Prestigio Visconte 121 Technical Service Manual
Prestigio Visconte 121
Notebook
Service Technical
Manual

Prestigio Visconte 121 Technical Service Manual
This page is left blank intentionally.

Prestigio Visconte 121 Technical Service Manual
I-I
Chapter 1 Introduction ______________________________________________________ 1-1
1.1 Overview Of This Manual__________________________________________________________ 1-1
1.2 System Overview ________________________________________________________________ 1-1
1.3 Other References____________________________________________ 1-Error! Bookmark not defined.
Chapter 2 The BIOS Setup ___________________________________________________ 2-1
2.1 Configuration Software ____________________________________________________________ 2-1
2.2 Running the Setup Utility __________________________________________________________ 2-2
2.3 Main Setup _____________________________________________________________________ 2-3
2.4 Advanced Setup _________________________________________________________________ 2-5
2.5 Security Setup___________________________________________________________________ 2-7
2.6 Boot Setup _____________________________________________________________________ 2-8
2.7 Exit Setup______________________________________________________________________ 2-9
Chapter 3 System Utilities____________________________________________________ 3-1
3.1 The BIOS Flash Utility ____________________________________________________________ 3-1
3.2 The KBC (H8) Flash Utility ________________________________________________________ 3-1
Chapter 4 Upgrading Memory ________________________________________________ 4-1
Chapter 5 Removing Mini-PCI Module __________________________________________ 5-1
Chapter 6 Preliminary Dis-Assembly ___________________________________________ 6-1
Chapter 7 Removing The HDD Drive ___________________________________________ 7-1
Chapter 8 Removing The Motherboard __________________________________________ 8-1
Chapter 9 Removing The Palmrest _____________________________________________ 9-1
Chapter 10 Removing The Modem Module _______________________________________ 10-1
Chapter 11 Removing The Heatsink ____________________________________________ 11-1
Chapter 12 Removing The LCD Display _________________________________________ 12-1
Chapter 13 Fuse Rating Table ________________________________________________ 13-1
CONTENTS

Prestigio Visconte 121 Technical Service Manual
I-II
This page is left blank intentionally.

Prestigio Visconte 121 Technical Service Manual
1-1
Chapter 1 Introduction
1.1 Overview Of This Manual
This Service Manual is written for engineers and technicians and is meant to help them to
service and repair the notebook. Detail descriptions on major parts and components will
not be discussed in this manual. This manual is mainly written with Office 2000 Word
software. Should you find any error or spelling mistake that we have inadvertently missed,
we apologize for such negligence; but please let us know.
1.2 System Overview
 VIA C3 Ezra-T EBGA 800MHz/933MHz/1GHz processor with 128KB (L1)/64KB
(L2) cache memory.
 Core Logic: VIA chipset composing of VT8606-T Twister (NorthBridge) and
VIA VT82C686B (SouthBridge).
 One SDRAM S.O. DIMM memory socket is upgradeable from the basic 128MB/256MB
to 640MB/768MB memory.
 512KB Flash ROM contains BIOS and is easily user upgradeable.
System Display
 UMA Module with embedded high performance 8MB/16MB/32MB video memory.
 Display Panel: TFT 12.1” XGA.
System Storage
 Industry standard 20GB/40GB 9.5mm hard disk drive.
 Optional external USB industry standard 3.5inch 1.44MB floppy disk drive.
 Optional external USB CD-ROM Drive, or
DVD-ROM drive, or
Combo Drive.

Prestigio Visconte 121 Technical Service Manual
1-2
System Keyboard
 83 full keys, including 2 Windows keys, and embedded numerical keypad.
Connectivity and Expansion
 One 15-pin VGA port.
 One microphone-in connector.
 One headphone-out.
 One RJ11 Fax/Modem connector.
 Two 4-pin USB ports.
 One DC-in Jack.
 One RJ45 LAN connector.
 One type II CF card connection.
 One IEEE1394 port.
 One type II slot for PCMCIA connection.
Power
 Two battery slots to support dual Lithium Ion (Li-Ion) battery packs.
 Offline battery charging time is around 2.5 hours for Li-Ion battery pack.
 Full range 110 to 240V auto-switch AC adapter; 100Vac input voltage on load power
consumption < or = 1W.
Physical
Weight (TFT color, 12.1”) : 1.33kg, including one battery pack.
Length/Width/Height : 265mm/220mm/23mm.
Note: Weight and height might change due to different configurations and models.
Environment
Operating Temperature : 10°C to 35°C.
Non-Operating Temperature : -20°C to 60°C.
Humidity : 20% to 80% non-condensing.
Shock : 5G operating, 60G non-operating.
Vibration : 3-200Hz @ 1.0G operating.
: 3-200Hz @ 1.5G non-operating.
Warning: Don't expose your notebook to excessive heat or coldness (frost). Don't
drop, spill fluids or open the exterior of the case. This can damage the
notebook and void the warranty.

Prestigio Visconte 121 Technical Service Manual
1-3
POWER MANAGEMENT
Advanced Configuration Power Interface (ACPI) 2.0 for Windows XP®.
OPERATING SYSTEM
Windows® XP.
OPTIONS
 Standard SDRAM S.O. DIMM self-fresh 512MB memory module for expansion from
128MB/256MB to 640MB/768MB.
 Optional Lithium Ion (Li-Ion) battery pack in slot B.
 External CD-ROM Drive, or
DVD-ROM Drive, or
Combo Drive.

Prestigio Visconte 121 Technical Service Manual
1-4
This page is left blank intentionally.

Prestigio Visconte 121 Technical Service Manual
2-1
Chapter 2 The BIOS Setup
2.1 Configuration Software
The notebook can easily be configured to suit your personal needs. The built-in SETUP
program allows you to setup various system parameters. The information is stored in a
battery-backed CMOS memory; so when the power is turned off, your setup is retained.
This Configuration Software is sometimes referred to as CMOS Setup, BIOS Setup, or
simply the SETUP.
Note: The SETUP can be activated by pressing <F2> during system boot-up.
You are requested to perform the following one-time procedure immediately after you have
upgraded/reprogrammed your BIOS:
•Press <F2> during system boot-up to get into the SETUP.
•Go to the EXIT sub-menu and choose Load Setup Defaults. Press Enter.
•Now, you can customize the BIOS for your personal needs.
For detail on the BIOS SETUP, read on.
Note: For information on the BIOS upgrade, contact your local notebook dealer.

Prestigio Visconte 121 Technical Service Manual
2-2
2.2 Running the Setup Utility
There are five major sub-menus in the SETUP program: Main Setup, Advanced Setup,
Security Setup, Boot Setup, and Exit Setup. Details on the five major sub-menus are
described on the following pages.
Movement within the SETUP utility
To move between the different item fields, use the cursor keys ↑and ↓. To move between
the five SETUP sub-menus, use the cursor keys ←and →. To change the value of a field,
press the <+> and <−> keys. When you select one item, this item will be highlighted and a
brief explanation would be displayed in the Item Specific Help box located on the right
side of the screen. The followings are some of the most commonly used keys:
•Press <F1> to enter the menu of Help.
•Press <F9> to enter the menu of Setup Defaults, then press Enter to continue or
press Esc to abort.
•Press <F10> to enter the menu of Save & Exit. This would save modifications you
have made. Then exit.
•Press Enter to execute command.
•Press Esc to get to the EXIT Setup sub-menu, or to the next higher-level sub-menu.
Note: The settings shown on the following sub-menu displays are factory default
settings.
The content of these sub-menu displays, described in the rest of this chapter, is
subject to change in the future.

Prestigio Visconte 121 Technical Service Manual
2-3
2.3 Main Setup
You will be greeted by this screen when you enter the Main Setup menu:
PhoenixBIOS Setup Utility
Main Advanced Security Boot Exit
Item Specific Help
System Time:
System Date:
 Internal HDD
System Memory:
Extended Memory:
CPU Type
CPU Speed
BIOS Version
KBC Version
[15:54:23]
[11/12/2002]
[20004MB]
640 KB
121856 KB
VIA C3 Processor
800 MHz
A01
P00
<Tab>,<Shift-Tab>, or <Enter>
selects field.
F1 Help
Esc Exit
 Select Item
 Select Menu
− / + Change Values
Enter Select  Sub-
Menu
F9 Setup Defaults
F10 Save and Exit
System Time:
Current time. Use <Tab>, <Shift-Tab>, or <Enter> keys to move around these fields. To
change the value, press <+> or <−> key.
System Date:
Today’s date. Use <Tab>, <Shift-Tab>, or <Enter> keys to move around these fields. To
change the value, press <+> or <−> key. Set any date from year 1901 to 2099. It will
automatically keep track of leap years. The system date can also be set from the operating
system.
Internal HDD:
Press [Enter] to enter the sub-menu. In the sub-menu, there are four options for HDD
type: Auto, User, CD/DVD, None. In general, you should choose the default value “Auto”
to let the system automatically detect the HDD you have in the system. If Auto fails to
recognize your HDD, you can choose value “User”; then enter the parameters according
to the specifications of your HDD.

Prestigio Visconte 121 Technical Service Manual
2-4
System Memory:
This is for display only. This shows the system memory is 640KB.
Extended Memory:
This is for display only. This shows the extended memory is 121856.
CPU Type:
This is for display only. This shows the type of CPU you have in your system.
CPU Speed:
This is for display only. This shows the processor speed is 800MHz.
BIOS Version:
This is for display only. This shows the BIOS version is A01.
KBC Version:
This is for display only. This shows the KBC version is P00.

Prestigio Visconte 121 Technical Service Manual
2-5
2.4 Advanced Setup
You will be greeted by this screen when you enter the Advanced Setup menu:
PhoenixBIOS Setup Utility
Main Advanced Security Boot Exit
Item Specific Help
NumLock on Boot:
Internal Mouse:
LCD Panel View Expansion:
Frame Buffer Size:
BootUp Message
Summary screen:
Silent Boot:
Legacy USB Support:
USB Operation Mode:
[LockOff]
[Enabled]
[Enabled]
[8 MB]
[Enabled]
[Disabled]
[Disabled]
[Enabled]
[2.0 Mode]
Configure NumLock using
option.
F1 Help
Esc Exit
 Select Item
 Select Menu
− / + Change Values
Enter Select  Sub-Menu
F9 Setup Defaults
F10 Save and Exit
NumLock on Boot:
There are two options to this field: LockOff and LockOn. If you want to have the system
automatically have Num-Lock enabled after system boot-up, you should choose LockOn.
Otherwise, you can choose LockOff. You can also manually enable the Num-Lock
function by pressing the Num-Lock keycap located near the upper-right corner of the
internal keyboard.
Internal Mouse:
There are two options to this field: Enabled and Disabled. Disabled prevents the internal
mouse from functioning, but frees up IRQ12.
LCD Panel View Expansion:
There are two options to this field: Enabled, and Disabled. Enabled allows the panel view
to be expanded; such expansion may have an adverse effect on the quality of displayed
graphic/text. Disabled, in some video mode, may reduce the panel view.
Frame Buffer Size:
There are three options for video memory: 8MB, 16MB, and 32MB. User can select which
memory size to be used according to the requirement.
BootUp Message:
There are two options to this field: Enabled, and Disabled. Disabled prevents displaying
of the logo screen. Refer to Silent Boot below.

Prestigio Visconte 121 Technical Service Manual
2-6
Summary screen:
There are two options to this field: Disabled, and Enabled. This field allows you to enable
or to disable the display of system configuration during system boot-up.
Silent Boot:
There are three options to this field: Enabled, Disabled, and Black.
•Enabled allows the system to display the logo screen during system boot-up.
•Disabled does not allow showing the logo screen during system boot-up. As a result,
the POST (Power On Self Test) screen would be displayed.
•Otherwise, a screen would be displayed. This <Black> screen would last for about 20
seconds, and would appear as if the system has no response.
Legacy USB Support:
There are two options to this field: Disabled, and Enabled. Enabled allows the system to
boot up from USB floppy.
USB Operation Mode:
There are two options to this field: 1.1 Mode, and 2.0 Mode.The default value is 2.0
Mode.

Prestigio Visconte 121 Technical Service Manual
2-7
2.5 Security Setup
You will be greeted by this screen when you enter the Security Setup menu:
PhoenixBIOS Setup Utility
Main Advanced Security Boot Exit
Item Specific Help
Set Supervisor Password
Set User Password
Password on Boot
Fixed disk boot sector:
Enter]
[Enter]
[Disabled]
[Normal]
Supervisor Password
controls access to the
setup utility
F1 Help
Esc Exit
 Select Item
 Select Menu
− / + Change Values
Enter Select  Sub-Menu
F9 Setup Defaults
F10 Save and Exit
Set Supervisor Password:
Press <Enter> to get into its sub-menu. In this sub-menu (not shown here), you can set
system Supervisor Password. The Supervisor Password controls the access to the
SETUP utility, as well as the access to system boot-up if Password on Boot is enabled.
Set User Password:
Press <Enter> to get into its sub-menu. In this sub-menu (not shown here), you can set
system User Password. The User Password controls the access to system boot-up if
Password on Boot is enabled.
Password on Boot:
The setting of this field is available only if the Supervisor Password, and/or the User
Password had been set. There are two options to this field: Enabled, and Disabled. If
enabled, you can use the Supervisor Password (or use the User Password, if User
Password had indeed been set) to access system during system boot-up.
Fixed disk boot sector:
There are two options to this field: Write Protect and Normal. If Write Protect, the HDD
will automatically prevent and protect against virus intrusion during boot-up.

Prestigio Visconte 121 Technical Service Manual
2-8
2.6 Boot Setup
You will be greeted by this screen when you enter the Boot Setup Menu:
PhoenixBIOS Setup Utility
Main Advanced Security Boot Exit
Item Specific Help
Network
Boot:
Boot Order
[Disabled]
+Hard Drive
Network Boot
USB Devices
USB CD-ROM
[Disabled]
- Disable Network
Boot function
[Enabled]
- Enable Network
Boot function
F1 Help
Esc Exit
 Select Item
 Select Menu
− / + Change Values
Enter Select  Sub-Menu
F9 Setup Defaults
F10 Save and Exit
Network Boot:
There are two options to this field, Enabled and Disabled. Enabled allows the system to
boot up from Network.
Boot Order:
There are four options to this field, +Hard Drive, USB Devices,Network Boot, and USB
CD-ROM.Use <+>and <−> to escalate and down-grade the boot priority of selected
device. In general, the Hard Drive would be the first boot-up choice.

Prestigio Visconte 121 Technical Service Manual
2-9
2.7 Exit Setup
You will be greeted by this screen when you enter the Exit Setup Menu:
PhoenixBIOS Setup Utility
Main Advanced Security Boot Exit
Item Specific Help
Exit Saving Changes
Exit Discarding
Changes
Load Setup Defaults
Discard Changes
Save Changes
Exit System Setup and save
your changes to CMOS.
F1 Help
Esc Exit
 Select Item
 Select Menu
− / + Change Values
Enter Select  Sub-Menu
F9 Setup Defaults
F10 Save and Exit
Exit Saving Changes:
Save the changes that you have just made, and then exit the SETUP.
Exit Discarding Changes:
If you don’t want to save the changes you have just made, choose this item to reject all the
changes and exit the SETUP.
Load Setup Defaults:
If you are not sure how to setup certain fields, choose this item. The system would get the
default settings for you.
Discard Changes:
If you don’t want to keep the changes you have just made, choose this item. The system
would load the previously saved values for you.
Save Changes:
Save the changes you have just made.

Prestigio Visconte 121 Technical Service Manual
2-10
This page is left blank intentionally.

Prestigio Visconte 121 Technical Service Manual
3-1
Chapter 3 System Utilities
3.1 The BIOS Flash Utility
You would get the BIOS flash utility (Phlash.exe), and the latest <rom-file> from PMDIST.
The format for the <rom-file> name is 300Adddd.rom; where “dddd” is a 4-digit running
number.
The following is the procedure for flashing BIOS:
•Boot up to Native MS-DOS mode. Make sure emm386.exe and himem.sys are not
loaded into the system memory.
•Enter the following DOS command from the CD-ROM drive:
Phlash /c <rom-file>
•The flashing will be completed when the system restarts after hitting any key.
Note: The flash utility program will issue a warning message, if the ROM file and the
system’s motherboard do not match with one another.
3.2 The KBC (H8) Flash Utility
You would get the KBC flash utility (H8fb.exe), and the latest <kbc-file> from PMDIST.
The format for the <kbc-file> name is CP10V-P00-.bin; where “00” is a 2-digit running
number.
The following is the procedure for flashing BIOS:
•Boot up to Native MS-DOS mode. Make sure emm386.exe and himem.sys are not
loaded into the system memory.
•Enter the following DOS command from the CD-ROM drive:
H8fb <kbc-file>
•The flashing will be completed when the system shutdown automatically.
