Powercast P2110-EVAL-02 User manual

Rev A.3 – 2013/02 P2110-EVAL-02: Lifetime Power
®
Page 1
Energy Harvesting evelopment Kit for Battery Charging
www.powercastco.com
P2110-EVAL-02
Lifetime Power
®
Energy Harvesting Development Kit for Battery C arging
User’s Manual
- featuring THINERGY
®
Micro-Energy Cell
Overview
The Lifetime Power
®
Energy Harvesting evelopment Kit for Battery Charging is a complete
demonstration and development platform for wireless battery-charging over distance powered by RF
energy (radio waves). This kit features a THINERGY
®
Micro-Energy Cell (MEC) from Infinite Power
Solutions (IPS) which has an ultra-thin form factor and extremely low leakage.
Batteries are charged by the P2110CSR Powerharvester
®
Chipset Reference esign, which converts RF
energy, stores it into an intermediate capacitor, and then provides a pulsed, regulated voltage output
which provides charge current to the attached storage. In this kit, the TX91501 transmitter is the source
of RF energy at 915MHz, but other sources from 850-950 MHz can also be used for power.
A regulated load voltage is provided to power an application device, and the Texas Instruments eZ430-
RF2500 wireless development tool is included for demonstration purposes.
Note:
This kit is based on the P 110CSR Powerharvester. Powercast’s P1110 Powerharvester component also
charges batteries and the main differences are as follows:
Parameter
P1110
P2110
CSR
Charging Method
Continuous
Pulsed
/ Intermittent
Output Voltage Range
1.8V
-
4.2V
2
V
–
5.5V
Output Voltage
Output voltage floats with the
battery voltage until the
configured maximum output
voltage is reached
Fixed, r
egulated output voltage
Usage
irect power
OR
Battery-charging (direct
connection to typical battery)*
Pulsed power
OR
Battery-charging (additional
circuitry typically required)
Operating / Charging
Range
(with identical antennas)
Shorter
–
roughly half as far as
the P2110.
Longer
–
roughly twice as far as
the P1110.
* P1110 is NOT to be used with thin-film batteries like THINERGY that require a fixed charging voltage.
The P1110 Evaluation Board kit (P1110-EVB) is also available to charge batteries using the P1110. The
P1110-EVB will receive power from the transmitter included with the P 110-EVAL-01 or P 110-EVAL-0
development kits.

Rev A.3 – 2013/02 P2110-EVAL-02: Lifetime Power
®
Page 2
Energy Harvesting evelopment Kit for Battery Charging
www.powercastco.com
Contents
The contents of the kit are shown in the image and table below.
Qty
Item
Description
1
Power and ata
Transmitter
(TX91501-3W-I )
3
-
wat
t
, 915 MHz transmitter for power and data
with integrated 8dBi
antenna and two power jacks. Sends a pre-programmed transmitter
I that is received by the P2110CSR Powerharvester and can be
decoded with additional components.
1
P2110
CSR
Evaluation
Board
(P2110CSR-EVB)
Evaluation board for P2110
CSR
Powerharvester. This board has an
SMA connector to connect the antennas and a 10-pin connector for
the Charging Board
1
Patch antenna
915MHz d
irectional antenna with 120
-
degree reception pattern
(included with the P2110CSR evaluation board)
1
ipole antenna
915MHz o
mni
-
directional antenna with 360
-
degree reception
(included with the P2110CSR evaluation board)
1
Charging
Board
(BAT-EVAL-01)
Charging Board for voltage selection, test points, and interfaces to
other devices.
1
THINERGY
MEC
Evaluation Card
THINERGY
MEC101 Micro
-
Energy Cell Evaluation Card
(
1mAH
)
from
Infinite Power Solutions
1
CABLE
-
A P
-
08
8
-
wire
cable for connecting the Charging Board to the IPS Application
evelopment Platform (A P).
1
eZ430
-
RF2500
Texas Instruments eZ430
-
RF2500 evelopment Tool
–
used to
demonstrate a low-power wireless application.

Rev A.3 – 2013/02 P2110-EVAL-02: Lifetime Power
®
Page 3
Energy Harvesting evelopment Kit for Battery Charging
www.powercastco.com
Set-up and Operation
Installation Overview
The following basic steps are required to operate the kit and are provided as an overview. etailed
installation instructions are provided immediately after this summary.
1. Connect an Antenna to the P2110CSR Evaluation Board (receiving unit)
2. Configure the P2110CSR Evaluation Board
3. Configure the Charging Board
4. Plug in the transmitter and point toward the receiving unit
Step-by-Step Installation
1. Connect an antenna to t e P2110CSR evaluation board (receiving unit)
This kit includes two receiving antennas matched to receive maximum energy at 915MHz – a dipole for
omni-direction charging and a patch for directional charging. The patch will work at further distance
than the dipole, or provide a faster charge rate when used at the same distance from the transmitter as
the dipole. Both antennas include an SMA connector for easy attachment to the P2110CSR evaluation
board.
The estimated operating distance with the included transmitter and receiving antennas is:
ipole antenna: 20-25 feet
Patch antenna: 40-45 feet
Other 915MHz antennas can be used, or if using an RF source other than the one included an antenna
with proper frequency matching should be used for best performance.
Note:
A C block must be used when the antenna is a C short. Below is a link to a coaxial inline C block that
can be used. For actual deployment, a series capacitor on the input to the harvester is the best and
lowest cost solution. The cap should be rated for the desired frequency to avoid unwanted insertion
loss. http://www.minicircuits.com/pdfs/BLK-89+.pdf
Note: Optional testing of P2110CSR Evaluation Board only (also requires Step 5).
To test the proper function of the P2110CSR Evaluation Board use the following settings or see the
instructions for the P2110CSR-EVB at http://www.powercastco.com/P F/P2110CSR-EVB.pdf
J1: Antenna connected
JP1: C6 connected
S2: LE
The LE will blink when sufficient power is available. The blinking rate is faster when
closer to the transmitter and slower when further from the transmitter.

Rev A.3 – 2013/02 P2110-EVAL-02: Lifetime Power
®
Page 4
Energy Harvesting evelopment Kit for Battery Charging
www.powercastco.com
2. Configure t e P2110CSR Evaluation Board
The P2110CSR Evaluation Board should be configured as follows when using the Charging Board:
JP1: C8 connected – C6 for shorter charge pulses, C8 for longer charge pulses
S1: Sets the charging voltage, VOUT
efault – 3.3V used for charging 2 rechargeable alkaline cells in series
4.1 – Use this setting to charge the onboard THINERGY MEC
4.2 – Use this to charge external lithium ion batteries
S2: MEAS – this assures all power goes to charging board
S3: not applicable
S4: not applicable
3. Configure t e C arging Board
BAT-EVAL-01 C arging Board (shown with attached eZ430-RF2500 wireless board)
3.1 Insert t e THINERGY MEC into t e C arging Board Card Connector
Slide the MEC Evaluation Card into the large black connector on the Charging Board. The exposed metal
leads should be facing downward and slide into the connector. The connector and MEC card are keyed
for proper insertion.
To charge a different battery than the included MEC card, set S1 switch to EXT and connect the external
battery across XBATT and GN , or use the through-hole solder connection, BT1.
THINERGY MEC Card Connector

Rev A.3 – 2013/02 P2110-EVAL-02: Lifetime Power
®
Page 5
Energy Harvesting evelopment Kit for Battery Charging
www.powercastco.com
3.2 Configure t e C arging Board for your desired application.
The following explains the functions of the jumpers and switches on the Charging Board:
JP1: Allows harvester signals (INT, RESET) to be sent to eZ430-RF2500 kit (explained below)
JP2: P2110CSR-EVB: Not used, do not connect a jumper. Output voltage is set on the EVB.
P2110-EVB rev B (lidded harvester): used to set the charging voltage. Place a shunt over
the jumper with the required voltage.
4.1V – used for charging the IPS MEC
4.2V – used for charging Li-ION or Li-Polymer cells
4.95V – used for charging 3 rechargeable alkaline cells in series
2.8V – used for charging 2 NiMH cells in series
3.3V – used for charging 2 rechargeable alkaline cells in series.
efault voltage, selected by leaving all jumpers open
Warning – do not connect more than one jumper at a time.
S1: Selects storage device
BATT – charges IPS MEC
OFF – disconnects battery from charger to eliminate leakage
EXT – charge external batteries (BT1 or XBATT)
– use IPS A P to charge IPS MEC (P1 – see instructions below)
S2: Selects battery output
VREG – regulated output, voltage controlled by S3
OFF – no output, used for charging only
LE – rapid battery discharge
S3: Selects desired output voltage regulation, 2.7V or 2.0V (2.7V for eZ430-RF2500 kit)
3.3 Plug t e C arging Board (BAT-EVAL-01) onto t e P2110CSR Evaluation Board using t e keyed
connector (J2) in t e test area.
4. Plug in t e transmitter and point toward t e receiving unit.
Plug in the TX91501 Powercaster Transmitter and point it toward the receiving unit. The front of the
transmitter has the Powercast logo and status LE . Please see the TX91501 User’s Manual for detailed
operating instructions.
http://www.powercastco.com/P F/TX91501-manual.pdf
The transmitter should be used in the upright (vertical) position and the receiving antennas should also
be positioned vertically.
Note:
As a precaution, do not operate the transmitter within 12 inches of the evaluation board when the patch
antennas are attached.

Rev A.3 – 2013/02 P2110-EVAL-02: Lifetime Power
®
Page 6
Energy Harvesting evelopment Kit for Battery Charging
www.powercastco.com
C arging Range
The line-of-sight range using the included transmitter and antennas is as follows:
ipole antenna: 20-25 feet
Patch antenna: 40-45 feet
C arge Current Calculation for THINERGY MEC
irect measurement of the THINERGY MEC is not available as access to the THINERGY battery terminals
was not provided to avoid possible damage to the cells. However, the charging current can be
calculated with the use of an oscilloscope with a voltage probe. Set the charging board to charge the
THINERGY MEC (JP2 to 4.1V, S1 to BATT, S2 to OFF). Attach a scope probe between the VBATT and GN
test points. Monitor the voltage on the scope, and you’ll notice two voltages over time, the open circuit
battery voltage, V
OC
, and the charging voltage, V
charge
which is set by JP2. Subtract V
OC
from V
charge
and
divide the result by the internal resistance of the battery and you will get the charging current for the
amount of time that the pulse-charger is on. The THINERGY MEC provided has an internal resistance of
approximately 35Ω.
Alternatively, charge current to the THINERGY MEC can be measured directly with the THINERGY A P
(not provided) using the 8-pin header P1 and the included cable (see below).
C arge Current Measurement
The charging current will only be shown for a small amount of time. To measure the current of an
external battery, set the Charging Board to charge the desired battery (JP2 to correct voltage, S1 to
BATT, S2 to OFF). The preferred method of measurement is to use an oscilloscope with a current probe
attached to battery terminal connection, XBATT or BT1. You can also place an ammeter in series with
the connection to XBATT or BT1, but depending on charging time, this method may not give accurate
results.
Wireless Sensor Demonstration
The Texas Instruments eZ430-RF2500 wireless development tool is included in the kit as a simple and
easy to use application demonstration. Please see the documentation from Texas Instruments for
software installation and operation. TI provides a free sensor demo PC application and the source code.
Powercast does not provide support for the eZ430-RF2500 kit.
To use the eZ430-RF2500 with the charging board:
• Install the Sensor Monitor software that comes with the eZ430-RF2500 kit
• Plug the eZ430-RF into a USB port, let windows search for drivers
• Launch the Sensor Monitor software. The access point node is shown middle of the window.
• Plug the THINERGY MEC into the Charging Board
• BAT-EVAL-01: S1 to BATT, S2 to VREG, S3 to 2.7V; P2110CSR-EVB: S1 to 4.1V
• Plug the eZ430-RF2500T target board into P2 on the Charging Board. A new node appear in the
Sensor Monitor window
• With the transmitter running, the THINERGY MEC will continue to pulse charge while the eZ430-
RF2500 continues to operate.
WARNING: O NOT ATTEMPT TO RECHARGE THE BATTERIES INCLU E WITH THE EZ430-RF2500 KIT AS
THEY ARE NOT RECHARGEABLE!

Rev A.3 – 2013/02 P2110-EVAL-02: Lifetime Power
®
Page 7
Energy Harvesting evelopment Kit for Battery Charging
www.powercastco.com
JP1 allows for two P2110CSR Powerharvester pin signals to be tied to the eZ430-RF2500 through P2. INT
is an output that goes high when the capacitor (C3-C5 on the P2110 Evaluation Board) reaches a charge
threshold and the C regulated output (3.3V default) is available. RESET is an input that turns the C
regulator off. These pins allow you to monitor the capacitor charging and control the output voltage,
respectively. Through JP1, INT can be tied either to pin 1 or pin 4 of P2, and RESET can be tied to pin 6.
These signals require code changes to the eZ430-RF2500, and are not implemented for the purpose of
this evaluation kit.
THINERGY MEC Low-Voltage S ut-off
The Charging Board provides low-voltage shut-off at 2.1V to protect the THINERGY MEC.
It is recommended to remove the THINERGY MEC Evaluation Card from the connector slot when not in
use to avoid unnecessary energy leakage.
THINERGY Application Development Platform (ADP)
The Charging Board has a header, P1, for connecting to the THINERGY A P and charging an MEC in the
A P. A cable is provided for easy connection. With the cable, connect pin 1 of P1 on the Charging Board
with pin 1 on the THINERGY A P header, J5. The A P can be configured in either “Pass-Thru” or
“Gated” mode for MEC charging. Gated mode is recommended to see the pulsed charging voltage and
current.
The J5 header pins on the A P pins are used as follows:
1. VIN-H not used
2. VIN-L charge from Powercast Charging Board
3. I/O-1 not used
4. I/O-2 not used
5. ENABLE tied to ground for enabling the A P EH interface
6. +5.0V not used
7. GATE inverted and delayed INT signal from P2110 (for measurement timing by A P)
8. A-GN ground

Rev A.3 – 2013/02 P2110-EVAL-02: Lifetime Power
®
Page 8
Energy Harvesting evelopment Kit for Battery Charging
www.powercastco.com
Documentation and Software
Powercast
Powercast documentation, including datasheets and user manuals:
http://www.powercastco.com/resources/
P2110-EVAL-02 evelopment Kit – overview
http://www.powercastco.com/P F/P2110-EVAL-02-overview.pdf
P2110-EVAL-02 evelopment Kit – user’s manual
http://www.powercastco.com/P F/P2110-EVAL-02-manual.pdf
P2110CSR Powerharvester Chipset reference esign – datasheet
http://www.powercastco.com/P F/P2110CSR-datasheet.pdf
P2110CSR Evaluation Board – instructions
http://www.powercastco.com/P F/P2110CSR-EVB.pdf
TX91501 Powercaster Transmitter – user’s manual
http://www.powercastco.com/P F/TX91501-manual.pdf
The P2110-EVAL-02 is subject to Powercast’s Limited Warranty for evelopment Systems
Infinite Power Solutions
THINERGY Micro-Energy Cells
http://www.infinitepowersolutions.com/product/thinergy
THINERGY Application evelopment Platform
http://www.infinitepowersolutions.com/product/thinergyadp
Technical support for THINERGY products is provided by Infinite Power Solutions.
Texas Instruments
eZ430-RF2500 Wireless evelopment Tool
http://focus.ti.com/docs/toolsw/folders/print/ez430-rf2500.html
Technical support for the eZ430-RF2500 wireless development tool is provided by Texas Instruments.

Rev A.3 – 2013/02 P2110-EVAL-02: Lifetime Power
®
Page 9
Energy Harvesting evelopment Kit for Battery Charging
www.powercastco.com
APPENDIX A – C arging Board Component Description
BAT-EVAL-01 C arging Board
Component
Description
J1
Keyed connector on the bottom to attach to
the P2110 Evaluation Board
CONN1
THINERGY
MEC
Evaluation Card
con
n
ector
–
Large, black connect
or
for the
THINERGY
MEC Evaluation Card. Insert the Card with metal leads facing downward.
JP1
P2110 I/O interface to P2
RESET P2110 input - turns off regulated output from P2110
INT P2110 output – high when Vout is active
INT P2110 output – high when Vout is active
JP2
Regulated charging voltage selection
–
ONLY CONNECT ONE AT A TIME
4.1V THINERGY Micro-Energy Cell
4.2V Li-ION or Li-Polymer cells
4.95V 3 Alkaline cells in series
2.8V 2 Ni-MH cells in series
3.3V 2 Alkaline cells in series (default setting with no jumper connection)
P1
Connector for IPS Application evelopment Platform
. Pin 1 is marked with “^”.
P2
Connector for output load
(e.g. for included eZ430-RF2500 kit or any low-power device with compatible connector)
S1
Switch for charge selection
BATT (Charge is directed to the MEC)
OFF (no charging)
EXT (Charge is directed to XBATT, BT1, or the A P header P1)
S
2
Switch for
output load
VREG (regulated output to S3)
OFF (output power from IPS MEC or external battery is OFF)
LE (power to LE for rapid drain of MEC, or other battery at BT1)
S3
Selection for r
egulat
or
output voltage
–
2.0 or 2.7V
(2.7V is required for the included eZ430-RF2500 kit with the pre-loaded TI firmware)
Note:
It is recommended to remove the THINERGY MEC Evaluation Card from the connector slot when not in
use to avoid unnecessary energy leakage.

Mouser Electronics
Authorized Distributor
Click to View Pricing, Inventory, Delivery & Lifecycle Information:
Powercast:
P2110-EVAL-02
