Pride Mobility QUANTUM SERIES User manual

QUANTUM
SERIES
32 Wedgwood Road Bicester, Oxon OX26 4UL
Including Models: Quantum 6000 and Quantum 6000XL

SAFETY GUIDELINES
Copyright©2008
PrideMobilityProductsLtd.
INFMANU3149/RevD/September 2008
QuantumRehab Dealer:_____________________________________________________________________
Address:________________________________________________________________________________
Phone Number:___________________________________________________________________________
PurchaseDate:____________________________________________________________________________
NOTE: This owner’s manual is compiled from the latest specifications and product information available
at the time of publication. We reserve the right to make changes as they become necessary. Any changes to
our products may cause slight variations between the illustrations and explanations in this manual and the
product you have purchased. The latest/current version of this manual is available on our website.
Thesymbolsbelowareusedthroughoutthisowner'smanualandonthe power chair to identify warningsandimportant
information.Itisveryimportantforyou toreadthem andunderstandthem completely.
WARNING! Indicates a potentially hazardous condition/situation. Failure to follow designated
procedures can cause either personal injury component damage or malfunction. On the product
this icon is represented as a black symbol on a yellow triangle with a black border.
MANDATORY! These actions should be performed as specified. Failure to perform mandatory
actions can cause personal injury and/or equipment damage. On the product this icon is
represented as a white symbol on a blue dot with a white border.
PROHIBITED! These actions are prohibited. These actions should not be performed at any time or
in any circumstances. Performing a prohibited action can cause personal injury and/or equipment
damage. On the product this icon is represented as a black symbol with a red circle and red
slash.
Quick Reference Information
088 609 661
WARNING! A Quantum Rehab Dealer or a qualified technician must perform the initial setup of
this power chair and must perform all of the procedures in this manual.

Quantum 6000 Series www.pridemobility.com 3
I. INTRODUCTION.................................................................................................................................... 4
II. SAFETY .................................................................................................................................................... 5
III. YOUR POWER CHAIR ....................................................................................................................... 17
IV. ASSEMBLY............................................................................................................................................ 22
V. COMFORT ADJUSTMENTS........................................................................................................... 25
VI. BATTERIES AND CHARGING ....................................................................................................... 32
VII. CARE AND MAINTENANCE ........................................................................................................... 36
VIII. WARRANTY........................................................................................................................................... 42
APPENDIX I - SPECIFICATIONS .......................................................................................................... 43
CONTENTS

4 www.pridemobility.com Quantum 6000 Series
I. INTRODUCTION
SAFETY
WELCOMEtoQuantumRehab, adivisionofPrideMobility ProductsLtd.(Pride).Thepower chairyouhave purchased
combinesstate-of-the-artcomponents with safety,comfortandstylinginmind.We areconfidentthatthesedesignfea-
tureswill provideyouwith the conveniencesyouexpect duringyourdailyactivities. Onceyouunderstand how tosafely
operateandcarefor your power chair,it should give you years of trouble free operation and service.
Readand followallinstructions, warningsandnotes inthismanual beforeattemptingtooperateyourpowerchairfor the
firsttime.Youmustalsoreadallinstructions,warningsandnotescontainedinanysupplementalinstructional bookletsfor
thecontroller,frontriggingsand/orseatingsystemthataccompaniedyourpowerchairbeforeinitialoperation.Your safety
dependsupon you, as wellasyourdealer, carer orhealthcareprofessionalinusing good judgement.
Ifthereisanyinformationin this manual which you do not understand, or if you require additionalassistance for setup
or operation, please contact your Quantum Rehab Dealer. Failure to follow the instructions in this manual and
thoselocatedon yourpowerchaircanleadto personal injuryand/ordamage tothepowerchair,andmayvoid
thewarranty.
PURCHASER’S AGREEMENT
Byaccepting delivery of this product,you promisethat you willnot change,alter ormodify this productor removeor
renderinoperableorunsafe anyguards,shields orothersafety featuresofthis product;fail,refuseorneglect toinstallany
retrofitkitsfrom time to time provided by Pride to enhance or preserve the safeuseofthisproduct.
SHIPPING AND DELIVERY
Beforeusing yourpowerchair,makesureyourdelivery iscompleteas somecomponentsmay beindividuallypackaged.
Ifyou do not receiveacompletedelivery, please contact your QuantumRehabDealer immediately.Where damage has
occurredduring transport, eithertothepackagingor content, pleasecontactthedelivery company responsible.
INFORMATION EXCHANGE
Wewanttohearyourquestions,commentsand suggestionsabout thismanual.We wouldalso liketohearaboutthesafety
andreliability ofyournewpower chair,andaboutthe service youreceivedfromyour QuantumRehabDealer.
Please notify us of any change of address, so we can keep you apprised of important information about safety, new
productsand newoptionsthat canincreaseyour abilitytouseand enjoyyourpower chair.Pleasefeel freetocontactus at
theaddress below:
PrideMobility ProductsLtd.
32 Wedgwood Road
Bicester,Oxon OX26 4UL
NOTE: If you ever lose or misplace your product registration card or your copy of this manual, contact us and
we will be glad to send you a new one immediately.

Quantum 6000 Series www.pridemobility.com 5
II. SAFETY
PRODUCT SAFETY SYMBOLS
Thesymbols belowareused onthepower chairtoidentify warnings,mandatoryactionsand prohibitedactions.It isvery
importantfor youtoreadand understandthemcompletely.
Read and follow the information in the owner’s manual.
Maximum seating weight.
Do not allow unsupervised children to play near the power chair while the batteries are
charging.
Keep your hands away from the tyres when driving. Be aware that loose fitting clothing
can become caught in drive tyres.
Use correct tie down points for controller harness to prevent the harness from getting
caught in the drive tyres, pinched in the seat frame or damaged when passing through
doorways.
Do not use a cell phone, walkie/talkie, laptop or other radio transmitter while operating.
Avoid exposure to rain, snow, ice, salt or standing water whenever possible. Maintain and
store in a clean and dry condition.

6 www.pridemobility.com Quantum 6000 Series
II. SAFETY
Removal of grounding prong can create electrical hazard. If necessary, properly install an
approved 3 pronged adapter to an electrical outlet having 2 pronged plug access.
Locked and in drive mode.
Place unit on level ground and stand to one side when changing from drive mode to
freewheel mode or freewheel mode to drive mode.
Unlocked and in freewheel mode.
Do not lift the mobility product while seated in it.
Do not place power chair in freewheel mode on an incline.
Do not place power chair in freewheel mode on a decline.
Do not lift the mobility product while seated in it.

Quantum 6000 Series www.pridemobility.com 7
Explosive conditions exist!
Battery Set Configuration:
+ = Positive (Red) Terminal Post
– = Negative (Black) Terminal Post
Connect Red wires to Red Positive (+) Terminal Posts
Connect Black wires to Black Negative (–) Terminal Posts
This product has been tested and passed at an immunity level of 20 V/m.
Do not connect an extension lead to the AC/DC converter or the battery charger.
Use only AGM or Gel Cell batteries to reduce the risk of leakage or explosive conditions.
II. SAFETY
Keep tools and other metal objects away from battery terminals. Contact with tools
can cause electrical shock.
Corrosive chemicals contained in battery.

8 www.pridemobility.com Quantum 6000 Series
II. SAFETY
Disposal and recycling Contact your Quantum Rehab Dealer for information on proper
disposal and recycling of your Pride product and its packaging.
Do not use batteries with different amp hour (Ah) capacities. Do not mix old and new
batteries. Always replace both batteries at the same time.
Indicates that power chair, with similarly labeled seating system, conforms to ANSI/
RESNA WC/Vol. 4, Section 19/ISO 7176 19 for transport of an occupied power chair in a
motor vehicle.
Indicates power chair securement points.

Quantum 6000 Series www.pridemobility.com 9
II. SAFETY
GENERAL GUIDELINES
MANDATORY! Do not operate your new power chair for the first time without completely reading
and understanding this owner’s manual.
Your powerchairisastate-of-the-artlife-enhancementdevice designedtoincrease mobility.Prideprovides anextensive
varietyof products tobest fitthe individualneeds of the powerchair user.Please be aware thatthe final selection and
purchasing decision regarding the type of power chair to be used is the responsibility of the power chair user, who is
capableof makingsuchadecision, andhis/herhealthcareprofessional (i.e.,medicaldoctor,physical therapist,etc.).
Thecontents ofthismanualare basedontheexpectation thatamobility device experthasproperly fitted thepowerchair
totheuserandhasassistedtheprescribinghealthcareprofessionaland/ortheQuantumRehabDealerintheinstruction
processfor the use of theproduct.
Therearecertainsituations,includingsomemedicalconditions,wherethepowerchairuserwillneedtopracticeoperating
the power chair in the presence of a trained attendant.Atrained attendant can be defined as a family member or care
professionalspeciallytrainedinassistingapowerchairuserinvariousdailylivingactivities.
Asyoubegin usingyourpowerchairduringdailyactivities,youwillprobablyencountersituationsinwhichyou willneed
somepractice. Simplytakeyourtime and youwillsoon be infulland confident controlasyoumanoeuvre throughdoor-
ways,onandoffoflifts,up and down ramps and over moderate terrain.
Belowaresomeprecautions,tipsand othersafety considerationsthatwillhelpyoubecomeaccustomed tooperatingyour
powerchairsafely.
Modifications
Pridehasdesignedandengineeredyourpowerchairtoprovidemaximummobilityandutility.Awiderangeofaccessories
is available from your Quantum Rehab Dealer to further customise your power chair to better suit your needs and/or
preferences.However,undernocircumstancesshouldyou modify,add,remove ordisableanyfeature,part orfunctionof
yourpower chair.
WARNING! Do not modify your power chair in any way not authorised by Pride. Do not use
accessories if they have not been tested or approved for Pride products.
Pre-Ride Safety Check
Gettoknowthefeelofyourpowerchairanditscapabilities.Priderecommendsthatyouperformasafetycheckbefore
eachusetomakesure your power chair operates smoothly and safely.
Performthefollowinginspectionsprior to using your power chair:
Checkforpropertyre inflation.Maintainbut donotexceed thepsi/bar/kPaair pressureratingineachtyre ifequipped
withpneumatictyres.
Checkall electrical connections. Make sure they are tight and notcorroded.
Checkallcontrollerconnections to the power base. Make sure they aresecured properly.
Checkthe brakes. See VII. “Care andMaintenance.”
Checkbattery charge. See VI. “Batteries and Charging.”
NOTE: If you discover a problem, contact your Quantum Rehab Dealer for assistance.

10 www.pridemobility.com Quantum 6000 Series
II. SAFETY
Weight Limitations
Yourpowerchairisrated foramaximum weightcapacity.Please refertothespecificationstableforthis limit.
WARNING! Stay within the specified weight capacity of your power chair. Exceeding the weight
capacity voids your warranty. Pride will not be held responsible for injuries and/or property damage
resulting from failure to observe weight limitations.
WARNING! Do not carry passengers on your power chair. Carrying passengers on your power
chair may affect the centre of gravity, resulting in a tip or a fall.
Tyre Inflation
Ifyourpowerchair isequipped withpneumatictyres,youshould checkorhavetheair pressurecheckedregularly. Proper
inflationpressures willprolongthe lifeofyour tyresandhelp ensurethesmooth operationofyourpower chair.
WARNING! It is important that the psi/bar/kPa air pressure rating indicated on the tyre be maintained
in pneumatic tyres at all times. Do not underinflate or overinflate your tyres. Low pressure may
result in loss of control, and overinflated tyres may burst. Failure to maintain the psi/bar/kPa air
pressure rating indicated on the tyres at all times may result in tyre and/or wheel failure.
WARNING! Inflate your power chair drive tyres from a regulated air source with an available
pressure gauge. Inflating your tyres from an unregulated air source could overinflate them, resulting
in a burst tyre.
NOTE: If the tyres on your power chair list the psi rating only, use the following conversion formulas to find
the bar or kPa rating: bar = psi x 0.06895; kPa = psi x 6.89476.
Incline Information
Moreandmorebuildingshaverampswithspecifieddegreesofinclination,designedforeasyandsafeaccess.Someramps
mayhave turning switchbacks(180-degreeturns)that requireyoutohave good corneringskillsonyour power chair.
Proceedwithextreme caution as you approach the downgrade of a ramp or other incline.
Takewideswings withyour powerchair’sfrontwheelsaroundanytightcorners. Ifyoudothat,thepowerchair’srear
wheelswill follow awidearc,notcut the cornershortandnotbump into orgethungupon any railingcorners.
When driving down a ramp, keep the power chair’s speed adjustment set to the slowest speed setting to ensure a
safelycontrolleddescent.
Avoid sudden stops and starts.
Whenclimbingan incline,trytokeepyourpowerchairmoving.Ifyoumuststop,startupagainslowlyandthenaccelerate
cautiously.When driving down an incline, set your power chair to the slowest speed setting and drive in the forward
directiononly. Ifyourpower chair startstomove downtheinclinefaster thanyouanticipatedor desired,allowit to come
toa complete stopbyreleasingthe joystick, thenpushthejoystick forward slightlytoensurea safely controlleddescent.
WARNING! When on any sort of an incline or decline, never place the power chair in
freewheel mode while seated on it or standing next to it.
WARNING! When climbing an incline, do not zigzag or drive at an angle up the face of
the incline. Drive your power chair straight up the incline. This greatly reduces the
possibility of a tip or a fall. Always exercise extreme caution when negotiating an incline.
WARNING! You should not travel up or down a potentially hazardous incline (i.e., areas
covered with snow, ice, cut grass or wet leaves).
WARNING! Never travel down an incline rearward. Doing so may cause the power
chair to tip. Always exercise caution when negotiating an incline.
WARNING! If your power chair is equipped with a reclining seatback, do not attempt
to negotiate inclines with the seat in a reclined position. Do not attempt to negotiate
obstacles with the seat in a reclined position unless an attendant is present to help
stabilise the chair. Failure to heed may result in the power chair tipping over.

Quantum 6000 Series www.pridemobility.com 11
II. SAFETY
Figure 1. Maximum Safe Slope (Ascending and Descending)
8.7% (5 )
WARNING! Even though your power chair is capable of climbing slopes greater than those illustrated
in figure 1, do not, under any circumstances, exceed the incline guidelines or any other
specifications presented in this manual. Doing so could cause instability in your power chair.
Priderecommendsthatthemaximumslopeofaninclineyouattempttosafelyascendordescendonyourpowerchairdoes
not exceed 8.7 % (5°). See figure 1.
WARNING! Any attempt to climb or descend a slope steeper than 8.7 % (5°) may put your power
chair in an unstable position and cause it to tip.
Freewheel Mode
Yourpowerchairisequippedwithtwomanualfreewheelleverstoallowformanualmanoeuvrabilitybyatrainedattendant.
Formore information abouthowtoplace your powerchairintoand out offreewheelmode,see III. “YourPowerChair.”
WARNING! Do not use your power chair in freewheel mode without an attendant present.
WARNING! Do not attempt to personally place your power chair in freewheel mode
while seated on it. Ask an attendant for assistance if necessary.
WARNING! Do not place your power chair in freewheel mode while on an incline or
decline. This could cause the chair to roll uncontrollably on its own.
Braking Information
Yourpower chairisequippedwith two powerful brakesystems:
Regenerative— useselectricityto rapidly slowthevehicle whenthejoystickreturns tothecentre/stop position.
DiscParkBrake—activatesmechanicallyafterregenerative brakingslowsthevehicletonearstop,orwhen poweris
removedfrom the systemforanyreason.
Cornering Information
Whileyourpowerchairisequippedwithfrontandrearcastorwheels,excessivelyhighcorneringspeedscanstillcreatethe
possibilityoftipping.Factorswhichaffectthepossibilityoftippinginclude,butarenotlimitedto:corneringspeed,steering
angle(howsharplyyouareturning),unevenroadsurfaces,inclinedroadsurfaces,ridingfromanareaoflowtractiontoan
areaof high traction (such aspassing froma grassyarea toa paved area– especiallyat highspeeds whileturning) and
abruptdirectional changes. High cornering speeds arenot recommended. Ifyou feelthat you maytip over ina corner,
reduceyour speed and steering angle (i.e.,lessenthesharpnessof the turn) to prevent yourpowerchairfromtipping.
WARNING! When cornering sharply, reduce your speed and maintain a stable centre of gravity.
This greatly reduces the possibility of a tip or fall.
Public Streets and Roadways
WARNING! You should not operate your power chair on public streets and roadways. Be aware
that it may be difficult for traffic to see you when you are seated on your power chair. Obey all
local pedestrian traffic rules. Wait until your path is clear of traffic, and then proceed with
extreme caution.

12 www.pridemobility.com Quantum 6000 Series
II. SAFETY
Outdoor Driving Surfaces
Yourpowerchairisdesignedtoprovideoptimumstabilityundernormaldrivingconditions—dry,levelsurfacescomposed
ofconcrete,blacktopor tarmac.However,Priderecognisesthattherewillbe timeswhenyouwillencounter othersurface
types.Forthisreason,yourpowerchairisdesignedto performadmirablyonpackedsoil,grassandgravel.Feelfreeto use
yourpowerchairsafely on lawns and in park areas.
Reduceyour power chair’sspeedwhen driving onuneventerrainand/or soft surfaces.
Avoidtallgrassthat canentangle therunninggear.
Avoidloosely packed gravel andsand.
Ifyou feelunsureabout adrivingsurface, avoidthatsurface.
Inclement Weather Precautions
Exposureof yourpowerchair toinclementweatherconditions shouldbeavoided whenever possible.Ifsuddenly caught
up in rain, snow, severe cold or heat while operating your power chair, proceed to shelter at the earliest opportunity.
Thoroughlydry yourpowerchair beforestoring,chargingor operatingyourpower chair.
PROHIBITED! Operating in rain, snow, salt, mist/spray conditions and on icy/slippery surfaces can
have an adverse affect on the electrical system. Maintain and store your power chair in a dry and
clean condition.
WARNING! Prolonged exposure to hot or cold conditions may affect the temperature of upholstered
and non upholstered items on the power chair, possibly resulting in skin irritation. Exercise caution
when using your power chair in extremely hot or cold conditions or when exposing your power
chair to direct sunlight for prolonged periods of time.
Stationary Obstacles (Steps, Kerbs, etc.)
Proceedwithextremecautionwhendrivingnearraisedsurfaces,unprotectedledgesand/ordrop-offs(kerbs,porches,stairs,etc.).
To navigate up overa kerb or stationary obstacle:
1. Approachthekerborobstacleslowly,andmakesurethepowerchairistravelingperpendiculartotheobstacle.Seefigure2.
2. Increasetheforwardspeedjustbeforethefrontwheels(orkerbclimbingmechanism)comeincontactwiththeobstacle.
3. Reducetheforwardspeedonlyaftertherearwheelshave cleared the obstacle.
Tonavigate down akerborstationaryobstacle:
1. Approachthekerborobstacleslowly,andmakesurethepowerchairistravelingperpendiculartotheobstacle.Seefigure2.
2. Reducetheforwardspeed just before the front wheels come in contact with the obstacle.
3. Increasetheforwardspeedonlyaftertherearwheelshaveclearedtheobstacleandyouareonceagainonalevelsurface.
KERB
KERB
Figure 2. Correct Kerb Approach Figure 3. Incorrect Kerb Approach

Quantum 6000 Series www.pridemobility.com 13
II. SAFETY
WARNING! Do not attempt to have your power chair climb or descend an obstacle that is higher
than 5 cm (2 in.) unless you have the assistance of an attendant.
WARNING! If your power chair is equipped with a kerb climber, do not attempt to climb any kerb
in excess of 5 cm (2 in.) in height. Do not approach kerbs at an angle; instead approach any kerb
you intend to ascend or descend in the forward position.
WARNING! Do not attempt to have your power chair proceed rearward down any step, kerb or
other obstacle. This may cause the power chair to tip.
Doors
Determineifthe door opens toward or away from you.
Driveyourpowerchairgentlyandslowlyforwardtopushthedooropen.Ordriveyour powerchair gentlyand slowly
rearwardto pull the door open.
Lifts
Modernlifts have a dooredgesafetymechanismthat, when pushed, reopenstheliftdoor(s).
Ifyouareinthe doorway of a lift when the door(s) begin toclose, push on the rubber dooredge or allow the rubber
dooredge to contact the powerchair and thedoor willreopen.
Usecarethathandbags, packages or power chair accessories donot become caught in liftdoors.
Lift/Elevation Products
Ifyouwillbetravelingwith yourpowerchair,youmayfinditnecessarytouse alift/elevationproducttoaidintransporta-
tion.Priderecommends that you closely reviewthe instructions, specifications andsafety information setforth by the
manufacturerofthelift/elevationproductbeforeusingthatproduct.
WARNING! Never sit on your power chair when it is being used in connection with any
type of lift/elevation product. Your power chair was not designed with such use in
mind and any damage or injury incurred from such use is not the responsibility of Pride.
Motor Vehicle Transport
Priderecommends thatyoudo notremainseated in yourpowerchair whiletravelingin amotorvehicle.The powerchair
shouldbestowed in the boot of a car or in the back of a truck or van withthebatteriesremovedandproperlysecured.In
addition,allremovablepowerchairparts,includingthearmrests,seat,frontriggings,controller and shrouds should be
removedand/orproperlysecuredduringmotorvehicletransport.Ifyourpowerchairisequippedwithatransit securement
system,refertoIV."Assembly"and thesupplementprovided withyourpower chairforadditional informationregarding
powerchair transport inamotorvehicle.
WARNING! Pride does not recommend using the power chair as a seat in a motor vehicle. The
power chair user should transfer into the vehicle seat and use the vehicle installed belt restraint
system if and whenever feasible. If your power chair is equipped with a manufacturer installed
transit securement system, please refer to the supplemental safety information provided with
your power chair.
WARNING! Ensure power chairs equipped with a transit securement system are properly secured
to the motor vehicle during transport. Power chairs that are not properly secured can become a
hazard to the user and to other vehicle passengers in the event of a crash, sudden stopping or
swerving, as the power chair could tip or slide out of place.
WARNING! Always be sure your power chair and its batteries are properly secured when it is being
transported. Batteries should be secured in an upright position and protective caps should be
installed on the battery terminals. Batteries should not be transported with any flammable or
combustible items.

14 www.pridemobility.com Quantum 6000 Series
II. SAFETY
Stairs and Escalators
Powerchairsarenotdesignedtotravelupor down stairs or escalators.Alwaysusealift.
WARNING! Never use your power chair to negotiate steps or escalators.
Positioning Belts
YourQuantumRehabDealer,therapist(s)andotherhealthcareprofessionalsareresponsiblefordeterminingyourrequirement
forapositioningbeltinordertooperateyourpowerchairsafely.Thepositioningbeltisnotdesignedforuseasarestraining
deviceina motorvehicle.Youshouldbeproperlybelted intoseatsapprovedbythevehiclemanufacturerwithyour power
chairproperlystowedforvehicletransportorsecuredusinganoptionaltransitsecurementsystem.
Positioningbeltsshouldbeinstalledasdetailedinthismanual.SeeV. “ComfortAdjustments.” Once installed, the belt
shouldbeplacedacrossthepelvisasdeterminedbyyourhealthcareprovider.Anchorpointsofthepositioningbeltsshould
be located so that a projected side-view angle of the pelvis is between 45°-75° of horizontal depending on the user’s
weight,posture andseatcushion thickness.
WARNING! If you require a positioning belt to safely operate your power chair, make sure it is
fastened securely in order to reduce the possibility of a fall from the power chair.
WARNING! The positioning belt is not designed for use as a seat belt in a motor vehicle. Nor is
your power chair suitable for use as a seat in any vehicle. Anyone traveling in a vehicle should be
properly belted into seats approved by the vehicle manufacturer. If your power chair is equipped
with a manufacturer installed transit securement system, please refer to the supplemental safety
information provided with your power chair.
Batteries
In addition to following the warnings below, be sure to comply with all other battery handling information. For more
informationabout yourpowerchair’sbatteries,seeVI.“BatteriesandCharging.”
WARNING! Battery posts, terminals and related accessories contain lead and lead
compounds. Wear goggles and gloves when handling batteries and wash hands after handling.
WARNING! Power chair batteries are heavy. See specifications table. If you are unable
to lift that much weight, be sure to get help. Use proper lifting techniques and avoid
lifting beyond your capacity.
WARNING! Always protect the batteries from freezing and never charge a frozen battery.
Charging a frozen battery may result in damage to the battery.
WARNING! Connect your battery harnesses in the proper manner. RED (+) cables must
be connected to positive (+) battery terminals/posts. BLACK ( ) cables must be
connected to negative ( ) battery terminals/posts. Protective caps should be installed
over all battery terminals. REPLACE cables immediately if damaged.
Removable Parts
WARNING! Do not attempt to lift or move a power chair by any of its removable parts, including the
armrests, seat, front riggings, controller and shrouds.
Preventing Unintended Movement
WARNING! If you anticipate being seated in a stationary position for an extended period of time,
turn off the power. This will prevent unexpected motion from inadvertent joystick contact. This
will also eliminate the possibility of unintended chair movement from electromagnetic (EM) sources.

Quantum 6000 Series www.pridemobility.com 15
II. SAFETY
Figure 4. IdealTransfer Position
Transfers
Transferringontoandoffofyourpowerchairrequiresagoodsense
ofbalance.Always havean attendantorhealthcare professional
presentwhilelearningtoproperly transferyourself.
Toeliminatethepossibilityofinjury,Priderecommendsthatyouor
atrainedattendant performthefollowingtasksbeforeattemptinga
transfer:
Turnoffthepower tothecontroller.
Ensure your power chair is not in freewheel mode. See III.
“YourPower Chair.”
Turnthecastor wheels toward the transfer destinationto im-
provepowerchairstabilityduringtransfer.
Makesure botharmrestsare flippeduporremoved fromyour
powerchair.
Flipupthefootplatformormovethelegrestsaside;thiswill
helpto keepyourfeet fromgettingcaughton thefrontrigging
duringthetransfer.
Reduce the distance between your power chair and the ob-
ject you are transferring onto.
WARNING! Before transferring, position yourself as far back as possible in the power chair seat
to prevent the power chair from tipping forward during transfer.
WARNING! Avoid putting all of your weight on the power chair armrests and do not use the armrests
for weight bearing purposes, such as transfers. Such use may cause the power chair to tip, resulting
in a fall from the power chair.
WARNING! Avoid putting all of your weight on the front riggings. Such use may cause the power
chair to tip.
User Positioning
Priderecommendsthatallusersbeseatedinanuprightpositionwiththeirpelvispositionedasfarrearwardaspossibleinthe
powerchairseat.All usersneedto discusspelvicpositioningwiththeir QuantumRehabDealer,therapist(s)orhealthcare
professionaltodetermineappropriatepelvicpositionwhenseatedonthepowerchairbasedontheuser’sindividualmedicalneeds.
Reaching and Bending
Neverreach, lean orbendwhile driving yourpowerchair. If itisabsolutely necessary toreach,leanor bend whileseated
onyour power chair,it is important tomaintain a stablecentre ofgravity and keepthe powerchair from tipping.Pride
recommendsthatthe power chair user determine his/her personallimitations and practice bendingand reaching in the
presenceofaqualified healthcareprofessional.
WARNING! Do not bend, lean or reach for objects if you have to pick them up from the
floor by reaching down between your knees or if you have to reach over the back of
the seat. Movements such as these may change your centre of gravity and the weight
distribution of the power chair, possibly causing your power chair to tip.
WARNING! Keep your hands away from the tyres when driving. Be aware that loose
fitting clothing can become caught in drive tyres.

16 www.pridemobility.com Quantum 6000 Series
II. SAFETY
Prescription Drugs/Physical Limitations
Usersmustexercisecareandcommonsensewhenoperatingapowerchair.This includesawareness ofsafety issueswhen
takingprescribed orover-the-counterdrugs orwhenthe userhasspecificphysical limitations.
WARNING! Consult your physician if you are taking prescribed or over the counter medication or
if you have certain physical limitations. Some medications and limitations may impair your ability
to operate your power chair in a safe manner.
Alcohol/Smoking
Thepowerchairuser mustexercisecareandcommonsensewhen operatinghis/herpowerchair.Thisincludesawareness
ofsafetyissueswhileundertheinfluenceofalcoholorwhilesmoking.
WARNING! Do not operate your power chair while you are under the influence of alcohol, as this
may impair your ability to operate your power chair in a safe manner.
WARNING! Pride strongly recommends that you do not smoke cigarettes while seated in your
power chair, although the power chair has passed the necessary testing requirements for cigarette
smoking. You must adhere to the following safety guidelines if you decide to smoke cigarettes
while seated in your power chair.
Do not leave lit cigarettes unattended.
Keep ashtrays a safe distance from the seat cushions.
Always make sure cigarettes are completely extinguished before disposal.
Electromagnetic and Radio Frequency Interference (EMI/RFI)
WARNING! Laboratory tests have shown that electromagnetic and radio frequency waves can
have an adverse affect on the performance of electrically powered mobility vehicles.
Electromagneticand Radio FrequencyInterference cancome fromsources such as cellularphones, mobiletwo-way
radios(such as walkie-talkies), radio stations, TVstations,amateurradio(HAM) transmitters, wireless computer links,
microwavesignals,pagingtransmittersandmedium-rangemobiletransceiversusedbyemergencyvehicles.Insomecases,
thesewavescancauseunintendedmovementordamagetothecontrolsystem.Everyelectrically-poweredmobilityvehicle
hasanimmunity(orresistance)toEMI.Thehighertheimmunitylevel,thegreatertheprotectionagainstEMI.Thisproduct
hasbeen tested and has passed at an immunity levelof20V/m.
WARNING! Be aware that cell phones, two way radios, laptops and other types of radio transmitters
may cause unintended movement of your electrically powered mobility vehicle due to EMI.
Exercise caution when using any of these items while operating your mobility vehicle and avoid
coming into close proximity of radio and TV stations.
WARNING! The addition of accessories or components to the electrically powered mobility vehicle
can increase the susceptibility of the vehicle to EMI. Do not modify your power chair in any way
not authorised by Pride.
WARNING! The electrically powered mobility vehicle itself can disturb the performance of other
electrical devices located nearby, such as alarm systems.
NOTE: For further information on EMI/RFI, go to the Resource Center on www.pridemobility.com. If
unintended motion or brake release occurs, turn your power chair off as soon as it is safe to do so. Contact
your Quantum Rehab Dealer to report the incident.

Quantum 6000 Series www.pridemobility.com 17
III. YOUR POWER CHAIR
THE QUANTUM 6000 SERIES POWER CHAIR
Your power chair has two main assemblies: the seatassemblyandthepowerbaseassembly. See figure 5.Typically, the
seatassembly includes thearmrests,seatback and seatbase.Thepower baseassemblyincludestwo motor/brake assem-
blies,twodrivewheels, four castor wheels, two batteries and wiring harnesses. See figures 5, 6 and 7.
Figure 5.The Quantum 6000 Series Power Chair
SEATBACK
DRIVEWHEEL
CASTORWHEEL
POWERBASE
ASSEMBLY
SEAT ASSEMBLY
JOYSTICK
FRONTRIGGING
(FOOT PLATFORM SHOWN)
SEATBASE
CONTROLLER
CASTORWHEEL
MANUALFREEWHEELLEVER
ARMREST
ARMREST

18 www.pridemobility.com Quantum 6000 Series
III. YOUR POWER CHAIR
Electrical Components
The electrical components consist of the controller assembly, the batteries and the motors. The batteries, motors and
controller power module (if equipped) are located on the power base assembly. The controller is located on the seat
assembly. Connectivity between thecontrollerand the motors, batteriesandthe battery chargeris provided byoneor
morewiringharnesses.Seefigure7.
ControllerCableConnector: The controllercable connector iswhere the controllerplugs into thepower base. Each
controlleruses a different type ofharness.Regardlessofwhich type of controller isused,theharnessmust be secured to
theseatassemblyandnotallowedtodragonthefloor.
MotorConnectors:This is where the controller connects to the motors.
BatteryConnector: Thisiswhere the controller connects to the batteries.
Figure 6.The Quantum 6000 Series Power Base
MANUALFREEWHEELLEVER
REAR SEAT MOUNT CONNECTORS FRONT SEAT MOUNT
CONNECTORS
FRONT COVER
REARSHROUDFASTENER
(FASTENER ON OPPOSITE
SIDE NOT SHOWN)
REARSHROUD

Quantum 6000 Series www.pridemobility.com 19
III. YOUR POWER CHAIR
ControllerPowerModule:Thisenablesthe controller to communicatewiththebatteries and themotors.
MainCircuitBreaker(locatedon the rearmain frame): Themaincircuit breaker is a safetyfeature built intoyour
powerchair.Whenthebatteriesand the motorsareheavilystrained (e.g., fromexcessiveloads),the main circuitbreaker
tripsto preventdamageto the motorsandthe electronics.Ifthecircuit trips,allowyour power chairto“rest” forapproxi-
matelyone minute.Thecircuit breakerwillreset itself.Turnonthecontroller, andcontinuenormaloperation. Ifthemain
circuitbreaker continues totriprepeatedly, contact your QuantumRehabDealer.
Figure 7. Quantum 6000 Series Electrical Components
QUICKRELEASE
BATTERY CONNECTORS
MAINCIRCUITBREAKER
CONTROLLERPOWERMODULE
TO MOTOR
CONNECTOR
CONTROLLER CONNECTOR

20 www.pridemobility.com Quantum 6000 Series
III. YOUR POWER CHAIR
Dual Manual Freewheel Levers
Foryourconvenience,yourpowerchairisequippedwithdualmanualfreewheellevers.Theleversarelocatedoneach
motor,andallowyouto disengagethedrive motorsandmanoeuvre thechairmanually.
WARNING! Do not use the power chair while the drive motors are disengaged! Do not
disengage the drive motors when the power chair is on an incline or decline, as the
unit could roll on its own! Only engage the freewheel mode when on a level surface.
WARNING! It is important to remember that when your power chair is in freewheel
mode, the braking system is disengaged.
To operatethe dualmanualfreewheellevers:
1. Pullupboth manual freewheelleverstoengage thedrivemotors(drive mode). Seefigure8.
2. Pushdownboth manual freewheelleversto disengage thedrivemotors(freewheel mode).Seefigure9.
NOTE: You must turn off the power before disengaging the drive motors, otherwise you may get an error
code on the controller. To clear this code, turn off the controller and place the power chair in drive mode.
Then, turn on the controller. The error message should be cleared. If it isn’t, contact your Quantum Rehab
Dealer.
NOTE: The power chair will be significantly easier to push with the power off.
WARNING! Avoid applying excessive force to the manual freewheel levers.
WARNING! Do not use your foot to operate the manual freewheel levers. Do not stand on the
manual freewheel levers. Applying excessive force to the manual freewheel levers may result in
damage to the freewheel levers, motors and brakes.
WARNING! Do not use the freewheel lever handles as tie down points to secure this product.
Figure 8. Drive Mode (Drive Engaged) Figure 9. Freewheel Mode (Drive Disengaged)
