PotteryBarn Display Shelf Galvi 52 In User manual

Display Shelf Galvi 52 In
Mounting Instructions
This item includes three metal Brackets and one galvi shelf.
Max. Load: Under Testing
Note: Assembly by two people recommended. Open the box safely and unpack all the included items. Do not discard
packing until assembly is completed.
Hardware Included: (6) Snap-screw, (6) Screws, (3) Allen Screw, (1) Allen Key
Tools Needed: Phillips Screwdriver, Pencil, Stud-Finder and Leveler.
1.Place the shelf on the floor so that holes provided on
the shelf match from the through holes provided on the
brackets, insert allen screw and tight with the help of
Allen key provided as shown in the illustration. Similarly,
attach rest two brackets.
2. Now, hold the shelf as per illustration in upright
position so that it is level against a wall at a desired
mounting location. Use a pencil to mark the wall through
each of the six mounting holes. Set the shelf aside and
unscrew the shelf from the brackets with the help of allen
key provided.
3. The provided Snap-screw cannot penetrate wood
studs. Therefore we have to determine if any of the six
marks of Step (2) happens to align with a wall stud. Use
a stud-finder to determine this. If any mark does align
with a stud, use a screwdriver to secure a provided
screw into the wall at this mark when instructed to do so
below.
4. For marks that do not align with a wall stud, use a
screwdriver to install a provided Snap-screw into the wall
at the mark. Engage the head of the Snap-screw with
the screwdriver and position the Snap-screw’s tip at the
mark. Rotate the Snap-screw clockwise while pushing it
firmly into the wall. The Snap-screw will automatically
drive itself into the wall. Continue rotating until the wide
end of the Snap-screw becomes even with the wall
surface. Do not over-tighten.
5. Now hold the brackets to the wall so that the holes in
the brackets align with either installed Snap-screw or a
stud. Use a screwdriver to secure a screw through each
hole and into the installed Snap-screw or stud. Rotate the screws clockwise until tight. Similarly attach rest
brackets.
6. Now place the shelf on installed brackets securely and match the through holes of the brackets to the
holes provided on the bottom of shelf, insert allen screws and tight with the help of Allen key provided as
shown in the illustration.
Assembly is complete.
The hardware included with this item is meant for
drywall mounting only. If your wall is made from
another material such as concrete or plaster,
please consult your local hardware store for
assistance in selecting the correct hardware.

Care Instructions:
Wipe with a soft, dry cloth. Do not use any abrasive or chemical household cleaners.
Thank you for your purchase!
Stores | Catalog | www.potterybarn.com
WARNING!
DO NOT MOUNT THIS ITEM ABOVE CRIBS, BEDS,
or CHANGING TABLES.
