POWERTECH PLUS MB-3613 User manual

9-Stage 12/24V Battery Charger
MB-3613
User Manual
1

The charger is suitable for 12V/24V regular ,lead-acid and Lithium Iron
Phosphate batteries with 5Ah~120Ah capacity.

Charging modes include: 12V/2A (standard), 12V/7.2A (standard),
12V/7.2A(AGM), 12V/7.2A(Lithium),12V/7.2A(recondition), 24V/2A
(standard), 24V/3.6A(standard) , 24V/3.6A (AGM) and 24V/3.6A
(Lithium).

4

LCD Display Information:
Charging Features:
Bad Battery Dete tion (1)
▪Measures the voltage of your battery prior to chargi g.
▪If the refere ce voltage is ≥30V±0.5, it's co sidered a 'bad
battery'.
Devul anisation (2)
▪Whe the chargi g period reaches four hours i Pulse
Chargi g mode a d the battery voltage variatio exceeds the
voltage setti g, the system e ters the ext mode.
▪Whe the battery voltage variatio is less tha 2V (12V
battery) or 4V (24V battery), devulca isatio is o lo ger
performed a d the system e ters the ext mode.
5

Pre Charge (3)
▪Ide tifies the battery voltage before chargi g.
▪If the battery voltage is lower tha the refere ce voltage, the
battery will be pre-charged i order to avoid damage to the
battery.
▪12V: 5-8V 2 mi utes, 8-10V 9 hours.
▪24V: 5-16V 2 mi utes, 16-20V 9 hours.
Constant Current (4)
▪The mai chargi g phase.
▪The battery will be charged with the maximum curre t as
quickly as possible.
▪70%~85% of the battery is charged i this stage.
Constant Voltage (5)
▪The boosti g phase.
▪The charger co sta tly adjusts the charge so as the battery
voltage gets higher, the chargi g curre t becomes smaller.
▪Co sta t voltage chargi g e ds whe the chargi g curre t
drops to =< 0.5C, at which time the battery should be almost
fully charged.
Re ondition (6)
▪Whe the battery has reached maximum voltage, the charge
cha ges to reco ditio mode si ce some batteries ca be
charged to 15.7V.
▪This charge lasts 2±0.2 hours at most a d is o ly activated by
selecti g 12V/RECON.
Voltage Analysis (7)
▪The i ter al circuit automatically detects the variatio of
battery voltage.
▪A alarm will sou d whe the voltage exceeds 2V (12V) or 4V
(24V).
6

Float Charge (8)
▪The mai te a ce charge.
▪Trickles the charge u til the battery is early at 100%
capacity.
▪Chargi g with a small curre t ca elimi ate the vulca izatio
of the egative electrode plate.
Pulse Charge (9)
▪O ce the battery voltage has bee adjusted i the previous
mode, the battery voltage retur s to 13V/26V whe the pulse
chargi g mode is executed.
Charging Profiles:
7

12V/2A SLOW standard charging mode
12V/7.2A FAST standard charging mode
12V/7.2A FAST AGM charging mode
12V/7.2A FAST Lithium charging mode
24V/2A SLOW standard charging mode
24V/3.6A FAST standard charging mode
24V/3.6A FAST AGM charging mode
24V/3.6A FAST Lithium charging mode
Power output mode 5.1A 13.8V

Lead-Acid and Lithium
Iron Phosphate
9

Problem
Battery failed
Reverse polarity
protection
Failed in
pre- charge stage
Failed in Analysis
stage
Failed in
Desulphation stage
Battery failed or
damaged
Er2
Er3
Er4
Er5
The buzzer flashes
five times and the
red light flashes
Er1 + Red LED
light on
Error Codes Solutions
Check the battery voltage is for 12V
system
Battery has problem. Replace with a new
battery and try again.
Battery is too old or damaged. Replace
with new battery and try again.
Check the battery voltage is for 12V system
Remove the reverse, unplug immediately
from mains, connect the red clamp to
positive (+) battery post, and black
clamp to negative (-) post.
Check battery specification,12V battery
use 12V mode; 24V battery use 24V mode.
If still doesn't work,replace with new
battery and try again.
9
Error Codes &Solutions:

Distributed by:
TechBra ds by Electus Distributio Pty. Ltd.
320 Victoria Rd, Rydalmere NSW 2116 Australia
Ph: 1300 738 555
I t’l: [phone]
Fax: [phone]
www.techbra ds.com
Made i Chi a
