Plantronics Voyager®PRO
User Guide

ii
Welcome
Thank you for purchasing the Plantronics
Voyager PRO headset. This guide contains
instructions for setting up and using your
new headset.
Before using this product, please refer to the
For Your Safety guide for important product
safety and charging information.
Registering Your Product
Visit www.plantronics.com/productregistration
to register your product online so we can provide
you with the best service and technical support.
Getting Assistance
The Plantronics Technical Assistance Center
is ready to assist you. You can find answers to
frequently asked questions, ask a question
using e-mail, receive service over the Internet,
or speak directly with a representative.
Visit www.plantronics.com/support or call
1-866-363-BLUE (2583).
NOTE If you are considering returning
this headset, please contact the Technical
Assistance Center first.
NOTE For pairing your headset, your Passkey
(PIN code) is 0000.
Contents

iii
EN
Contents
Package Contents and Accessories ........................................... iv
Charging Your Headset ................................................................2
Checking the Battery Status ..............................................3
Automatic Battery Status Alerts .........................................3
Pairing Your Headset....................................................................4
How to Pair Your Headset with
Your Phone for the First Time ............................................4
Adjusting the Fit ...........................................................................6
Changing Eartips................................................................7
Headset Controls and Indicators..................................................8
Using More Than One Bluetooth Phone ....................................11
How to Initiate a Call ........................................................11
How to Answer a Call While Talking
on the Other Paired Phone...............................................11
Troubleshooting..........................................................................12
Product Specifications ...............................................................13
Limited Warranty ........................................................................14

iv
Package Contents and Accessories
Volume Up (+) and
Down (-) Buttons
Mute (press +/- buttons
simultaneously)
Micro USB Charging Jack
Dual Microphones with Wind Screens
Call Control Button

1
EN
Package Contents and Accessories
For a complete list of accessories available for purchase, go to www.plantronics.com.
Eartip
Status Indicator LED
Power On/Off
Check Battery Button AC Charger
(100-240v)
Soft Gel Eartips (S, M, L)
and Foam Eartip Covers

2
Charging Your HeadsetCharging Your Headset
Using the AC Charger
Your new headset performs best when fully
charged. Do not use your headset while it is
connected to the charger. While your headset is
charging, the indicator light glows red.
NOTE Always charge at near room temperatures;
never charge battery at temperatures below 0ºC
(32ºF) or above 40ºC (104ºF).
CHARGING TIME
1.5 hours ........................
Full charge
30 minutes .....................
Minimum charge
before first use
2
1

3
EN
Checking the Battery Status
To check the status, the headset must be powered
on. Tap the power button. The indicator light flashes
red to show the battery charge level.
Automatic Battery Status Alerts
When the battery charge is very low, a tone and
voice prompt in English will automatically occur.
Charging Your Headset
CHARGE INDICATOR LIGHTS
Red Flashes Battery Level
SMore than 2/3 full
S S 1/3 to 2/3 full
S S S Less than 1/3 full
LOW BATTERY WARNINGS
Battery Level Tone Voice Prompt
30 minutes of
talk time remaining
(this alert only
occurs during
an active call)
Double high
tone every
15 minutes
“Battery Low”
repeats every
30 minutes
10 minutes
of talk time
remaining
Triple high
tone every
30 seconds
“Recharge
Battery” repeats
every 3 minutes
Charging Your Headset

4
Pairing Your HeadsetPairing Your Headset
Before using your headset for the first
time, you must pair it with your Bluetooth®
enabled phone. Your new headset includes
Plantronics QuickPair™Technology to simplify
the Bluetooth setup process. The first time
you turn your headset on, your headset
automatically enters pairing mode for 10
minutes. Once paired successfully, your
headset stays on for instant use.
If not successfully paired after 10 minutes, your
headset automatically powers off. When you
turn the headset on again, it automatically goes
into pairing mode until successfully paired with
a Bluetooth phone.
NOTE This headset is equipped with Secure
Simple Pairing (SSP). If your phone supports SSP,
you will not need to enter a Passkey (PIN code).
How to Pair Your Headset with Your
Phone for the First Time
1 Turn on your phone’s Bluetooth feature.
For most phones, select Settings/Tools >
Connections > Bluetooth > On. See your
phone’s user guide for more information.
2 Turn the headset on.
Press and hold the power button until the
indicator LED flashes red/blue. The headset
is now in pairing mode.
If you don’t see the red/blue flash, press and
hold the power button to turn your headset
off, and then press and hold the power
button again until you see the red/blue flash.

5
EN
Pairing Your Headset
3 Use the commands on your phone to
locate your headset.
For most phones, select Settings/Tools >
Devices > Bluetooth > PROPlantronics.
See your phone’s user guide for more
information.
4 If prompted for the Passkey (PIN code),
enter 0000.
Pairing is successful when the indicator on
your headset flashes blue. Your headset is
now connected and ready to use.
NOTE To pair your headset with an additional
phone, turn on the phone then repeat steps 2
through 4.
2
1
SETTINGS
SETTINGS
Time and Date
Phone Settings
Bluetooth
Sound Settings
Network Services
Security
Reset Settings
3
4
BLUETOOTH
BLUETOOTH
Discover/
Search
BLUETOOTH
BLUETOOTH
PROPlantronics
PASSKE Y
0000
Pairing Your Headset

6
Adjusting the Fit
Ensure a proper fit for optimal sound clarity
and comfort.
1 Guide the earloop behind your ear and
place the headset so that the speaker
and eartip rest comfortably in your ear.
2 For optimal voice clarity, pivot the boom
up or down to point the microphones
toward the corner of your mouth.
The headset can be worn on either ear by
adjusting the mic boom.
1 Pivot the boom into an upright position.
2 Rotate the boom and speaker to the
other side of the headset.
2
1
1
2

7
EN
Adjusting the Fit
Changing Eartips
The headset comes with the medium eartip
installed, but you can replace it with the optional
small or large eartip provided.
1 To remove the eartip, grip the eartip with
your thumb and forefinger. Gently push
it into the speaker housing and rotate it
a quarter turn to the left. Gently lift the
eartip away from the headpiece.
2 To attach a new eartip, align the tabs on
the eartip with the slots on the speaker
housing. Gently push the eartip into
housing while turning it a quarter turn
to the right. The eartip will stop rotating
when it is attached.
NOTE The optional foam eartip cover can be
used for a more comfortable and stable fit.
1
2

8
Headset Controls and Indicators
Action Indicator LED Tone
Powering on/off Press power on/off
button 2 seconds.
On: blue glow for 2 seconds
Off: red glow for 2 seconds
On: ascending tones
Off: descending tones
Check if headset is
powered on
Tap call control button
or volume + or - button.
Short blue flash None
Call answer/end Tap call control button. None Single low tone followed
by low-low-high tones
Transfer a call from
headset to phone or
from phone to headset
While on a call, press
call control button for
1 second.
None Single followed by
double low tones
Reject call Press call control button
for 1 second during
incoming call.
None Single low tone
DURATION: TAP is under 1 second. PRESS is 1-4 seconds as directed.

9
EN
Headset Controls and Indicators
Action Indicator LED Tone
Missed call Tap any button to
clear indicator LED.
Triple purple flash
every 10 seconds for 5
minutes or until cleared
None
Mute
(during a call)
Press and hold
volume +and -buttons
simultaneously until you
hear status prompt.
Prompts only occur
during an active call.
None Mute on: sequence starts with the
high-low tones plus voice prompt
“Mute On” (in English). 15 minutes
later just the high-low tones advise
status. Full sequence repeats every
30 minutes until Mute is de-activated.
Mute off: high-low tones followed by
voice prompt “Mute Off” (in English).
Adjust the volume
(during a call)
Tap volume +or -
button.
Single blue flash Tone at each change in volume.
Double tone when min/max volume
level reached.
WARNING Do not use headsets at high volumes for an extended period of time. Doing so can cause
hearing loss. Always listen at moderate levels. See www.plantronics.com/healthandsafety for more
information on headsets and hearing.
DURATION: TAP is under 1 second. PRESS is 1-4 seconds as directed.

10
Headset Controls and Indicators
Action Indicator LED Tone
Redial Double-tap call
control button.
None Double low tone
Voice-activated redial
(if supported by phone)
Press call control
button for 1 second.
None Single low tone (phone
may then prompt you to
say a command)
Call indicator LED
(enable/disable)
With headset powered
on, press power,
volume +and - buttons
simultaneously for 1
second.
Turn indicator on: blue glow
increases for 2 seconds.
Turn indicator off: blue glow
fades for 2 seconds
Single low tone
Reconnect after leaving
Bluetooth range range for
more than 30 seconds
Tap call control button. Single blue flash Single low tone
DURATION: TAP is under 1 second. PRESS is 1-4 seconds as directed.

11
EN
Using More Than One Bluetooth Phone
Plantronics Voyager PRO supports multipoint
technology, which allows you to use one
headset with two different Bluetooth mobile
phones. To pair your headset to a second
phone, see “Pairing Your Headset” on page 4.
How to Initiate a Call
The headset initiates or redials a call on the
phone that most recently made an outgoing call.
To use the second phone, initiate the call using
the controls on that phone. The second phone
forms an active link with the headset.
NOTE The headset cannot place a current call
on hold while answering a call from the second
phone.
How to Answer a Call While Talking on
the Other Paired Phone
To answer a second call, the current call must
be terminated or transferred back to the first
phone. To transfer the call, see “Headset
Controls” on page 8.
NOTE If you choose not to answer the second
call, and you have voice mail on the second
phone, the call will go to voice mail.
1 Terminate the current call.
Tap the call control button.
2 Answer the second call.
Tap the call control button again.
TIP To avoid issues switching between calls,
use the call control button on the headset rather
than your phone controls.

12
Troubleshooting
My phone did not
locate the headset.
Turn both your phone and headset off and on, and then repeat the pairing process
on page 4.
I could not enter
my Passkey/PIN code.
Turn both your phone and headset off and on, and then repeat the pairing process
on page 4. Your Passkey (PIN code) is 0000.
I cannot hear
caller/dial tone.
The headset may not be turned on. Tap any button. If a blue light flashes then
the headset is on. If not, then press the power on/off button for approximately 2
seconds until you hear a tone or see the indicator glow blue.
Your headset battery may be drained. Charge your battery. See “Charging Your
Headset” on page 2.
Your headset was out of range from your phone for more than 30 seconds. Move
back into range and manually reconnect by pressing the call control button.
Callers cannot
hear me.
Make sure that the headset is sitting correctly in your ear with the microphone
pointing towards the corner of your mouth. See “Adjusting the Fit” on page 6.
Check that you have not activated the Mute feature. See “Headset Controls” on
page 9.

13
EN
Talk time* Up to 6 hours
Standby time* Up to 5 days or 120 hours
Range* Up to 33 feet (10 meters)
Headset weight 17.5 grams
Battery type Rechargeable, non-
replaceable lithium ion
polymer
Charge time 1.5 hours for full charge
Bluetooth version 2.1 + EDR (Enhanced Data
Rate) and Secure Simple
Pairing (SSP)
Bluetooth profiles Headset (HSP) and Hands-
Free (HFP)
Power
requirements
5V DC – 180 mA
Storage/operating
temperature
32ºF - 104ºF (0-40ºC)
Charging
temperature
32ºF - 104ºF (0-40ºC)
Product Specifications
* Performance dependent on battery and may vary by
device. Audio quality degrades as you move out of
range and is dependent upon the device with which
the headset is paired.

14
This warranty covers defects in materials and workmanship of products manufactured, sold or certified by
Plantronics which were purchased and used in the United States and Canada.
The warranty lasts for one year from the date of purchase of the products.
This warranty extends to you only if you are the end user with the original purchase receipt.
We will, at our option, repair or replace the products that do not conform to the warranty. We may use func-
tionally equivalent reconditioned/refurbished/remanufactured/pre-owned or new products or parts.
To obtain service in the U.S., contact Plantronics at 1-866-363-BLUE (2583). To obtain service in Canada call
[phone].
THIS IS PLANTRONICS’ COMPLETE WARRANTY FOR THE PRODUCTS.
This warranty gives you specific legal rights, and you may also have other rights that vary from state to state.
Please contact your dealer or our service center for the full details of our limited warranty, including items not
covered by this limited warranty.
Limited Warranty

15
EN
© Plantronics, Inc., 2009. Tous droits réservés. Plantronics, le logo Plantronics, Plantronics Voyager, QuickPair et
Sound Innovation sont des marques de commerce ou des marques déposées de Plantronics, Inc. Bluetooth®et les
logos Bluetooth sont des marques de Bluetooth SIG, Inc. utilisées sous licence par Plantronics. Les autres noms de
produit et de service sont la propriété de leur détenteur respectif.
Brevets : États-Unis 5 210 791; brevets en instance
80836-03 (03/09)
Plantronics, Inc.
345 Encinal
Santa Cruz, CA 95060
United States
Tel: [phone]
www.plantronics.com
©2009 Plantronics, Inc. All rights reserved. Plantronics, the logo design, Plantronics Voyager, QuickPair, and
Sound Innovation are trademarks or registered trademarks of Plantronics, Inc. The Bluetooth®word mark and logos
are owned by the Bluetooth SIG, Inc. and any use of such marks by Plantronics, Inc. is under license. All other
trademarks are the property of their respective owners.
Patents US 5,210,791; Patents Pending
81575-01 (03/09)
