PowerTech ZM9124 User manual

Instruction Manual
Blanket Solar Panel
with Charge Controller
ZM9124

2
CONTENTS
Warnings & Safety Information ..................................................................3
Before First Use .............................................................................................4
Box Contents.................................................................................................4
Operating Instructions.................................................................................4
How to charge a 12V battery...................................................................... 5
MPPT Solar Charger Indicator....................................................................5
Troubleshooting............................................................................................6
Specifications................................................................................................. 7
Warranty Information...................................................................................8

3
WARNINGS & SAFETY INFORMATION
Please ensure that you have read the product manual and instructions in full
before using this product. Failure to do so many result in incorrect operation and
potentially impact the performance of the product.
This product converts natural sunlight into DC electricity. It is designed to charge
a 12V battery.
For optimum performance, protect the solar cell from dust, dirt, and other debris.
• Use and store the product in a dry and ventilated location.
• Do not use in flammable or explosive areas.
• Stop use immediately if any wires become loose or electronic components are
exposed.
• Do not pick panel up directly by the solar cells.
• Use the gap between solar cells to pick up the panel.
• Do not stand or walk on the solar panel.
WARNING: The manufacturer is not responsible for any potential injury from
misuse
• Ensure battery has enough voltage for the solar charge controller to recognise
the battery type before first installation.
• Battery cable should be as short as possible to minimise loss.
• The regulator is suitable for with LiFePO4 batteries and lead-acid batteries
(Flooded, LEAD, AGM, & GEL). Not suitable for nickel metal hydride, or other
battery types.
• Charge regulator is only suitable for regulating solar modules. Never connect
another charging source to the charge regulator.
• The MPPT solar charge controller will be hot when working. Please install in a
flat, well ventilated area.

4
BOX CONTENTS
1 x 200W Blanket Solar Panel
1 x 20A MPPT Solar Controller
2 x 50A Connector 10CM Lead with Rubber Cap
1 x 50A Connector 4.5M Extension Lead
1 x 50A Connector to Alligator Clips 0.5M Lead
BEFORE FIRST USE
OPERATING INSTRUCTIONS
Prior to using your product, please read all the safety and operating instructions
thoroughly. Please ensure you follow the steps below before using the product.
We recommend you keep the original packaging for storing the product when
not in use.
Please pay close attention to the section entitled Warnings & Safety Information.
Find a safe and convenient place to keep this instruction manual for future
reference.
Unpack the product but keep all packaging materials until you have made sure
your new product is undamaged and in good working order. Ensure you have all
accessories listed in this manual.
• Unfold the solar panel
• Place the unfolded solar panel in a postion that receives direct sunlight, facing
to the sun. Ensure that no shadows are covering the solar cells.
• Tilt the solar panel at a suitable angle. This can be the same as your local
lattitude (additional support may be necessary, not supplied).
• Connect the solar panel to the MPPT solar charge controller before connecting
battery clamp lead to the solar controller.

5
HOW TO CHARGE A 12V BATTERY
• Connect the battery to the solar charge controller.
• Connect load to the MPPT solar charge controller.
• Connect solar panel to the MPPT solar charge controller.
• Reverse this order when disconnecting.
NOTE: Heavy loads should not be connected to the battery.
WARNING: The reverse order applies when uninstalling. An improper sequence
order can damage the controller.
MPPT SOLAR CHARGER INDICATOR
INDICATOR STATUS MEANING
Solar Panel Steady on Solar panel voltage is higher than the light
control voltage
O Solar panel voltage is less than the light
control voltage
Battery Any status Indicate battery energy left is low, right is
high.
The left is
flashing
Battery is nearly or already empty.
Load Steady on Load receiving power
O Battery voltage is abnormal

6
TROUBLESHOOTING
ISSUE LIKELY CAUSE SOLUTION
Charging symbol not
displaying even when the
solar panel is in the sun
Solar has been improperly
connected to the MPPT
controller
Reconnect the solar panel
ensuring that the positive
and negative terminals are
appropriately connected
Load icon is o Battery is low, the load
will start when the battery
voltage is higher than 11.5V
Charge the battery
The MPPT controller will
not turn on
Battery is insuciently
charged
Check, and if necessary
alter the battery’s
connection to the MPPT
controller
Battery has been connected
improperly
Reduce load watts

7
SPECIFICATIONS
Solar Panel
Solar Cell Type Monocrystalline 166 x 166mm
Power Output 200W
Open Circuit Voltage 24.7V
Short Circuit Current 9.06A
Working Voltage 20.1V
Working Current 8.5A
Weight 5.8KG
Dimensions Folded: 560(W) x 390(H)mm
Unfolded: 1170(W) x 1120(H)mm
MPPT Solar Charge Controller
Rated Charge Current 20A
Rated Discharge Current 20A
Rated Voltage 12V/24V auto work
Mppt Eciency Max:99%
Over Load, Short Circuit Protection ≥1.5 rated current
No Load Current <10mA
Over Voltage Protection 16V; ×2/24V
Voltage Of Stop Charging 14.7V; ×2/24V
Discharge Recovery Voltage 12.0V; ×2/24V
Over Discharge Voltage 10.8V; ×2/24V
Usb Output 5V 1A
Working Temperature -35 C~+55°C
Dimension Of Controller 131 × 99.5 × 29.5 mm
Weight 300g
