PR Lighting LED STUDIO 3605 User manual

LED STUDIO 3605
PR-3605T
PR-3605D
This product manual contains important information about the safe installation and its use. Please read and
follow these instructions carefully and keep user’s manual in a safe place for future reference.
PR LIGHTING LTD.
http://www.pr-lighting.com

2/8
INDEX
SAFETY AND WARNING 3
PRODUCT’S STRUCTURE AND INSTALLATION 4
MAINTENANCE 5
TROUBLESHOOTING 5
GRILLE COVER 5
TECHNICAL DATA 6
MEASUREMENTS 7
COMPONENTS’ ORDER CODES 7
BACKCOVER 8
Please note that as part of our ongoing commitment to continuous product development, specifications are subject to change
without notice. Whilst every care is taken in the preparation of user’s manual we reserve the right to change specifications in the
course of product improvement. The publisher cannot be held responsible for the accuracy of the information herein, or any
consequence arising from them.
Every unit is tested completely and packed properly by the manufacturer. Please make sure the packing and / or the unit are in good
condition before installation and use. Should there be any damage caused by transportation, consult your dealer and do not use the
unit. Any damage caused by improper use will not be assumed by the manufacturer and / or dealer.
ACCESSORIES
These items are packed together with the product:
Name Quantity Unit Remark
Power Adaptor 1 Pc
User’s Manual 1 Pc
Grille Cover 1 pc

3/8
SAFETY AND WARNING
When unpacking and before disposal of the carton, ensure there is no transportation damage before using the product. Should there be
any damages caused by transportation, consult your dealer and do not use it.
ONLY can the product be used indoors, IP20.Keep it in dry place, avoid use in damp, excessively hot and dusty environment and
contact with water or other liquids.
The product is not designed or intended to be mounted directly on to inflammable surfaces.
The product is only intended for installation, operation and maintenance by qualified personnel.
Do not project the beam onto inflammable surfaces, minimum distance is0.5m. 0.5m
Avoid direct exposure to the light from the lamp. The light is harmful to eyes.
Do not attempt to dismantle and/or modify the product in any way.
Electrical connection must only be carried out by qualified personnel.
Before installation, ensure that the voltage and frequency of power supply match the requirements of the product
Do not connect this product to any other types of dimmer apparatus.
Exterior surface temperatures of the product after 5 minutes’ operation is 45℃, while steady is 55℃.
There is no user serviceable parts inside the product. Before the use of it, ensure all covers (housing is)are fixed and all screws fastened.
It is forbidden to use it while covers (housing is) are open.
If any questions or advice, don’t hesitate to contact the dealer or us.
Always disconnection from POWER, when the device not in use or before any cleaning maintenance
work !

4/8
INSTALL THE PROJECTOR
How to use:
The product is mobile lighting device. Use on flat surface, not fit for use in high place. The product can be manually
rotated with angle from 0 degree of 90 degrees. Plastic head screws at both ends and rotate it till the angle desired,
then tighten the two screws.
There are two types of grille cover for avoidance of straight light for the client. It’s easy for its removal, loosen two
screws on one side of the light panel, remove the cover and tighten both screws.
The baffle door supplied can be used for advertisement and rotatable, unfasten the two plastic head screws at both
ends and move it till the angle desired, at last tighten them.
After installation, take out the Power Adaptor supplied with the product, plug the output end of the adaptor into the
input end of the product’s power cord. After powered on, the light panel will be on.
Note:
1. Before use, please check if the screws at the both ends of the rotating axes are tightened.
2. While use, DO NOT squeeze grille cover with great force ormove it forcefully , otherwise it is deformed or broken .

5/8
MAINTENANCE
To prolong the life of the product it is very important to do maintenance work. If the product is idle for a long time, damp, smoke or
particularly dirty around can cause great accumulation of dirt on its cover and housing. So it should be cleaned to maintain an
optimum light output and at the same time kept from being corrupted by acid gas.
Cleaning frequency depends on the environment in which the product operates. Soft cloth and typical glass cleaning products should
be used for cleaning with due care. It is recommended to clean product at least once every 20 days.
Do not use any organic solvent, e.g. alcohol, to clean housing of the product.
TROUBLESHOOTING
PROBLEM ACTION
The product can’t be on
¾Power cord is not correctly connected.
¾Power Adaptor damaged or abnormal, Call a qualified person
The beam appears dim
¾The product is too hot. Take necessary ventilation measures to make it
cool.
Grille Cover Component

6/8
TECHNICAL DATA
POWERADAPTOR:
Input voltage:
100V-240V AC, 50/60Hz
Output voltage:
12V DC
POWER CONSUMPTION:
8W@220V
LED:
Power consumption 6W
Quantity
Manufacturers Rated LED Life More than 30000 Hours
COLOURTEMPERATURE:
PR-3605T 3200K
PR-3605D 5600K
CRI
Ra>93
LIGHT OUPUT:
200 lm
BEAMANGLE:
Field angle(one-tenth peak) θ90
°~150°
HOUSINGAND IP:
High Tensile aluminum alloy, IP20
WORK ENVIRONMENTTEMPERATURE:
-20°C~40°C
WEIGHT:
0.75kg
One light board with 24pcs bulbs

7/8
MEASUREMENTS
COMPONENT ORDER CODES
NAME PARTNO. QUANTITY REMARK
POWER ADAPTOR 192010158 1 12V 0~1A
LED PANEL(PR-3605T) 150020264 1 CT3200K
LED PANEL (PR-3605D) 150020265 1 CT5600K

8/8
PR LIGHTING LTD.
PR New Hi-tech Science Park, 1582 Xingye Avenue
Nancun Panyu, Guangzhou, 511442 China
TEL: [phone]
FAX: [phone]
P/N: 320020168
Version: 20130514
