Polar Electro CS Cadence Sensor W.I.N.D. User manual

User Manual
Cadence Sensor W.I.N.D.

max 4 mm / 0.16’’
A
1
2
3
4
C

Polar CS cadence sensor W.I.N.D. is designed
to measure cadence, i.e. crank revolutions per
minute when cycling. No other use is intended
or implied.
The latest version of this user manual can be
downloaded at www.polar.fi/support.
Please follow the pictures on the front cover.
Product Elements
1. Cadence Sensor (picture 1 A)
2. Cadence Magnet (picture 3 C)
Installing the Polar Cadence Sensor
For a video tutorial, go to
http://www.polar.fi/en/support/video_tutorials.
To install the cadence sensor and cadence
magnet, you need cutters.
1. Check the chain stay for a suitable place
for the cadence sensor. Do not install the
sensor on the same side as the chain. The
Polar logo on the sensor should be facing
away from the crank (picture 1).
2. Attach the rubber part to the sensor
(picture 2).
3. Clean and dry a suitable place for the
sensor and place the sensor on the chain
stay. If the sensor touches the rotating
crank, move the sensor slightly upwards.
Pass the cable ties over the sensor and
rubber part. Do not tighten them fully yet
(picture 3).
4. Place the cadence magnet vertically on the
inner side of the crank. Before attaching
the magnet, clean and dry the area
thoroughly. Attach the magnet to the crank
and secure with the tape (picture 3).
ENGLISH
1

5. Fine-tune the positioning of both the
cadence magnet and the sensor so that the
magnet passes close to the sensor without
actually touching it. The gap between the
sensor and the magnet should be under 4
mm/0.16’’.
The gap is correct when you can fit a cable
tie between the magnet and the sensor.
There is a small caved dot at the backside
of the sensor, which indicates the spot the
magnet should be pointing at when passing
the sensor (picture 4).
6. Rotate the crank to test the cadence
sensor. The flashing red light on the sensor
indicates that the magnet and the sensor
are positioned correctly. Tighten the cable
ties securely and cut off any excess cable
tie ends.
Cadence Sensor Teaching
Your new cadence sensor must be introduced to
your Polar training computer in order to receive
cadence data. This enables training in a group
without interference from other sensors.
The Polar training computer and sensor that
came with the product set have already been
synchronized but teaching is necessary when
you start using a new sensor.
For further information on teaching, refer to the
user manual of Polar training computer in
question.
ENGLISH
2

Care and Maintenance
Keep the cadence sensor clean. Clean it with a mild
soap and water solution, and rinse off with clean water.
Dry it carefully with a soft towel. Never use alcohol or
any abrasive material, such as steel wool or cleaning
chemicals. Do not immerse the cadence sensor in
water.
Your safety is important to us. Check that you can turn
your handlebars normally, and that the cable wires for
brakes or gears do not catch the sensor. Make sure the
sensor does not disturb pedaling or using the brakes or
gears. While riding your bike, keep your eyes on the
road to prevent possible accidents and injury. Avoid
hard hits as these may damage the sensor.
Cadence sensor battery
Contact your authorized Polar Service Center for a
replacement of cadence sensor. Polar recycles used
sensors. Please see the separate Polar Customer
Service Card for details.
ENGLISH
3

Frequently Asked Questions
What should I do if...
...the cadence reading is 0 or there is no cadence
reading while cycling?
• Make sure the position and distance of the cadence
sensor to the crank magnet are appropriate.
• Check that you have activated the cadence function
in the Polar training computer. For further
information, see Cadence Sensor Teaching.
• If the 0 reading appears irregularly, this may be due
to temporary electromagnetic interference in your
current surroundings.
• If the 0 reading is constant, you may have exceeded
3000 riding hours and the battery is empty.
...there are irregular cadence or heart rate readings?
• Disturbance may occur near microwave ovens and
computers. Also WLAN base stations may cause
interference when training with Polar cadence
sensor W.I.N.D. To avoid erratic reading or
misbehaviors, move away from possible sources of
disturbance.
Frame material may affect the transmission range.
Technical Specification
Operating temperature: -10 ºC to +50 ºC / +14 ºF to +122 ºF
Battery life: Average 3000 riding hours
Accuracy: ±1 %
Material: Thermoplastic polymer
Water resistance: Splash proof
ENGLISH
4

Limited Polar international Guarantee
• This guarantee does not affect the consumer’s
statutory rights under applicable national or state
laws in force, or the consumer’s rights against the
dealer arising from their sales/purchase contract.
• This limited Polar international guarantee is issued
by Polar Electro Inc. for consumers who have
purchased this product in the USA or Canada. This
limited Polar international guarantee is issued by
Polar Electro Oy for consumers who have purchased
this product in other countries.
• Polar Electro Oy/Polar Electro Inc. guarantees the
original consumer/purchaser of this device that the
product will be free from defects in material or
workmanship for two (2) years from the date of
purchase.
•The receipt of the original purchase is
your proof of purchase!
• The guarantee does not cover the battery, normal
wear and tear, damage due to misuse, abuse,
accidents or non-compliance with the precautions;
improper maintenance, commercial use, cracked,
broken or scratched cases/displays, elastic strap and
Polar apparel.
• The guarantee does not cover any damage/s, losses,
costs or expenses, direct, indirect or incidental,
consequential or special, arising out of, or related to
the product.
• Items purchased second hand are not covered by
the two (2) year warranty, unless otherwise
stipulated by local law.
• During the guarantee period, the product will be
either repaired or replaced at any of the authorized
Polar Service Centers regardless of the country of
purchase.
Guarantee with respect to any product will be limited to
countries where the product has been initially
marketed.
ENGLISH
5

This product is compliant with Directive 93/42/EEC.
The relevant Declaration of Conformity is available at
www.support.polar.fi/declaration_of_conformity.
This crossed out wheeled bin marking shows that Polar
products are electronic devices and are in the scope of
Directive 2002/96/EC of the European Parliament and
of the Council on waste electrical and electronic
equipment (WEEE) and batteries and accumulators
used in products are in the scope of Directive
2006/66/EC of the European Parliament and of the
Council of 6 September 2006 on batteries and
accumulators and waste batteries and accumulators.
These products and batteries/accumulators inside Polar
products should thus be disposed of separately in EU
countries. Polar encourages you to minimize possible
effects of waste on the environment and human health
also outside the European Union by following local
waste disposal regulations and, where possible, utilize
separate collection of electronic devices for products,
and battery and accumulator collection for batteries
and accumulators.
ENGLISH
6

Copyright © 2010 Polar Electro Oy, FIN-90440
KEMPELE, Finland.
Polar Electro Oy is a ISO 9001:2000 certified
company.
All rights reserved. No part of this manual may be used
or reproduced in any form or by any means without
prior written permission of Polar Electro Oy. The names
and logos marked with a ™ symbol in this user manual
or in the package of this product are trademarks of
Polar Electro Oy. The names and logos marked with a ®
symbol in this user manual or in the package of this
product are registered trademarks of Polar Electro Oy.
Disclaimer
The material in this manual is for informational
purposes only. The products it describes are subject to
change without prior notice, due to the manufacturer’s
continuous development program.
Polar Electro Inc./Polar Electro Oy makes no
representations or warranties with respect to this
manual or with respect to the products described
herein.
Polar Electro Inc./Polar Electro Oy shall not be liable
for any damages, losses, costs or expenses, direct,
indirect or incidental, consequential or special, arising
out of, or related to the use of this material or the
products described herein.
ENGLISH
7

Manufactured by
Polar Electro Oy
Professorintie 5
FIN-90440 KEMPELE
Tel [phone]
Fax [phone]
www.polar.fi
