POSBank AnyShop D5 User manual

1-5. Installation Recommendations
1. Avoid installing during thunderstorms. (Possibility of dangerous exposure to electricity.)
2. Install away from damp spaces or water-leaks.
3. Beware of static occurrence during installation.
4. Use only ground connected and quality certified power cords and cables.
5. Keep out of direct sun-light, extremely high or low temperatures, or high humidity areas.
6. Install product away from areas prone to shocks or vibration.
7. Install product away from sewing machines, welding equipment, electric stoves, audio equipment and other high frequency generating
equipment.
8. Installation and use in close proximity to an air-conditioning unit is not recommended.
9. Do not connect cables underneath carpets or floorboards.
10. Only use power cables supplied by pre-approved and certified venders.
11. Never use power cords from high power source appliances.
e.g. Electronic heaters, Electric stoves, Audio equipment, Air-conditioners, Refrigerators etc.
12. The use of multiple connections in a shared power outlet/socket is not recommended.

Chapter 2. Product Overview
2-1. Inside Your Package
1. Please check your package and confirm its contents.
2. The POS terminal main unit, power cable, user manual and driver CD are included in the package. If any items are missing or damaged,
please contact your dealer for assistance.
.

[Package Contents]
AnyShop_D5 main unit
Driver CD
User manual
Power cable

[Optional Devices]
[12 inch LCD Monitor]
[Front] [Rear]
[Customer Display (CDP)]
[Front] [Rear]

2-2. Pre-installation Preparation
1. Remove protective film from touch-screen to prevent possible operating difficulties.
2. Attach all optional parts before setting up the main POS unit.
2-3. Product Outline
- Each part of product may differ depending on the specific POS model.

[Front View]
Magnetic Stripe Reader
(MSR)
LCD & Touch-
panel display
Power LED
Power switch
Dual speakers
HDD LED
LAN LED
Smart Card Reader (SCR)

[Rear View]
Customer display (CDP)
- optional
HDD
I/O port
Stand
USB port

[Power & I/O Ports]
Description
Description
1
Power connector
6
Ethernet port (LAN)
2
PS/2 mouse connector
7
USB port
3
PS/2 keyboard connector
8
Cash box port
4
COM1, COM2, COM3 port
9
LPT port
5
VGA/monitor port
2 6 8
1 3 4 5 7 9

2-4. Installation of Optional Devices
[CDP Installation] Warning: Completely remove AC power cable when opening main unit or installing optional devices.
1. Insert (-) driver in the grooves marked: and detach cover from rear
of main unit.
2. Connect to the main unit using the CDP-cable and
insert the display in customer display space.
3. Testing: CDP is successfully installed when system boots
after powering on.
(CDP and 12 inch LCD monitor are used only with the COM4 port.)

[2nd Display Installation: 12 inch LCD Monitor]
1. Remove both screws as shown above and remove cover.
2. Replace standard cover with “Optional Cover”and reinsert screws.

3. Use 2nd display cable to connect monitor to main unit.
4. Place monitor into frame and insert the 4 screws as shown.
5. Use the 2 remaining screws to secure the unit, and finally
replace the cover.

6. Testing: CDP is successfully installed when system boots
after powering on.
(CDP and 12 inch LCD Monitor are used only with COM4 port.)
Warning: Completely remove AC power cable when
opening main unit or installing optional devices.
2nd display installation complete

[Keyboard & Mouse Connection]
1. Keyboard connection: PS/2 type keyboard.
2. Mouse connection: PS/2 type mouse.

[Connection via USB Port]
Four USB ports are provided in the POS unit, two at the rear I/O and two at the side, all of which support the standard USB 2.0.
Some USB devices (optional devices) are only functional with specific driver software installed.
If multiple USB devices are used together, this may result in abnormal functionality.
Using a USB hub with external adapter for supplying power is recommended.
Dependent on the type of device, it is possible for the USB device to be recognized later than normal.

[Connection via Ethernet Port (LAN)]
The Ethernet port located at the rear I/O supports 10/100/1000Mbps using an RJ45 connector cable.
When connected properly, the LAN LED light will be switched on.

[Connection via Line-in Port]
1. Speaker connection
2. Microphone connection

[Printer Connection]
Connect printer cable to either Serial, Parallel or USB port as required.

[Power Cable Connection]
Insert power cable into power connector socket.
INPUT: 100-240V~,50/60Hz 1.5A OUTPUT: DC 12V 5A

2-5. Basic Operations
[Switching On POS]
»NB: Switch on all peripheral units prior to powering on POS main unit.
1. Press POWER button on the POS unit. (POWER LED will light up.)
2. Confirm that Windows loads correctly.
