600 Line Upright Bike (UBK) Assembly Guide
To assemble the equipment, follow the steps in the order listed in this assembly guide. For more product information, visit us at www.precor.com.
WARNING
At least two people are required to assemble the equipment. DO NOT attempt assembly
by yourself.
Seat
Rear stabilizer
Upright Support
Bottle holder
Handle bars
Console
mount
Front stabilizer
We recommend you:
▪ Assemble the equipment close to where you plan to use it.
▪ Assemble the equipment on a solid, at surface, so that it remains level and stable.
▪ Locate the equipment at least 19.7 inches (0.5 meter) away from walls or furniture on either side of the
equipment, and 19.7 inches (0.5 meter) away from objects behind or in front of the equipment.
▪ DO NOT move the equipment without assistance.
Required tools and hardware
For hardware, the US English acronym is used throughout the guide and in all localized versions.
Tools Component Description Quantity Component Description Quantity
▪ 6 mm hex wrench
▪ 10 mm hex wrench
▪ 5/32-inch hex wrench
▪ 13 mm open-end, box or
socket wrench
▪ 17 mm open-end wrench
▪ #2 Phillips screwdriver
▪ Wire cutter
▪ Fish tape
Socket head cap screw
(SHCS) / M12 x 80 mm
2 Pan head cap screw
(PHCS) / M5 x 12 mm
2
Socket head cap screw (SHCS) /
M8 x 25 mm
4 Washer, zinc / 8.2 mm 3
Button head cap screw (BHCS) /
M10 x 40 mm
4 Washer, black / 8.1 mm 4
Plug for access hole on upright
support
1 Nylon lock nut / M8 3
Attach the stabilizers
NOTE
The front stabilizer has two wheels. These wheels help to move the location of
the bike.
Figure 1 Figure 2
To attach the stabilizers:
1. Place the rear stabilizer under the bracket at the rear of the bike (Figure 1).
2. Attach the rear stabilizer using two M10 x 40 mm BHCS. Fully tighten the screws using a
6 mm hex wrench (Figure 2).
3. Place the front stabilizer underneath the bracket at the front of the bike (Figure 3).
4. Secure the front stabilizer using two M10 x 40 mm BHCS. Fully tighten the screws using
a 6 mm hex wrench (Figure 4).
Figure 3 Figure 4
To attach the seat:
1. Place the seat on the bracket so that the three bolts extend through the screw holes.
2. Attach an 8.2 mm washer and M8 Nylon lock nut to each bolt. Fully tighten the fasteners using a 13 mm
socket wrench.
Figure 5

Attach the upright support and cables
CAUTION
DO NOT attempt to connect electrical power until all assembly procedures are complete and properly installed.
To attach the upright support and cables:
1. Retrieve the cables for the console that you plan to install on this bike and for any PVS equipment that you
plan to install on the console.
2. Remove the wire tie securing the base unit data cable inside the upright support channel. Save the tie for use
in Step 4.
If you are installing PVS equipment on the console, continue with Step 3. If you are not installing PVS
equipment, skip to Step 5.
3. Feed the television and power cables through the opening just above the front stabilizer.
4. Use the wire tie from Step 1 to bind the upper ends of the cables together.
5. Using a sh tape, place the upright support on the oor with its lower end next to the bike. Thread the cable(s)
upward through the support and secure them to the top of the support.
6. Remove the extra serial number label from the upright support channel and set it aside for attachment to the
console mount bracket during console installation.
7. Lift the upright support and position its lower end over the upright support channel. Set the upright support
so that it rests on the metal tab within the upright support channel to prevent sliding (Figure 6).
IMPORTANT
DO NOT pinch the cable during this step.
8. Insert two M12 x 80 mm SHCS through the opening on the support and into the screw holes on the body
assembly (Figure 7). Fully tighten using a 10 mm hex wrench.
Figure 6
Figure 7
Attach the handlebars:
1. Place the handlebars on the arms of the upright support.
2. Thread the heart rate cable through the nearest arm of the upright
support (Figure 8), then up through the support itself and out the
opening in console mount.
TIP
Use the access hole near the top of the upright support to
guide the cable to the upper opening.
Figure 8
3. Set the handlebars on the upright support and pull the extra cable
through the upright support.
IMPORTANT
DO NOT pinch the cable during this step.
4. Attach it using four screws and washers. Fully tighten the screws using a
6 mm hex wrench.
Figure 9
5. Place the plug in to the access hole on the upright support.
Figure 10
To attach the bottle holder:
1. Position the bottle holder against the upright support so that the
screw holes in the bottle holder line up with those in the support.
2. Secure the bottle holder to the upright support using two M5 x 12
mm PHCS. Fully tighten using a #2 Phillips screwdriver.
NOTE
Due to the curvature of the upright support, insert the
screws at an angle.
Figure 11
Level the equipment
Make sure the equipment is level before allowing anyone to use it.
CAUTION
To eliminate movement, make sure the adjustable feet
are in contact with the oor. Rotating the adjustable feet
cannot compensate for extremely uneven surfaces.
To level the equipment:
1. Try to shake the equipment. If there is any movement, tip the
equipment to one side to locate the adjustable foot.
2. Correct the height of each adjustable foot as follows:
If you want to ... Then turn the
adjustable feet …
Raise the
equipment
Counterclockwise
Lower the
equipment
Clockwise
3. When you are nished adjusting the equipment, recheck for
movement and readjust as necessary.
