Pride 1103 Ultra User manual

JAZZY
How a Power Chair should FEEL!™
Including Model: Jazzy 1103 Ultra
1-800-800-8586 (US) 1-888-570-1113 (Canada)
SERIES

SAFETY GUIDELINES
Copyright©2007
PrideMobilityProductsCorp.
INFMANU2429/RevD/June2007
AuthorizedPrideProvider:___________________________________________________________________
Address:_______________________________________________________________________________
PhoneNumber:__________________________________________________________________________
PurchaseDate:___________________________________________________________________________
NOTE: This owner’s manual is compiled from the latest specifications and product information available
at the time of publication. We reserve the right to make changes as they become necessary. Any changes to
our products may cause slight variations between the illustrations and explanations in this manual and the
product you have purchased. The latest/current version of this manual is available on our website.
WARNING! An authorized Pride Provider or a qualified technician must perform the initial setup
of this power chair and must perform all of the procedures in this manual.
Thesymbolsbelowareusedthroughoutthisowner's manual andonthepowerchair to identifywarningsandimportant
information.Itisvery importantforyou toreadthem andunderstandthemcompletely.
WARNING! Indicates a potentially hazardous condition/situation. Failure to follow designated
procedures can cause either personal injury, component damage, or malfunction. On the product,
this icon is represented as a black symbol on a yellow triangle with a black border.
MANDATORY! These actions should be performed as specified. Failure to perform mandatory
actions can cause personal injury and/or equipment damage. On the product, this icon is
represented as a white symbol on a blue dot with a white border.
PROHIBITED! These actions are prohibited. These actions should not be performed at any time
or in any circumstances. Performing a prohibited action can cause personal injury and/or equipment
damage. On the product, this icon is represented as a black symbol with a red circle and red
slash.
Quick Reference Information
088 609 661

Jazzy 1103 Ultra www.pridemobility.com 3
I. INTRODUCTION....................................................................................................................................4
II. SAFETY ....................................................................................................................................................6
III. YOUR POWER CHAIR.......................................................................................................................18
IV. ASSEMBLY............................................................................................................................................23
V. COMFORT ADJUSTMENTS...........................................................................................................25
VI. BATTERIES AND CHARGING .......................................................................................................35
VII. CARE AND MAINTENANCE ...........................................................................................................39
VIII.WARRANTY...........................................................................................................................................45
CONTENTS

4 www.pridemobility.com Jazzy 1103 Ultra
I. INTRODUCTION
SAFETY
WELCOMEtoPrideMobility Products Corporation (Pride). The power chair youhave purchased combines state-of-
the-artcomponentswithsafety, comfort,and stylingin mind.Weareconfidentthatthesedesignfeatureswillprovideyou
withtheconveniencesyouexpectduringyourdailyactivities.Once you understand how to safely operateand care for
yourpower chair, it shouldgiveyouyears of troublefreeoperationandservice.
Readand followallinstructions,warnings,andnotesinthismanual beforeattempting tooperateyourpowerchairforthe
first time. Inaddition, your safetydependsupon you, as well asyour provider,caretaker, or healthcare professional in
usinggoodjudgement.
Ifthereisanyinformationin this manual which you do not understand, or if yourequire additional assistance for setup
or operation, please contact your authorized Pride Provider. Failure tofollow the instructionsin this manualand
those located on your powerchair can lead to personal injury and/or damage to the powerchair, including
voidingthewarranty.
PURCHASER’S AGREEMENT
Byacceptingdelivery of this product, you promisethat you will notchange, alter,ormodify this product or remove or
renderinoperableor unsafeanyguards,shields,orothersafetyfeaturesofthisproduct;fail,refuse, orneglecttoinstallany
retrofitkits from time to time provided by Pride to enhance or preserve the safe useofthisproduct.
SHIPPING AND DELIVERY
Beforeusing yourpowerchair,makesureyourdelivery iscompleteas somecomponentsmaybe individuallypackaged.
Ifyoudonot receiveacomplete delivery,pleasecontactyourauthorized PrideProviderimmediately.Wheredamagehas
occurredduring transport, eithertothepackaging or content, pleasecontactthedelivery company responsible.
INFORMATION EXCHANGE
Wewanttohearyourquestions,comments,andsuggestionsaboutthismanual.Wewouldalsoliketohearaboutthesafety
andreliability ofyournewpower chair, andaboutthe service youreceivedfromyour authorizedPrideProvider.
Please notify us of any change of address, so we can keep you apprised of important information about safety, new
products,and new options that can increase your abilitytouseandenjoyyourpower chair.Pleasefeelfreetocontact us
attheaddressbelow:
USA: Canada:
PrideMobilityProductsCorporation PrideMobilityProductsCompany
Attn.:Customer CareDepartment 380VansickleRoad Unit 350
182SusquehannaAvenue St.Catharines,OntarioL2R 6P7
Exeter, PA18643-2694 1-888-570-1113
[e-mail]
800-424-8205
NOTE: If you ever lose or misplace your product registration card or your copy of this manual, contact us and
we will be glad to send you a new one immediately.

Jazzy 1103 Ultra www.pridemobility.com 5
I. INTRODUCTION
PRIDE OWNERS CLUB
As an owner of a Pride product, you are encouraged to enroll in the Pride Owners Club. Complete and return your
enclosedproduct registrationcardor visitPride’sweb siteatwww.pridemobility.com.
Fromour homepage,select“Owners Club”toentera page dedicatedtocurrent and potentialPrideproduct owners.You
willgainaccessto interviews,stories,recreation ideas,dailyliving tips,productand fundinginformation,and interactive
messageboards. Thesemessageboards inviteyoutocommunicate withotherPride customers aswellas Priderepresen-
tativeswho are availabletoassist you withanyquestionsor concerns youmayhave.

6 www.pridemobility.com Jazzy 1103 Ultra
II. SAFETY
PRODUCT SAFETY SYMBOLS
Thesymbolsbeloware usedon thepowerchairtoidentify warnings,mandatoryactions,andprohibited actions.Itisvery
importantfor youtoread and understandthemcompletely.
Corrosive chemicals contained in battery. Use only AGM or Gel-Cell batteries to reduce
the risk of leakage or explosive conditions.
Do not lift the mobility vehicle while seated in it.
Do not lift the mobility vehicle while seated in it.
Explosive conditions exist!
Do not place power chair in freewheel mode on a decline.
Do not place power chair in freewheel mode on an incline.
Pinch/Crush points created during assembly.

Jazzy 1103 Ultra www.pridemobility.com 7
II. SAFETY
Read and follow the information in the owner’s manual.
Maximum seating weight.
Locked and in drive mode.
Place unit on level ground and stand behind or to one side when changing from drive
mode to freewheel mode or freewheel mode to drive mode.
Unlocked and in freewheel mode.
Use correct tie-down points for controller harness to prevent the harness from getting
caught in the drive tires or pinched in the seat frame.
Wear safety goggles.
Use only AGM or Gel-Cell batteries to reduce the risk of leakage or explosive conditions.

8 www.pridemobility.com Jazzy 1103 Ultra
II. SAFETY
Do not allow unsupervised children to play near the power chair while the batteries are
charging.
Keep your hands away from the tires when driving. Be aware that loose fitting clothing
can become caught in drive tires.
Avoid exposure to rain, snow, ice, salt, or standing water whenever possible. Maintain
and store in a clean and dry condition.
Do not use a cell phone, walkie/talkie, laptop, or other radio transmitter while operating.
Do not connect an extension cord to the AC/DC converter or the battery charger.
Removal of grounding prong can create electrical hazard. If necessary, properly install
an approved 3-pronged adapter to an electrical outlet having 2-pronged plug access.
Keep tools and other metal objects away from battery terminals.

Jazzy 1103 Ultra www.pridemobility.com 9
II. SAFETY
Do not use batteries with different amp-hour (Ah) capacities. Do not mix old and new
batteries. Always replace both batteries at the same time.
Do not remove anti-tip wheels.
Battery charger for indoor use only.
Disposal and recycling - Contact your authorized Pride Provider for information on proper
disposal and recycling of your Pride product and its packaging.
This product has been tested and passed at an immunity level of 20 V/m.
Contains Lead.
Disposal and recycling - Contact your authorized Pride Provider for information on proper
disposal and recycling of your Pride product and its packaging.

Battery Set Configuration:
++
++
+ = Positive (Red) Terminal Post
- = Negative (Black) Terminal Post
Connect Red wire to Red Positive (+) Terminal Post
Connect Black wire to Black Negative (–) Terminal Post

10 www.pridemobility.com Jazzy 1103 Ultra
II. SAFETY
GENERAL GUIDELINES
MANDATORY! Do not operate your new power chair for the first time without completely reading
and understanding this owner’s manual.
Your powerchairisastate-of-the-artlife-enhancement devicedesignedtoincreasemobility. Prideprovidesan extensive
varietyof products to bestfit the individual needsof the power chairuser. Please beaware thatthe final selection and
purchasing decision regarding the type of power chair to be used is the responsibility of the power chair user, who is
capableof makingsucha decision, andhis/herhealthcare professional (i.e.,medicaldoctor,physical therapist,etc.).
Thecontents ofthismanual are basedonthe expectationthatamobility deviceexperthasproperly fittedthepower chair
tothe userandhas assistedtheprescribing healthcareprofessionaland/orthe authorizedPrideProvider intheinstruction
processfor the use of theproduct.
Therearecertainsituations,includingsomemedicalconditions, wherethepowerchairuserwillneedtopracticeoperating
the power chair in the presence of a trained attendant.Atrained attendant can be defined as a family member or care
professionalspeciallytrainedinassistingapowerchairuserinvariousdailylivingactivities.
Asyoubeginusingyourpowerchairduringdailyactivities, youwillprobablyencountersituationsinwhichyouwill need
somepractice.Simplytakeyourtimeandyouwillsoonbeinfullandconfidentcontrolasyoumaneuverthroughdoorways,
onandoffofelevators, up and down ramps, and over moderate terrain.
Belowaresome precautions,tips,andothersafetyconsiderationsthatwillhelp youbecomeaccustomedtooperatingyour
powerchairsafely.
Modifications
Pridehasdesignedandengineeredyourpowerchairtoprovidemaximummobilityandutility.Awiderangeofaccessories
isavailablefromyourauthorized Pride Provider to further customize your power chairto better suit your needsand/or
preferences.However, under nocircumstancesshouldyou modify,add,remove,or disable anyfeature,part,or function
ofyour power chair.
WARNING! Do not modify your power chair in any way not authorized by Pride. Do not use
accessories if they have not been tested or approved for Pride products.
Pre-Ride Safety Check
Gettoknowthefeelofyourpowerchairanditscapabilities.Priderecommendsthatyouperformasafetycheckbefore
eachuse to make sure your power chair operates smoothly and safely.
Performthe following inspections prior to using your power chair:
!Checkforpropertireinflation.Maintainbutdonotexceed35psi(2.4bar)ineachtireifequippedwithpneumatictires.
!Checkall electrical connections. Make sure they are tight andnotcorroded.
!Checkallcontrollerconnections to the power base. Make sure they aresecured properly.
!Checkthe brakes. See VII. “Careand Maintenance.”
!Checkbattery charge. See VI. “Batteries andCharging.”
NOTE: If you discover a problem, contact your authorized Pride Provider for assistance.

Jazzy 1103 Ultra www.pridemobility.com 11
II. SAFETY
Weight Limitations
Yourpowerchairis ratedfora maximumweightcapacity.Pleaserefertothespecifications tableforthis limit.
MANDATORY! Stay within the specified weight capacity of your power chair. Exceeding the weight
capacity voids your warranty. Pride will not be held responsible for injuries and/or property damage
resulting from failure to observe weight limitations.
WARNING! Do not carry passengers on your power chair. Carrying passengers on your power
chair may affect the center of gravity, resulting in a tip or a fall.
Tire Inflation
Ifyourpowerchair isequippedwith pneumatictires,you shouldcheckor havetheair pressurecheckedregularly.Proper
inflationpressureswillprolong thelifeof yourtiresand helpensurethe smoothoperationof yourpowerchair.
WARNING! It is important that 35 psi (2.4 bar) tire pressure be maintained in pneumatic tires at all
times. Do not underinflate or overinflate your tires. Low pressure may result in loss of control, and
overinflated tires may burst. Failure to maintain 35 psi (2.4 bar) tire pressure in pneumatic tires at
all times may result in tire and/or wheel failure.
WARNING! Inflate your power chair drive tires from a regulated air source with an available pressure
gauge. Inflating your tires from an unregulated air source could overinflate them, resulting in a
burst tire.
Incline Information
Moreandmorebuildingshaverampswithspecifieddegreesofinclination,designedforeasyandsafeaccess.Someramps
mayhave turning switchbacks(180-degreeturns) that requireyoutohave good corneringskillsonyour power chair.
!Proceedwith extreme caution as you approach the downgrade of a ramp or other incline.
!Takewideswingswithyourpowerchair’s frontwheels aroundany tightcorners.Ifyoudothat,the powerchair’srear
wheelswill follow awidearc,notcut the cornershort,andnotbump into orgethungupon any railingcorners.
!When driving down a ramp, keep the power chair’s speed adjustment set to the slowest speed setting to ensure a
safelycontrolleddescent.
!Avoid sudden stops andstarts.
Whenclimbinganincline,trytokeepyourpowerchairmoving.Ifyoumuststop,startupagainslowlyandthenaccelerate
cautiously. When driving down an incline, set your power chair to the slowest speed setting and drive in the forward
directiononly.If yourpowerchair startstomovedown theinclinefaster thanyouanticipatedor desired,allowit to come
toa complete stopbyreleasing the joystick, thenpushthe joystick forwardslightlytoensure a safelycontrolleddescent.
WARNING! When on any sort of an incline or decline, never place the power chair in
freewheel mode while seated on it or standing next to it.
WARNING! When climbing an incline, do not zigzag or drive at an angle up the face of the
incline. Drive your power chair straight up the incline. This greatly reduces the possibility
of a tip or a fall. Always exercise extreme caution when negotiating an incline.
WARNING! You should not travel up or down a potentially hazardous incline (i.e., areas
covered with snow, ice, cut grass, or wet leaves).
WARNING! Never travel down an incline backward. Doing so may cause the power chair
to tip. Always exercise extreme caution when negotiating an incline.

12 www.pridemobility.com Jazzy 1103 Ultra
II. SAFETY
WARNING! If your power chair is equipped with a reclining seatback, do not attempt to negotiate
inclines with the seat in a reclined position. Do not attempt to negotiate obstacles with the seat
in a reclined position unless an attendant is present to help stabilize the chair. Failure to heed
could result in the power chair tipping over.
WARNING! Even though your power chair is capable of climbing slopes greater than those illustrated
in figure 1, do not, under any circumstances, exceed the incline guidelines or any other
specifications presented in this manual. Doing so could cause instability in your power chair.
Incompliance with theAmericanswithDisabilitiesActof 1990, all handicappublicaccessramps are required tohavea
maximumslope of 5° (8.7%).Therefore,Priderecommendsthat the maximum slopeofaninclineyou attempt to safely
ascend or descend on your power chair does not exceed 5° (8.7%). See figure 1.
WARNING! Any attempt to climb or descend a slope steeper than 5° (8.7%) may put your power
chair in an unstable position and cause it to tip.
Figure 1. Maximum Safe Slope (Ascending and Descending)
5 (8.7%)
Freewheel Mode
Yourpowerchairisequippedwithtwomanualfreewheelleverstoallowformanualmaneuverabilitybyatrainedattendant.
Formore information abouthowto place your powerchairinto and outoffreewheelmode, see III.“YourPowerChair.”
WARNING! Do not use your power chair in freewheel mode without an attendant present.
WARNING! Do not attempt to personally place your power chair in freewheel mode while
seated on it. Ask an attendant for assistance if necessary.
WARNING! Do not place your power chair in freewheel mode while on an incline or decline.
This could cause the chair to roll uncontrollably on its own.
Braking Information
Yourpowerchairisequipped with twopowerfulbrakesystems:
!Regenerative— useselectricityto rapidlyslowthevehicle whenthejoystick returnstothecenter/stop position.
!DiscParkBrake—activatesmechanicallyafterregenerativebrakingslowsthevehicle tonear stop,orwhenpoweris
removedfrom thesystemforany reason.
Cornering Information
Whileyourpowerchairisequippedwithfrontandrearcasterwheels,excessivelyhighcorneringspeedscanstillcreatethe
possibilityoftipping.Factorswhichaffectthepossibilityoftippinginclude,butarenotlimitedto:corneringspeed,steering
angle(howsharply youare turning),uneven roadsurfaces,inclinedroadsurfaces,ridingfromanareaoflowtractiontoan
areaof high traction (suchas passingfrom a grassy area toa paved area – especiallyat high speed while turning),and
abruptdirectional changes. High cornering speeds arenot recommended.If you feelthat youmay tipover in acorner,
reduceyour speed and steering angle(i.e.,lessenthesharpness of the turn) topreventyourpowerchair from tipping.
WARNING! When cornering sharply, reduce your speed and maintain a stable center of gravity.
This greatly reduces the possibility of a tip or fall.

Jazzy 1103 Ultra www.pridemobility.com 13
II. SAFETY
Public Streets and Roadways
WARNING! You should not operate your power chair on public streets and roadways. Be aware
that it may be difficult for traffic to see you when you are seated on your power chair. Obey all
local pedestrian traffic rules. Wait until your path is clear of traffic, and then proceed with extreme
caution.
Outdoor Driving Surfaces
Yourpowerchairisdesignedtoprovideoptimumstabilityundernormaldrivingconditions—dry,levelsurfacescomposed
ofconcrete,blacktop,orasphalt.However,Priderecognizes thattherewillbetimeswhenyou willencounterothersurface
types.Forthisreason,yourpowerchairisdesignedtoperformadmirablyonpackedsoil,grass,andgravel.Feelfreeto
useyourpowerchairsafelyonlawnsandinparkareas.
!Reduceyour power chair’s speed whendrivingonuneven terrain and/or softsurfaces.
!Avoid tallgrass thatcan entangletherunninggear.
!Avoidloosely packedgravelandsand.
!Ifyou feelunsureabout adrivingsurface, avoidthatsurface.
Inclement Weather Precautions
Exposureof yourpowerchair toinclementweather conditions shouldbeavoided wheneverpossible.If suddenly caught
up in rain, snow, severe cold or heat while operating your power chair, proceed to shelter at the earliest opportunity.
Thoroughlydry yourpowerchair beforestoring,charging,oroperating yourpowerchair.
PROHIBITED! Operating in rain, snow, salt, mist/spray conditions, and on icy/slippery surfaces
can have an adverse affect on the electrical system. Maintain and store your power chair in a dry
and clean condition.
WARNING! Prolonged exposure to hot or cold conditions may affect the temperature of upholstered
and non-upholstered items on the power chair, possibly resulting in skin irritation. Exercise caution
when using the power chair in extremely hot or cold conditions or when exposing your power
chair to direct sunlight for prolonged periods of time.
Stationary Obstacles (Steps, Curbs, etc.)
Proceedwithextreme caution when driving near raised surfaces, unprotectedledges and/or drop-offs (curbs,porches,
stairs,etc.).Besureyourpower chairistravelingperpendicularto anycurbyoumaybe requiredto navigate.Seefigure2.
WARNING! Do not attempt to have your power chair climb or descend an obstacle that is higher
than 2 in. (5 cm) unless you have the assistance of an attendant.
WARNING! Do not attempt to have your power chair proceed backward down any step, curb, or
other obstacle. This may cause the power chair to tip.
Figure 2. Correct Curb Approach Figure 3. Incorrect Curb Approach

14 www.pridemobility.com Jazzy 1103 Ultra
II. SAFETY
Stairs and Escalators
Powerchairsarenotdesigned to travel up or down stairs or escalators.Alwaysuse an elevator.
WARNING! Never use your power chair to negotiate steps or escalators.
Doors
!Determineif the door opens toward or away from you.
!Driveyourpowerchairgentlyandslowlyforwardtopushthedooropen.Ordriveyourpowerchairgentlyandslowly
backwardto pull the dooropen.
Elevators
Modernelevators have a door edge safety mechanism that, when pushed, reopens the elevator door(s).
!Ifyou are in the doorway ofan elevator whenthe door(s)begin to close,push on therubber dooredge or allowthe
rubberdoor edge to contact thepower chairand thedoor willreopen.
!Usecare that pocketbooks, packages,or powerchair accessoriesdo notbecomecaught in elevator doors.
Lift/Elevation Products
Ifyouwillbetravelingwithyourpower chair,youmay findit necessarytousealift/elevationproducttoaidin transporta-
tion.Priderecommendsthatyou closely review the instructions, specifications, and safety information set forthby the
manufacturerofthelift/elevationproductbeforeusingthatproduct.
WARNING! Never sit on your power chair when it is being used in connection with any
type of lift/elevation product. Your power chair was not designed with such use in mind
and any damage or injury incurred from such use is not the responsibility of Pride.
Motor Vehicle Transport
Priderecommends thatyoudo notremainseated inyourpower chairwhiletraveling in amotorvehicle. Thepowerchair
shouldbestowed in the trunk ofa car orin the backof a truckor van withbatteries removedand properly secured.
WARNING! Do not sit on your power chair while it is in a moving vehicle.
WARNING! Always be sure your power chair and its batteries are properly secured when it is being
transported. Batteries should be secured in an upright position and protective caps should be
installed on the battery terminals. Batteries should not be transported with any flammable or
combustible items.
Positioning Belts
Your authorized Pride Provider, therapist(s), and other healthcare professionals are responsible for determining your
requirementfor a positioning beltin orderto operateyour powerchair safely.
WARNING! If you require a positioning belt to safely operate your power chair, make sure it is
fastened securely in order to reduce the possibility of a fall from the power chair.
WARNING! The positioning belt is not designed for use as a seat belt in a motor vehicle. Nor is
your power chair suitable for use as a seat in any vehicle. Anyone traveling in a vehicle should be
properly belted into seats approved by the vehicle manufacturer.

Jazzy 1103 Ultra www.pridemobility.com 15
Batteries
In addition to following the warnings below, be sure to comply with all other battery handling information. For more
informationabout yourpowerchair’sbatteries,seeVI.“Batteries andCharging.”
MANDATORY! Battery posts, terminals, and related accessories contain lead and lead
compounds. Wear goggles and gloves when handling batteries and wash hands after
handling.
WARNING! Power chair batteries are heavy. See specifications table. If you are unable to
lift that much weight, be sure to get help. Use proper lifting techniques and avoid lifting
beyond your capacity.
WARNING! Always protect the batteries from freezing and never charge a frozen battery.
Charging a frozen battery may result in damage to the battery.
WARNING! Connect the battery harnesses in the proper manner. RED (+) cables must be
connected to positive (+) battery terminals/posts. BLACK (-) cables must be connected to
negative (-) battery terminals/posts. Protective caps should be installed over all battery
terminals. REPLACE cables immediately if damaged.
Removable Parts
WARNING! Do not attempt to lift or move a power chair by any of its removable parts, including
the armrests, seat, foot riggings, controller, and shrouds.
Preventing Unintended Movement
WARNING! If you anticipate being seated in a stationary position for an extended period of time,
turn off the power. This will prevent unexpected motion from inadvertent joystick contact. This
will also eliminate the possibility of unintended chair movement from electromagnetic (EM) sources.
Reaching and Bending
Neverreach,lean,orbendwhile drivingyourpowerchair.Ifitis absolutelynecessarytoreach,lean, orbend whileseated
onyour power chair, itis important tomaintain astable centerof gravityand keepthe powerchair fromtipping. Pride
recommendsthatthe power chair user determine his/her personallimitations and practicebending and reachingin the
presenceofaqualifiedhealthcareprofessional.
WARNING! Do not bend, lean, or reach for objects if you have to pick them up from the
floor by reaching down between your knees or if you have to reach over the back of the
seat. Movements such as these may change your center of gravity and the weight
distribution of the power chair. This may cause your power chair to tip.
WARNING! Keep your hands away from the tires when driving. Be aware that loose fitting
clothing can become caught in drive tires.
II. SAFETY

16 www.pridemobility.com Jazzy 1103 Ultra
II. SAFETY
Figure 4.IdealTransfer Position
Transfers
Transferring onto and off of your power chair requires a
goodsenseof balance.Alwayshaveanattendantorhealth-
careprofessionalpresentwhilelearningtoproperlytransfer
yourself.
Toeliminatethepossibilityofinjury,Priderecommendsthat
youor a trained attendant perform the following tasks be-
foreattemptingatransfer:
!Turnoffthepower to thecontroller.
!Ensureyourpowerchairisnot infreewheelmode.See
III.“YourPowerChair.”
!Turnthecasterwheelstowardthetransferdestination
toimprovepower chairstability duringtransfer.
!Make sure both armrests are flipped up or removed
fromyour powerchair.
!Flip up the foot platform or move the leg rests aside;
thiswill help to keep your feet from getting caught on
thefootriggingduringthetransfer.
!Reducethedistancebetween yourpowerchairandthe
objectyou are transferringonto.
WARNING! Before transferring, position yourself as far back as possible in the power chair seat
to prevent the power chair from tipping forward during transfer.
WARNING! Avoid putting all of your weight on the power chair armrests and do not use the armrests
for weight bearing purposes, such as transfers. Such use may cause the power chair to tip, resulting
in a fall from the power chair.
WARNING! Avoid putting all of your weight on the foot riggings. Such use may cause the power
chair to tip.
Prescription Drugs/Physical Limitations
Usersmustexercise careand commonsense whenoperatingapowerchair.Thisincludesawarenessofsafety issueswhen
takingprescribed orover-the-counterdrugs orwhenthe userhasspecific physicallimitations.
WARNING! Consult your physician if you are taking prescribed or over-the-counter medication or
if you have certain physical limitations. Some medications and limitations may impair your ability
to operate your power chair in a safe manner.
Alcohol/Smoking
Thepowerchairusermustexercise careandcommonsensewhenoperatinghis/her powerchair.This includesawareness
ofsafetyissueswhileundertheinfluenceofalcoholorwhilesmoking.
WARNING! Do not operate your power chair while you are under the influence of alcohol, as this
may impair your ability to operate your power chair in a safe manner.

Jazzy 1103 Ultra www.pridemobility.com 17
II. SAFETY
WARNING! Pride strongly recommends that you do not smoke cigarettes while seated in your
power chair, although the power chair has passed the necessary testing requirements for cigarette
smoking. You must adhere to the following safety guidelines if you decide to smoke cigarettes
while seated in your power chair.
!Do not leave lit cigarettes unattended.
!Keep ashtrays a safe distance from the seat cushions.
!Always make sure cigarettes are completely extinguished before disposal.
Electromagnetic and Radio Frequency Interference (EMI/RFI)
WARNING! Laboratory tests have shown that electromagnetic and radio frequency waves can
have an adverse affect on the performance of electrically-powered mobility vehicles.
Electromagneticand Radio FrequencyInterference cancome from sources suchas cellularphones, mobile two-way
radios(such as walkie-talkies), radio stations,TVstations,amateurradio(HAM) transmitters, wireless computer links,
microwavesignals,pagingtransmitters, and medium-range mobile transceivers used by emergencyvehicles. In some
cases,thesewavescancauseunintendedmovementordamageto thecontrolsystem.Everyelectrically-poweredmobility
vehiclehasanimmunity(orresistance)toEMI.Thehighertheimmunitylevel,thegreatertheprotectionagainstEMI.This
producthas been tested and has passed at an immunity level of 20 V/m.
WARNING! Be aware that cell phones, two-way radios, laptops, and other types of radio transmitters
may cause unintended movement of your electrically-powered mobility vehicle due to EMI.
Exercise caution when using any of these items while operating your mobility vehicle and avoid
coming into close proximity of radio and TV stations.
WARNING! The addition of accessories or components to the electrically-powered mobility vehicle
can increase the susceptibility of the vehicle to EMI. Do not modify your power chair in any way
not authorized by Pride.
WARNING! The electrically-powered mobility vehicle itself can disturb the performance of other
electrical devices located nearby, such as alarm systems.
NOTE: For further information on EMI/RFI, go to the Resource Center on www.pridemobility.com. If
unintended motion or brake release occurs, turn your power chair off as soon as it is safe to do so. Call Pride
at 800-424-8205 to report the incident.

18 www.pridemobility.com Jazzy 1103 Ultra
III. YOUR POWER CHAIR
THE JAZZY 1103 ULTRA
The Jazzy 1103 Ultra has two main assemblies: the seat and the power base. See figures 5 and 6. Typically, the seat
assemblyincludesthearmrests, seatback,andseat base.Thepower baseassemblyincludes twomotor/brakeassemblies,
twodrive wheels, two anti-tip wheels,twocasterwheels,twobatteries, and the electrical components.
SEATBACK
CONTROLLER
(VSI SHOWN)
REAR
SHROUD
ANTI-TIP WHEEL
DRIVEWHEEL
CASTER WHEEL
Figure 5.The Jazzy 1103 Ultra
JOYSTICK
FOOT PLATFORM
SEATBASE
ARMRESTS
FRICTION LOCK LEVER
SEATBACK
RELEASELEVER
SEAT ASSEMBLY
POWERBASE
ASSEMBLY

Jazzy 1103 Ultra www.pridemobility.com 19
JAZZY 1103ULTRASPECIFICATIONS
Suspension: ActiveTrac
DriveWheels: 10in.(25.4cm)pneumaticorsolidavailable
CasterWheels: 8in.(20.32cm)solid,rear-mounted
Anti-tipWheels: 5in.(12.7cm)solid,front-mounted
MaximumSpeed:¹ Upto4mph(6.43km/h)
Range:¹ Up to 25 miles(40km)
Brakes: “IntelligentBraking”electronicregenerative,discparkbrake
GroundClearance:² 2.5in.(6.35cm)
TurningRadius:² 20.75in.(52.7cm)
OverallSize:² Length:35.5in.(90.17cm)
Width:23in.(58.42cm)
Drivetrain: Twomotor, mid-wheeldrive
Batteries:³ Two12-volt,deep-cycle,U-1batteries
BatteryCharger: 4-amp,onboard (standard)
Off-board (optional)
WeightCapacity: 300lbs.(136kg)
200lbs.(90.72kg)withTRU-BalancePowerPositioningSystems
160lbs.(72.57kg)withSynergyManualTilt
ComponentWeights: Base:104lbs.(47.17kg)
StandardSeat:37lbs.(16.78kg)
Batteries:24.5lbs.(11.11kg)each
III. YOUR POWER CHAIR
¹ Varieswith base model, user weight, terraintype, battery amp-hour rating(Ah), battery charge,batterycondition,
motors,controller type,tiretype,and tire condition.
² Duetomanufacturingtolerancesandcontinuedproductimprovement,thisspecificationcanbesubjecttovarianceof
(+ or – ) 3%.
³ AGMor Gel-Cell type required. SeeVI.“BatteriesandCharging.”
NOTE: All specifications subject to change without notice.

20 www.pridemobility.com Jazzy 1103 Ultra
III. YOUR POWER CHAIR
Figure 6. The Jazzy 1103 Ultra Power Base
MOTOR/BRAKEASSEMBLY
ARTICULATINGBEAM
POWER SEAT ACTUATOR
REARSHROUDFASTENERS
YELLOWFASTENER(LOCATED
UNDERFRONTSHROUD)
ELECTRICAL COMPONENTS
The electrical components are located on the power base. The ammeter and the charger power cord receptacle are
located on the right side of the power base. The main circuit breaker is located on the front of the battery tray. The
controllerconnectorand the motor connectors are locatedon the power pod,inside the powerbase. See figure7.
Ammeter:Theammeter displays thecharger’scurrentoutputin amps. SeeVI.“Batteries and Charging.”
ChargerPowerCordReceptacle:Thisiswherethechargerpower cordplugsintothe onboardbatterycharger.SeeVI.
“BatteriesandCharging.”
