Pride JAZZY GO 2 User manual

JAZZY GO 2
32 Wedgwood Road • Bicester, Oxon OX26 4UL

SAFETY GUIDELINES
Copyright©2008
PrideMobilityProductsLtd.
INFMANU3738/RevA/April2008
AuthorisedPride Dealer:_____________________________________________________________
Address:__________________________________________________________________________
PhoneNumber:_____________________________________________________________________
PurchaseDate:______________________________________________________________________
NOTE: This owner’s manual is compiled from the latest specifications and product information avail-
able at the time of publication. We reserve the right to make changes as they become necessary. Any
changes to our products may cause slight variations between the illustrations and explanations in
this manual and the product you have purchased. The latest/current version of this manual is available
on our website.
WARNING! An authorised Pride Dealer or a qualified technician must perform the initial
setup of this power chair and must perform all of the procedures in this manual.
The symbols below are used throughout this owner's manual and on the power chair to identify warnings and
importantinformation.Itisvery importantforyou toreadthem andunderstandthem completely.
WARNING! Indicates a potentially hazardous condition/situation. Failure to follow designated
procedures can cause either personal injury, component damage or malfunction. On the
product, this icon is represented as a black symbol on a yellow triangle with a black border.
MANDATORY! These actions should be performed as specified.Failure to perform mandatory
actions can cause personal injury and/or equipment damage. On the product, this icon is
represented as a white symbol on a blue dot with a white border.
PROHIBITED! These actions are prohibited. These actions should not be performed at any
time or in any circumstances. Performing a prohibited action can cause personal injury
and/or equipment damage. On the product, this icon is represented as a black symbol with
a red circle and red slash.
Quick Reference Information
088 609 661

Jazzy Go 2 www.pridemobility.com 3
I. INTRODUCTION....................................................................................................................................4
II. SAFETY ....................................................................................................................................................5
III. YOUR POWER CHAIR.......................................................................................................................17
IV. ASSEMBLY............................................................................................................................................20
V. COMFORT ADJUSTMENTS...........................................................................................................22
VI. BATTERIES AND CHARGING .......................................................................................................26
VII. CARE AND MAINTENANCE ...........................................................................................................30
VIII.WARRANTY...........................................................................................................................................35
CONTENTS
IX. APPENDIX I - SPECIFICATIONS .................................................................................................36

4 www.pridemobility.com Jazzy Go 2
I. INTRODUCTION
SAFETY
WELCOME to Pride Mobility Products Ltd. (Pride). The power chair you have purchased combines state-of-the-art
componentswithsafety,comfortandstylinginmind.Weareconfidentthatthesedesignfeatureswillprovideyouwith the
conveniencesyouexpectduring yourdailyactivities.Onceyou understandhowtosafelyoperateandcare foryourpower
chair, it shouldgiveyouyears oftrouble-freeoperationand service.
Ifthere is any information in thismanual which you do not understand, or if you requireadditional assistance for setup
or operation, please contact your authorised Pride Dealer. Failure to follow the instructions in this manual and
thoselocatedon yourpowerchaircanlead topersonal injuryand/ordamageto thepowerchair,andmayvoid
thewarranty.
PURCHASER’S AGREEMENT
Byaccepting delivery of this product,you promise thatyou will notchange, alter ormodify this product orremove or
renderinoperable orunsafeany guards,shieldsor othersafetyfeaturesofthisproduct;fail, refuseorneglect toinstallany
retrofitkitsfromtimetotime provided by Pride to enhance or preserve the safe use of this product.
SHIPPING AND DELIVERY
Beforeusing yourpowerchair,makesureyourdelivery iscompleteas somecomponentsmaybe individuallypackaged.
Ifyoudonotreceiveacomplete delivery, please contact your authorised Pride Dealer immediately.Where damage has
occurredduringtransport, either tothepackagingorcontent, please contact thedeliverycompanyresponsible.
INFORMATION EXCHANGE
Wewanttohearyourquestions,comments andsuggestionsaboutthismanual.Wewouldalsoliketohearaboutthesafety
andreliability of yournewpowerchair,andabouttheserviceyou receivedfromyourauthorisedPride Dealer.
Please notify us of any change of address, so we can keep you apprised of important information about safety, new
productsand newoptionsthatcan increaseyourability touseandenjoy yourpowerchair.Pleasefeel freetocontactus at
theaddressbelow:
PrideMobility ProductsLtd.
32 Wedgwood Road
Bicester, Oxon OX26 4UL
NOTE: If you ever lose or misplace your product registration card or your copy of this manual, contact us and
we will be glad to send you a new one immediately.
Readand followallinstructions,warningsandnotesin thismanualbefore attemptingtooperate yourpowerchair forthe
firsttime.Youmustalsoreadallinstructions,warnings andnotescontainedinanysupplementalinstructional bookletsfor
thecontroller,frontriggingsand/orseatingsystemthataccompaniedyourpowerchairbeforeinitialoperation.Your safety
dependsuponyou, as wellasyourprovider, carer orhealthcareprofessionalinusing good judgement.

Jazzy Go 2 www.pridemobility.com 5
II. SAFETY
Read and follow the information in the owner’s manual.
Do not allow unsupervised children to play near the power chair while the batteries are
charging.
Keep your hands away from the tyres when driving. Be aware that loose fitting clothing
can become caught in drive tyres.
Use correct tie-down points for controller harness to prevent the harness from getting
caught in the drive tyres, pinched in the seat frame, or damaged when passing through
doorways.
Avoid exposure to rain, snow, ice, salt or standing water whenever possible. Maintain
and store in a clean and dry condition.
PRODUCT SAFETY SYMBOLS
Thesymbols belowareusedon thepowerchairto identifywarnings,mandatory actionsandprohibitedactions. Itisvery
importantfor you toreadandunderstand themcompletely.
Maximum seating weight.
Do not use a cell phone, walkie/talkie, laptop or other radio transmitter while operating.

6 www.pridemobility.com Jazzy Go 2
II. SAFETY
Do not lift the mobility vehicle while seated in it.
Do not lift the mobility vehicle while seated in it.
Wear safety goggles.
Corrosive chemicals contained in battery.
Contains Lead.
Removal of grounding prong can create electrical hazard. If necessary, properly
install an approved 3-pronged adapter to an electrical outlet having 2-pronged
plug access.
Do not connect an extension lead to the AC/DC converter or the battery charger.

Jazzy Go 2 www.pridemobility.com 7
II. SAFETY
EMI-RFI - This product has been tested and passed at an immunity level of 20 V/m.
Explosive conditions exist!
Use only AGM or Gel-Cell batteries to reduce the risk of leakage or explosive
conditions.
Keep tools and other metal objects away from battery terminals.
Battery Set Configuration:
++
++
+ = Positive (Red) Terminal Post
- = Negative (Black) Terminal Post
Connect Red wire to Red Positive (+) Terminal
Post
Connect Black wire to Black Negative (–)
Terminal Post
Do not use batteries with different amp-hour (Ah) capacities. Do not mix old and
new batteries. Always replace both batteries at the same time.
Do not remove anti-tip wheels.

8 www.pridemobility.com Jazzy Go 2
Battery charger for indoor use only.
Do not place power chair in freewheel mode on a decline.
Do not place power chair in freewheel mode on an incline.
II. SAFETY
Disposal and recycling - Contact your authorised Pride Dealer for information on
proper disposal and recycling of your Pride product and its packaging.
Place unit on level ground and stand to one side when changing from
drive mode to freewheel mode or freewheel mode to drive mode.
Unlocked and in freewheel mode.
Locked and in drive mode.
Pinch/Crush point.

Jazzy Go 2 www.pridemobility.com 9
II. SAFETY
GENERAL GUIDELINES
MANDATORY! Do not operate your new power chair for the first time without completely reading
and understanding this owner’s manual.
Your powerchairis astate-of-the-artlife-enhancement devicedesignedto increasemobility.Prideprovidesan extensive
varietyof products to bestfit theindividual needsof thepower chairuser.Please beaware thatthe finalselection and
purchasing decision regarding the type of power chair to be used is the responsibility of the power chair user, who is
capableof making suchadecision,and his/herhealthcareprofessional(i.e., medical doctor,physicaltherapist,etc.).
Thecontents of thismanualarebased ontheexpectationthat a mobilitydeviceexperthas properlyfittedthepower chair
totheuserandhasassistedtheprescribinghealthcareprofessionaland/ortheauthorisedPrideDealerintheinstruction
processfor the use of theproduct.
Therearecertainsituations,includingsomemedicalconditions,wherethepowerchairuserwillneedtopracticeoperating
the power chair in the presence of a trained attendant.Atrained attendant can be defined as a family member or care
professionalspeciallytrainedinassistingapowerchairuserinvariousdailylivingactivities.
Asyoubeginusingyourpowerchairduringdailyactivities, youwill probablyencountersituationsinwhichyouwillneed
somepractice. Simply takeyourtimeand you willsoonbein full andconfidentcontrolas you manoeuvrethroughdoor-
ways,onandoffoflifts,upanddownrampsandovermoderateterrain.
Belowaresomeprecautions,tipsandother safetyconsiderationsthatwillhelp youbecomeaccustomedtooperating your
powerchair safely.
Modifications
Pridehasdesignedandengineeredyourpowerchairtoprovidemaximummobilityandutility.Awiderangeofaccessories
areavailable from your authorised PrideDealer to furthercustomise your power chairto better suityour needs and/or
preferences.However,under nocircumstancesshould youmodify,add, removeordisable anyfeature,part orfunctionof
yourpower chair.
WARNING! Do not modify your power chair in any way not authorised by Pride. Do not use
accessories if they have not been tested or approved for Pride products.
Pre-Ride Safety Check
Gettoknowthefeelofyourpowerchairanditscapabilities.Priderecommendsthatyouperformasafetycheckbefore
eachusetomakesureyourpowerchairoperatessmoothlyandsafely.
Performthefollowinginspectionspriortousingyourpowerchair:
!Checkforpropertyreinflation.Maintainbutdonotexceed thepsi/bar/kPaairpressureratingindicatedon each tyre
forpneumatictyres.
!Checkallelectricalconnections. Make sure they are tight and not corroded.
!Checkallcontrollerconnections to the power base. Make sure they aresecured properly.
!Checkthe brakes. See VII. “Careand Maintenance.”
!Checkbatterycharge. See VI. “Batteries and Charging.”
NOTE: If you discover a problem, contact your authorised Pride Dealer for assistance.

10 www.pridemobility.com Jazzy Go 2
II. SAFETY
Weight Limitations
Yourpowerchairisratedfora maximumweightcapacity.Pleaserefertothe specificationstableforthis limit.
MANDATORY! Stay within the specified weight capacity of your power chair. Exceeding the weight
capacity voids your warranty. Pride will not be held responsible for injuries and/or property damage
resulting from failure to observe weight limitations.
WARNING! Do not carry passengers on your power chair. Carrying passengers on your power
chair may affect the centre of gravity, resulting in a tip or a fall.
Tyre Inflation
Ifyourpowerchairisequippedwith pneumatictyres,you shouldcheckorhavethe airpressurechecked regularly.Proper
inflationpressures willprolongthelife ofyourtyres andhelpensurethe smoothoperationof yourpowerchair.
WARNING! It is important that the psi/bar/kPa air pressure rating indicated on the tyre be maintained
in pneumatic tyres at all times. Do not underinflate or overinflate your tyres. Low pressure may
result in loss of control, and overinflated tyres may burst. Failure to maintain the psi/bar/kPa air
pressure rating indicated on the pneumatic tyres at all times may result in tyre and/or wheel failure.
WARNING! Inflate your power chair drive tyres from a regulated air source with an available
pressure gauge. Inflating your tyres from an unregulated air source could overinflate them, resulting
in a burst tyre.
Incline Information
Moreandmorebuildingshaverampswithspecifieddegreesofinclination,designedfor easyandsafeaccess.Someramps
mayhave turning switchbacks(180-degreeturns)thatrequire you tohavegoodcornering skills onyourpowerchair.
!Proceedwithextremecautionasyouapproach the downgrade of a ramp or other incline.
!Take wideswingswithyourpowerchair’sfrontwheels aroundanytightcorners.Ifyoudothat, thepowerchair’s rear
wheelswillfollow a widearc,notcutthecorner short andnotbumpintoor get hung uponanyrailingcorners.
!When driving down a ramp, keep the power chair’s speed adjustment set to the slowest speed setting to ensure a
safelycontrolleddescent.
!Avoid sudden stopsand starts.
Whenclimbinganincline,trytokeepyourpowerchairmoving.Ifyoumuststop,startupagain slowlyandthenaccelerate
cautiously.When driving down an incline, set your power chair to the slowest speed setting and drive in the forward
directiononly. Ifyourpowerchair starts tomovedownthe inclinefasterthanyou anticipatedordesired,allow it tocome
toa complete stop byreleasingthejoystick, then pushthejoystickforwardslightly to ensureasafelycontrolleddescent.
WARNING! When on any sort of an incline or decline, never place the power chair in
freewheel mode while seated on it or standing next to it.
WARNING! When climbing an incline, do not zigzag or drive at an angle up the face of
the incline. Drive your power chair straight up the incline. This greatly reduces the
possibility of a tip or a fall. Always exercise extreme caution when negotiating an
incline.
WARNING! You should not travel up or down a potentially hazardous incline (i.e., areas
covered with snow, ice, cut grass or wet leaves).
WARNING! If your power chair is equipped with a reclining seatback, do not attempt
to negotiate inclines with the seat in a reclined position. Do not attempt to negotiate
obstacles with the seat in a reclined position unless an attendant is present to help
stabilise the chair. Failure to heed could result in the power chair tipping over.
NOTE: If the tyres on your power chair list the psi rating only, use the following conversion formulas to
find the bar or kPa rating: bar = psi x 0.06895; kPa = psi x 6.89476.

Jazzy Go 2 www.pridemobility.com 11
II. SAFETY
Figure 1. Maximum Safe Incline/Decline Angles
WARNING! Even though your power chair is capable of climbing slopes greater than those illustrated
in figure 1, do not, under any circumstances, exceed the incline guidelines or any other
specifications presented in this manual. Doing so could cause instability in your power chair.
Priderecommendsthat the maximum slope of an inclineyou attempt to safely ascendor descend on your power chair
does not exceed 8.7% (5 °). See figure 1.
WARNING! Any attempt to climb or descend a slope steeper than 8.7% (5 °) may put your power
chair in an unstable position and cause it to tip.
Freewheel Mode
Yourpowerchairisequippedwithtwomanualfreewheelleverstoallowformanualmanoeuvreabilitybyatrainedattendant.
Formoreinformationabouthowto placeyourpowerchairintoandoutoffreewheelmode,see III.“YourPowerChair.”
WARNING! Do not use your power chair in freewheel mode without an attendant present.
WARNING! Do not attempt to personally place your power chair in freewheel mode
while seated on it. Ask an attendant for assistance if necessary.
WARNING! Do not place your power chair in freewheel mode while on an incline or
decline. This could cause the chair to roll uncontrollably on its own.
Braking Information
Yourpowerchairis equipped withtwopowerfulbrakesystems:
!Regenerative— useselectricitytorapidly slow thevehiclewhen the joystickreturnstothe centre/stopposition.
!DiscPark Brake — activatesmechanicallyafterregenerativebraking slows thevehicletonearstop, or whenpower
isremoved from the systemforanyreason.
Cornering Information
Whileyourpowerchairisequippedwithfrontandrearcastorwheels,excessivelyhighcorneringspeedscanstillcreatethe
possibilityoftipping.Factorswhichaffectthepossibilityoftippinginclude,butarenotlimitedto:corneringspeed,steering
angle(howsharplyyouareturning),unevenroadsurfaces,inclinedroadsurfaces,ridingfromanareaoflowtractiontoan
areaofhightraction(suchaspassingfromagrassyareatoapavedarea—especiallyathighspeedwhileturning)andabrupt
directionalchanges.Highcorneringspeedsarenotrecommended.Ifyoufeelthatyoumaytipoverinacorner,reduceyour
speedandsteeringangle(i.e.,lessenthesharpnessoftheturn)topreventyourpowerchairfromtipping.
WARNING! When cornering sharply, reduce your speed and maintain a stable centre of gravity.
This greatly reduces the possibility of a tip or fall.
WARNING! Never travel down an incline rearward. Doing so may cause the power chair to tip.
Always exercise extreme caution when negotiating an incline.

12 www.pridemobility.com Jazzy Go 2
II. SAFETY
Figure 2. Correct Kerb Approach Figure 3. Incorrect Kerb Approach
Public Streets and Roadways
WARNING! You should not operate your power chair on public streets and roadways. Be aware
that it may be difficult for traffic to see you when you are seated on your power chair. Obey all
local pedestrian traffic rules. Wait until your path is clear of traffic, and then proceed with
extreme caution.
Outdoor Driving Surfaces
Yourpowerchairisdesignedtoprovideoptimumstabilityundernormaldrivingconditions—dry,levelsurfacescomposed
ofconcrete,blacktoportarmac.However,Priderecognisesthattherewillbetimeswhen youwillencounter othersurface
types.Forthisreason, yourpowerchairisdesigned toperformadmirablyonpacked soil,grassandgravel.Feel freetouse
yourpowerchairsafelyonlawnsand in park areas.
!Reduceyourpower chair’sspeedwhendrivingonuneven terrain and/or softsurfaces.
!Avoidtallgrassthatcan entangletherunninggear.
!Avoid looselypackedgravelandsand.
!Ifyou feelunsureabouta drivingsurface,avoidthat surface.
Inclement Weather Precautions
Exposureof yourpowerchairto inclementweatherconditionsshould be avoidedwheneverpossible. If suddenlycaught
up in rain, snow, severe cold or heat while operating your power chair, proceed to shelter at the earliest opportunity.
Thoroughlydry yourpowerchairbefore storing,chargingoroperatingyourpower chair.
PROHIBITED! Operating in rain, snow, salt, mist/spray conditions and on icy/slippery surfaces can
have an adverse affect on the electrical system. Maintain and store your power chair in a dry and
clean condition.
WARNING! Prolonged exposure to hot or cold conditions may affect the temperature of upholstered
and non-upholstered items on the power chair, possibly resulting in skin irritation. Exercise caution
when using the power chair in extremely hot or cold conditions or when exposing your power
chair to direct sunlight for prolonged periods of time.
Stationary Obstacles (Steps, Kerbs, etc.)
Proceedwithextreme caution when driving near raised surfaces, unprotectedledges and/or drop-offs (kerbs, porches,
stairs,etc.). Besureyourpowerchairistravelingperpendiculartoanykerb youmaybe requiredtonavigate. Seefigure2.
WARNING! Do not attempt to have your power chair climb or descend an obstacle that is higher
than 2.5 cm (1 in.) unless you have the assistance of an attendant.
WARNING! Do not attempt to have your power chair proceed rearward down any step, kerb or
other obstacle. This may cause the power chair to tip.
KERB
KERB

Jazzy Go 2 www.pridemobility.com 13
Stairs and Escalators
Powerchairsarenotdesignedtotravelupor down stairs or escalators.Always usea lift.
WARNING! Never use your power chair to negotiate steps or escalators.
Doors
!Determineifthedooropens toward or away from you.
!Driveyour powerchairgently andslowlyforward topushthedooropen,ordriveyourpowerchairgentlyandslowly
rearwardto pull the door open.
Lifts
Modernliftshave a door edgesafetymechanismthat,whenpushed, reopens the liftdoor(s).
!Ifyouareinthe doorway of a lift when the door(s) begin toclose, push on the rubber door edge or allowthe rubber
dooredge to contact the powerchair and the doorwill reopen.
!Usecarethathandbags, packages or power chair accessories donot become caught in lift doors.
Lift/Elevation Products
Ifyouwillbetravelingwithyour powerchair,youmay finditnecessarytouse alift/elevationproducttoaidintransporta-
tion.Priderecommends that you closely reviewthe instructions, specifications and safetyinformation set forth bythe
manufacturerofthelift/elevation productbeforeusingthatproduct.
WARNING! Never sit on your power chair when it is being used in connection with any
type of lift/elevation product. Your power chair was not designed with such use in
mind and any damage or injury incurred from such use is not the responsibility of
Pride.
Motor Vehicle Transport
Priderecommends thatyoudonot remainseatedinyour powerchairwhiletraveling inamotor vehicle. Thepowerchair
shouldbe stowed in the bootof a caror in theback of atruck or van withbatteries removed andproperly secured.
WARNING! Do not sit on your power chair while it is in a moving vehicle.
WARNING! Always be sure your power chair and its batteries are properly secured when it is being
transported. Batteries should be secured in an upright position and protective caps should be
installed on the battery terminals. Batteries should not be transported with any flammable or
combustible items.
Positioning Belts
YourauthorisedPrideDealer, therapist(s)andotherhealthcareprofessionalsareresponsiblefordetermining yourrequire-
mentforapositioningbeltinordertooperateyourpower chairsafely.Typically,thepositioningbeltisnotdesignedforuse
asa restrainingdevicein amotorvehicle.
Positioningbeltsshouldbeinstalled as detailed in this manual. SeeV. “ComfortAdjustments.”Once installed, the belt
shouldbeplacedacross the pelvis as determined by the user’s healthcaredealer.Anchor points of the positioningbelts
shouldbe located so thata projectedside-view angleof the pelvisis between30°–75° ofhorizontal depending onthe
user’sweight,posture and seatcushionthickness.
WARNING! If you require a positioning belt to safely operate your power chair, make sure it is
fastened securely in order to reduce the possibility of a fall from the power chair.
WARNING! The positioning belt is not designed for use as a seat belt in a motor vehicle.
II. SAFETY

14 www.pridemobility.com Jazzy Go 2
Batteries
In addition to following the warnings below, be sure to comply with all other battery handling information. For more
informationabout your powerchair’sbatteries,see VI. “BatteriesandCharging.”
MANDATORY! Battery posts, terminals and related accessories contain lead and lead
compounds. Wear goggles and gloves when handling batteries and wash hands after
handling.
WARNING! Power chair batteries are heavy. See specifications table. If you are unable
to lift that much weight, be sure to get help. Use proper lifting techniques and avoid
lifting beyond your capacity.
WARNING! Always protect the batteries from freezing and never charge a frozen battery.
Charging a frozen battery may result in damage to the battery.
Removable Parts
WARNING! Do not attempt to lift or move a power chair by any of its removable parts, including
the armrests, seat, front riggings, controller and shrouds.
Preventing Unintended Movement
WARNING! If you anticipate being seated in a stationary position for an extended period of time,
turn off the power. This will prevent unexpected motion from inadvertent joystick contact. This
will also eliminate the possibility of unintended chair movement from electromagnetic (EM) sources.
Reaching and Bending
Neverreach, lean orbendwhiledrivingyour power chair. If itisabsolutelynecessary to reach,leanorbendwhile seated
onyour power chair,it is important to maintaina stable centreof gravity andkeep the powerchair fromtipping. Pride
recommendsthatthe power chair user determine his/herpersonal limitations and practicebending and reaching in the
presenceofaqualifiedhealthcareprofessional.
II. SAFETY
WARNING! Do not bend, lean or reach for objects if you have to pick them up from
the floor by reaching down between your knees or if you have to reach over the
back of the seat. Movements such as these may change your centre of gravity and
the weight distribution of the power chair. This may cause your power chair to tip.
WARNING! Keep your hands away from the tyres when driving. Be aware that loose
fitting clothing can become caught in drive tyres.
WARNING! Connect the battery harnesses in the proper manner. RED (+) cables must
be connected to positive (+) battery terminals/posts. BLACK (-) cables must be
connected to negative (-) battery terminals/posts. Protective caps should be installed
over all battery terminals. REPLACE cables immediately if damaged.

Jazzy Go 2 www.pridemobility.com 15
II. SAFETY
Figure 4.IdealTransfer Position
Transfers
Transferring onto and off of your power chair requires a good
senseofbalance.Alwayshaveanattendantorhealthcare profes-
sionalpresentwhilelearningtoproperlytransferyourself.
To eliminatethepossibilityof injury,Priderecommendsthat you
ora trainedattendantperform thefollowingtasks beforeattempt-
ingatransfer:
!Turnoffthepowertothecontroller.
!Ensure your power chair is not in freewheel mode. See III.
“YourPowerChair.”
!Turn the castor wheels toward the transfer destination to
improvepowerchairstabilityduringtransfer.
!Makesurebotharmrestsareflipped uporremovedfromyour
powerchair.
!Flipupthe foot platformormovetheleg rests aside;thiswill
helptokeepyourfeetfrom gettingcaughtonthefrontrigging
duringthetransfer.
!Reducethe distancebetweenyour powerchairand theobject
youare transferringonto.
WARNING! Before transferring, position yourself as far back as possible in the power chair seat
to prevent the power chair from tipping forward during transfer.
WARNING! Avoid putting all of your weight on the power chair armrests and do not use the armrests
for weight bearing purposes, such as transfers. Such use may cause the power chair to tip, resulting
in a fall from the power chair and personal injury.
WARNING! Avoid putting all of your weight on the front riggings. Such use may cause the power
chair to tip.
Prescription Drugs/Physical Limitations
Usersmustexercisecareandcommon sensewhenoperatingapowerchair.Thisincludesawareness ofsafetyissueswhen
takingprescribed orover-the-counterdrugsor whentheuserhas specificphysicallimitations.
WARNING! Consult your physician if you are taking prescribed or over-the-counter medication or
if you have certain physical limitations. Some medications and limitations may impair your ability
to operate your power chair in a safe manner.

16 www.pridemobility.com Jazzy Go 2
II. SAFETY
WARNING! Pride strongly recommends that you do not smoke cigarettes while seated in your
power chair, although the power chair has passed the necessary testing requirements for cigarette
smoking. You must adhere to the following safety guidelines if you decide to smoke cigarettes
while seated in your power chair.
!Do not leave lit cigarettes unattended.
!Keep ashtrays a safe distance from the seat cushions.
!Always make sure cigarettes are completely extinguished before disposal.
Electromagnetic and Radio Frequency Interference (EMI/RFI)
WARNING! Laboratory tests have shown that electromagnetic and radio frequency waves can
have an adverse affect on the performance of electrically-powered mobility vehicles.
Electromagneticand Radio FrequencyInterference can comefrom sourcessuch ascellular phones,mobile two-way
radios(suchas walkie-talkies), radio stations, TV stations,amateurradio(HAM)transmitters,wirelesscomputer links,
microwavesignals,pagingtransmittersandmedium-rangemobiletransceiversusedbyemergencyvehicles.Insomecases,
thesewavescancauseunintendedmovementordamagetothecontrolsystem.Everyelectrically-poweredmobilityvehicle
hasanimmunity(orresistance)toEMI.Thehighertheimmunitylevel,thegreatertheprotectionagainstEMI.Thisproduct
hasbeentestedand has passed at an immunity level of 20 V/m.
WARNING! Be aware that cell phones, two-way radios, laptops and other types of radio transmitters
may cause unintended movement of your electrically-powered mobility vehicle due to EMI.
Exercise caution when using any of these items while operating your mobility vehicle and avoid
coming into close proximity of radio and TV stations.
WARNING! The addition of accessories or components to the electrically-powered mobility vehicle
can increase the susceptibility of the vehicle to EMI. Do not modify your power chair in any way
not authorised by Pride.
WARNING! The electrically-powered mobility vehicle itself can disturb the performance of other
electrical devices located nearby, such as alarm systems.
NOTE: For further information on EMI/RFI, go to the Resource Centre on www.pridemobility.com. If
unintended motion or brake release occurs, turn your power chair off as soon as it is safe to do so. Contact
Pride to report the incident.
Alcohol/Smoking
Thepowerchairusermustexercisecare andcommonsense whenoperatinghis/her powerchair.Thisincludesawareness
ofsafetyissueswhileundertheinfluenceofalcoholorwhilesmoking.
WARNING! Do not operate your power chair while you are under the influence of alcohol, as this
may impair your ability to operate your power chair in a safe manner.

Jazzy Go 2 www.pridemobility.com 17
III. YOUR POWER CHAIR
THE JAZZY GO 2
TheJazzy Go2hastwomainassemblies:theseatassemblyandthepowerbaseassembly.Seefigure 5.Typically,theseat
assemblyincludes the armrests, seatbackand seat base.The powerbase assembly includesthe two motors,two drive
wheels,twocastorwheels,twoanti-tipwheels,twobatteriesandafootplatform. See figures 5 and 6.
SEATBACK
Figure 5.The Jazzy Go 2
JOYSTICK
ARMRESTS
DRIVEWHEEL
POWERBASE
ASSEMBLY
FREEWHEEL
LEVERS
SEAT ASSEMBLY
FRONTRIGGING
(FOOT PLATFORM SHOWN)
SEATBASE
CONTROLLER
CASTOR
WHEEL

18 www.pridemobility.com Jazzy Go 2
III. YOUR POWER CHAIR
Electrical Components
Theelectrical componentsarelocated onthepower base.Themaincircuitbreakerislocated towardtherear ofthepower
base.The controller and charger connectors arelocated on therear of the powerbase. See figure 6.
ControllerConnector:Thisiswhere the controller connects tothepowerbase.Eachcontroller uses a different typeof
cable.Regardlessofwhichtypeofcontrollerisused, the cable must be secured to the seat assembly and not allowed to
dragonthe floor.
Off-boardChargerPortConnector:Thisiswherethepowermoduleconnects to the off-board charger port which is
mountedunderneaththecontroller.
MainCircuitBreaker:Themaincircuitbreakerisasafety featurebuiltintoyourpowerchair.Whenthebatteries andthe
motorsareheavilystrained (e.g.,fromexcessiveloads),themaincircuit breakertripstopreventdamagetothe motorsand
theelectronics.Ifthecircuittrips,allow yourpowerchairto“rest”forapproximatelyone minute.Next,pushinthecircuit
breakerbutton,turn on the controller andcontinuenormaloperation.Ifthe main circuit breaker continuestotriprepeat-
edly,contact an authorised PrideDealer.
Figure 6.The Jazzy Go 2 Power Base
CIRCUIT
BREAKER
SEAT PEDESTAL
CONTROLLER CONNECTOR
FREEWHEEL
LEVERS
BATTERY COVER
OFF-BOARD
CHARGERPORT
CONNECTOR

Jazzy Go 2 www.pridemobility.com 19
DRIVE MODE
FREEWHEEL
MODE
DRIVE MODE
FREEWHEEL
MODE
Manual Freewheel Levers
Thepower chairhasamanual freewheelleveron eachmotor. Manualfreewheellevers enableyoutodisengage thedrive
motorsinordertopushthechair.
NOTE: You must turn off the power before disabling the drive systems, otherwise you may get an error code on
the controller. To clear this code, turn off the controller and place the power chair in drive mode. Then turn on
the controller. The error message should be cleared. If not, contact an authorised Pride Dealer.
To engage or disengage the drive system:
1. Locate the levers on therear section ofthe power base. Seefigure 7.
2. Push the two levers forward to engagethedrivemotors(drivemode).Seefigure7
3. Pull the twoleversrearwardtodisengagethe drive motors (freewheel mode).Seefigure7.
Anti-Tip Wheels
Theanti-tipwheelsareanintegralandimportantsafetyfeature ofyourpowerchair.Theyareboltedtotheframeatthe rear
ofthe power base. Seefigure 7.
III. YOUR POWER CHAIR
Figure 7.Back of Power Base
ANTI-TIP WHEELS
MANUAL
FREEWHEEL
LEVERS
WARNING! Do not use the freewheel lever handles as tie-down points to secure this product.
PROHIBITED! Do not, under any circumstances, remove the anti-tip wheels from your power chair.
WARNING! It is important to remember that when your power chair is in freewheel
mode, the braking system is disengaged.
WARNING! Do not use the power chair while the drive motors are disengaged! Do not
disengage the drive motors when the power chair is on an incline, as the unit could
roll on its own. Only engage the freewheel mode when on a level surface.

20 www.pridemobility.com Jazzy Go 2
INITIAL ASSEMBLY
Yourpowerchairmayrequiresomeassemblyeitherbeforeinitialuseoraftertransportation.Itmayalsorequiredisassembly
tomakesomecomfortadjustments.Figure8detailsthosepartsofthepowerchairthataredesignedtobedisassembledand
assembledbyanenduserorbyaqualifiedcarerbeforeusingtheproductormakingcomfortadjustments. There aretwohex
keysprovided forusewithcontrollerinstallationandadjustment,andfootplatformadjustment.
NOTE: Any nylon insert lock nut removed during the disassembly or adjustment of the power chair must be
replaced with a new nut. Nylon insert lock nuts should not be reused as it may cause damage to the nylon
insert, resulting in a less secure fit. Replacement nylon insert lock nuts are available at local hardware stores
or through your authorised Pride Dealer.
IV. ASSEMBLY
SEAT INSTALLATION
ARMREST WIDTH ADJUSTMENT
Figure 8.Jazzy Go 2 AssemblyView
FOOT PLATFORM
DEPTH ADJUSTMENT
BATTERIES
CONTROLLER
POSITION
SEATHEIGHT
ADJUSTMENT
BATTERY COVER
