POSIFLEX PST-1000 Series User manual

TM
Rev. : A
L1L1
L0L0 LPLP
L2L2 L3L3 L4L4
PST-1000 SERIES
TECHNICAL MANUAL

TM
SOME IMPORTANT NOTES
FCC NOTES
This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions manual, may cause interference to radio communications.
It has been tested and found to comply with limits for a Class A digital device pursuant to subpart J of
Part 15 of FCC Rules, which are designed to provide reasonable protection against interference when
operated in a commercial environment. Operation of this equipment in a residential area is likely to
cause interference in which case the user at his own expense will be required to take whatever measures
to correct the interference.
WARRANTY LIMITS
Warranty will terminate automatically when the machine is opened by any person other than
the authorized technicians. The user should consult his/her dealer for the problem happened. Warranty
voids if the user does not follow the instructions in application of this merchandise. The manufacturer is
by no means responsible for any damage or hazard caused by improper application.
ABOUT THIS MANUAL
This manual assists the user especially the software programmer who provides the software
system for POS application to utilize the hardware of the PST1000 series that is a member of the
POSIFLEX integrated point-of-sale terminal product family. The PST1000 is a compact point-of-sale
system that gives the most user friendly upgrade transition from ECR and combines the performance
and affordability of personal computers with the elegance and reliability of business machine. The
PST1000 also provides the built-in networking capability for easy communication among multiple
terminals in addition to the data transfer and control through back office server.
The manufacturer of the PST1000 series heartily apologizes to the user for reserving the right
to change or to modify this manual without notice due to the rapid and constant progress and
improvement on science and technology. The user may always obtain the most up to date information
through our web site: http://www.mustekposiflex.com.tw or http://www.posiflex.com.tw
©Copyright Mustek Corp. 1998
All rights are strictly reserved. No part of this documentation may be reproduced, stored in a retrieval
system, or transmitted in any form or by any means, electronic, mechanical, photocopying, or otherwise,
without the prior written consent of Mustek Corp. the publisher of this documentation.
TRADE MARKS AND SERVICE MARKS
POSIFLEX is a registered trademark of Mustek Corp..
Other brand and product names are trademarks and registered trademarks and service marks of
their respective owners.

i
TM
TABLE OF CONTENTS
OVERVIEW. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 1
SCOPE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 1
FEATURES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 1
MODEL NUMBERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 2
GENERAL SPECIFICATIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 1
SYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 1
POWER SOURCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 1
SYSTEM POWER ON/OFF CONTROL. . . . . . . . . . . . . . . . . . . 2 - 1
OPERATOR DISPLAY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 2
LCD −OD-300 for PST 1000. . . . . . . . . . . . . . . . . . . . . . 2 - 2
CRT display (VGA interface)-for PST 1010 . . . . . . . . . . 2 - 2
UPS SUPPORT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 3
PROGRAMMABLE KEYBOARD. . . . . . . . . . . . . . . . . . . . . . . . 2 - 3
INPUT / OUTPUT PORTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 4
SSD MEMORY WITH HDD EMULATION . . . . . . . . . . . . . . . . . 2 - 4
24VDC POWER SUPPLY TO POS PRINTER . . . . . . . . . . . . . 2 - 4
PRELOAD DOS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 4
LED COLOR. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 5
EXTERIOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 5
ENVIRONMENTAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 5
ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 6
OPTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 6
CUSTOMER DISPLAY. . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 6
MAGNETIC STRIPE READER . . . . . . . . . . . . . . . . . . . . 2 - 7
Reader application. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 7
Card data format. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 7
TWO EXTRA COM PORTS FOR PST1000. . . . . . . . . . 2 - 7

ii
TM
KEY TOP OPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 8
UPS BATTERY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 8
PRINTER: PP-3000. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 8
INTERNAL MODEM CARD . . . . . . . . . . . . . . . . . . . . . . . 2 - 8
HDD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 8
RELIABILITY SPECIFICATION . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 1
SYSTEM DEFINITIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 1
BLOCK DIAGRAM. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 1
EXTERNAL KEYBOARD CONNECTOR . . . . . . . . . . . . . . . . . 4 - 2
LAN PORT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 2
CRT DISPLAY PORT CONNECTOR. . . . . . . . . . . . . . . . . . . . . 4 - 2
SERIAL PORT COM1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 3
SERIAL PORT COM2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 4
SERIAL PORT COM3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 4
SERIAL PORT COM4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 5
CASH DRAWER CONTROLLER . . . . . . . . . . . . . . . . . . . . . . . 4 - 5
PARALLEL PORT LPT1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 6
CUSTOMER DISPLAY CONNECTOR . . . . . . . . . . . . . . . . . . . 4 - 7
24 VDC CONNECTOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 7
UPS BATTERY CONNECTOR. . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 7
APPLICATION GUIDES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 1
OPERATOR DISPLAY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 1
CRT MONITOR (PST1010) . . . . . . . . . . . . . . . . . . . . . . . 5 - 1
LCD DISPLAY (OD-300 FOR PST1000) . . . . . . . . . . . . 5 - 1
EPSON command mode (power on default). . . . . . . . . . . . . 5 - 2
PST command mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 3
CUSTOMER DISPLAY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 4

iii
TM
PD-101 (LED DISPLAY). . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 5
PD-201 (LCD DISPLAY). . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 6
EPSON command mode (power on default). . . . . . . . . . . . . 5 - 6
PST command mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 7
PD-2101 (VFD DISPLAY). . . . . . . . . . . . . . . . . . . . . . . . . 5 - 8
Futaba emulation mode. . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 9
Noritake emulation mode . . . . . . . . . . . . . . . . . . . . . . . . 5 - 10
Aedex emulation mode. . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 10
Epson emulation mode (power on default). . . . . . . . . . . . . . 5 - 11
PD-7001 (LCD DISPLAY). . . . . . . . . . . . . . . . . . . . . . . . . 5 - 12
Jumper settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 12
Epson mode −2 lines x 20 characters. . . . . . . . . . . . . . . . . 5 - 13
Noritake mode −2 lines x 20 characters. . . . . . . . . . . . . . . 5 - 15
Epson mode −4 lines x 26 characters. . . . . . . . . . . . . . . . . 5 - 18
PROGRAMMABLE KEYBOARD. . . . . . . . . . . . . . . . . . . . . . . . 5 - 20
HOT KEY PROGRAMMING. . . . . . . . . . . . . . . . . . . . . . . 5 - 20
Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 20
Enter “Hot key programming” mode . . . . . . . . . . . . . . . . . 5 - 20
Input the content to be programmed . . . . . . . . . . . . . . . . . 5 - 21
Exit “Hot key programming” mode. . . . . . . . . . . . . . . . . . 5 - 21
COMMON PROGRAMMING (KBM.EXE). . . . . . . . . . . . 5 - 22
Command listing in view mode . . . . . . . . . . . . . . . . . . . . 5 - 22
Command listing in ASCII-code editing mode. . . . . . . . . . . 5 - 23
Command listing in SCAN-code editing mode. . . . . . . . . . . 5 - 24
ANSWER BACK CODE . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 25
SHORTCUT UTILITY (RWM.EXE) . . . . . . . . . . . . . . . . . 5 - 25
HARDWARE LIMITATION. . . . . . . . . . . . . . . . . . . . . . . . 5 - 26
SSD MEMORY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 27
POWER ON/OFF CONTROL. . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 28
EXTERNAL POWER SWITCH . . . . . . . . . . . . . . . . . . . . 5 - 28
SOFTWARE SWITCH OFF. . . . . . . . . . . . . . . . . . . . . . . 5 - 28
CASH DRAWER. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 29
UPS BATTERY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 29

iv
TM
HARDWARE DETAILS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 1
MAIN BOARD (PST888). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 1
PCB LAYOUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 1
CONNECTORS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 2
JUMPER SETTINGS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 4
CPU select. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 4
CPU voltage select. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 4
CLOCK select . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 5
RTC select. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 5
Customer display hardware handshake select. . . . . . . . . . . . 6 - 5
COM1 DC select. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 5
COM2 DC select. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 5
PROGRAMMABLE KEYBOARD. . . . . . . . . . . . . . . . . . . . . . . . 6 - 6
CONTROL BOARD LAYOUT. . . . . . . . . . . . . . . . . . . . . . 6 - 6
CONNECTORS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 6
JUMPER SETTINGS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 7
MODIFICATION FOR MSR . . . . . . . . . . . . . . . . . . . . . . . 6 - 7
Adding an ISO MSR . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 7
VGA CARD (PST023) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 8
SERVICE AND SPARE PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 1
SERVICE GUIDE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 1
OPENING THE KEYBOARD . . . . . . . . . . . . . . . . . . . . . . 7 - 1
DETACHING THE REAR CABINET . . . . . . . . . . . . . . . . 7 - 5
SPARE DRAWING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 8
ASSEMBLY DRAWING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 11

v
TM
APPENDIX—Font Tables For Posiflex Customer Displays . . . . . Appendix- 1
CONTENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Appendix- 2
FONT FOR OD-300 . . . . . . . . . . . . . . . . . . . . . . . . . . . Appendix- 3
FONT FOR OD-300JPN . . . . . . . . . . . . . . . . . . . . . . . Appendix- 4
FONT FOR PD-201 . . . . . . . . . . . . . . . . . . . . . . . . . . . Appendix- 5
FONT FOR PD-201JPN. . . . . . . . . . . . . . . . . . . . . . . . Appendix- 6
FONT FOR PD-2101 PAGE 0. . . . . . . . . . . . . . . . . . . Appendix- 7
FONT FOR PD-2101 PAGE 1. . . . . . . . . . . . . . . . . . . Appendix- 8
FONT FOR PD-2101 EPSON PAGE 0. . . . . . . . . . . . Appendix- 9
FONT FOR PD-2101 EPSON PAGE 1. . . . . . . . . . . . Appendix-10
FONT FOR PD-7001 PAGE 0. . . . . . . . . . . . . . . . . . . Appendix-11
FONT FOR PD-7001 PAGE 1. . . . . . . . . . . . . . . . . . . Appendix-12
FONT FOR INTERNATIONAL CHARACTER SET. .Appendix-13

vi
TM

PST-1000 series Technical Manual 1 - 1
TM
OVERVIEW
SCOPE
The PST1000 series is a series of fully integrated PC based point-of-sale
terminals. This series provides the most user-friendly environment for ECR upgrade
with its powerful capability from PC. This series also provides a powerful
programmable keyboard with 112 key-sites of a comfortable size 18 x 22 mm in 8 x
14 matrix and a 6 position control key which is capable of sending answer back codes
according to the position of the key.
FEATURES
lHighest security for business machine
lGreatest User’s convenience and easiest software programming
lHighest profitability for end users
lBest compatibility and flexibility to any hardware / software application
lHighest performance in most compact size point-of-sale system
lMost cost effective with top quality, reliability and serviceability of point-
of-sale system at reasonable price
lPowerful programming ability (hot key programming, programming under
Windows, multiple page, multiple level, whole range key content, time
delay, position sense answer back code covering most ECR functions, etc.)
lBuilt-in UPS function to support the system from intermittent power
failure
lAccidental power off protection – only power on or software controlled
power off function accessible from exterior of the system. This feature,
together with the UPS function, provides a data-loss-free environment.

PST-1000 series Technical Manual 1 - 2
TM
MODEL NUMBERS
Customer Display
Operator
(Cashier) Display
OPTIONAL CUSTOMER DISPLAY:
PD-101, PD-201 or PD-2101
or PD-7001 series
9” monochrome
CRT DISPLAY PST1010
OD-300 -- 2 * 20
LCD DISPLAY PST1000

PST-1000 series Technical Manual 2 - 1
TM
GENERAL SPECIFICATION
SYSTEM
lCPU speed : 486DX4-100
l4 MB DRAM (expandable to 32 MB max. option)
l3.5” FDD 1.44 MB
lBuilt-in IDE interface supports up to mode 4
lTwo half-length ISA expansion slots and one half-length PCI expansion
slot for the model without CRT display. One (ISA) slot will be occupied if
the CRT display is used.
lDCI Technology for best compatibility of input devices
Non-volatile Solid State memory 2MB with HDD emulation (expandable to 16
MB max. option)
POWER SOURCE
Item Specification
High range of voltage input 180 ~ 264 Vac
Low range of voltage input 90 ~ 130 Vac
Input frequency 47 ~ 63 Hz
Power consumption of 9” mono CRT types: 43W nom., 52W max..
Power consumption of LCD types: 31W nom., 38W max..
Note on power consumption measurement: measured without printer.
SYSTEM POWER ON/OFF CONTROL
lOne main power ON/OFF push switch hidden inside front door area for
direct drive on PSU
lOne ON (controlled ON/OFF) switch at right end of front edge of the
system
lPosition LP of the 6 position lock can be programmed as the software
shutdown control according to POSIFLEX standard

PST-1000 series Technical Manual 2 - 2
TM
OPERATOR DISPLAY
LCD (RS232 interface)– OD-300 for PST 1000
Display Type monochrome STN – 2 * 20 LCD
View area 149 * 23 mm
Resolution 5*7 dot matrix
Character color Dark blue
Back-light color Yellow-green
View angle (V) 10°to 40°(for CR ≥2)
View angle (H) -30°to 30°(for CR ≥2)
Swivel range 45°left, 30°right
Tilt angle 90°max
Power source included in display connector
CRT display (VGA interface)– for PST 1010
Display Type 9” monochrome CRT 10” color CRT
Size 228 mm (9”) diag. 175 (6.9”) * 125 (4.9”)
mm
Resolution 800 * 600 max. 1024 * 768 max.
Position movable range Back & forth: 48mm (1.890”) max.
Left to right: 30mm (1.181”) max.
Swivel range 90°left, 90°right
Tilt angle 20°max.
Power source
(UPS supported) included in VGA display connector AC input from output outlet of system power
Video memory 512 KB
Note: For 10” color monitor, the AC power is used instead of the UPS supported DC
power source in the VGA display connector. Hence, the 10”color monitor is not
supported by the UPS function while the 9” mono monitor is supported.

PST-1000 series Technical Manual 2 - 3
TM
UPS SUPPORT (battery not included)
lSupports system operation for 5~10 min. depending on loading condition
of 24V printer and whether the UPS battery is fully charged
lSTANDBY LED turned on when UPS stand-by at power on or AC power
present during system off
lSTANDBY LED flashes and system beeps when UPS starts working and
discharging
PROGRAMMABLE KEYBOARD
lSpill-proof construction
lExtension keyboard wedge connector
lTransparent key caps over key tops
l6 position key switch control, with key extractable at L0 and L1
lSecurity Key lock function locks up whole keyboard port
l5 pages of programmable key definitions defined by 6 position key switch
l112 sites max. of fully programmable keys for each page
l255 bytes max. can be programmed for each key
lTotal memory for keys to be programmed: 8 KB
lProgrammable under DOS, Windows 3.1, or Windows95 without TSR or
DLL program
lMulti-page programming
lMulti - level programming
lTime - delay programming
lHot key programming (teach & learn)
lAnswer back signal when position key changed or when enquired.
lStandard layout includes one quad key, two double keys, 12 numeric keys
00 0~9 and 92 single keys

PST-1000 series Technical Manual 2 - 4
TM
INPUT / OUTPUT PORTS
l1 X LAN port (Ethernet 10 base T)
lFor PST 1010, 4 X serial communication ports with COM1 capable of
supporting 5 V DC while each of the rest capable of supplying both DC
+5V and DC +12V at 1A. Default setting is +5 V DC for COM1 and no
DC output for all other ports.
lFor PST 1000, only one serial port (COM2) can be used freely, (COM1 is
used for both cashier and customer display and +5V DC output is default).
l1 X parallel port
lOne independent control for a dedicated cash drawer
l1 X VGA display port with UPS supported DC supply for cashier display
on PST 1010
l1 X 24 VDC / 2 Amp. supply
lUPS connector for 2.3AH/12V Lead Acid battery or above
SSD MEMORY WITH HDD EMULATION
l2MB standard
lTwo memory sockets to support 2 memory modules
lEach memory module can be 2MB,4MB,8MB
lMax SSD memory up to 16MB
24VDC POWER SUPPLYTO POS PRINTER
lUPS supported
l24 +/- 1.2 VDC at 2 AMP load
lMax. ripple + noise: 240 mV
lAccessory: cable CCBLA-146
PRELOAD DOS

PST-1000 series Technical Manual 2 - 5
TM
LED COLOR
lPOWER LED: green
lSTANDBY INDICATOR: yellow
lMSR INDICATOR: dual color (green for good reading, red for invalid
reading)
EXTERIOR
lDIMENSIONS:
WIDTH: 408 mm (16.1”)
DEPTH: 465 mm (18.0”)
HEIGHT: 228 mm (9.0”) for LCD models (with OD300)
379 mm (14.9”) for CRT models (with 9” mono)
lWEIGHT
12.5Kg for CRT models
8.0Kg for LCD models
ENVIRONMENTAL
lTemperature range:
Operating: 0°C~ +40°C
Non-operating: -20°C ~ +70°C
lHumidity range:
Operating: 20%RH ~ 80%RH, non-condensing max. wet bulb 26°C
Non-operating: 10%RH ~ 80%RH, non-condensing max. wet bulb 28.9°C

PST-1000 series Technical Manual 2 - 6
TM
ACCESSORIES
lUSER’S MANUAL: 1 COPY
lELECTRONIC KEY FOR PROGRAMMABLE KEYBOARD : 4 PCS (1
SET)
lMECHANICAL KEY FOR FRONT DOOR: 2 PCS
lPST LEGEND SHEET IN 4 COLORS
lCABLE FOR CASH DRAWER CONTROL (CCBLA-180 FOR CR-3100
/ CR3200)
lDISKETTE FOR DRIVER UTILITY
lCOM 1 TERMINATOR FOR PST 1010
lVFD TERMINATOR
lPOWER CORD
OPTIONS
CUSTOMER DISPLAY
MODEL Number PD101 PD201 PD2101 PD7000 series
Display Media LED LCD VFD LCD
Number of rows 1 2 2 2 or 4
Characters per row 8 16 20 10 or 20 or 26
Character width (mm) 12.5 4.8 7.2 8.35 or 17.95
Character height (mm) 14.2 8.0 11.25 8.35 or 17.95
Character in dot matrix
format 7 segments 5 X 7 5 X 7 8 x 16, 16 x 16 or 6 x 8
Character color Green Dark blue Green
505 nm Dark blue
Horizontal slide (mm) N.A. N.A. 95 95
Horizontal rotation 360°360°360°360°
Inclined viewing angle 60°/8 60°/8 14.5°and 30°14.5°and 30°
Display area
(mm x mm) 100.2 x 14.2 99 x 24 216 x 32 196 x 42.4
Remark : PD101 has 7 status indicator LED lamp

PST-1000 series Technical Manual 2 - 7
TM
MAGNETIC STRIPE READER
Reader application
Applicable card type ISO 7811 JIS X6302
Card feed method Manual Manual
Card feed direction Bi-direction Uni-direction
Card feed speed 5 ~ 55 IPS 100-1200mm/sec
Read / write function Read only Read only
Life of head Approx. 300,000 passes 300,000 passes
Error rate Less than 0.5% Less than 0.1%
Available models Tracks 1 & 2 or tracks 1, 2 & 3 JIS - II
Card data format
Card standard IATA ABA THRIFT JIS I JIS - II
Track used Track 1 Track 2 Track 3 Track 2 Rear side
Recording method F2F
(FM) F2F (FM) F2F (FM) F2F (FM) F2F (FM)
Recording density 210 BPI 75 BPI 210 BPI 35 BPI 210 BPI
Recording capacity
(characters / bits) 79 / 7 40 / 5 107 / 5 40 / 5 72 / 7
TWO EXTRA COM PORTSFOR PST1000
lCOM3 & COM4 BOTH CAPABLE OF SUPPLYING +5 VDC
AND +12 VDC POWER WHILE DEFAULTED TO GIVE
NO DC OUTPUT
lTHIS OPTION COMES WITH A VGA PORT AS WHAT IS FOR
PST1010

PST-1000 series Technical Manual 2 - 8
TM
KEY TOP OPTION
lQUAD KEY
lDOUBLE KEY
lSINGLE KEY
lBLANK KEY
UPS BATTERY
l2.3 AH/12V Lead Acid battery
PRINTER: PP-3000
lDOT MATRIX 9 PIN
lHIGH SPEED BI-DIRECTIONAL
lFRICTION TYPE
l40 COLUMNS FOR 15.4 CPI
lACCEPTS PAPER WIDTH 2.25/3/3.25 INCHES WITH
ADJUSTABLE PAPER GUIDE
lPRINTS ON ORDINARY OR UP TO 3-FOLD CARBONLESS
COPY PAPER
INTERNAL MODEM CARD
lAFM100 – CUSTOMIZED SIZE TO FIT INTO THE SYSTEM
HDD
l850MB AND ABOVE

PST-1000 series Technical Manual 3 - 1
TM
RELIABILITY SPECIFICATION
lPOWER SUPPLY MTBF: 50,000 HRS
lMONITOR MTBF: 30,000 HRS
lFDD MTBF: 30,000 HRS
lSSD MEMORY DATA HOLD TIME: 100 YRS
lVFD LIFE EXPECTANCY: 30,000 HRS
lLCD PANEL LIFE EXPECTANCY: 50,000 HRS
lLCD BACK LIGHT LIFE EXPECTANCY: 20,000 HRS
lMSR LIFE EXPECTANCY: 300,000 PASSES
lKEY SWITCH LIFE EXPECTANCY: 10,000,000 STROKES
l6 POSITION KEY LIFE EXPECTANCY: 25,000 TIMES

PST-1000 series Technical Manual 3 - 2
