Power Fist 8622946 User manual

V 4.3 8622946
Please read and understand all instructions before use. Retain this manual for
future reference.
User Manual
196cc Plate Compactor

8622946 196cc Plate Compactor V 4.3
2 For technical questions call 1-800-665-8685
SPECIFICATIONS
Compacting Plate Dimensions (LxW) 20-7/8 x 14-5/8 in.
Vibrations/Minute 5,500 VPM
Travel Speed 82 ft/min
Compaction Force 2,473 lb
Compaction Depth 9-3/4 in.
Compaction Area/Hour 6,002 sq. ft
Water Tank Volume 3.7 gallons (14 litres)
Operation Weight 139 lb (63 kg)
INTRODUCTION
The 196cc plate compactor is designed to compact granular soils, crushed aggregate,
asphalt, paving stones, bricks and other materials. Ideal for smaller jobs like trenches,
retaining walls and other tight areas that don't require as much compaction.
The plate compactor comes with a 3.7 gallon water tank with spray bar for use on
asphalt and to help control dust. The paving pad prevents the compactor from
damaging or scuffing concrete pads, paving stones, bricks etc. The folding wheel kit
simplifies the task of moving the compactor around the jobsite and the handle folds
down for easy storage.
A separate engine manual is included. Please consult it when necessary.
SAFETY
WARNING! Read and understand all instructions before using this tool. The
operator must follow basic precautions to reduce the risk of personal injury
and/or damage to the equipment.
196cc Plate Compactor

V 4.3 196cc Plate Compactor 8622946
Visit www.princessauto.com for more information 3
Keep this manual for safety warnings, precautions, operating or inspection and
maintenance instructions.
HAZARD DEFINITIONS
Please familiarize yourself with the hazard notices found in this manual. A notice is
an alert that there is a possibility of property damage, injury or death if certain
instructions are not followed.
DANGER! This notice indicates an immediate and specific hazard that will result in
severe personal injury or death if the proper precautions are not taken.
WARNING! This notice indicates a specific hazard or unsafe practice that could
result in severe personal injury or death if the proper precautions
are not taken.
CAUTION! This notice indicates a potentially hazardous situation that may result
in minor or moderate injury if proper practices are not taken.
NOTICE! This notice indicates that a specific hazard or unsafe practice will
result in equipment or property damage, but not personal injury.
WORK AREA
1. Operate in a safe work environment. Keep your work area clean, well lit and
free of distractions.
2. Keep anyone not wearing the appropriate safety equipment away from the
work area.
3. Store unused tools properly in a safe and dry location to prevent rust or
damage. Lock tools away and keep out of the reach of children.
4. Do not install or use in the presence of flammable gases, dust or liquids.
PERSONAL SAFETY
WARNING! Wear personal protective equipment approved by the Canadian
Standards Association (CSA) or American National Standards Institute (ANSI).
PERSONAL PROTECTIVE EQUIPMENT
1. Always wear impact safety goggles that provide front and side protection for
the eyes. Eye protection equipment should comply with CSA Z94.3-07 or ANSI
Z87.1 standards based on the type of work performed.

8622946 196cc Plate Compactor V 4.3
4 For technical questions call 1-800-665-8685
2. Wear gloves that provide protection based on the work materials or to reduce
the effects of tool vibration.
3. Wear protective clothing designed for the work environment and tool.
4. Non-skid footwear is recommended to maintain footing and balance in the
work environment.
5. Wear steel toe footwear or steel toe caps to prevent a foot injury from
falling objects.
6. Wear a NIOSH approved respirator when working on materials that produce
hazardous fumes, dust or particulate matter.
7. This tool can cause hearing damage. Wear hearing protection gear with an
appropriate Noise Reduction Rating to withstand the decibel levels.
PERSONAL PRECAUTIONS
Control the tool, personal movement and the work environment to avoid personal
injury or damage to tool.
1. Do not operate any tool when tired or under the influence of drugs, alcohol or
medications.
2. Avoid wearing clothes or jewelry that can become entangled with the moving
parts of a tool. Keep long hair covered or bound.
3. Do not overreach when operating a tool. Proper footing and balance enables
better control in unexpected situations.
4. Securely hold this tool using both hands. Using a tool with only one hand can
result in loss of control.
SPECIFIC SAFETY PRECAUTIONS
WARNING! DO NOT let comfort or familiarity with product (gained from repeated
use) replace strict adherence to the tool safety rules. If you use this tool
unsafely or incorrectly, you can suffer serious personal injury.
1. Use the correct tool for the job. This tool was designed for a specific function.
Do not modify or alter this tool or use it for an unintended purpose.
2. Do not operate the tool if the safety guards are missing.
3. Do not allow anyone to stand next to the plate compactor while it is in
operation. The compactor’s plate can cause a serious injury.

V 4.3 196cc Plate Compactor 8622946
Visit www.princessauto.com for more information 5
4. Before operation, the operator has to be made familiar with the necessary
safety precautions and operating techniques.
5. All users must understand the operation of all controls and learn how to stop
the engine quickly in case of emergency.
a. Become familiar with the machine’s controls and all the caution, warning and
danger decals affixed to the machine before attempting to start or operate.
6. The engine and exhaust are hot during operation. Severe thermal burns can
occur on contact, especially with the muffler.
a. Remove accumulated debris from the muffler and cylinder area.
Combustible debris, such as leaves, grass, brush, etc. can catch fire if
they come in contact with a hot engine.
b. Do not place anything on the engine while it is running.
c. Allow the muffler, engine cylinder and fins to cool before touching grass-
covered or brush-covered unimproved land.
7. Always operate this equipment with all guard and safety devices in place.
Never operate this machine if any guard or safety devices have been removed
or if they have malfunctioned.
8. Do not insert your hand or finger between the pulley cover and engine during
operation to avoid injury to your hand.
9. Never operate the plate compactor with the belt cover removed. The exposed
belt and pulley may cause serious injury when the tool is in use.
10. Never leave the machine unattended while running as it will move on its own.
Move the throttle lever to low gear and shut the plate compactor’s engine off
before leaving the area.
11. Do not use on steep slopes, as the tool can topple over
12. Never pick up or carry a machine while the engine is running.
13. If the unit strikes a foreign object, stop the engine, disconnect the spark plug,
thoroughly inspect the machine for any damage and repair the damage before
restarting and operating the machine.
14. Stay away from the edge of ditches and avoid actions that may cause the plate
compactor to topple over.
15. Do not operate on concrete or extremely hard, dry, compacted surfaces. The
plate will jump rather than vibrate and could damage both plate and engine.
