MOPEC USER MANUAL
HEATED FORCEPS AND TAMPERS - BK300 SERIES

HEATED FORCEPS AND TAMPERS
BK300 SERIES
TABLE OF CONTENTS
TABLE OF CONTENTS 2
INTRODUCTION 2
GENERAL NOTES 2
SPECIMEN SAFETY 3
USER SAFETY 3
POWER LEAD & CONNECTION TO ELECTRICAL SUPPLY 4
SPECIFICATION 4
LOCATION 5
OPERATING INSTRUCTIONS 6
CLEANING INSTRUCTIONS 6
ROUTINE INSPECTION RECOMMENDATIONS 7
WARRANTY TERMS AND CONDITIONS 7
INTRODUCTION
Mopec’s Heated Forceps and Tampers Systems are designed to take up minimal bench-top
space and come complete with a power supply and control unit. The ergonomic design ensures
user comfort while performing specimen placement, and the anti-microbial coating helps prevent
bacteria and virus growth.
GENERAL NOTES
1. This product is designed for laboratory use only. Always follow good laboratory practice.
2. If this product is not used in accordance with these instructions then basic safety
protection may be affected.
3. Only use the plug in power supply unit supplied.
4. Before using any cleaning or decontamination method please refer to the Maintenance
and Cleaning section to ensure the proposed method will not damage the unit.
5. Connect only to a power supply with the corresponding voltage to that specified on the
power pack.
2

6. Ensure that the power supply has an earth (ground) terminal.
SPECIMEN SAFETY
It is the users responsibility, to ensure that the temperature set on the instrument, is at a level
where no damage is caused to diagnostic specimens used with the equipment. In the event of
this instrument malfunctioning, all specimens within the device should be checked to ensure no
harm or damage to the specimen has been caused.
Amendments:
Issue 6: August 2022
Symbols:
This symbol appears in documents and on equipment to warn the user that there are
hot surfaces on the equipment.
This symbol appears in documents and on equipment to warn the user that
instructions must be followed to ensure correct or safe operation.
USER SAFETY
The equipment you have purchased complies with the following European Directives EMC
Directive 89/336/EEC and Low Voltage Directive 73/23/EEC as indicated in the EC Declaration
of Conformity included in the document. This instrument has been designed and constructed in
a manner which minimizes the risk of electrical shock to the operator, offers maximum protection
from overheating and provides clear and adequate labeling of instrument controls.
The instrument requires no regular servicing, but Mopec does recommend an annual inspection,
as detailed in the manual, which will prolong the life of the instrument to ensure continued
safety.
Do not touch any electrical contacts or open any closure plates. RISK OF
ELECTRIC SHOCK!
DO NOT:
1. Do not attempt to plug anything into the Mopec Control Unit except Mopec Heated
Forceps and Heated Tampers.
3

2. Do not attempt to use the Mopec Control Unit Power Supply if its voltage rating or plug
style differs from your local standard. This may cause damage to the Mopec Controller
Unit and may result in fire or electric shock!
3. Do not use the Mopec Heated Forceps or Heated Tampers System near inflammable
materials! Vapour in solvents from histology laboratories such as xylene, toluene and
industrial denatured alcohol and other low flashpoint liquids may be ignited by the hot
tips of the forceps, causing serious fire and risk of injury.
4. Do not leave working Mopec Heated Forceps or Tampers in cold water! This will sustain
a high power demand which can over stress the Mopec Control Unit Power Supply and
Control Unit.
5. Do not use it for non-specified purposes without prior consultation with the supplier.
6. Do not attempt a repair. Repairs should only be undertaken by a trained service
engineer.
DO:
1. Only use a Mopec Control Unit Power Supply!
2. Keep the Mopec Control Unit and power supply dry.
3. Maintain the apparatus in a reasonably clean condition.
4. Switch off before removing the plug.
POWER LEAD & CONNECTION TO ELECTRICAL SUPPLY
Check the electrical supply is compatible with the rating label. IF IN DOUBT
CONSULT AN ELECTRICIAN. THE PRODUCT MUST BE EARTHED!
Where the mains supply or plug connection differs refer to local regulations
or consult an electrician.
SPECIFICATION
Mopec Heated Forceps and Tampers are electrically heated instruments designed to assist in
the orientation and positioning of histological specimens during embedding in paraffin wax.
Mopec Heated Forceps and Tampers incorporate safe, low-voltage, energy controlled heating
elements which constantly maintain their tips at the optimum temperature for manipulation of
specimens in histological wax. They may be used continuously, without adjustment, and without
significantly influencing the temperature of the medium or tissue. Eliminating the task of
keeping the forceps at a usable temperature enables the operator to concentrate on orientation
of the tissue, and results in a significant increase in productivity.
Mopec Control Unit and Power Supply:
Dimensions: Width 120mm x Depth 120mm x Height 40mm
Weight (Control Unit): 486g (1.1 lbs)
4

Power Supply: 100/240V a.c. power pack supplied with interchangeable UK, EU and US
sockets
Capacity: Two Mopec Heated Forceps or Heated Tampers
Mopec Heated Forceps - Serrated Jaws
Available with 1mm (Red), 2mm (Yellow) and 4mm (Blue) width tips.
Tip Length: 19.5mm
Forceps Length:150mm
Cable Length: 1.1 Meter
Weight: 63g
Forceps Material: Stainless Steel
Finger Grip: Silicone
Mopec Heated Forceps - Smooth Jaws
Available with 1mm (Red), 2mm (Yellow) and 4mm (Blue) width tips.
Tip Length: 19.5mm
Forceps Length: 150mm
Cable Length: 1.1 Meter
Weight: 63g
Forceps Material: Stainless Steel
Finger Grip: Silicone
Mopec Heated Tampers
Tamper Sizes Available: 8x8mm (Red), 16x16mm (Yellow) 25x28mm (Blue)
Tamper Length: 120mm
Cable Length: 1 Meter
Weight: 33g
Tamper Material: Stainless Steel/Brass
Finger Grip: Polyolefin Shrink
Mopec Heated Forceps/Tampers Stand
Capacity: Two Mopec Heated Forceps/Tampers
Weight: 235g
Material: Antimicrobial Powder Coated Steel
LOCATION
The product must be placed on a smooth, level and sturdy work surface. Suitable for use in
ambient temperatures 5˚C to 40˚C with a maximum humidity 80% (temperature 31˚C)
decreasing to 50% (temperature 40˚C).
5

OPERATING INSTRUCTIONS
1. Plug the power pack in.
2. Insert the power supply cable into the socket at the rear of the Mopec Control Unit. Make
sure the cable is fully pushed in and locked into place using a lock ring.
3. Place the Control Unit in a convenient dry location on the workbench, or on a shelf, with
its front panel accessible.
4. Check that the green On/Off switch on the front of the Control Unit is in the “O” or “Off”
position.
5. Plug a Mopec heated forcep or tamper into an input socket at the front of the Control
Unit. Push in and rotate.
6. Rest the Mopec forcep or tamper horizontally on top of the Control Unit, with the forcep
tips or tamper base in free air.
7. Turn on the Control Unit using the green on/off switch: “I” position.
8. The Control Unit may be operated with one or two pairs of Mopec heated
forceps/tampers. Each pair of forceps/tampers is independent of the other.
9. The Mopec heated forceps and tampers may be used continuously. They may be left
switched on for long periods without risk of damage, providing the forcep tips or tamper
base remain in free air and are NOT in contact with any heat absorbing surface.
CLEANING INSTRUCTIONS
1. The case work of the Mopec Control Unit, including the control panel, may be wiped
using small quantities of mild detergent or polishes applied with a soft cloth.
2. Never clean the Mopec Heated Forceps or Tampers with abrasives or chemical solvents!
The plastic covering the arms of the Mopec Heated Forceps and Tampers and the
silicone finger grip of the forceps will be damaged by abrasive cleaning agents, and by
the excessive use of solvents including: ethanol, ether, xylene, toluene and chloroform.
3. Do Not attempt to clean the Mopec Heated Forceps or Tampers or their power cable with
bleach.
4. Do Not attempt to sterilize the Mopec Heated Forceps or Tampers using an autoclave.
5. Excess wax may be removed from the hot tips of the Mopec Heated Forceps or base of
the Tamper by wiping them with a dry tissue. For more thorough cleaning, always switch
off and unplug the power supply from the wall socket. Excess wax can be easily peeled
away from the silicone finger grip area of the Mopec Heated Forceps. It is recommended
that excess wax buildup on the arms of the forceps and power cable is removed using
hot air from a hair dryer to melt the wax and using a tissue to absorb the molten wax.
6. The Mopec Control Unit and Mopec Heated Forceps and Tampers may be wiped using a
tissue or moistened with a little water, to which a small quantity of mild detergent may be
added. Care must be taken to avoid water entering the switch and the connector sockets
on the Mopec Control Unit.
6

ROUTINE INSPECTION RECOMMENDATIONS
Mopec recommends that a simple annual inspection be made for all Mopec laboratory
equipment in order that any malfunction can be identified and rectified as early as possible. This
is to ensure user safety and prolong instrument lifespan.
RECOMMENDED CHECKS TO BE MADE:
1. Condition of Power Lead: A visual inspection to ensure the insulation is not damaged
and that the correct fuse is fitted.
2. Functioning of the On/Off switch: The On/Off switch should glow green when set to the
On position.
3. Condition of the Mopec heated forceps or tamper cables: A visual inspection to ensure
the insulation is not damaged.
WARRANTY TERMS AND CONDITIONS
1. Mopec warrants to the Customer that the product purchased is free from defects in
materials and workmanship.
2. Provided the terms of payment are duly complied with, Mopec undertakes to remedy any
original defects arising from faulty materials or workmanship, in any goods
manufactured/supplied by Mopec, which under proper and normal conditions of use,
may develop within a period of twelve months from the date of delivery.
3. In the case of components which by their nature of application have an unpredictable
life, this guarantee shall only be to the extent of the guarantee given by the
manufacturers of these articles.
4. Mopec will accept no liability, where in the opinion of the company the defect has been
caused by damage due to the Customers failure to follow operating instructions, correct
installation, wear and tear, or damage due to the use of spare parts other than those
spare parts of Mopec or which are recommended by Mopec, the defect has been caused
by alterations or repairs being undertaken by a person(s) other than an authorized
representative of Mopec.
5. Any damage claim must be in writing, and give the serial number and description of the
goods, order number and date of delivery, and will not apply where any names or serial
numbers or other information which may be attached to or inscribed upon the goods
have been removed, covered up or defaced in any way.
6. Any goods or parts thereof, which may require repair or replacement, shall be repaired
or replaced (at the election of Mopec) at the works of Mopec. The product to be repaired
shall be delivered to Mopec by the customer at the Customer’s risk and expense. Any
such goods or parts will be delivered by Mopec to the Customer free within the United
States but if required to be borne by the Customer. All faulty parts removed from the
7

equipment will become Mopec’s property. Any other repairs or work by Mopec will be
carried out under the terms and conditions for specialist engineers currently in force.
7. In the event of replacement with a new or reconditioned model, the replacement unit will
continue the warranty period of the original equipment.
8. If any goods or parts thereof are returned unnecessarily all costs involved, including a
charge for inspection, handling and the return carriage must be paid by the sender.
9. Please retain the original packaging over the warranty period.
EC DECLARATION OF CONFORMITY
We herewith confirm the following products:
Mopec Heated Forceps (1mm, 2mm, and 4mm)
Mopec Heated Tampers (1mm, 2mm, and 4mm)
Mopec Control Unit - BK330
Mopec Power Supply - BK320
Conforms with requirements outlined by the following European Directives:
Low Voltage Directive 2014/35/EU
EMC Directive 2014/30/EU
RoHS Directive 2011/65/EU
We confirm the declaration:
Mopec
800 Tech Row
Madison Heights, MI 48071
Conforms with the requirements of the following standards:
BS EN 61010-1:2010
BS EN 61010-2-010:2014
Safety requirements for electrical equipment for measurement, control and laboratory use.
BS EN 61236-1:2013
Electrical equipment for measurement control and laboratory use - EMC requirements.
