Precision Rated Optics LS-200 SERIES User manual

LS-200 SERIES
Light Source
Operation Guide
V.3.2.20

2
888-545-1254 | www.PrecisionRatedOptics.com
LS-200 Series
Contents
1. Introduction..........................................................................................................................................................3
2. Warranty...............................................................................................................................................................3
3. Safety Information................................................................................................................................................3
4. Preparing for Operation......................................................................................................................................4
4.1 Unpacking the Instrument ................................................................................................................................4
4.2 Power Supply....................................................................................................................................................4
5. Operation ..............................................................................................................................................................5
5.1 Display and Controls........................................................................................................................................5
5.1.1 Front (Panel Board)...................................................................................................................................5
5.1.3 LCD...........................................................................................................................................................5
5.2 Turning the Instrument on and off....................................................................................................................5
5.3 Switching the Wavelength................................................................................................................................6
5.4 Frequency Output.............................................................................................................................................6
5.5 Auto-Wavelength Recognition.........................................................................................................................6
5.6 Switching Backlighting of the LCD on and off................................................................................................6
5. 7 Setting the Output Power.................................................................................................................................6
5.8 Connecting with Optical Power Meter.............................................................................................................6
6. Specifications ........................................................................................................................................................7
7. Maintenance..........................................................................................................................................................7

www.PrecisionRatedOptics.com | 888-545-1254
3
LS-200 Series
1. Introduction
The 200 Series Dual Light Source offers excellent stability and portability for accurate fiber optic testing. Single
output port provides stable laser power at dual wavelengths. The compact unit operates in either continuous wave
(CW) mode or modulated mode.
Designed with the technician in mind, output power is instantly adjustable from the keypad. A convenient “Low
Battery” indicator reminds the user to recharge the battery, while the lightweight, compact, ruggedized case of the
200 Series delivers rock-solid reliability under all working conditions.
2. Warranty
Three Years Limited Warranty
Products are warranted against the defective components and workmanship for a period of three years from the
date of delivery to the original customer. Any product found to be defective within the warranty period would be
returned to authorized service center for repair, replacement and calibration.
Exclusions
The warranty on your equipment shall not apply to defects resulting from the following:
Unauthorized repair or modification including battery replacement
Misuse
Negligence
Accident
Returning Product
To return product, you may contact PRO to obtain additional information if necessary. To serve you better, please
specify the reasons for the return. All delivery and mails should be sent to the following address:
121 Park Avenue, Quakertown, PA
3. Safety Information
Warning
Never look directly into optical outputs or a fiber while the equipment is on. Invisible and visible laser
beam may damage your eyes.
Do not short-circuit the terminal of AC adapter I charger and the batteries. Excessive electrical current
may cause personal injury due to fumes, electric shock or equipment damage.
Connect DC power cord with the equipment and wall socket properly. While inserting the DC plug, make
sure there is no dust or dirt on the terminals and both plugs are fully seated. Incomplete engagement may
cause fuming, electric shock or equipment damage and may result in personal injury.
Do not operate the equipment near hot objects, in hot environments, in dusty/ humid atmosphere or when
condensation is present on the equipment. This may result in electric shock, product malfunction or poor
performance.

4
888-545-1254 | www.PrecisionRatedOptics.com
LS-200 Series
4. Preparing for Operation
4.1 Unpacking the Instrument
Packing Material
We suggest that you keep the original packing material. Using the original packing material is your guarantee of
protecting the instrument during transit.
Standard Accessories:
Light Source, FC/PC, SC/PC, ST/PC Interchangeable Connector, User Manual, Worldwide-Compatible AC/DC
Power Adaptor, Rechargeable Ni-MH Batteries (x2), Test Report, Soft Carrying Case
Checking for Damage in Transit
After unpacking the instrument, check to see whether it was damaged in transit. This is particularly likely if the
outer casing is clearly damaged. If there is damage, do not attempt to operate the instrument or to repair it without
authorization. Doing so can cause further damage and you may lose your warranty qualification.
4.2 Power Supply
There are battery indicator and power plug on the screen to show the power supply. When you use the DC 6v
charger, there is no battery indicator on the screen. When you do not connect the DC 6v charger, the adapter
indicator will disappear on the screen.
When you use the battery, the battery indicator on the screen will show the remaining charge. An empty battery
indicator means the power is almost out. When the battery charge is extremely low to supply the necessary power,
the instrument will automatically switch off after several beeps of the buzzer. Please change the battery or
recharge it

www.PrecisionRatedOptics.com | 888-545-1254
5
LS-200 Series
5. Operation
5.1 Display and Controls
5.1.1 Front (Panel Board)
Key
Function
Wavelength Shifting Key: Switches working wavelength between 850nm, 1300nm,
1310nm, 1490nm and 1550nm.
Modulated Wavelength Shifting Key: Switches modulated wavelength
and continuous wavelength.
Output Power Increase and Decrease: Increase or decrease output power by 0.1 dB and
the adjustable range is ±3dB wavelength.
SINGLE: Auto-wavelength recognition is off.
TWIN: Auto-wavelength recognition is on .
Switches backlighting on/off.
Switches Instrument on/off. Long keypress while powering on to activate the instrument
without Auto-off function.
5.1.3 LCD
5.2 Turning the Instrument on and off
1) Press the "ON/OFF" key briefly.
2) The instrument powers on.(See the figure)
3) Press the "ON/OFF" key briefly again.
4) The instrument powers off.
Note: Auto-off function
1) The instrument powers off automatically if no key press in 10 minutes.
2) Press the "ON/OFF" key for about 2 seconds to power on the instrument with "Auto-off" function
deactivated.

6
888-545-1254 | www.PrecisionRatedOptics.com
LS-200 Series
5.3 Switching the Wavelength
Press the [ ] Key to switch the wavelength between 850nm, 1300nm, 1310nm, 1490nm and 1550nm.
5.4 Frequency Output
The instrument defaults to CW when it switches on. When it is set to CW, there is no frequency on display.
Press the [CW/Hz] Key to select the output among 270Hz, 1 kHz and 2 kHz.
5.5 Auto-Wavelength Recognition
Press the [TWIN] Key to turn on and off the auto-wavelength recognition function.
5.6 Switching Backlighting of the LCD on and off
Press the backlighting Key to switch the backlighting of the LCD on and off.
5. 7 Setting the Output Power
Press the [ ] key to increase the output power. The measurement range is from -2dBm to -8dBm. Each time
you press it, the value increases by 0.1dBm.
Press the [ ] key to decrease the output power. The measurement range is from -2dBm to -8dBm. Each time
you press it, the value decreases by 0.1dBm.
5.8 Connecting with Optical Power Meter
It can work with optical power meter to measure the loss of optical fiber accurately.

www.PrecisionRatedOptics.com | 888-545-1254
7
LS-200 Series
6. Specifications
Model
LS-202D
LS-201T
LS-202T
LS-201Q
Output Wavelength
(nm)
1310 / 1550
1310 / 1490 /
1550
1310 / 1550 / 1625
850 / 1300 / 1310 / 1550
Emitter Type
LD
Connector
FC/PC, SC/PC, ST/PC (Interchangeable)
Output Stability
Short-Term (15 min.): < ±0.05dB
@ 1310,1550nm
Long Term (>8 Hours ): < ±0.1dB
@ 1310,1550nm
Short-Term (15 min.): < ±0.05dB @
1310,1550nm; ±0.1dB @ 1625nm
Long-Term (8 Hours ): < ±0.1dB @
1310,1550nm; ±0.2dB @ 1625nm
Short-Term (15 min) <±0.05dB @
1310nm/1550nm / ±0.1dB @
850nm/1300nm
Long-Term (>8 Hours) <±0.1dB @
1310nm/1550nm / ±0.2dB @
850nm/1300nm
Central Wavelengths
± 20nm
Spectral Width
5 nm
Output Frequency
(Hz)
270 / 1,000 / 2000
Output Power
-5 dBm
Power Supply
2500mAh Ni-MH AA (x2), AC/DC Power Supply
Operating
Temperature
14º F ~ 122º F (-10º C ~ 50º C )
Storage Temperature
-4º F ~ 158º F (-20º C ~ 70º C)
Weight & Dimensions
(HxWxD)
6.3” x 3” x 1.8” / 9.5 oz (160 x 76 x 45 mm / 270 g)
Warranty
Standard 1-Year Manufacturer Warranty (Extended Warranty Available)
7. Maintenance
Please disconnect the DC adapter/charger and cover the protective dust cap once you finish using.
It is a good idea to clean the connector and the instrument when they get dirty through use. Optical
cleaning pads and anhydrous alcohol is recommended. And please be careful not to get the detergent
inside the instrument.
To ensure the measurement accuracy, please send the instrument to Service Center for calibration once a
year.

Precision Rated Optics, Inc.
Headquarters
121 Park Avenue
Quakertown, PA 18951
