PR Lighting XPar 336-W User manual

XPar 336-W
PR-8951
This product manual contains important information about the safe installation and use of this
projector. Please read and follow these instructions carefully and keep this manual in a safe place
for future reference.
PR LIGHTING LTD.
http://www.pr-lighting.com

2/14
INDEX
SAFE USAGE OF THE PROJECTOR 3
INSTALLING THE PROJECTOR 4
CONTROL SYSTEM AND POWER CONNECTIONS 4
DMX TERMINATOR 5
SETUP OPTIONS-PROJECTOR CONFIGURATION 5
TO SET THE DMX START ADDRESS 6
OPERATION MENU 7
DMX PROTOCOL 9
INDICATION OF LED DISPLAY 12
MAINTENANCE 12
TROUBLESHOOTING 12
TECHNICAL DATA 13
ELECTRICAL DIAGRAM 16
COMPONENT ORDER CODES 17
Please note that as part of our ongoing commitment to continuous product development, specifications are subject to change without
notice. Whilst every care is taken in the preparation of this manual we reserve the right to change specifications in the course of
product improvement. The publishers cannot be held responsible for the accuracy of the information herein, or any consequence
arising from them.
Every unit is tested completely and packed properly by the manufacturer. Please make sure the packing and / or the unit are in good
condition before installation and use. Should there be any damage caused by transportation, consult your dealer and do not use the
unit. Any damage caused by improper use will not be assumed by the manufacturer and / or dealer.
ACCESSORIES
These items are packed together with the projector:
Name Quantity Unit Remark
Barn door 1 Pc Optional
Safety cord 1 Pc
This manual 1 Pc
Signal cable 1 Pc Optional

3/14
SAFE USAGE OF THE PROJECTOR
When unpacking and before disposing of the carton, check there is no transportation damage before using the projector.
Should there be any damage caused by transportation, consult your dealer and do not use the apparatus.
The projector can be used indoors and outdoors, IP20.
The projector is not designed or intended to be mounted directly on to inflammable surfaces.
The projector is only intended for installation, operation and maintenance by qualified personnel.
Do not project the beam onto inflammable surfaces, minimum distance is 5m. 5m
Avoid direct exposure to the light from the lamp. The light is harmful to eyes.
Do not attempt to dismantle and/or modify the projector in any way.
Electrical connection must only be carried out by qualified personnel.
Before installation, ensure that the voltage and frequency of power supply match the power requirements of the projector.
It is essential that each projector is correctly earthed and that electrical installation conforms to all relevant standards.
Do not connect this device to any other types of dimmer apparatus.
Make sure that the power-cord is never crimped or damaged by sharp edges. Never let the power-cord come into contact
with other cables. Only handle the power-cord by the plug. Never pull out the plug by tugging the power-cord.
Keep the optical system clean. Do not touch the LED lens with bare hands.
When the projector is hanged to a high place, please use a safety cord provided to pass through the projector handles as
a secondary safety fixing for safety seasons. For details, refer to “INSTALL THE PROJECTOR “section.
LED lens shall be changed if they have become visibly damaged to such an extent that their effectiveness is impaired,
for example by cracks or deep scratches.
Exterior surface temperatures of the projector after 5 minutes operation is 45℃, when achieving steady state it is50℃.
There is no user serviceable parts inside the projector, do not open the housing and never operate the projector with the
covers removed.
Always disconnect from the mains, when the device is not in use or before cleaning it or
before attempting any maintenance work !
If you have any questions, don’t hesitate to consult your dealer or manufacturer.

4/14
INSTALL THE PROJECTOR
When the projector is used, as the right figure above, unfold the support to certain angle and put the projector onto a
flat surface. Make sure it is steady.
When the projector is used at a high place, as the left figure above, fold the support, turn it round to the top of the
projector, connect a lamp hook to the mounting hole reserved in the support by screws, and then hang the hook to a high
place. Eventually, use the safety cord provided to pass through the handles and hang it as a second safety fixing.
CONTROL SYSTEM AND POWER CONNECTION
Connection between the controller and a projector and between one projector and another must be made with a 2
core-screened cable, with each core having at least a 0.5mm diameter. Please use the projector’s cannon 3- pin signal
input and output cables as connection. The 3-pin signal connections are connected as shown in the figure above.
Note: Care should be taken to ensure that none of the pins touch the metallic body of the plug or each other. The body of
the plug is not connected in any way. The XPar 336-W accepts digital control signals in protocol DMX512 (1990).
The amount of projectors connected in parallel is not more than 32. Connect the controller’s output to the first fixture’s
input cable with a 3-pin signal cable, connect the first fixture’s output cable to the second fixture’s input cable and connect
the rest fixtures in the same way. Eventually, connect the last fixture’s output cable to a DMX terminator. Note: Only when
all the start addresses of fixtures are set the same, synchronous control could be achieved.
When the first fixture is not connected to the controller, and all the other connections are the same as above, it is master /
slave mode connection. To achieve master / slave mode, set the first fixture master , the others salve( slave is default).
As for power connections, each projector has to be supplied separately by external power. Use the power cord of each
projector to connect the mains power directly, paying attention to the voltage and frequency marked on the panel of the
projector.
Lamp Hook Mounting Hole
Safety Cable
Support
FUNCTION
DMX IN
3
11
DMX OUT
3
22
3
2
PIN
1
1
GND
DATA +
DATA -
DMX512

5/14
All of the connections are as the figure below.
DMX TERMINATOR
In the Controller mode, at the last fixture in the chain, the DMX output has to be connected with a DMX terminator. This
prevents electrical noise from disturbing and corrupting the DMX control signals.
The DMX terminator is simply an XLR connector with a 120 (ohm) resistor connected across pins 2 and 3, which is
then plugged into the output socket on the last projector in the chain. The connections are illustrated below.
SETUP OPTIONS-PROJECTOR CONFIGURATION
Projector configuration can be set conveniently via push-button switch and LED display.
Launch the projector and press button ENTER for more than 5 seconds to unlock the panel, the LCD will show the
function menu of the projector, each main menu has its submenus and each submenu has a specific function. For
details, please see the “OPERATION MENU” section.
DMX Controller
Power IN Power IN Power IN
DMX OUT DMX IN DMX OUT DMX IN XLR terminator
21
3
120
DMX TERMINATOR
CONNECTION
Connect a 120 (OHM) resistor
across pins 2 and 3 in an XLR plug
and insert into the DMX out socket
on the last unit in the chain.
PIN 3
PIN 2
ENTERUP DOWN
FUNC

6/14
Press button UP or DOWN if you want to browse through the various Setup Options. Press button ENTER to save your
settings or enter the next menu. Press button UP or DOWN to change values(add or subtract)
Press button FUNC, it will return to the upper menu one by one or browse through the main menu.
TO SET THE DMX START ADDRESS
Each Xpar336-W must be given a DMX start address so that the correct projector responds to the correct control signals.
This DMX start address is the channel number from which the projector starts to “listen” to the digital control information
being sent out from the controller. The Xpar336-W have 2 DMX modes, which are standard mode and extended mode.
For example, the standard mode has 4 channels, so set the No. 1 projector’s address 001, No. 2 projector’s address
005, No. 3 projector’s address 009, No. 4 projector’s address 013, and so on.
Launch the projector. Press button ENTER for more than 5 seconds to unlock the panel.
Press button FUNC, UP or DOWN to find “AddR” menu.
Then press ENTER to show DMX address and press UP or DOWN to set DMX address.
At this time, the address will flash continuously. Press button ENTER to confirm and it means the setting has been
enabled.
Press button FUNC, it will return to the upper menu one by one.

7/14
OPERATION MENU
1st LEVEL 2nd LEVEL 3rd LEVEL
AddR
(DMX address)
XXX
（XXX:1~512）
CNFG
(Config settings)
dmX
(DMX mode)
STd
(Standard mode)
EXT
(Extended mode)
dISP
(Display settings)
ON
OFF
(Shut off digital CRT
without pressing
buttons in 5 minutes)
mORS
(Master /Slave Settings)
SLAV
(Slave)
mAST
(Master)
FACT
(Reset factory setup) yES
TRmd
(Transmit parameters) yES
INFO
(Information)
TImE
(Fixture usage time) XXXX
TEmP
(LED board temperature) XX
VER
(Version) X.X.X
TEST
(Test mode)
A
(Amber)
W
(White)
A/
W
( Amber /white)
mENU
(Operation mode)
dmx
(DMX mode)
PR 01
(Preset memory 01）
PR 02
(Preset memory 02
）
Note:
[1]: parameters transmitted: Display settings, operation mode and DMX mode.

8/14
DMX PROTOCOL
Standard
mode
Extended
mode FUNCTION DMX DESCRIPTION
1 1 Dimmer 000-255 Linear Dimming from dark to light
2 Dimmer Fine 000-255 Dimmer in 16 Bit precision
2 3 White 000-255 Linear adjustment from dark to light
4 White Fine 000-255 White in 16 Bit precision
3 5 Amber 000-255 Linear adjustment from dark to light
6 Amber fine 000-255 Amber in 16 Bit precision
4 7 Strobe 000 No Strobe
001-255 Strobe from slow to fast

9/14
INDICATION OF LED CHARACTER
Decimal point of the first character On DMX signal OK
Off No DMX signal
Decimal point of the third character On Master / slave signal is OK
Off No master / slave signal
Decimal point of the fourth character On When setting master mode
Off When setting slave mode
Parameters that LED characters display Flash Parameters not saved, press “ENTER” to save them
MAINTENANCE
To prolong the life of the projector, it is very important to do the maintenance work. Cooling fans must be cleaned once
every 15days and external lens cleaned periodically for an optimum light output. DO NOT USE ANY SOLVENT
CONTAINING CHEMICAL ELEMENT.
Cleaning frequency depends on the environment in which the fixture operates. Soft cloth and typical glass cleaning
products should be used for cleaning with care. It is recommended to clean projector at least once every 20 days.
Do not use any organic solvent, e.g. alcohol, to clean housing of the apparatus.
TROUBLESHOOTING
PROBLEM ACTION
The projector doesn’t switch on
 Power connection is not correct.
 Power supply is damaged or abnormal. Call a qualified personnel
to fix it.
 Connection of control board is not correct. Call a qualified
personnel to fix it.
The projector can be turned on, but LEDs do
not emit light and are out of control.
 Connection of LED board is not correct. Call a qualified
personnel to fix it.
The lamp comes on but the projector
doesn’t respond to the controller
 Make sure that the projector is correctly configurated.
 Replace or repair the DMX cable.
The beam appears dim
 The projector is too hot. Take ventilation measures to make it
cool.

100~240V AC,
10/14
TECHNICAL DATA
VOLTAGES:
50/60Hz
POWER CONSUMPTION:
120W@220V
LED:
Power consumption 3W
Quantity 36（27W+9A））
Manufacturers Rated LED Life 50000 Hours
COLOURS:
White+ Amber
DIMMER:
0-100% linearly adjustable
STROBE:
1~25F.P.S
LIGHT ANGLE
Light Spot Angle(1/10 Maximum) θ 26°
Beam Angle(1/2 Maximum) θ1/2 15°
Lens Angle: 15° (Optional 8°, 25 °, 45°)
CONTROL:
DMX512, 3 pin interfaces
4 channels in standard mode, and 7 channels in extended mode
Master /Slave Synchronous Control mode
2 Pre-set memories
Self-test mode
OTHER FUNCTIONS:
LED board temperature display
Fixture usage time display
Parameters about DMX mode, Display setting status, operation mode can be transmitted by synchronous control.
HOUSING:
High temperature ABS +die-casting aluminum, IP20

11/14
WORK ENVIRONMENT TEMPERATURE:
-20°C~40°C
WEIGHT:
2.3kg
SIZES:
LIGHT OUTPUT:
277
224
196
167
26.2°Diameter(m)
Distance(m)
5m
6m
5m
6m 7m
4m
2m
4m
2m
0m 1m
1m
3m
3m
7m
0m 5m 10m 15m 20m 25m 30m
710162965261
1873 468 208 117 75 52
58831302325212086
26.2°lux（W A)
26.2°lux（W)
26.2°lux（A)
13.8611.559.246.934.622.310
26.2°

12/14

13/14
COMPONENT ORDER CODES
NAME PART NO. QUANTITY REMARK
LED LENS 070070047 36 15°
SIGNAL CABLE 230090002 1 3meters
POWER SUPPLY 190010118 1 150W58V
DRIVER BOARD 230060134 1
LED CONTROL BOARD 230060138 1
LED LAMP BOARD 230020286 1

14/14
PR LIGHTING LTD.
PR New Hi-tech Science Park, 1582 Xingye Avenue
Nancun Panyu, Guangzhou, 511442 China
TEL: [phone]
FAX: [phone]
P/N: 320020093
Version: 20120717
