Pride Mobility Quantum Jazzy 1420 User manual

Owner’s Manual
1-800-800-8586 (Exeter, PA) • 1-888-570-1113 (St. Catharines, ON) • www.quantumrehab.com

SAFETY GUIDELINES
Copyright©2006
PrideMobilityProductsCorp.
INFMANU1206/RevF/May2006
www.quantumrehab.com QuantumJazzy1420
Thesymbolsbelowareusedthroughoutthisowner'smanual and on the power chair toidentify warnings and
importantinformation.Itisveryimportantfor you toreadthemandunderstandthem completely.
WARNING! Failure to follow designated procedures can cause either personal injury,
component damage, or malfunction (black symbol on yellow triangle with black border).
MANDATORY! These actions should be performed as specified. Failure to perform
mandatory actions can cause injury to personnel and/or damage to equipment (white
symbol on blue dot).
PROHIBITED! These actions are prohibited. These actions should not be performed at any
time or in any circumstances. Performing a prohibited action can cause injury to personnel
and/or damage to equipment (black symbol with red circle and red slash).

3
QuantumJazzy1420 www.quantumrehab.com
I. INTRODUCTION.................................................................................................................................4
II. SAFETY .................................................................................................................................................6
III. YOUR POWER CHAIR....................................................................................................................13
IV. ASSEMBLY/DISASSEMBLY........................................................................................................18
V. COMFORT ADJUSTMENTS........................................................................................................20
VI. BATTERIES AND CHARGING ....................................................................................................27
VII. OPERATION.......................................................................................................................................31
VIII.CARE AND MAINTENANCE ........................................................................................................39
IX. WARRANTY........................................................................................................................................44
CONTENTS
Thisowner’smanualiscompiledfromthelatestspecificationsandproductinformationavailableatthetimeofpublication.We
reserve the right to make changes as they become necessary.Any changes to our products may cause slight variations
betweentheillustrationsandexplanationsinthismanualandtheproductyouhavepurchased.

4www.quantumrehab.com QuantumJazzy1420
I. INTRODUCTION
SAFETY
WELCOMEto QuantumRehab, adivision ofPride MobilityProducts Corporation(Pride). Thepower chairyou have
purchasedcombines state-of-the-art componentswith safety, comfort,and stylingin mind.We areconfident thatthese
designfeatureswillprovideyouwiththeconveniencesyouexpectduringyourdailyactivities.Onceyouunderstandhow
to safelyoperateand care for your power chair, itshould give you years oftrouble free operationand service.
Read andfollow allinstructions,warnings,andnotesinthismanual before attempting to operateyourpowerchairforthe
first time. Inaddition, your safetydepends upon you,as well asyour provider,caretaker, or healthcare professional in
usinggoodjudgement.
Ifthereisanyinformation in thismanualwhichyoudo not understand,orifyourequire additionalassistanceforsetupor
operation,pleasecontactyour QuantumRehabSpecialist.Failuretofollowtheinstructionsinthismanualandthose
locatedonyourpowerchaircan leadtopersonalinjuryand/ordamagetothe powerchair,includingvoidingthe
warranty.
PURCHASER’S AGREEMENT
Byaccepting delivery of this product,you promise thatyou will notchange, alter, or modifythis product orremove or
renderinoperableorunsafeanyguards, shields, orothersafetyfeaturesofthisproduct;fail,refuse,orneglecttoinstallany
retrofitkits from time to time provided byPride toenhance orpreserve thesafe useof thisproduct.
INFORMATION EXCHANGE
Wewanttohearyour questions,comments,andsuggestionsaboutthismanual.We wouldalsoliketohearaboutthesafety
andreliabilityofyour newpowerchair,and abouttheserviceyou receivedfromyourQuantum RehabSpecialist.
Please notify us of any change of address, so we can keep you apprised of important information about safety, new
products,andnew optionsthat canincrease your abilityto useand enjoyyour power chair.Please feel freeto contactus
atthe addressbelow:
PrideMobilityProductsCorporation
Attn:CustomerCareDepartment
182SusquehannaAvenue
Exeter, PA18643-2694
[e-mail]
800-424-8205
NOTE: If you ever lose or misplace your product registration card or your copy of this manual, contact us and
we will be glad to send you a new one immediately.

5
QuantumJazzy1420 www.quantumrehab.com
I. INTRODUCTION
PRIDE OWNERS CLUB
Asanowner of aPrideproduct, youareinvited to registeryourproduct’swarrantyandenroll in thePrideOwners Club.
You may do so by filling out and returning your enclosed product registration card or by visiting Pride's web site at
www.pridemobility.com.Asaregisteredmember,eachtimeyouvisitoursite,youwillhaveaccess tothemostinteractive
andhonesteducationalvenueavailabletodayforpeoplewithmobilityneeds,theirfamilies,andfriends.
Fromourhomepage,select“Owners Club” toenterapagededicated to currentandpotentialPrideproductowners.You
willgainaccesstointerviews,stories,recreationideas,dailylivingtips,productandfundinginformation, and interactive
messageboards.Thesemessageboardsinviteyouto communicate withotherPridecustomersaswellas Pride represen-
tativeswhoare available toassist you withany questions orconcernsyou mayhave.
MyQuantum Rehab Specialist:
Name:_____________________________________________________________________________________
Address:_______________________________________________________________________________
Phone Number:__________________________________________________________________________
Purchase Date:___________________________________________________________________________

6www.quantumrehab.com QuantumJazzy1420
II. SAFETY
SAFETY
MANDATORY! Do not operate your new power chair for the first time without completely reading
and understanding this owner’s manual.
Your powerchairisastate-of-the-artlife-enhancementdevicedesignedtoincreasemobility.Prideprovidesanextensivevarietyof
productstobestfittheindividualneedsofthepowerchairuser.Pleasebeawarethatthefinalselectionandpurchasingdecisionregarding
thetypeofpowerchairtobeusedistheresponsibilityofthepowerchairuser,whoiscapableofmakingsuchadecision,andhis/her
healthcareprofessional(i.e.,medicaldoctor,physicaltherapist,etc.).
Thecontentsofthismanualarebasedontheexpectationthatamobilitydeviceexperthasproperlyfittedthepowerchairtotheuserand
hasassistedtheprescribinghealthcareprofessionaland/ortheQuantumRehabSpecialistintheinstructionprocessfortheuseofthe
product.
Therearecertainsituations,includingsomemedicalconditions,wherethepowerchairuserwillneedtopracticeoperatingthepower
chairinthepresenceofatrainedattendant.Atrainedattendantcanbedefinedasafamilymemberorcareprofessionalspeciallytrained
inassistingapowerchairuserinvariousdailylivingactivities.
Asyoubeginusingyourpowerchairduringdailyactivities,youwillprobablyencountersituationsinwhichyouwillneedsomepractice.
Simplytakeyourtimeandyouwillsoonbeinfullandconfidentcontrolasyoumaneuverthroughdoorways,onandoffofelevators,up
anddownramps,andovermoderateterrain.
Belowaresomeprecautions,tips,andothersafetyconsiderationsthatwillhelpyoubecomeaccustomedtooperatingyourpowerchair
safely.
Modifications
Pridehasdesignedandengineeredyourpowerchairtoprovidemaximummobilityandutility.Awiderangeofaccessoriesisavailable
fromyourQuantumRehabSpecialisttofurthercustomizeyourpowerchairtobettersuityourneedsand/orpreferences.However,
undernocircumstancesshouldyoumodify,add,remove,ordisableanyfeature,part,orfunctionofyourpowerchair.
WARNING! Do not modify your power chair in any way not authorized by Pride. Unauthorized
modifications may result in personal injury and/or damage to your power chair.
Pre-Ride Safety Check
Gettoknowthefeelofyourpowerchairanditscapabilities.Priderecommendsthatyouperformasafetycheckbeforeeachuseto
makesureyourpowerchairoperatessmoothlyandsafely.SeeVIII.“CareandMaintenance.”
Performthefollowinginspectionspriortousingyourpowerchair:
!Checkforpropertireinflation.Maintain35psi(2.4bar)ineachtireifequippedwithpneumatictires.
!Checkallelectricalconnections.Makesuretheyaretightandnotcorroded.
!Checkallcontrollerconnectionstotheelectronicstray.Makesuretheyaresecuredproperly.
!Checkthebrakes.SeeVIII.“CareandMaintenance.”
!Checkbatterycharge.SeeVI.“BatteriesandCharging.”
NOTE: If you discover a problem, contact your Quantum Rehab Specialist for assistance.

7
QuantumJazzy1420 www.quantumrehab.com
II. SAFETY
Weight Limitations
Yourpowerchairisratedforamaximumweightcapacity.Pleaserefertothespecificationstableforthislimit.
WARNING! Exceeding the weight capacity voids your warranty and may result in personal injury
and/or damage to your power chair. Pride will not be held responsible for injuries and/or property
damage resulting from failure to observe weight limitations.
WARNING! Do not carry passengers on your power chair. Carrying passengers on your power
chair may result in personal injury and/or property damage.
Tire Inflation
Ifyourpowerchairisequippedwithpneumatictires,youshouldcheckorhavetheairpressurecheckedatleastonceaweek.Proper
inflationpressureswillprolongthelifeofyourtiresandhelpensurethesmoothoperationofyourpowerchair.
WARNING! It is important that 35 psi (2.4 bar) tire pressure be maintained in pneumatic tires at
all times. Do not underinflate or overinflate your tires. Low pressure may result in loss of control,
and overinflated tires may burst. Failure to maintain 35 psi (2.4 bar) tire pressure in pneumatic
tires at all times may result in tire and/or wheel failure, causing serious personal injury and/or
damage to your power chair.
WARNING! Inflate your power chair drive tires from a regulated air source with an available
pressure gauge. Inflating your tires from an unregulated air source could overinflate them, resulting
in a burst tire and/or personal injury.
Incline Information
Moreandmorebuildingshaverampswithspecifieddegreesofinclination,designedforeasyandsafeaccess.Somerampsmayhave
turningswitchbacks(180-degreeturns)thatrequireyoutohavegoodcorneringskillsonyourpowerchair.
!Proceedwithextremecautionasyouapproachthedowngradeofaramporotherincline.
!Takewideswingswithyourpowerchair’sfrontwheelsaroundanytightcorners.Ifyoudothat,thepowerchair’srearwheelswill
followawidearc,notcutthecornershort,andnotbumpintoorgethunguponany railingcorners.
!Whendrivingdownaramp,keepthepowerchair’sspeedadjustment settotheslowestspeedsettingtoensureasafelycontrolled
descent. See VII.“Operation.”
!Avoidsuddenstopsandstarts.
Whenclimbinganincline,trytokeepyourpowerchairmoving.Ifyoumuststop,startupagainslowlyandthenacceleratecautiously.
Whendrivingdownanincline,setyourpowerchairtotheslowestsettinganddriveintheforwarddirectiononly.Ifyourpowerchair
startstomovedowntheinclinefasterthanyouanticipatedordesired,allowittocometoacompletestopbyreleasingthejoystick,then
pushthejoystickforwardslightlytoensureasafelycontrolleddescent.
WARNING! When climbing an incline, do not zigzag or drive at an angle up the face of the incline.
Drive your power chair straight up the incline. This greatly reduces the possibility of a tip or a fall.
Always exercise extreme caution when negotiating an incline.
WARNING! You should not travel up or down a potentially hazardous incline (i.e., areas covered
with snow, ice, cut grass, or wet leaves).
WARNING! When on any sort of an incline or decline, never place the power chair in freewheel
mode while seated on it or standing next to it. Doing so may result in personal injury and/or
damage to your power chair.
WARNING! Never travel down an incline backwards. This may result in personal injury.

8www.quantumrehab.com QuantumJazzy1420
II. SAFETY
5 (8.7%)
Figure 1. Maximum Safe Angle (Ascending and Descending)
WARNING! Even though your power chair is capable of climbing slopes greater than those illustrated
in figure 1, do not, under any circumstances, exceed the incline guidelines or any other
specifications presented in this manual. Doing so could cause instability in your power chair,
resulting in personal injury and/or damage to your power chair.
Incompliancewith theAmericanswith DisabilitiesActof 1990, allhandicap publicaccess rampsare required tohave a
maximumslope of 5°(8.7%).Therefore, Priderecommends thatthe maximum slopeof anincline youattempt tosafely
ascend or descend on your power chair does not exceed 5°(8.7%). See figure 1.
WARNING! Any attempt to climb or descend a slope steeper than 5° (8.7%) may put your power
chair in an unstable position and cause it to tip, resulting in personal injury.
Braking Information
Yourpowerchairisequippedwithtwopowerfulbrakesystems:
!Regenerative—useselectricitytorapidlyslowthevehiclewhenthejoystickreturnstothecenter/stopposition.
!DiscParkBrake—activatesmechanicallyafterregenerativebrakingslowsthevehicletonearstop,orwhenpowerisremoved
fromthesystemforanyreason.
Cornering Information
Whileyourpowerchairisequippedwithrearcasterwheelsandfrontanti-tipwheels,excessivelyhighcorneringspeedscanstillcreate
thepossibilityoftipping.Factorswhichaffectthepossibilityoftippinginclude,butarenotlimitedto:corneringspeed,steeringangle(how
sharplyyouareturning),unevenroadsurfaces,inclinedroadsurfaces,ridingfromanareaoflowtractiontoanareaofhightraction(such
aspassingfromagrassyareatoapavedarea–especiallyathighspeedwhileturning),andabruptdirectionalchanges.Highcornering
speedsarenotrecommended.Ifyoufeelthatyoumaytipoverinacorner,reduceyourspeedandsteeringangle(i.e.,lessenthe
sharpnessoftheturn)topreventyourpowerchairfromtipping.
WARNING! When cornering sharply, reduce your speed. This greatly reduces the possibility of a
tip or fall. To avoid personal injury and/or property damage, always exercise common sense when
cornering.
Outdoor Driving Surfaces
Yourpowerchairisdesignedtoprovideoptimumstabilityundernormaldrivingconditions—dry,levelsurfacescomposedofconcrete,
blacktop,orasphalt.However,Priderecognizesthattherewillbetimeswhenyouwillencounterothersurfacetypes.Forthisreason,
yourpowerchairisdesignedtoperformadmirablyonpackedsoil,grass,andgravel.Feelfreetouseyourpowerchairsafelyonlawns
andinparkareas.
!Reduceyourpowerchair’sspeedwhendrivingonuneventerrainand/orsoftsurfaces.
!Avoidtallgrassthatcanentangletherunninggear.
!Avoidlooselypackedgravelandsand.
!Ifyoufeelunsureaboutadrivingsurface,avoidthatsurface.

9
QuantumJazzy1420 www.quantumrehab.com
II. SAFETY
Freewheel Mode
Yourpowerchairisequippedwithamanualfreewheellevertoallowformanualmaneuverabilitybyatrainedattendant.Formore
informationabouthowtoplaceyourpowerchairintoandoutoffreewheelmode,seeIII.“YourPowerChair.”
WARNING! Do not use your power chair in freewheel mode without an attendant present. Personal
injury may result.
WARNING! Do not attempt to personally place your power chair in freewheel mode while seated
on it. Personal injury may result. Ask an attendant for assistance if necessary.
WARNING! Do not place your power chair in freewheel mode while on an incline. The chair could
roll uncontrollably on its own, causing personal injury.
Stationary Obstacles (Steps, Curbs, etc.)
Proceedwithextremecautionwhendrivingnearraisedsurfaces,unprotectedledgesand/ordrop-offs(curbs,porches,stairs,etc.).The
correctmethodforapproachingacurbisillustratedinfigure2.
WARNING! Do not attempt to have your power chair climb or descend an obstacle that is higher
than two inches unless you have the assistance of an attendant.
WARNING! Do not attempt to have your power chair proceed backwards down any step, curb, or
other obstacle. This may cause the power chair to tip and cause personal injury.
Public Streets and Roadways
WARNING! You should not operate your power chair on public streets and roadways. Be aware
that it may be difficult for traffic to see you when you are seated on your power chair. Obey all
local pedestrian traffic rules. Wait until your path is clear of traffic, and then proceed with extreme
caution.
Stairs and Escalators
Powerchairsarenotdesignedtotravelupordownstairsorescalators. Alwaysuseanelevator.
WARNING! Never use your power chair to negotiate steps or escalators. You may cause injury to
yourself and to others and/or damage your power chair.
Figure 2. Correct Curb Approach Figure 3. Incorrect Curb Approach

10 www.quantumrehab.com QuantumJazzy1420
II. SAFETY
WARNING! Before transferring, position
yourself as far back as possible in the power
chair seat to prevent the power chair from tipping forward during transfer and causing injury.
WARNING! Avoid using your armrests for weight bearing purposes. Such use may cause the power
chair to tip and cause personal injury.
WARNING! Avoid putting all of your weight on the foot riggings. Such use may cause the power
chair to tip and cause personal injury.
Doors
!Determineifthedooropenstowardorawayfromyou.
!Driveyourpowerchairgentlyandslowlyforwardtopushthedooropen.Ordriveyourpowerchairgentlyandslowlybackwards
topullthedooropen.
Elevators
Modernelevatorshaveadooredgesafetymechanismthat,whenpushed,reopenstheelevatordoor(s).
!Ifyouareinthedoorwayofanelevatorwhenthedoor(s)begintoclose,pushontherubberdooredgeorallowtherubberdoor
edgetocontactthepowerchairandthedoorwillreopen.
!Usecarethatpocketbooks,packages,orpowerchairaccessoriesdonotbecomecaughtinelevatordoors.
Lift/Elevation Products
Ifyouwillbetravelingwithyourpowerchair,youmayfinditnecessarytousealift/elevationproducttoaidintransportation.Pride
recommendsthatyoucloselyreviewtheinstructions,specifications,andsafetyinformationsetforthbythemanufacturerofthelift/
elevationproductbeforeusingthatproduct.
Figure 4.IdealTransfer Position
Transfers
Transferringontoandoffofyourpowerchairrequiresagoodsense
ofbalance.Alwayshaveanattendantorhealthcareprofessional
presentwhilelearningtoproperlytransferyourself.
Toeliminatethepossibilityofinjury,Priderecommendsthatyouora
trainedattendantperformthefollowingtasksbeforeattemptinga
transfer:
!Turnoffthepowertothecontroller.SeeVII.“Operation.”
!Ensureyour power chair is not in freewheel mode. See
III.“YourPower Chair.”
!Turnthe caster wheelstoward the transferdestinationto
improvepowerchairstabilityduringtransfer.
!Makesurebotharmrestsareflippedupor removed from
your power chair.
!Flip up the foot platform or move the leg rests aside;
thiswillhelptokeepyourfeet from gettingcaughtonthe
footriggingduringthetransfer.
!Reduce the distance between your power chair and the
objectyou are transferring onto.

11
QuantumJazzy1420 www.quantumrehab.com
II. SAFETY
Motor Vehicle Transport
Priderecommendsthatyou do notremainseatedin your powerchairwhiletraveling inamotorvehicle. The powerchair
shouldbe stowed inthe trunk of a car or inthe back ofa truck or van with the batteriesremoved and properlysecured.
WARNING! Do not sit on your power chair while it is in a moving vehicle. Personal injury and/or
property damage may result.
WARNING! Always be sure your power chair and its batteries are properly secured when it is being
transported. Failure to do so may result in personal injury and/or damage to your power chair.
Positioning Belts
YourQuantumRehabSpecialist,therapist(s),andotherhealthcareprofessionalsareresponsiblefordeterminingyourrequirementfora
positioningbeltinordertooperateyourpowerchairsafely.
WARNING! If you require a positioning belt to safely operate your power chair, make sure it is
fastened securely. Serious personal injury may result if you fall from the power chair.
WARNING! The positioning belt is not designed for use as a seat belt in a motor vehicle. Nor is
your power chair suitable for use as a seat in any vehicle. Anyone traveling in a vehicle should be
properly belted into seats approved by the vehicle manufacturer.
Inclement Weather Precautions
Exposureofyourpower chair toinclementweather conditions shouldbeavoidedwhenever possible.Ifsuddenlycaught
up in rain, snow, severe cold, or heat while operating your power chair proceed to shelter at the earliest opportunity.
Thoroughlydryyourpowerchair beforestoring,charging,or operating yourpowerchair
WARNING! Operating in rain, snow, salt, mist/spray conditions, and on icy/slippery surfaces can
cause personal injury and/or damage to the power chair and electrical system. Maintain and
store your power chair in a dry and clean condition.
Reaching and Bending
Neverreach,lean,orbendwhiledrivingyour power chair.Ifitisabsolutely necessary toreach,lean,orbendwhileseated
onyour power chair, it isimportant to maintain astable center of gravityand keep the power chair from tipping. Pride
recommendsthat the power chair user determine his/her personal limitations and practice bending and reaching in the
presenceofaqualifiedhealthcareprofessional.
WARNING! Do not bend, lean, or reach for objects if you have to pick them up from the floor by
reaching down between your knees. Movements such as these may change your center of gravity
and the weight distribution of the power chair. This may cause your power chair to tip, possibly
resulting in personal injury.
WARNING! Prevent personal injury! Keep your hands away from the tires when driving. Be aware
that loose fitting clothing can become caught in drive tires.
Preventing Unintended Movement
WARNING! If you anticipate being seated in a stationary position for an extended period of time,
turn off the power. This will prevent unexpected motion from inadvertent joystick contact. This
will also eliminate the possibility of unintended chair movement from electromagnetic (EM) sources.
Failure to do so may result in personal injury.
Removable Parts
WARNING! Do not attempt to lift or move a power chair by any of its removable parts. Personal injury and/
or damage to the power chair may result.

12 www.quantumrehab.com QuantumJazzy1420
II. SAFETY
Batteries
Inadditiontofollowingthewarnings below,besuretocomplywithallotherbatteryhandlinginformation.Formoreinformationabout
yourpowerchair’sbatteries,seeVI.“BatteriesandCharging.”
WARNING! Power chair batteries are heavy. See specifications table. If you are unable to lift that
much weight, be sure to get help. Lifting beyond your capacity can result in personal injury.
WARNING! Battery posts, terminals, and related accessories contain lead and lead compounds.
Wash hands after handling.
WARNING! Always protect the batteries from freezing and never charge a frozen battery. Charging
a frozen battery may result in personal injury and/or damage to the battery.
Prescription Drugs/Physical Limitations
Usersmustexercisecareandcommonsensewhenoperatingapowerchair.Thisincludesawarenessofsafetyissueswhentaking
prescribedorover-the-counterdrugsorwhentheuserhasspecificphysicallimitations.
WARNING! Consult your physician if you are taking prescribed or over-the-counter medication or
if you have certain physical limitations. Some medications and limitations may impair your ability
to operate your power chair in a safe manner.
Alcohol
Thepowerchairusermustexercisecareandcommonsensewhenoperatinghis/herpowerchair.Thisincludesawarenessofsafety
issueswhileundertheinfluenceofalcohol.
WARNING! Do not operate your power chair while you are under the influence of alcohol, as this
may impair your ability to operate your power chair in a safe manner.
Electromagnetic and Radio Frequency Interference (EMI/RFI)
WARNING! Laboratory tests have shown that electromagnetic and radio frequency waves can
have an adverse affect on the performance of electrically-powered mobility vehicles.
Electromagneticand Radio Frequency Interference can come from sources such as cellular phones, mobile two-way
radios(suchas walkie-talkies),radio stations,TV stations, amateurradio (HAM)transmitters, wireless computerlinks,
microwavesignals, paging transmitters, and medium-rangemobile transceivers usedby emergency vehicles. In some
cases,thesewavescancauseunintendedmovement or damage tothecontrolsystem.Everyelectrically-poweredmobility
vehiclehasanimmunity(orresistance)toEMI.Thehighertheimmunitylevel,thegreatertheprotectionagainstEMI.This
producthas beentested andhas passedat animmunity levelof 20V/m.
WARNING! Be aware that cell phones, two-way radios, laptops, and other types of radio transmitters
may cause unintended movement of your electrically-powered mobility vehicle due to EMI.
Exercise caution when using any of these items while operating your mobility vehicle and avoid
coming into close proximity of radio and TV stations.
WARNING! The addition of accessories or components to the electrically-powered mobility vehicle
can increase the susceptibility of the vehicle to EMI. Do not modify your power chair in any way
not authorized by Pride.
WARNING! The electrically-powered mobility vehicle itself can disturb the performance of other
electrical devices located nearby, such as alarm systems.
NOTE: For further information on EMI/RFI, visit the Resource Center on www.pridemobility.com. If unin-
tended motion or brake release occurs, turn your power chair off as soon as it is safe to do so. Call Pride at 800-
424-8205 to report the incident.

13
QuantumJazzy1420 www.quantumrehab.com
THE QUANTUM JAZZY 1420
TheQuantumJazzy1420hastwomainassemblies:theseatandthepowerbase.Seefigures5and6.Typically,theseatassembly
includesthearmrests,seatback,andseatbase.Thepowerbaseassemblyincludestwomotor/brakeassemblies,twodrivewheels,two
anti-tipwheels,twocasterwheels,twobatteries,andwiringharnesses.
SEATBACK
ARMRESTS
CONTROLLER
(REMOTE PLUS SHOWN)
BODYSHROUD
ANTI-TIP WHEELS
DRIVE WHEEL
CASTER WHEEL
Figure 5.The Quantum Jazzy 1420
POWERBASE
ASSEMBLY
SEAT ASSEMBLY
JOYSTICK
FOOTRIGGING
(SWING-AWAY
FOOTRESTS
SHOWN)
SEATBASE
III. YOUR POWER CHAIR

14 www.quantumrehab.com QuantumJazzy1420
SPECIFICATIONS
Suspension: Active-TracSuspensionwithRearSuspension
DriveWheels: 16in.,pneumatic,center-mounted(solidtiresareoptional)
CasterWheels: 9in.,pneumatic,reararticulating(solidtiresareoptional)
Anti-tipWheels: 8in.,solid,frontmounted
MaximumSpeed:¹ Upto4.5mph(upto6mphwithhigh-speedmotors)
Brakes: “IntelligentBraking,”electronicregenerative,discparkbrake
GroundClearance:² 4.5in.
TurningRadius:² 22.5in.
OverallSize:² Length:45.5in.
Width:26.75in.
SeatingOptions: SynergySeat
TRU-BalancePowerPositioningSystems
Medium-BackSeat
High-BackSeat
RecliningSeat
PowerElevatingSeat
Drivetrain: Twomotor, mid-wheeldrive
Batteries:³ Two12-volt,Group24batteries
Two12-volt,NF-22batteries(PowerElevatingSeatOption)
Range:¹ Up to 25 miles
BatteryCharger: 8-amp,Off-board(standard)
5-amponboard/8-ampoff-boardcombo
Electronics: 70-ampPGRemotePlusController
70-ampMicrodriveController
WeightCapacity: 500lbs.(425lbs.withhigh-speedmotors/400lbs.withTRU-Balance)
ComponentWeights: Base:136lbs.
Seat: 44 lbs.
Batteries:53.5lbs.each
¹Varieswithuserweight, terraintype, batteryamp hourrating (AH),battery charge,battery condition,and tirecondition.
²Duetomanufacturing tolerancesandcontinued productimprovement,this specification canbe subject tovarianceof(+ or–)3%.
³AGMorGel-Celltyperecommended.
NOTE: All specifications subject to change without notice.
III. YOUR POWER CHAIR

15
QuantumJazzy1420 www.quantumrehab.com
III. YOUR POWER CHAIR
BATTERY
REAR SEAT TOWER
LOCATION (TOWER NOT
SHOWN)
REAR SEAT TOWER
LOCATION (TOWER NOT
SHOWN)
ELECTRONICSTRAY
FRONT SEAT TOWER
LOCATION (TOWER NOT
SHOWN)
Figure 6.The Quantum Jazzy 1420 Power Base (Shroud Removed)
FREEWHEELLEVER
MAINCIRCUIT
BREAKER
AMMETER CONTROLLERCONNECTOR
(REMOTEPLUSSHOWN)
CHARGERPOWERCORD
Figure 7.The Quantum Jazzy 1420 ElectronicsTray (Onboard Charging System Shown)
POWERMODULE
ONBOARD BATTERY
CHARGER (UNDERNEATH
ELECTRONICS TRAY) FRONT SEAT TOWER
LOCATION (TOWER NOT
SHOWN)
SPARE
FUSES CHARGERFUSE

16 www.quantumrehab.com QuantumJazzy1420
Electronics Tray
Theelectronicstrayislocated onthebackofthepowerbase.Seefigures6and7.Theammeter,thechargerpowercord,themain
circuitbreaker,thecontrollerconnector,andthechargerfusearealllocatedontheelectronicstray.
Ammeter(onboardchargingsystemshownonly):Theammeterdisplaysthecharger’scurrentoutputinamps.SeeVI.“Batteries
andCharging.”
ChargerPowerCord(onboardchargingsystemonly):Connectstheonboardchargertoanelectricaloutletforbatterycharging.
Main Circuit Breaker: The main circuit breaker is a safety feature built into your power chair. When the batteries and the
motorsare heavilystrained (e.g.,from excessiveloads), themain circuitbreaker tripsto preventdamage tothe motorsand the
electronics.Ifthecircuittrips,allowyourpowerchairto“rest”forapproximatelyoneminute.Next,pushinthecircuitbreaker
reset button, turn on the controller, and continue normal operation. If the main circuit breaker continues to trip repeatedly,
contactyourQuantumRehabSpecialist.
ControllerConnector:Thisiswherethecontrollerconnectstothepowerbase.
ChargerFuse(onboardchargingsystemonly):Thechargerfuseprotectstheammeterfromcurrentoverload.Therearethree
fusesontheelectronicstray.Thetoponeisthechargerfuse.Thebottomtwoarespares.
Lighting System Connector(Not Shown): This is where the lighting system connects to the power base. Standard lighting
systems have a single pin connector. Full lighting systems use a 3-pin connector.
Active-Trac Suspension
TheQuantumJazzy1420isequippedwithActive-TracSuspension(ATS). ATSisasystemdesignedtomakethe powerchairtraverse
differenttypesofterrainandobstacleswhilemaintainingsmoothoperation.WithATS,thefrontanti-tipwheelsworkinconjunctionwith
themotorsuspensiontohelpyoumaneuveroverobstaclesinexcessoftwoinchesinheight.
Asthefrontanti-tipwheelscomeincontactwithanobstacle,thefrontanti-tipwheelassemblyisdrawnupward. Atthesametime,the
motorsareforceddownward.Thisallowsthemotorstopushthepowerchairoveranobstaclewithoutthepossibilityofbecoming“hung
up.”
ATSalsohelpsinday-to-dayoperatingconditions.Forinstance,whenyoureleasethejoystick,thepowerchairbeginstoslowdown.
Asthechairslowsdown,thefrontanti-tipwheelswillautomaticallydroptowardtheground. Thiswillreducetheforwardtipthatis
typicallyencounteredwithmid-wheeldrivechairs.
III. YOUR POWER CHAIR

17
QuantumJazzy1420 www.quantumrehab.com
Manual Freewheel Lever
Foryourconvenience,yourpowerchairisequippedwithamanualfreewheellever.Seefigures8and9.Thisleverallowsyouto
disengagethedrivemotorsandmaneuverthechairmanually.
WARNING! Do not use your power chair while the drive motors are disengaged unless you are in
the presence of an attendant! Do not disengage the drive motors when your power chair is on an
incline. The chair could roll down on its own, causing injury!
WARNING! It is important to remember that when your power chair is in freewheel mode, the
braking system is disengaged.
Tooperatethemanualfreewheellever:
1. Pullthemanualfreewheelleveroutandrotateclockwiseforfreewheelmode(drivedisengaged.)Seefigure8.
2. Rotatethemanualfreewheellevercounterclockwisefordrivemode(drivemotorsengaged.)Seefigure9.
3. Iftheleverisdifficulttomoveineitherdirection,slightlyrockthepowerchairbackandforth.Thelevershouldthenmovetothe
desiredposition.
III. YOUR POWER CHAIR
Figure 8. Freewheel Mode (Drive Disengaged) Figure 9. Drive Mode (Drive Engaged)
MANUAL
FREEWHEELLEVER MANUAL
FREEWHEELLEVER

18 www.quantumrehab.com QuantumJazzy1420
IV. ASSEMBLY/DISASSEMBLY
INITIAL ASSEMBLY
Yourpowerchairmayrequiresomeassembly eitherbeforeinitialuseoraftertransportation.Itmayalsorequiredisassem-
blytomakesome comfortadjustments.
NOTE: Any nylon insert lock nut removed during the disassembly or adjustment of the power chair must be replaced
witha new nut. Nylon insert lock nuts should notbereusedasitmay cause damage to the nylon insert, resultinginaless
secure fit. Replacement nylon insert lock nuts are available at local hardware stores or through your Quantum Rehab
Specialist.
Seat Installation
Itmaybenecessarytoinstallthe seat eitherpriortoinitialoperationor after transportingyourpowerchair.Most seatsare
attachedtothepowerbasewiththeUniversalMountingSystem(UMS).TheUMSconsistsofuniversalpartsthatmaybe
attachedto any medium-back or high-back seat, regardlessof seat width orseat depth. The twomain components are
aluminumextrusions mountedto theseat base.These extrusionsattach to a pair oftrapeze barsthat aremounted tothe
powerbase. See figure 10. If your power chair is equipped with a Synergy Seat or a TRU-Balance Power Positioning
System,refertotheinformationprovided in separatemanuals.
WARNING! Do not pick up the seat frame by the armrests. They are free to pivot, and you may
lose control of the seat if they do so, resulting in personal injury or damage to the chair.
Figure 10. Seat Installation
REARTRAPEZEBAR
FRONT TRAPEZE BAR
SEAT LATCH SAFETY
REAR EXTRUSION
FRONT EXTRUSION

19
QuantumJazzy1420 www.quantumrehab.com
IV. ASSEMBLY/DISASSEMBLY
To install the seat:
1. Setthe trapeze barsto the desired height.Tochangethe trapeze bar
height,seeV.“ComfortAdjustments.”
2. Tilttheseatbackand slidetherearextrusionontothe rear trapezebar.
Seefigure10.
3. Lowerthe frontextrusion ontothe fronttrapeze bar untiltheseat
locksintoplace.
4. Flipthe seatlatchsafety down.
WARNING! Make sure the seat latch safety is flipped
down before using your power chair.
Power elevating Seat Installation (Optional)
Yourpowerchairmaybeequippedwiththepowerelevatingseatoption.Whilethe
seatitselfmaybeanyoneofthestylesofferedforthismodel,thewaytheseatbase
attachestothepowerchairpowerbaseisdifferent.
To install the power seat:
l. Aligntheseatbaseshafttotheholeintheactuator.Seefigure11.
2. Inserttheseatshaftintotheactuatorandpushtheseatleverforwardtolock
theseatintoplace.
3. Plug the power elevating seat switch cable into the connector on the
electronicstray.
Controller Installation
Dependingonthevariousconfigurationsandoptionsyouhavechosenforyour
powerchair,itmayhavebeenshippedwithoutthecontrollermoduleinstalledinthe
armrest.
WARNING! Do not place the controller cable so that
it can be pinched in the seat frame or power base
frame.
1. Flipupeithertherightorleftarmrest.
2. Onacontourseat,flipupthearmrestandloosenthesetscrew.Seefigure12. On
thestandardseat,loosenthesetscrewsinthemountingblock.Seefigure19.
3. Slidethecontrollerintothearmrest.
4. Tightenthesetscrew(s)andlowerthearmrest.
5. Routethecontrollercablesothatitcannotbepinchedintheseathinge.
6. Removetherearlidtoexposetheelectronicstray.
7. Plugthecontrollerconnectorintotheelectronicstray.Seefigure7=.
8. Securethecontrollercabletothearmrestreceiverwithoneormorewireties.
Figure 11.Power Elevating Seat
Actuator
Figure 12. Controller Installation
(UndersideofArmrest)
SETSCREW

20 www.quantumrehab.com QuantumJazzy1420
COMFORT ADJUSTMENTS
Afterbecomingfamiliarwithyourpowerchair’soperation,youmayfindtheneedtomakesomeadjustmentstoincreaseyour
comfort,suchasseatheightandangle,armrestangle,foot platformheightandangle,andcontrollerposition.Ifyourpower
chairis equippedwith aSynergy Seat orTRU-Balance PowerPositioning System,refer totheinformation providedin
separatemanuals.Ifyourpowerchairisequippedwithamedium-back,ahigh-back,orarecliningseat,refertothefollowing
information.
WARNING! If your power chair was configured at your Quantum Rehab Specialist, please consult
your healthcare professional before changing the seat position or making any other adjustment.
Some adjustments may degrade power chair performance and safety by changing the center of
gravity.
Youmayneedthefollowingtomakecomfortadjustments:
!metric/standardhexkeyset
!metric/standardsocketsetandratchet
!adjustablewrench
Seat Height andAngle Adjustment
Theseat isattached to thepower base through the UMS.You
can change the seat height by raising the front and rear seat
towers. If you raise or lower only one set of towers (front or
rear),you canalso changethe seat base angle (dump).
To change the seat height:
1. Turn offthepower to thecontroller.SeeVII.“Operation.”
2. Unplugthecontrollerconnector(s)fromtheelectronicstray.
3. Flipup the seat latch safety.See figure13.
4. Squeezethe seat latch and releasethe seat from the front
trapezebar.
5. Slidethe seatforwardand removeitfrom thepowerbase.
6. Removethe quick-release pinsfromtheseat towers (front
andrear). See figure14.
7. Removeboth trapezebars from theseat towers.
8. Liftofftheshroud
9. Removethe ball detentpinfromeach ofthefourseat tow-
ers.See figure 14.
10. Movethe seat towersup or down tothe desired height.
11. Reinstalltheballdetent pinintoeachseat tower.
12. Reinstalltheshroud.
13. Reinstall the trapeze bars and secure with the quick-re-
leasepins.
14. Reinstalltheseat.
NOTE: Make sure the seat latch safety is flipped down
before using the power chair seat.
15. Plugthecontrollerconnector(s)into theelectronicstray.
Figure 13. Seat Latch Safety (Disengaged)
Figure 14. Seat Height Adjustment
QUICK-RELEASE
PIN
TRAPEZEBARS
BALL DETENT PINS
SEAT TOWER
V. COMFORT ADJUSTMENTS
