Patient Instruction Manual

2
CONTACT INFORMATION
Patient services
Phone: [phone] (press 1, 1) Email: [e-mail]
Hours: 24 hours a day, 7 days a week
Returning your monitor
Phone: [phone] (press 1, 5) Email: [e-mail]
Hours: 7:30 a.m. - 7:00 p.m. CST
Billing assistance
Phone: [phone] Email: [e-mail]
Hours: 8:00 a.m. - 5:00 p.m. CST
General information
Web: www.preventicesolutions.com/patients.html
Return your monitor to UPS on: ------------ / ------------ / ------------
Preventice Services is not an emergency response service. Contact your doctor immediately if your
symptoms worsen. If you are experiencing a medical emergency, dial 911.
The BodyGuardian Connect smartphone cannot be used to make phone calls, including calls to 911,
or perform other smartphone functions. Viewing the smartphone is prohibited while driving, operating heavy
machinery or in situations that may jeopardize your safety.

3
INSURANCE INFORMATION
On behalf of your physician, you are being provided with a heart monitor from Preventice Services. This test
will be billed in two parts:
1. Your medical professional will bill your insurance for the in-office hook-up and the final reading of the test results.
2. Preventice Services will bill your insurance for the use of the monitor along with providing the physician with
24/7 monitoring center service and all requested data and reports.
Your insurance company will usually send you an Explanation Of Benefits (EOB) describing the amount paid and
the amount you owe Preventice. An EOB is not a bill.
Our goal is to help your physician diagnose your heart condition without delay or concerns about billing. We offer
patient-friendly payment options, including a discounted rate at the time of service or a reduced rate when your
insurance indicates a large fee payable by you for our services or the physician’s services.
All equipment is the sole property of Preventice Services. To avoid financial liability and to ensure that you do
not receive a bill for the value of the equipment in your possession (up to $2,400), please return the equipment
immediately after your service ends. Any request for an extension of your study beyond your prescribed study
needs to come from your physician through a new order sent to Preventice Services. Be aware that the second
study may not be covered by all insurance providers and you may be responsible for those charges.
Our Notice of Privacy Practices is available for your review at www.preventicesolutions.com
Patient financial obligations and billing information

4
INTRODUCTION
Your physician has prescribed you the BodyGuardian Heart Remote Monitoring System and monitoring center
service provided by Preventice Services to detect irregular heart rhythms. You must wear the monitor for the
length of time your doctor has prescribed.
Instructional videos with subtitles and online help are available on BodyGuardian Heart smartphone to help you
use your monitor. From the Home screen, tap Help and Settings → Videos.
For additional resources, visit: www.preventicesolutions.com/patients.html
If you are receiving the monitor at home and require assistance, call Preventice Services at: 888.500.3522
For the manufacturer’s Instructions for Use, visit: www.preventicesolutions.com/docs/BGH-IFU.pdf
Resources and assistance
Air travel
The monitor cannot be worn while traveling on an aircraft. This monitor does not operate outside the United
States. Contact Patient Services if you plan to travel outside the United States.
Welcome to BodyGuardian Heart
Caution: Federal law (USA) restricts this device to sale by or on the order of a physician.
Remove BodyGuardian Heart as soon as your physician or qualified health care professional ends your
service. Any data or information transmitted or received by Preventice after your physician or qualified health care
professional has ended your service will not be processed, reviewed or analyzed by Preventice, and Preventice
shall have no liability for any such information or data.
When your study concludes

5
INTRODUCTION
Ensure that the following equipment is included in the box.
Equipment
BodyGuardian Connect
smartphone
Note Your equipment may vary from the components pictured. Preventice reserves the right to modify, change, or discontinue
products or accessories at any time.
monitor charging
cradle
power cord with
adapter
BodyGuardian Heart monitors (2)
The 1and 2stickers help to distinguish the monitors
from one another. Do not place stickers on the bottom
of the monitor. Your monitors may be white or black.
Both versions operate identically.
smartphone charger
BodyGuardian Strip(s)
There are two types of Strips:
green and blue. You have received
the Strip requested by your doctor.

6
GETTING STARTED
With one monitor firmly snapped into the charging
cradle, plug the charging cradle into a wall outlet.
All monitor lights will go out when the monitor is fully
charged.
Charge one of the monitors
Plug the charger into the smartphone and a wall
outlet. The smartphone is fully charged when the
battery indicator on the screen is solid green.
Charge the smartphone
Charging the smartphone can take up to 4 hours.
Charging
Fully charged
Charging Fully charged
Prepare your skin
1. If hair is present, remove the hair where you will
place the monitor (see p.9 for chest locations).
2. Thoroughly clean the area with soap and water.
Dry the area completely.
3. Do not apply lotions, oils, or perfumes.

7
GETTING STARTED
1. Line up the snaps on the monitor and the Strip.
2. The snaps aren’t evenly spaced. To make sure
the snaps are lined up, the orientation of the
logo on both the monitor and the Strip must be
the same.
3. Press firmly to securely connect all four snaps
one by one.
4. Firmly snap the second
monitor into the plugged-
in charging cradle so it is
charged and ready when
you switch monitors.
• The amber battery light on the monitor will
come on while it is charging.
• All monitor lights will go out when the monitor
is fully charged.
1. Line up snaps
3. Connect snaps
2. Align logos
Snap the charged monitor to a
Strip for the first time

8
GETTING STARTED
1. Familiarize yourself with the chest placement illustrations below and at right.
2. Peel away the Strip’s adhesive backing, then place the Strip and monitor on your chest in one of the placement
locations shown at right. Make sure one of the two arrows on the Strip is pointing up.
3. Ensure the Strip is spread out evenly, with no wrinkles.
4. To achieve a tight, smooth connection with the skin, press and
hold the Strip over the gel pads against the skin. It may take
a minute or so to form a good connection with the skin and
contours of the chest.
Attach BodyGuardian Heart to your chest
Do not wrinkle
the Strip.
Ensure the
Strip is spread
out evenly.
Do not tuck or
pin the Strip
to bra or other
clothing.
Too far to
right side of
chest
Too low, too
far to left
side of chest
Too low
Examples of incorrect placement
Too low
Gel pads

9
GETTING STARTED
Preferred placement options (vertical)
 Offset slightly to your left side, closer to your heart.
You can angle this placement up to 30° clockwise from true
vertical to avoid muscle, fat, and bra.
OrientationAngle
Alternate placements options (horizontal)
 Two fingers below the collarbone.
You can angle this placement up to 30° counter-clockwise
from true horizontal to avoid muscle, fat, and bra.
Angle
0°
30°
Do not exceed 30°
clockwise from vertical
Do not exceed 30° counter-
clockwise from horizontal
 Important Avoid placement over thick muscle and fatty tissue.
30°
0°
Orientation
Right
Right
Right
Right
Left
Left
Left
Left
Do not apply BodyGuardian Heart over open wounds, lesions, infected or inflamed areas. Apply only to intact, clean skin. If
you have skin allergies or hypersensitivities to adhesives, consult your doctor to select the appropriate option.

10
GETTING STARTED
Turn on monitor
Turn on smartphone
Press and release the center button on the monitor.
Do not hold the button down.
The green center light on the monitor will remain lit
or blinking once it has powered on.
1. Press and hold the power key.
2. Once the smartphone is powered on, it will
automatically connect to the monitor.
3. Stay within 3 feet of the smartphone, remain
still, and watch the smartphone for Strip contact
errors. If you receive a Poor Contact message,
see p.16 of this manual.
1. Power on 2. Auto-
connects 3. Stay close
Congratulations
Once you see the Monitoring Status on the
smartphone change to Monitoring, you have
successfully set up your monitor.

11
DAILY USAGE
Keep the smartphone within 10
feet of the monitor at all times
Charge the smartphone nightly
Fully charged
Keep the smartphone with you. However, if (1) you get
separated from the smartphone, (2) the smartphone battery
depletes or (3) you go out of cellular network range, the
monitor will continue to collect data and automatically send
it when the smartphone is back in range.
Ensure the smartphone is within 10 feet of the location
where you sleep. Leave the smartphone turned on and plug
it into the smartphone charger and into a wall power outlet.
The smartphone is fully charged when the battery indicator
on the screen is completely solid green.
Note: If you don’t want to be disturbed by alerts while
sleeping or while at an event, tap Do Not Disturb on
the smartphone.
DAILY USAGE
Tip The smartphone supports multiple languages. Tap Help and Settings → Settings → Change Language.

12
DAILY USAGE
The green BodyGuardian Strips are repositionable. They can be removed from your
chest, then reapplied back onto your chest when switching monitors, for example.
1. Unsnap the monitor from the Strip on your chest.
Then firmly snap the monitor into the plugged-in
charging cradle.
Do not pause or power off the monitor.
The monitor will automatically power off
when it is done transferring data.
2. Slowly peel the Strip from your chest. Then snap
the other, fully-charged monitor onto the Strip.
3. Place the Strip and monitor back onto your chest.
4. Power on the monitor by pressing and releasing
the center button. Do not hold the button down.
Remain near the phone. The phone will
automatically detect the new monitor.
• If you need to put the Strip down after removing and before reapplying to your chest, be sure to place the Strip on
a clean, dry surface.
• Use a new Strip every three days OR when it no longer adheres to your skin. Strips are disposable.
21
3 4
Wear one of the monitors while the other one remains in the charging cradle. Switch the monitor on your chest first
thing in the morning and at night before you go to sleep, or at any time if the battery is low.
Switching monitors with green Strips

13
DAILY USAGE
11 223 3
Removing the monitor
1. Hold the Strip against your skin.
2. Lift one side of the monitor until the snaps release.
3. Repeat on the other side, then snap the monitor
into the plugged-in charging cradle.
Attaching the charged monitor
1. Snap the fully-charged monitor to the Strip.
2. Power on the monitor by pressing and releasing the
center button. Do not hold the button down.
3. The phone will automatically detect the new monitor.
Do not pause or power off the monitor.
The monitor will automatically power off when
it is done transferring data.
Remain near the phone when attaching the
fully-charged monitor.
The blue BodyGuardian Strips cannot be reapplied to your chest after removal.
You can switch monitors without removing the blue Strip from your body.
• Use a new Strip every three days OR when it no longer adheres to your skin. Strips are disposable.
Switching monitors with blue Strips
Wear one of the monitors while the other one remains in the charging cradle. Switch the monitor on your chest first
thing in the morning and at night before you go to sleep, or at any time if the battery is low.

14
DAILY USAGE
Recording your symptoms
If you begin to feel symptoms related to the reason your
monitor was prescribed such as dizziness, chest pain
or shortness of breath, you can manually record these
events.
1. Press and release the center button on the monitor.
2. Hold as still as possible for 60 seconds.
3. On the smartphone, select the symptoms you are
feeling. You may select up to 3 symptoms.
4. Tap Save.
You must scroll to
see the full list of
symptoms.

15
DAILY USAGE
3. Replace monitor 4. Tap OK to resume
Replacing the Strip
Change the Strip every three days OR when it no longer
adheres to the skin. Strips are disposable. Remove the Strip
while showering or use a warm, damp cloth to blot
while removing. Slowly peel back and roll the adhesive away
from your chest, continually blotting with water.
Showering, bathing, swimming, air
travel, or MRI
1. On the smartphone, tap Pause. Then tap Yes to
confirm.
2. Remove the monitor from the Strip. The monitor is NOT
waterproof, but the Strip is.
3. Dry off your skin and the Strip completely. Then snap
the monitor back onto the Strip.
4. On the smartphone, tap OK to resume monitoring.
1. Tap Pause 2. Remove monitor
Do not rip or tear off the Strip quickly. Improper
removal may cause skin irritation.
Pause the monitor and remove it from the
Strip only when you shower, swim, travel on an
airplane, or undergo an MRI.

16
TROUBLESHOOTING
CAUSE
This message indicates poor contact between your skin, the monitor and Strip. It
is NOT related to the Bluetooth or cellular connection of the smartphone.
Check the monitor snaps
Ensure all four snaps are securely fastened between the monitor and the Strip.
Check the chest application
Skin preparation
Ensure that the skin on the placement location on your chest has been
prepared appropriately:
• Remove hair, excess oils, lotions, perfumes, etc. The placement
location should be clean and dry.
• Wash the placement location with soap and water. Use alcohol if
soap and water are not available.
Tap OK
Tap OK on the smartphone to dismiss the message.
RESOLUTIONS
Poor Contact message appears on the
smartphone
a.
continue

17
TROUBLESHOOTING
Chest placement location
Ensure that BodyGuardian Heart is positioned properly on the chest.
See p.9 of this manual for chest placement locations.
Ensure one of two arrows on the Strip is pointing up.
Tip:For the horizontal position, some patients acquire a better signal
when BodyGuardian Heart is placed higher up on the chest, closer
to the collarbone, to avoid fleshy tissue areas. BodyGuardian Heart
receives a higher quality signal when placed over firmer areas.
Strip-to-skin adhesion
Ensure that the Strip is securely adhered to the skin without wrinkles or
bubbles. If the Strip is not securely adhered or loose edges, wrinkles,
bubbles exist, replace the Strip. When applying the Strip, apply pressure
on the gel pads to ensure good contact with the skin.
Apply
pressure to
gel pads
Replace the Strip
1. Ensure that the chest placement location is properly prepared. See 3a. Skin preparation.
2. When applying the new Strip, allow the Strip to conform to your body. This can take as long as 2 minutes.
If the message persists, contact Preventice: 888.500.3522 (press 1, 1, 4).
b.
c.

18
TROUBLESHOOTING
If no monitor lights are lit, the monitor is not
powered on. To power on the monitor:
1. Press and release the center button on the monitor.
Do not hold the button down.
2. Once the monitor powers on and the smartphone
connects to the monitor, Monitoring Status will
change to Monitoring.
Note: If there is data on the monitor, the smartphone
will download that data before it moves to a status of
Monitoring. This could take several minutes.
The Pause button on the smartphone
is disabled OR Monitoring Status on
the smartphone is 'Searching'
CAUSE
These conditions occur when the smartphone is not
connected to one of your monitors. This problem is often
caused when neither monitor is powered on. This occurs
most often when switching monitors.
Check to see if the monitor is powered on.
RESOLUTION

1. Power on monitor 2. Status will change
continue

19
TROUBLESHOOTING
If any monitor lights are lit, the monitor is powered on.
If the monitor is powered on, check to see if the smartphone is downloading
data.
1. On the smartphone, tap Monitoring Status.
2. Tap the blue arrows to display both monitors.
3. If the smartphone displays a monitoring status of Downloading
data that means data is being downloaded from the monitor to the
smartphone. Tap the white Downloading data entry. This will display
orange radiating rings that indicate that downloading is active.
Note: If the smartphone does NOT display Downloading data,
contact Preventice: 888.500.3522 (press 1, 1, 4).
4. Once the smartphone has finished downloading, the status on the
smartphone will change to Monitoring. This could take several minutes.
Note: The smartphone must be within 3 feet of the monitor on your
chest to efficiently complete the downloading process.

2. Tap blue arrows
1. Tap Monitoring Status
3. Phone will connect
If the issue persists, contact Preventice:
888.500.3522 (press 1, 1, 4).

20
TROUBLESHOOTING
When switching monitors, the smartphone displays
‘Downloading data’ for an extended time
CAUSE
This occurs when there is a large amount of collected data on the monitor that is
currently being downloaded to the smartphone.
RESOLUTION
Wait for the smartphone to finish downloading.
1. Keep the smartphone within 3 feet of the monitor you just placed on your
chest to allow the downloading process to complete.
2. Once the smartphone has finished downloading, the status on the
smartphone will change to Monitoring. This could take several minutes to
several hours depending on the amount of data to be downloaded from the
monitor.
