Prebena PKT-8-PR100 Installation instructions

Original Operating Manual for Motor-
Powered Hybrid Fastener Driver Tools
PKT-8-PR100
PKT-8-PR100-LM
PKT-8-PR100-SET
PKT-8-PR100-SET4
PKT-8-PR100-LM-SET
PKT-8-PR100-LM-SET4
PKT-8-RKP100
PKT-8-RKP100-LM
PKT-8-RKP100-SET
PKT-8-RKP100-SET4
PKT-8-RKP100-LM-SET
PKT-8-RKP100-LM-SET4
Warning: Please read the instructions and warnings for
this tool carefully before use. Failure to do so could
lead to serious injury.

Table of contents
Information about the manual .........................................................4
Integral part of the fastener driving tool.........................................5
Other applicable documents..........................................................6
Design features of the text.............................................................6
Design features of warning notices ...............................................7
Design features of notices to material damage.............................7
Definitions related to the tool.........................................................8
Safety .................................................................................................9
Proper use .....................................................................................9
Improper use................................................................................10
Safety notices ..............................................................................10
Personnel qualifications...............................................................17
Safety devices .............................................................................17
Personal protective equipment....................................................19
Description ......................................................................................21
Scope of delivery .........................................................................21
Information on the rating plate.....................................................22
Overview of the tool.....................................................................23
Task and function ........................................................................27
Control panel ...............................................................................28
Before operation .............................................................................30
Unpacking the fastener driving tool.............................................30
Checking the condition ................................................................30
Filling with compressed air ..........................................................32
Fastening and removing the magazine .......................................37
Loading and emptying the magazine...........................................40
Attaching and removing rechargeable batteries..........................43
Turning on the tool.......................................................................44
Checking the function..................................................................44
Operation.........................................................................................46
Selecting triggering process ........................................................46
Adjusting the insertion depth .......................................................47
Using imprint protection...............................................................49
Driving in nails .............................................................................50
Setting down the fastener driving tool .........................................53
Using the crossbar hook..............................................................54
Venting the fastener driving tool..................................................54

After operation................................................................................56
Turning off the tool ......................................................................56
Removing the rechargeable battery............................................57
Emptying the magazine...............................................................57
Transport and storage ...................................................................58
Packing the fastener driving tool.................................................59
Transporting the fastener driving tool..........................................60
Storing the fastener driving tool...................................................61
Cleaning and maintenance............................................................62
Cleaning ......................................................................................62
Maintenance................................................................................64
Eliminating malfunctions...............................................................65
Rectifying malfunctions in transport to the shot channel.............65
Eliminating other malfunctions ....................................................66
Overview of malfunctions ............................................................67
Ordering accessories.....................................................................70
Available accessories..................................................................70
Information about ordering nails..................................................70
Technical data.................................................................................71
Fastener driving tools..................................................................71
Compressed air cartridge KT-1000.............................................72
Battery and batter charging station .............................................73
Disposing of the fastener driving tool..........................................74
Manufacturer's address.................................................................75
Warranty..........................................................................................76
Index ................................................................................................77

Information about the manual
4
Information about the manual
This operating manual will help you to use the following motor-
powered fastener driving tools safely, economically and as intended:
Tool type
Equipment
PKT-8-PR100
for paper-tape half head nails 34°, standard
magazine with loading capacity for one nail strip,
compressed air cartridge, without battery
PKT-8-PR100-LM
for paper-tape half head nails 34°, long magazine
with loading capacity for two nail strips,
compressed air cartridge, without battery
PKT-8-PR100-SET
for paper-tape half head nails 34°, standard
magazine with loading capacity for one nail strip,
compressed air cartridge, charger, rechargeable
battery 5.5 Ah
PKT-8-PR100-SET4
for paper-tape half head nails 34°, standard
magazine with loading capacity for one nail strip,
compressed air cartridge, charger, rechargeable
battery 4.0 Ah
PKT-8-PR100-LM-SET
for paper-tape half head nails 34°, long magazine
with loading capacity for two nail strips,
compressed air cartridge, charger, rechargeable
battery 5.5 Ah
PKT-8-PR100-LM-SET4
for paper-tape half head nails 34°, long magazine
with loading capacity for two nail strips,
compressed air cartridge, charger, rechargeable
battery 4.0 Ah
PKT-8-RKP100
for plastic and paper-tape round head nails 20°,
standard magazine with loading capacity for one
nail strip, compressed air cartridge, without
battery
PKT-8-RKP100-LM
for plastic and paper-tape round head nails 20°,
long magazine with loading capacity for two nail
strips, compressed air cartridge, without battery

Information about the manual
5
Tool
Equipment
PKT-8-RKP100-SET
for plastic and paper-tape round head nails 20°,
standard magazine with loading capacity for one
nail strip, compressed air cartridge, charger,
rechargeable battery 5.5 Ah
PKT-8-RKP100-SET4
for plastic and paper-tape round head nails 20°,
standard magazine with loading capacity for one
nail strip, compressed air cartridge, charger,
rechargeable battery 4.0 Ah
PKT-8-RKP100-LM-SET
for plastic and paper-tape round head nails 20°,
long magazine with loading capacity for two nail
strips, compressed air cartridge, charger,
rechargeable battery 5.5 Ah
PKT-8-RKP100-LM-
SET4
for plastic and paper-tape round head nails 20°,
long magazine with loading capacity for two nail
strips, compressed air cartridge, charger,
rechargeable battery 4.0 Ah
Integral part of the fastener driving tool
This operating manual is an integral part of the fastener driving tool.
▶Always keep this operating manual available for the users in the
compartment provided for it in the transport case included with
delivery.
▶If the operating manual is lost or has become illegible, request a
new copy from the manufacturer.
▶If you sell the fastener driving tool or convey it to a third party by
some other means, deliver the operating manual together with it.
▶Make certain this operating manual is available for every user.
▶Do not throw away this operating manual.

Information about the manual
6
Other applicable documents
This manual includes the following documents:
•Operating manual for cartridge KT-1000
•If the fastener driving tool was delivered with a rechargeable
battery and charger: Operating manual for rechargeable battery
and charger
•Declaration of Conformity
•Spare parts list
Design features of the text
Text elements of this operating manual are designed as follows:
Normal text
•Bulleted lists
−Second level bulleted lists
▶Series of steps
Tips for using the tool.

Information about the manual
7
Design features of warning notices
DANGER
Notices with the word DANGER warn of a
dangerous situation leading to death or serious
injuries.
WARNING
Notices with the word WARNING warn of a
dangerous situation that may possibly lead to death
or serious injuries.
CAUTION
Notices with the word CAUTION warn of a situation
that may to slight or moderate injuries.
ENVIRONMENTAL PROTECTION
Notices with the word ENVIRONMENTAL
PROTECTION warn of actions that may lead to
damage to the environment.
Design features of notices to material damage
ATTENTION!
These notices warn of a situation that will lead to
material damage and limited functionality.

Information about the manual
8
Definitions related to the tool
Motor-powered hybrid fastener driving tools are referred to in this
operating manual in shortened form as "fastener driving tools" or,
when clear from the context, as "tools."
Definition of the tool sides
The sides of the fastener driving tool are defined as follows relative
to the direction of motion of the nails:
1
front: tool tip
2
right
3
rear
4
left

Safety
9
Safety
Failure to comply with the safety instructions in this operating manual
may lead to serious accidents with severe or even fatal injuries.
▶Make note of and follow all warnings and notices in this operating
manual and on the fastener driving tool while working with the
fastener driving tool.
Proper use
The fastener driving tools described here are hand-guided, motor-
powered hybrid power tools. They are used to drive nails into wood
materials with strength C30 in accordance with EN 338 and a
maximum bulk density of 460 kg/m³.
Use of the fastener driving tool on other materials is only permitted
after consultation with the manufacturer.
The allowable nail types are:
•RKP: Round head nail, in paper-tape nail strip
•PR: Half head nail, in paper-tape nail strip
The tool is also able to process round head nail type RK with
plastic-tape nail strips.
Observing safety requirements
Proper use also includes:
•complying with accident prevention regulations and the
requirements and standards in force at the operation site,
•observing and following all the instructions specified in this
operating manual, especially the safety instructions.

Safety
10
Improper use
Any usage other than what is described here is improper and
therefore contrary to the designated usage.
The following types of usage in particular are classified as improper:
•Operation by persons who do not know how to use fastener driving
tools and the materials used with them
•Operation with the safety device bypassed
•Use of nail types not specified in this operating manual
•Operation with compressed air cartridges other than those named
in this manual
•Operation with materials other than those named in this manual
•Operation with rechargeable batteries other than those named in
this manual
Consequences of improper usage
Improper usage can lead to serious personal injuries and material
damage.
Improper usage will also cause claims under the warranty or liability
to be voided. The manufacturer assumes no liability resulting from
improper usage.
Safety notices
General power tool safety warnings
WARNING Read all safety warning and all instructions.
Failure to follow the warnings and instructions may result in electric
shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
1. Work area safety
Keep work area clean and will lit. Cluttered or dark areas invite
accidents.
Do not operate power tools in explosive atmospheres, such as
in the presence of flammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or fumes.
Keep children and bystanders away while operating a power
tool. Distractions can cause you to lose control.

Safety
11
2. Electrical safety
Avoid body contact with earthed or grounded surfaces, such as
pipes, radiators, ranges and refrigerators. There is increased risk
of electric shock if your body is earthed or grounded.
Do not expose power tools to rain or wet conditions. Water
entering a power tool will increase the risk of electric shock.
3. Personal safety
Stay alert, watch what you are doing and use common sense
when operating a power tool. Do not use a power too while you
are tired or under the influence of drugs, alcohol or medication.
A moment of inattention while operating power tools may result in
serious personal injury.
Use personal protective equipment. Always wear eye
protection. Protective equipment such as dust mask, non-skid
safety shoes, hard hat, or hearing protection used for appropriate
conditions will reduce personal injuries.
Prevent unintentional starting. Ensure the switch is in the off-
position before connecting to power source and/or battery pack,
picking up or carrying the tool. Carrying power tools with your
finger on the switch or energising power tools that have the switch on
invites accidents.
Do not overreach. Keep proper footing and balance at all times.
This enables better control of the power tool in unexpected
situations.
Dress properly. Do not wear loose clothing or jewellery. Keep
your hair, clothing and gloves away from moving parts. Loose
clothes, jewellery or long hair can be caught in moving parts.
4. Power tool use and care
Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer at
the rate for which it was designed.
Do not use the power tool if the switch does not turn it on and
off. Any power tool that cannot be controlled with the switch is
dangerous and must be repaired.
Disconnect the plug from the power source and/or the battery
pack from the power tool before making any adjustments,
changing accessories, or storing power tools. Such preventive

Safety
12
safety measures reduce the risk of starting the power tool
accidentally.
Store idle power tools out of the reach of children and do not
allow persons unfamiliar with the power tool or these
instructions to operate the power tool. Power tools are dangerous
in the hands of untrained users.
Maintain power tool. Check for misalignment or binding of
moving parts, breakage of parts and any other condition that
may affect the power tool’s operation. If damaged, have the
power tool repaired before use. Many accidents are caused by
poorly maintained power tools.
Use power tool, accessories and tool bits etc. in accordance
with these instructions, taking into account the working
conditions and the work to be performed. Use the power tool for
operations different from those intended could result in a hazardous
situation.
5. Battery tool use and care
Recharge only with the charger specified by the manufacturer. A
charger that is suitable for one type of battery pack may create a risk
of fire when used with another battery pack.
Use power tools only with specifically designated battery packs.
Use of any otherÛattery packs may create a risk of injury and fire.
When battery pack is not in use, keep it away from other metal
objects, like paper clips, coins, keys, nails, screws or other
small metal objects, that can make a connection from one
terminal to another. Shorting the battery terminals together may
cause burns or a fire.
Under abusive conditions, liquid may be ejected from the
battery; avoid contact. If contact accidentally occurs, flush with
water. If liquid contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irritation or burns.
Do not use a battery pack or tool that is damaged or modified.
Damaged or modified batteries may exhibit unpredictable behaviour
resulting in fire, explosion or risk of injury.
Do not expose a battery pack or tool to fire or excessive
temperature. Exposure to fire or temperature above 130 °C may
cause explosion.

Safety
13
Follow all charging instructions and do not charge the battery
pack or tool outside the temperature range specified in the
instructions. Charging improperly or at temperatures outside the
specified range may damage the battery and increase the risk of fire.
6. Service
Have your power tool serviced by a qualified repair person
using only identical replacement parts. This will ensure that the
safety of the power tool is maintained.
Safety instructions for fastener driving tools
•Always assume that the tool contains fastener. Careless
handling of the fastener driving tool can result in unexpected firing
of fastener and personal injuries.
•Do not point the tool towards yourself or anyone nearby.
Unexpected triggering will discharge the firing of fastener and
personal injuries.
•Do not actuate the tool unless the tool is placed firmly against
the workpiece. If the tool is not in contact with the workpiece, the
fastener may be deflected away from your target.
•Disconnect the tool from the power source when the fastener
jams in the tool. While removing a jammed fastener, the fastener
driving tool may be accidentally activated if it is plugged in.
•Use caution while removing a jammed fastener. The
mechanism may be under compression and the fastener may be
forcefully discharged while attempting to free a jammed condition.
•Do not use this fastener driving tool for fastening electrical
cables. It is not designed for electric cable installation and may
damage the insulation of electric cables thereby causing electric
shock or fire hazards.
Preventing explosion hazards
Serious or fatal injuries possible due to explosion.
▶Never use the fastener driving tool in places subject to a danger
of explosion.
▶Never operate the fastener driving tool with oxygen or with any
other flammable gases or gas mixtures.
▶Do not expose the compressed air cartridge to temperatures
above 100 °C.

Safety
14
Preventing serious or fatal injuries
Serious or fatal injuries possible if the fastener driving tool is used
incorrectly.
▶The nails have high penetrating power! Never point the fastener
driving tool at yourself, other persons or animals.
▶Always hold the tool while working by the insulated handle
surfaces.
▶The fastener driving tool must only be triggered when the tool tip
is pressed against the workpiece.
▶Make certain you do not accidentally activate or touch the
triggering mechanism. Be especially attentive of this when setting
the tool down or changing your working position.
▶Remove the rechargeable battery and vent the fastener driving
tool before every maintenance task.
▶Ricocheting nails are also dangerous! Normally the fastener
driving tool must only be triggered when the tool tip is pressed
against the material.
▶Do not drive nails into power lines, gas lines or water lines.
Serious or fatal injuries possible if unauthorized changes are made
to the fastener driving tool.
▶Do not make any changes to the fastener driving tool.
▶Make certain the safety devices are not bypassed or made non-
functional in some other way.
▶Use the fastener driving tool only with the compressed air
cartridge specified in this operating manual.
▶Use the fastener driving tool only with the rechargeable battery
specified in this operating manual.
▶Use the fastener driving tool only with the nail types specified in
this operating manual.
Danger of asphyxiation for children playing packaging films.
▶Do not allow children to play with the packaging film.
▶Keep the packaging material where it is inaccessible for children.

Safety
15
Preventing risks of injury
Injuries possible if the fastener driving tool is used incorrectly.
▶Always keep the fastener driving tool in the transport case and
where it is inaccessible for children and other unauthorized
persons.
▶Never operate or transport the fastener driving tool with the
compressed air cartridge inserted.
▶Wear safety goggles and sturdy work clothes when operating the
fastener driving tool.
▶Hold the fastener driving tool so that you cannot be injured by a
possible recoil.
▶Use the fastener driving tool only when you have a secure
footing.
Injuries possible on the sharp tips of the nails.
▶Wear sturdy protective gloves when handling the fastener driving
tool and especially while loading it.
Hearing impairment possible due to loud operating noises.
▶Wear hearing protection while operating the fastener driving tool.
Injuries due to recoil possible during operation.
▶Use the fastener driving tool only when you have a secure
footing.
▶Make certain your hands remain warm and dry while operating
the fastener driving tool.
▶Hold the fastener driving tool securely, but without too much hand
pressure.
Injuries possible due to compressed air.
▶Make certain the discharged air is not directed at persons,
animals or body parts.
▶Make certain all the parts of the compressed air supply are in
flawless condition.

Safety
16
Preventing material damage
Damage or malfunctions in the fastener driving tool possible if
operated improperly.
▶Never open the housing of the fastener driving tool.
▶Do not use the fastener driving tool if it has been dropped or is
damaged.
DANGER
Risk of death due to operating a faulty fastener
driving tool.
Only the manufacturer is permitted to open the tool
and carry out repairs.
▶If the tool is damaged, send it in to the
manufacturer for repairs (see manufacturer's
address on page 75).

Safety
17
Personnel qualifications
All persons who work with or on the fastener driving tool must have
the following proficiencies and experience:
•Proficiency in working with fastener driving tool
•Ability to estimate the hazards associated with fastener driving
tools and proficiency for averting these hazards
•Knowledge of the applicable industrial safety regulations at the
workplace
•Familiarity with the required protective clothing
•Familiarity with the notices and instructions in the operating manual
and the other materials included with delivery
Persons who use the fastener driving tool in the commercial sector
must also be trained regarding the special risks in their workplace.
Persons without the proficiencies described above may only operate
the fastener driving tool under the supervision of and after having
been instructed by an experienced and qualified person.
Safety devices
Triggering safety device
Fastener driving tools are equipped with a triggering safety device on
the tool tip. The trigger can only be enabled if the triggering safety
device is pressed in.
WARNING
Very severe injuries when operating the fastener
driving tool with a faulty or bypassed triggering
safety device.
▶Use the fastener driving tool only with a
functioning triggering safety device.
▶Trigger the fastener driving tool only when the
tool tip is firmly pressed against the material.

Safety
18
Blank safety device
The fastener driving tool is equipped with a blank safety device. The
blank safety device blocks the triggering mechanism when there are
only 5–8 nails in the magazine.
Information signs on the fastener driving tool
The following mandatory signs are imprinted on the base of the
fastener driving tool:
Mandatory
sign
Meaning
Wear hearing protection while operating the
fastener driving tool.
Wear safety goggles while operating the fastener
driving tool.
Read this operating manual before startup.

Safety
19
The following symbol is attached to the front of the fastener driving
tool:
Pictograms
Meaning
Markings and warnings for tools with contact
actuation capability.
▶Do not leave your finger on the trigger when
the device is picked up, moved between work
areas and positions, or when walking, as
leaving your finger on the trigger can lead to
unintended operation.
▶In the case of devices with switchable
triggering, always check that the device is set
to the correct mode before use.
▶Do not use this tool in contact actuation for
applications such as closing boxes or crates
and fitting transportation safety systems on
trailers and lorries.
▶Be careful when changing from one driving
location to another.

Safety
20
Personal protective equipment
The fastener driving tool generates nails, compressed air and noise.
▶Wear suitable personal protective equipment for all tasks with the
fastener driving tool.
▶Take note of and follow the regulations at the place where the tool
is used when putting together the protective equipment.
Suitable protective equipment includes the following elements:
•Safety helmet
•Sturdy protective gloves
•Safety goggles
•Close fitting protective clothing
•Safety shoes with steel toecaps and non-slip soles
•Hearing protection
