50mm of the microphone.
Fig. 4 Position the boom so that the microphone sits two finger-widths
from the corner of your mouth.
Make sure the front of the microphone faces your mouth.
If necessary, carefully rotate the microphone into the proper
position. Avoid repeated twisting of the boom.
POLARIS™ AND STARBASE®ADDITIONAL FEATURES
Polaris and StarBase Headset Models
Fig. 5 The Polaris and StarBase headset models are fitted with a
standard modular connector.
To use these models, simply insert the connector into the headset
port of a compatible telephone.
GB DIAGRAM KEY
5543 Mirage User Guide 25/4/01 3:29 pm Page 5

4
VOLUME ADJUSTMENT/MUTE SWITCH
Fig. 6 If you are using an M12 or E10 adapter there is a variable
volume control. Start with setting 4, then increase or decrease
the setting until you reach a comfortable listening volume.
You can prevent a caller from hearing your voice by pressing the
mute switch on the adapter. Voice contact can be retrieved by
pressing the switch again.
If you use an adapter please refer to the adapter user guide.
If you do not have an adapter these features will be controlled
by your telephone system. Please refer to the appropriate
user guide.
CLOTHING CLIP
Fig. 7 The clothing clip keeps the headset properly positioned by
supporting the weight of the cord. Attach the clothing clip
comfortably at chest height, making sure there is enough slack
to allow for head movement.
FITTING WITH GLASSES
Fig. 8 If you are wearing glasses you can use the glasses clip to help
make the headset feel more stable. Slip the clip onto your
glasses and attach the headset to the clip. If you are wearing
thinner metal frames, use the middle tab to help hold the clip
in place. Then you can attach the headset.
QUICK DISCONNECT™
Fig. 9 Some headsets are fitted with a Quick Disconnect connector.
Before you use your headset, join the adapter cable and the
Quick Disconnect together.
When you separate the Quick Disconnect, you put the ongoing
conversation ‘on hold’ without removing the headset.
To do this, grasp the Quick Disconnect as shown and pull
straight apart. To resume the call, reconnect the two halves.
DIAGRAM KEY GB
5543 Mirage User Guide 25/4/01 3:29 pm Page 6

5
GB TROUBLESHOOTING GUIDE
PROBLEM
Earpiece is uncomfortable
Headset is not fitted correctly. Check that the earhook is properly
positioned.
Move the receiver to different positions for ideal comfort.
PROBLEM
Callers cannot hear me
Blocked voice tube. Remove voice tube and speak into silver tube;
if you can now be heard, then replace voice tube.
Poor position of voice tube or microphone. Ensure voice tube is
positioned correctly (see fig 2).
Ensure noise cancelling microphone is positioned correctly
(see fig 4).
Transmit level too low. If you have an M12 or E10 adapter, turn
up the transmit volume on the side of the adapter until the caller
can hear you. Refer to the adapter user guide.
PROBLEM
I cannot hear callers/sudden loss of sound
Headset is not fitted correctly. Check that the earhook is
properly positioned.
Headset not plugged in correctly. Check that the Quick
Disconnect™ and other connectors are correctly plugged in.
Receive level too low. Turn up the receive volume control
on the adapter.
PROBLEM
Echo on line/hear my own voice
Transmit level too high. Adjust the transmit volume control. Refer
to your adapter or telephone equipment user guide for guidance.
5543 Mirage User Guide 25/4/01 3:29 pm Page 7

3
6
TROUBLESHOOTING GUIDE GB
MAINTENANCE HINTS FOR OPTIMUM PERFORMANCE
Replace voice tube every six months.
Clean the headset and cable with a moist cloth once a month.
If using a M12 amplifier, replace the batteries every six to nine months.
5543 Mirage User Guide 25/4/01 3:29 pm Page 8

7
DK OVERSIGT
JUSTERING AF ØRESTYKKET
Fig. 1 Inden du sætter hovedsættet på øret, flyttes modtageren udad så
meget som muligt.
Placér ørekrogen over øret og tryk forsigtigt modtageren mod dit
øre, indtil den yder maksimal hørelse.
JUSTERING AF MIKROFONRØRET
Modeller med standard mikrofonrør
Fig. 2 Mikrofonrøret kan justeres på 2 måder: Enten ved at dreje det
ved metalkuglesamlingen, eller ved at føre det teleskopiskt ind
og ud.
Hold hovedsættet fast mod dit øre med den ene hånd.
Justér mikrofonrøret med den anden hånd, således at spidsen
af mikrofonrøret sidder to finger- bredder fra mundvigen.
in stemme bliver tydeligere, hvis du undgår at placere
mikrofonrøret foran munden.
Modeller med støjannullering
Fig. 3 Mikrofonarmen formes forsigtigt med begge hænder som vist.
Mikrofonarmen skal bøjes eller drejes minimum 0,5cm fra
mikrofonen for at undgå beskadigelse.
Fig. 4 Mikrofonarmen placeres, således at mikrofonen sidder to
fingerbredder fra mundvigen.
Sørg for at mikrofonens forside vender mod din mund. Hvis det
er nødvendigt, drejes mikrofonen forsigtigt til den rigtige stilling.
Undgå at dreje mikrofonarmen igen og igen.
YDERLIGERE FUNKTIONER FOR POLARIS™ OG STARBASE™
MODELLERNE
Fig. 5 Polaris og StarBase modellerne er udstyret med et standard
modularstik.
For at bruge disse modeller, skal modularstikket tilsluttes
hovedsættets port på en kompatibel telefon.
5543 Mirage User Guide 25/4/01 3:29 pm Page 9

3
8
OVERSIGT DK
VOLUMEJUSTERING/MUTESWITCH
Fig. 6 Hvis du bruger en M12 eller E10 forstærker, er der en variabel
volumekontrol. Start med indstilling 4 og skru op eller ned, indtil
du opnår den mest behagelige lydstyrke.
Du kan forhindre opringeren i at høre din stemme, ved at trykke
muteknappen på forstærkeren ned. Lyden kan høres igen, ved at
trykke muteknappen op.
Hvis du bruger forstærker, se venligst forstærkerens
brugsanvisning.
Hvis du ikke bruger forstærker, justeres lyden direkte på din
telefon og mute switchen er som regel en knap på telefonen feks
‘vente’ eller ‘parkering’. Se venligst telefonanlæggets
brugsanvisning.
TØJKLIPS
Fig. 7 Tøjklipsen støtter ledningens vægt, og holder derved hovedsættet
på plads.
Sæt tøjklipsen fast på en for dig behagelig måde i brysthøjde, og
sørg for at der er nok slæk til hovedets bevægelse.
VED BRUG AF BRILLER
Fig. 8 Hvis du bruger briller, kan du bruge brilleklipsen til at gøre
hovedsættet mere stabil. Sæt klipsen fast på brillerne og sæt
hovedsættet på klipsen. Hvis du har et tyndt brillestel, kan du
bruge den midterste flig til at holde klipsen på plads med.
Derefter kan du sætte hovedsættet fast.
QUICK-STIK (HURTIGFRAKOBLING)
Fig. 9 Nogle hovedsæt er udstyret med et Quick-stik. Inden du tager
hovedsættet i brug, samles Quick-stikket.
Når du skiller Quick-stikket ad, sætter du den igangværende
samtale i ventestilling, uden at fjerne hovedsættet.
Dette gøres ved at gribe fat i Quick-stikket som vist, hvorefter det
trækkes fra hinanden. For at genoptage samtalen, kobles de to
halvdele sammen igen.
5543 Mirage User Guide 25/4/01 3:29 pm Page 10
