Owner’s Manual

www.pridemobility.com Jazzy Select
SAFETY GUIDELINES
Copyright©2006
PrideMobilityProductsCorp.
INFMANU3059/RevC/September 2006
Thesymbolsbelowareusedthroughoutthisowner'smanualandonthe power chair to identify warningsandimportant
information.Itisvery importantforyou toreadthemandunderstand themcompletely.
WARNING! Failure to follow designated procedures can cause either personal injury, component
damage, or malfunction (black symbol on yellow triangle with black border).
MANDATORY! These actions should be performed as specified. Failure to perform mandatory
actions can cause injury to personnel and/or damage to equipment (white symbol on blue dot).
PROHIBITED! These actions are prohibited. These actions should not be performed at any time or
in any circumstances. Performing a prohibited action can cause injury to personnel and/or damage
to equipment (black symbol with red circle and red slash).

Jazzy Select www.pridemobility.com 3
I. INTRODUCTION ...................................................................................................................................4
II. SAFETY....................................................................................................................................................6
III. YOUR POWER CHAIR ......................................................................................................... 16
IV. ASSEMBLY............................................................................................................................ 21
V. COMFORT ADJUSTMENTS .............................................................................................. 23
VI. BATTERIES AND CHARGING ........................................................................................... 28
VII. OPERATION .......................................................................................................................... 32
VIII. CARE AND MAINTENANCE .............................................................................................. 35
IX. WARRANTY........................................................................................................................... 41
CONTENTS
Thisowner’smanualiscompiledfromthelatestspecificationsandproductinformationavailableatthetimeofpublication.
Wereservetheright tomakechanges astheybecome necessary.Anychangestoour productsmaycause slightvariations
betweentheillustrationsand explanationsinthismanualand theproductyouhavepurchased.

4 www.pridemobility.com Jazzy Select
I. INTRODUCTION
SAFETY
WELCOMEtoPrideMobility Products Corporation (Pride). The power chair youhave purchasedcombines state-of-
the-artcomponentswithsafety, comfort,and stylingin mind.Weareconfidentthatthesedesignfeatureswillprovideyou
withtheconveniencesyouexpectduringyourdailyactivities.Once you understand how to safely operateand care for
yourpower chair, it shouldgiveyouyears of trouble freeoperationandservice.
Readand followallinstructions,warnings,andnotesinthismanual beforeattempting tooperateyourpowerchairforthe
first time. Inaddition, your safetydependsupon you, as well asyour provider,caretaker, or healthcare professionalin
usinggoodjudgement.
Ifthere isanyinformation inthismanual whichyoudo notunderstand,or ifyourequire additionalassistanceforsetup or
operation,please contact your authorized Pride Provider. Failuretofollowtheinstructionsinthismanualandthose
locatedonyourpowerchaircanleadtopersonalinjuryand/ordamagetothepowerchair,includingvoiding the
warranty.
PURCHASER’S AGREEMENT
Byacceptingdelivery of this product, you promisethat youwill notchange, alter,ormodify this product or remove or
renderinoperableor unsafeanyguards,shields,orothersafetyfeaturesofthisproduct;fail,refuse, orneglecttoinstallany
retrofitkits from time to time provided by Pride to enhance or preserve the safe useofthisproduct.
INFORMATION EXCHANGE
Wewanttohearyourquestions,comments,andsuggestionsaboutthis manual.Wewouldalsoliketohear aboutthesafety
andreliability ofyournewpower chair, andabouttheservice youreceivedfromyour authorized PrideProvider.
Please notify us of any change of address, so we can keep you apprised of important information about safety, new
products,and new options that can increase your abilitytouseandenjoyyourpower chair.Pleasefeelfreetocontactus
attheaddressbelow:
PrideMobility ProductsCorporation
Attn:Customer CareDepartment
182SusquehannaAvenue
Exeter, PA18643-2694
[e-mail]
800-424-8205
NOTE: If you ever lose or misplace your product registration card or your copy of this manual, contact us
and we will be glad to send you a new one immediately.

Jazzy Select www.pridemobility.com 5
I. INTRODUCTION
PRIDE OWNERS CLUB
Asan owner of a Prideproduct,youareinvitedto register your product’swarrantyand enroll in the Pride OwnersClub.
You may do so by filling out and returning your enclosed product registration card or by visiting Pride's web site at
www.pridemobility.com.Asaregistered member,each timeyou visitoursite,youwillhaveaccesstothemostinteractive
andhonesteducationalvenueavailabletodayforpeoplewithmobilityneeds,theirfamilies,andfriends.
Fromour homepage,select“Owners Club”toentera page dedicatedtocurrent and potentialPrideproduct owners.You
willgainaccessto interviews,stories,recreation ideas,dailyliving tips,productand fundinginformation,and interactive
messageboards. Thesemessageboards inviteyoutocommunicate withotherPride customers aswellas Priderepresen-
tativeswho are availabletoassist you withanyquestionsor concerns youmayhave.
MyAuthorizedPrideProvider:
Name:_____________________________________________________________________________________
Address:___________________________________________________________________________________
Phone Number:______________________________________________________________________________
Purchase Date:_______________________________________________________________________________

6 www.pridemobility.com Jazzy Select
II. SAFETY
Prevent personal injury and equipment damage. Do not connect an extension cord to
the AC/DC converter or the battery charger.
Read and follow the information in the owner’s manual.
Maximum seating weight.
Removal of grounding prong can create electrical hazard. If necessary, properly install
an approved 3-pronged adapter to an electrical outlet having 2-pronged plug access.
Failure to heed could result in personal injury and/or property damage.
Prevent personal injury! Keep your hands away from the tires when driving. Be aware
that loose fitting clothing can become caught in drive tires.
Avoid exposure to rain, snow, ice, salt, or standing water whenever possible. Maintain
and store in a clean and dry condition.
PRODUCT SAFETY SYMBOLS
Thesymbolsbeloware usedon thepowerchairtoidentify warnings,mandatoryactions,andprohibited actions.Itisvery
importantfor youtoread and understandthemcompletely.

Jazzy Select www.pridemobility.com 7
Use only AGM or Gel-Cell batteries to reduce the risk of leakage or
explosive conditions.
Prevent personal injury and product damage! Keep tools and other metal
objects away from battery terminals.
Do not remove the anti-tip wheels.
Do not lift the mobility vehicle while seated in it.
Do not lift the mobility vehicle while seated in it.
Corrosive chemicals contained in battery.
EMI-RFI - This product has been tested and passed at an immunity level
of 20 V/m.
II. SAFETY

8 www.pridemobility.com Jazzy Select
II. SAFETY
Prevent personal injury and product damage! Battery charger requires proper ventilation
to prevent overheating. Remove the battery charger from the case before charging the
batteries. Failure to remove the battery charger from the carrying case before use may
reduce the operating life of the charger.
Explosive conditions exist!
Disposal and recycling - Contact your authorized Pride Provider for information on proper
disposal and recycling of your Pride product and its packaging.
Locked and in drive mode.
Unlocked and in freewheel mode.
Use correct tie-down points for controller harness to prevent the harness from getting
caught in the drive tires or pinched in the seat frame.

Jazzy Select www.pridemobility.com 9
II. SAFETY
SAFETY
MANDATORY! Do not operate your new power chair for the first time without completely reading
and understanding this owner’s manual.
Your powerchairis astate-of-the-artlife-enhancement devicedesigned toincreasemobility. Prideprovidesan extensive
varietyof products to best fit the individualneeds of the powerchair user. Please be awarethat the final selectionand
purchasing decision regarding the type of power chair to be used is the responsibility of the power chair user, who is
capableof makingsucha decision, andhis/herhealthcare professional (i.e.,medicaldoctor,physical therapist,etc.).
Thecontents ofthismanual are basedonthe expectationthatamobility deviceexperthasproperly fittedthepower chair
tothe userandhas assistedtheprescribing healthcareprofessionaland/orthe authorizedPrideProvider intheinstruction
processfor the use of theproduct.
Therearecertainsituations,includingsomemedicalconditions, wherethepowerchairuserwillneedtopracticeoperating
the power chair in the presence of a trained attendant.Atrained attendant can be defined as a family member or care
professionalspeciallytrainedinassistingapowerchairuserinvariousdailylivingactivities.
Asyoubeginusingyourpowerchairduringdailyactivities, youwillprobablyencountersituationsinwhichyouwill need
somepractice.Simplytakeyourtimeandyouwillsoonbeinfullandconfidentcontrolasyoumaneuverthroughdoorways,
onandoffofelevators, up and down ramps, and over moderate terrain.
Belowaresomeprecautions, tips,andother safetyconsiderationsthatwillhelp theuserbecome accustomedtooperating
thepower chairsafely.
Modifications
Pridehasdesignedandengineeredyourpowerchairtoprovidemaximummobilityandutility.Awiderangeofaccessories
isavailablefromyourauthorized Pride Provider to further customize your power chairto better suityour needs and/or
preferences.However, under nocircumstancesshouldyou modify, add,remove,ordisable any feature,part,orfunction
ofyour power chair.
WARNING! Do not modify your power chair in any way not authorized by Pride. Unauthorized
modifications may result in personal injury and/or damage to your power chair.
Pre-Ride Safety Check
Gettoknowthefeelofyourpowerchairanditscapabilities.Priderecommendsthatyouperformasafetycheckbefore
eachuse to make sure your power chair operates smoothly and safely.
Performthefollowing inspectionspriortousingyourpowerchair:
!Checkfor proper tire inflation. Maintain butdo noexceed35psi(2.4bar)in each tire if equipped withpneumatic
tires.
!Checkall electrical connections. Make sure they are tight andnotcorroded.
!Checkallcontrollerconnections to the power base. Make sure they aresecured properly.
!Checkthe brakes. See VIII. “Care andMaintenance.”
!Checkbattery charge. See VI. “Batteries andCharging.”
NOTE: If you discover a problem, contact your authorized Pride Provider for assistance.

10 www.pridemobility.com Jazzy Select
II. SAFETY
Weight Limitations
Yourpowerchair isratedfor amaximumweight capacity. Pleaserefertothespecificationstableforthis limit.
WARNING! Exceeding the weight capacity voids your warranty and may result in personal injury
and/or damage to your power chair. Pride will not be held responsible for injuries and/or property
damage resulting from failure to observe weight limitations.
WARNING! Do not carry passengers on your power chair. Carrying passengers on your power
chair may result in personal injury and/or property damage.
Tire Inflation
Ifyourpowerchair isequippedwith pneumatictires,you shouldcheckor havetheair pressurecheckedregularly.Proper
inflationpressureswillprolong thelifeof yourtiresand helpensurethe smoothoperationof yourpowerchair.
WARNING! It is important that 35 psi (2.4 bar) tire pressure be maintained in pneumatic tires at all
times. Do not underinflate or overinflate your tires. Low pressure may result in loss of control, and
overinflated tires may burst. Failure to maintain 35 psi (2.4 bar) tire pressure in pneumatic tires at
all times may result in tire and/or wheel failure, causing serious personal injury and/or damage to
your power chair.
WARNING! Inflate your power chair drive tires from a regulated air source with an available pressure
gauge. Inflating your tires from an unregulated air source could overinflate them, resulting in a
burst tire and/or personal injury.
Incline Information
Moreandmorebuildingshaverampswithspecifieddegreesofinclination,designedforeasyandsafeaccess.Someramps
mayhave turning switchbacks(180-degreeturns) that requireyoutohave good corneringskillsonyour power chair.
!Proceedwith extreme caution as you approach the downgrade of a ramp or other incline.
!Takewideswingswithyourpower chair’sfrontwheelsaroundanytightcorners.Ifyoudo that,the powerchair’s rear
wheelswill follow awidearc,notcut the cornershort,andnotbump into orgethungupon any railingcorners.
!Whendrivingdowna ramp, keep the power chair’s speed adjustment set to theslowest speed settingto ensure a
safelycontrolled descent. SeeVII.“Operation.”
!Avoid sudden stops and starts.
Whenclimbinganincline,trytokeepyourpowerchairmoving.Ifyoumuststop,startupagainslowlyandthenaccelerate
cautiously.When driving downanincline,setyourpowerchairtotheslowestsetting and drive in the forward direction
only. If your power chair starts to move down the incline faster than you anticipated or desired, allow it to come to a
completestop byreleasingthe joystick, thenpushthe joystick forwardslightlyto ensureasafelycontrolled descent.
WARNING! When climbing an incline, do not zigzag or drive at an angle up the face of the incline.
Drive your power chair straight up the incline. This greatly reduces the possibility of a tip or a fall.
Always exercise extreme caution when negotiating an incline.
WARNING! You should not travel up or down a potentially hazardous incline (i.e., areas covered
with snow, ice, cut grass, or wet leaves).
WARNING! When on any sort of an incline or decline, never place the power chair in freewheel
mode while seated on it or standing next to it. Doing so may result in personal injury and/or
damage to your power chair.
WARNING! Never travel down an incline backwards. This may result in personal injury.

Jazzy Select www.pridemobility.com 11
II. SAFETY
Figure 1. Maximum Safe Slope (Ascending and Descending)
WARNING! Even though your power chair is capable of climbing slopes greater than those illustrated
in figure 1, do not, under any circumstances, exceed the incline guidelines or any other
specifications presented in this manual. Doing so could cause instability in your power chair,
resulting in personal injury and/or damage to your power chair.
Incompliance with theAmericanswithDisabilitiesActof 1990, all handicappublicaccessramps are required tohavea
maximumslope of 5° (8.7%).Although the Select haspassedtestingtoascendanddescend 10° (17.5%) inclines, Pride
recommendsthat themaximumslope ofanincline you attempttosafely ascendordescend on yourpowerchair doesnot
exceed 6° (10.5%). See figure 1.
WARNING! Any attempt to climb or descend a slope steeper than 6° (10.5%) may put your power
chair in an unstable position and cause it to tip, resulting in personal injury.
Braking Information
Yourpowerchairis equipped withtwopowerfulbrake systems:
1. Regenerative —useselectricityto rapidlyslowthe vehiclewhenthejoystick returnstothe center/stopposition.
2. DiscParkBrake— activatesmechanically afterregenerativebrakingslowsthevehicletonearstop,orwhenpoweris
removedfrom thesystemforany reason.
Cornering Information
Whileyourpowerchairisequippedwithtwocasterwheels, excessivelyhighcorneringspeedscanstillcreatethepossibil-
ityoftipping.Factorswhichaffectthepossibilityoftipping include,but arenotlimitedto:corneringspeed,steeringangle
(howsharplyyouareturning),unevenroadsurfaces,inclinedroadsurfaces,ridingfromanareaoflowtractiontoanarea
ofhigh traction (such as passing from a grassy area to a pavedarea–especiallyathighspeedwhileturning), and abrupt
directionalchanges.Highcorneringspeedsarenotrecommended.Ifyoufeelthatyoumaytip over in a corner, reduce
your speed and steering angle (i.e., lessen the sharpness of the turn) to prevent your power chair from tipping.
WARNING! When cornering sharply, reduce your speed. This greatly reduces the possibility of a
tip or fall. To avoid personal injury and/or property damage, always exercise common sense when
cornering.
Motor Vehicle Transport
Priderecommends thatyoudo notremainseated inyourpower chairwhiletraveling in amotorvehicle. Thepowerchair
shouldbestowed in the trunk ofa caror inthe backofa truck or van with thebatteries removedand properlysecured.
WARNING! Do not sit on your power chair while it is in a moving vehicle. Personal injury and/or
property damage may result.
WARNING! Always be sure your power chair and its batteries are properly secured when it is being
transported. Failure to do so may result in personal injury and/or damage to your power chair.

12 www.pridemobility.com Jazzy Select
CURB
CURB
II. SAFETY
Freewheel Mode
Yourpowerchairisequippedwithtwo manualfreewheelleverstoallowformanualmaneuverabilitybyatrainedattendant.
Formoreinformationabouthowtoplaceyourpowerchairintoandoutoffreewheelmode,seeIII.“YourPower Chair.”
WARNING! Do not use your power chair in freewheel mode without an attendant present. Personal
injury may result.
WARNING! Do not attempt to personally place your power chair in freewheel mode while seated
on it. Personal injury may result. Ask an attendant for assistance if necessary.
WARNING! Do not place your power chair in freewheel mode while on an incline. The chair could
roll uncontrollably on its own, causing personal injury.
Outdoor Driving Surfaces
Yourpowerchairisdesignedtoprovideoptimumstabilityundernormaldrivingconditions—dry,levelsurfacescomposed
ofconcrete,blacktop,orasphalt.However,Priderecognizesthattherewillbetimeswhenyouwillencounterothersurface
types.Forthisreason,yourpowerchairisdesignedtoperformadmirablyonpackedsoil,grass,andgravel.Feelfreeto
useyourpowerchairsafelyonlawnsandinparkareas.
!Reduceyour power chair’sspeed whendrivingonuneven terrain and/or softsurfaces.
!Avoidtallgrassthatcan entanglethe runninggear.
!Avoid loosely packed gravel andsand.
!Ifyou feelunsureabout adrivingsurface, avoidthatsurface.
Stationary Obstacles (Steps, Curbs, etc.)
Proceedwithextreme caution when driving near raised surfaces, unprotectedledges and/ordrop-offs (curbs, porches,
stairs,etc.). The correctmethodforapproaching a curb isillustratedinfigure 2.
WARNING! Do not attempt to have your power chair climb or descend an obstacle that is higher
than 2 inches unless you have the assistance of an attendant.
WARNING! Do not attempt to have your power chair proceed backwards down any step, curb, or
other obstacle. This may cause the power chair to tip and cause personal injury.
Figure 2. Correct Curb Approach Figure 3. Incorrect Curb Approach
Stairs and Escalators
Powerchairsarenot designed to travel up or downstairs or escalators. Alwaysuse anelevator.
WARNING! Never use your power chair to negotiate steps or escalators. You may cause injury to
yourself and to others and/or damage your power chair.

Jazzy Select www.pridemobility.com 13
II. SAFETY
Transfers
Transferring onto and off of your power chair requires good
senseof balance.Always have an attendant or healthcare pro-
fessionalpresent while learning to properlytransferyourself.
Toeliminate the possibility of injury, Pride recommends that
youora trained attendant perform thefollowing tasksbefore
attemptingatransfer:
!Turn offthepower to the unit. SeeVII. “Operation.”
!Ensureyourpowerchairisnot infreewheelmode. SeeIII.
“YourPowerChair.”
!Turnthe frontcaster wheelstoward thetransfer destination
toimprovepower chairstability duringtransfer.
!Makesure both armrests areflippedup or removed from
yourpower chair.
!Flip up the foot platform or move the leg rests aside; this
willhelp to keep your feet from getting caught on thefoot
riggingduringthetransfer.
!Reduce the distance between your power chair and the
objectyou are transferringonto. Figure 4.IdealTransfer Position
WARNING! Before transferring, position yourself as far back as possible in the power chair seat
to prevent the power chair from tipping forward during transfer and causing injury.
WARNING! Prevent personal injury and product damage! Avoid putting all of your weight on the
power chair armrests and do not use the armrests for weight bearing purposes, such as transfers.
Such use may cause the power chair to tip, resulting in a fall from the power chair.
WARNING! Avoid putting all of your weight on the foot riggings. Such use may cause the power
chair to tip and cause personal injury.
Doors
!Determineif the door opens toward or away from you.
!Driveyourpowerchairgentlyandslowlyforwardtopushthedooropen.Ordriveyourpowerchairgentlyandslowly
backwardsto pull the door open.
Elevators
Modernelevators have a door edge safety mechanism that, when pushed, reopens the elevator door(s).
!Ifyouare in the doorway of an elevatorwhen thedoor(s) beginto close,push onthe rubber dooredge orallow the
rubberdoor edge to contact thepowerchair and the door willreopen.
!Usecare that pocketbooks, packages,orpower chair accessories donotbecome caught in elevatordoors.
Lift/Elevation Products
Ifyouwillbetravelingwithyourpower chair,youmay findit necessarytousealift/elevationproductto aidin transporta-
tion.Priderecommendsthatyou closely review the instructions, specifications, and safety information set forthby the
manufacturerofthe lift/elevationproduct beforeusing thatproduct
WARNING! Never sit on your power chair when it is being used in connection with any type of lift/
elevation product. Your power chair was not designed with such use in mind and any damage or
injury incurred from such use is not the responsibility of Pride.

14 www.pridemobility.com Jazzy Select
II. SAFETY
Inclement Weather Precautions
Exposureof yourpowerchair toinclementweather conditions shouldbeavoided wheneverpossible.If suddenly caught
up in rain, snow, severe cold or heat while operating your power chair, proceed to shelter at the earliest opportunity.
Thoroughlydry yourpowerchair beforestoring,charging,oroperating yourpowerchair.
WARNING! Operating in rain, snow, salt, mist/spray conditions, and on icy/slippery surfaces can
cause personal injury and/or damage to the power chair and electrical system. Maintain and store
your power chair in a dry and clean condition.
Positioning Belts
YourauthorizedPrideProvider,therapist(s),andother healthcare professionals areresponsiblefordetermining your re-
quirementfor a positioningbeltin order tooperateyourpower chair safely.
WARNING! If you require a positioning belt to safely operate your power chair, make sure it is
fastened securely. Serious personal injury may result if you fall from the power chair.
WARNING! The positioning belt is not designed for use as a seat belt in a motor vehicle. Nor is
your power chair suitable for use as a seat in any vehicle. Anyone traveling in a vehicle should be
properly belted into seats approved by the vehicle manufacturer.
Public Streets and Roadways
WARNING! You should not operate your power chair on public streets and roadways. Be aware
that it may be difficult for traffic to see you when you are seated on your power chair. Obey all
local pedestrian traffic rules. Wait until your path is clear of traffic, and then proceed with extreme
caution.
Reaching and Bending
Neverreach,lean,orbendwhile drivingyourpowerchair.Ifitis absolutelynecessarytoreach,lean, orbendwhileseated
onyour power chair, itisimportant to maintain a stablecenterof gravity and keep thepowerchair from tipping. Pride
recommendsthatthe power chair user determine his/her personallimitations andpractice bendingand reachingin the
presenceofaqualifiedhealthcareprofessional.
WARNING! Do not bend, lean, or reach for objects if you have to pick them up from the floor by
reaching down between your knees. Movements such as these may change your center of gravity
and the weight distribution of the power chair. This may cause your power chair to tip, possibly
resulting in personal injury.
WARNING! Prevent personal injury! Keep your hands away from the tires when driving. Be aware
that loose fitting clothing can become caught in drive tires.
Batteries
In addition to following the warnings below, be sure to comply with all other battery handling information. For more
informationabout yourpowerchair’sbatteries,seeVI.“Batteries and Charging.”
WARNING! Power chair batteries are heavy. See specifications table. If you are unable to lift that
much weight, be sure to get help. Lifting beyond your capacity can result in personal injury.
WARNING! Battery posts, terminals, and related accessories contain lead and lead compounds.
Wash hands after handling.
WARNING! Always protect the batteries from freezing and never charge a frozen battery. Charging
a frozen battery may result in personal injury and/or damage to the battery.

Jazzy Select www.pridemobility.com 15
II. SAFETY
Removable Parts
WARNING! Prevent personal injury and/or product damage. Do not attempt to lift or move a power
chair by any of its removable parts, including the armrests, seat, foot riggings, controller, and shrouds.
Preventing Unintended Movement
WARNING! If you anticipate being seated in a stationary position for an extended period of time,
turn off the power. This will prevent unexpected motion from inadvertent joystick contact. This
will also eliminate the possibility of unintended chair movement from electromagnetic (EM) sources.
Failure to do so may result in personal injury.
Prescription Drugs/Physical Limitations
Usersmustexercise careand commonsense whenoperatingapowerchair.Thisincludesawareness ofsafety issueswhen
takingprescribed orover-the-counterdrugs orwhenthe userhasspecific physicallimitations.
WARNING! Consult your physician if you are taking prescribed or over-the-counter medication or
if you have certain physical limitations. Some medications and limitations may impair your ability
to operate your power chair in a safe manner.
Alcohol
Thepowerchairusermustexercise careandcommonsensewhenoperatinghis/her powerchair.This includesawareness
ofsafetyissueswhileundertheinfluenceofalcohol.
WARNING! Do not operate your power chair while you are under the influence of alcohol, as this
may impair your ability to operate your power chair in a safe manner.
Electromagnetic and Radio Frequency Interference (EMI/RFI)
WARNING! Laboratory tests have shown that electromagnetic and radio frequency waves can
have an adverse affect on the performance of electrically-powered mobility vehicles.
Electromagneticand Radio FrequencyInterference can come fromsources such as cellularphones, mobile two-way
radios(such as walkie-talkies), radio stations,TVstations,amateurradio(HAM) transmitters, wireless computer links,
microwavesignals,pagingtransmitters, and medium-range mobile transceivers used by emergencyvehicles. Insome
cases,thesewavescancauseunintendedmovementordamageto thecontrolsystem.Everyelectrically-poweredmobility
vehiclehasanimmunity(orresistance)toEMI.Thehighertheimmunitylevel,thegreatertheprotectionagainstEMI.This
producthas been tested and has passed at an immunity level of 20 V/m.
WARNING! Be aware that cell phones, two-way radios, laptops, and other types of radio transmitters
may cause unintended movement of your electrically-powered mobility vehicle due to EMI.
Exercise caution when using any of these items while operating your mobility vehicle and avoid
coming into close proximity of radio and TV stations.
WARNING! The addition of accessories or components to the electrically-powered mobility vehicle
can increase the susceptibility of the vehicle to EMI. Do not modify your power chair in any way
not authorized by Pride.
WARNING! The electrically-powered mobility vehicle itself can disturb the performance of other
electrical devices located nearby, such as alarm systems.
NOTE: For further information on EMI/RFI, go to the Resource Center on www.pridemobility.com. If
unintended motion or brake release occurs, turn your power chair off as soon as it is safe to do so. Call
Pride at 800-424-8205 to report the incident.

16 www.pridemobility.com Jazzy Select
III. YOUR POWER CHAIR
THE JAZZY SELECT
TheJazzySelecthastwomainassemblies:theseatassemblyandthepowerbaseassembly.Seefigure 5.Typically,theseat
assemblyincludesthearmrests, seatback,andseat base.Thepower baseassemblyincludes twomotor/brakeassemblies,
twodrivewheels,twocasterwheels,twoanti-tipwheels,twobatteries,andwiringharnesses.Seefigures5,6,and7.
SEATBACK
DRIVEWHEEL
CASTERWHEEL
Figure 5.The Jazzy Select
POWERBASE
ASSEMBLY
SEAT ASSEMBLY JOYSTICK
FOOTRIGGING
(FOOT PLATFORM SHOWN)
SEATBASE
SEATBACK
RELEASELEVER
ARMRESTS
JOYSTICK MODULE
ANTI-TIP WHEEL
FREEWHEELLEVER

Jazzy Select www.pridemobility.com 17
III. YOUR POWER CHAIR
JAZZYSELECTSPECIFICATIONS
Suspension: Active-Trac
DriveWheels: 10in.,pneumatic(10in.solidoptional)
Anti-TipWheels: 5in.,solid(front-mounted)
RearCasterWheels: 6in.,solid(rear-mounted)
MaximumSpeed:¹ Upto 4.0mph
Brakes: “IntelligentBraking”electronicregenerative,discparkbrake
GroundClearance:² 3.0 in.
TurningRadius:² 22in.
OverallSize:² Length:40.5 in.(withfootplatform)
Width: 23.5 in.
SeatingOptions: Medium-back(standard)
Medium-backwithSolidSeatPan(optional)
High-back(optional)
High-backwithSolidSeatPan(optional)
Drivetrain: Twomotor, mid-wheeldrive
Batteries:³ Two12-volt,U-1batteries
BatteryCharger: 5-amp,off-board
Electronics: 40-ampGC
WeightCapacity: 300lbs.
ComponentWeights: Base: 90 lbs.
StandardSeat:30lbs.
Batteries:24.5lbs.each
¹Varies with user weight, terrain type, battery amp hour rating (AH), battery charge, battery condition, and tire condition.
²Due to manufacturing tolerances and continued product improvement, this specification can be subject to variance of (+ or – ) 3%.
³AGMorGel-Cell type recommended.
NOTE: All specifications subject to change without notice.

18 www.pridemobility.com Jazzy Select
III. YOUR POWER CHAIR
Figure 6.The Jazzy Select Power Base
REARSHROUD SEAT POST
MAINCIRCUITBREAKER
OFF-BOARDCHARGER PORT
JOYSTICK MODULE
CONNECTOR
FRONT COVER

Jazzy Select www.pridemobility.com 19
JOYSTICK MODULE CONNECTOR MOTOR CONNECTOR
MOTOR CONNECTOR
BATTERY CONNECTOR
MAIN CIRCUIT BREAKER
OFF-BOARD CHARGER PORT
BATTERY CONNECTORS
BATTERY 
CONNECTORS
III. YOUR POWER CHAIR
Electrical Components
Theelectrical componentsarelocatedeither onorinsidethe powerbase.Themain circuitbreakerandoff-board charger
portarelocatedonthe front of the power base.The power module islocated under the frontcover. Seefigures 6 and 7.
MainCircuitBreaker:Themaincircuitbreakerisasafetyfeaturebuiltintoyourpowerchair.Whenthebatteriesandthe
motorsareheavilystrained(e.g.,fromexcessiveloads),themaincircuitbreakertripstopreventdamagetothemotorsand
theelectronics.Ifthecircuittrips, allowyour powerchairto“rest”forapproximatelyone minute.Next, pushinthecircuit
breakerbutton, turn onthecontroller,and continue normaloperation.Ifthe main circuitbreakercontinuesto trip repeat-
edly,contact yourauthorizedPrideProvider.
Off-boardChargerPort:Thisiswherethe power module connects to the batterycharger.
PowerModule:Providesconnectionbetween thejoystickmodule andthemotors, batteries,andoff-board charger port.
Figure 7. Jazzy Select Electrical Components

20 www.pridemobility.com Jazzy Select
Manual Freewheel Levers
TheJazzySelecthas amanualfreewheelleveron eachmotor. Manualfreewheel leversenableyou todisengagethedrive
motorsfromthegearboxesandmaneuverthechair manually.
WARNING! Do not use the power chair while the drive motors are disengaged! Do not disengage
the drive motors when the power chair is on an incline, as the unit could roll on its own, causing
injury!
To engage or disengage the drive motors:
1. Locate the lever oneachside of the power base.Seefigure 5.
2. Pull both levers upwardtoengagethedrive motors. See figure 8.
3. Push both levers downward todisengagethedrivemotors.See figure 9.
Ifaleverisdifficulttomovein eitherdirection,slightlyrockthepowerchairbackandforth.Thelever shouldthenmoveto
thedesiredposition.
WARNING! It is important to remember that when your power chair is in freewheel mode, the
braking system is disengaged.
III. YOUR POWER CHAIR
Figure 9. Freewheel Mode (Drive Disengaged)
Figure 8. Drive Mode (Drive Engaged)
FREEWHEELLEVER
FREEWHEELLEVER
