1. ATTENTION!!!
Please read this instruction manual very carefully before you start using your Ironing table.
The customer by purchasing this product declares that he is fully aware, and accepts everything
mentioned in this operating manual.
Primula S.A. assumes neither responsibility for any errors herein, nor for incidental nor for resulting
damage in connection with the performance or use of this operating manual.
You may not copy, reproduce, or translate this operating manual, or parts of it, to another language
without prior written consent of Primula S.A.
Any information in this manual may be subject to change without any prior notice.
CAUTION! PLEASE READ CAREFULLY THE INSTRUCTION MANUAL BEFORE INSTALLING THE IRONING
TABLE!!!
1st edition –July 2017
© Primula S.A. 2017
Company name: Primula S.A
Address: 14th km Thessaloniki –Kilkis,
57200 Liti, Thessaloniki, Greece
Industry: Manufacturing of Ironing, Pressing and Finishing Equipment

Instruction Manual
4
Telephone: [phone]
Fax: [phone]
Web: www.primula.gr
E-mail: [email protected]
2. Technical Details
2.1 Identification Data
The Ironing Table, that you have purchased, is a machine of high advanced technology with many
advantages, unique in its kind. It is manufactured according to International and European safety
standards by a company with experience, since 1969, in this sector. Congratulations for your choice!
Regarding its characteristics, the Ironing Table includes a serial number plate (see below) where all its
specifications are displayed. Every warning and symbol that is placed on the Ironing Table is in
accordance with the specifications of the European standards.
The serial number plate has been placed in a visible place on the Ironing Table and is made from
fadeless material.
Amongst others, the Serial Number plate displays the following:
Company Logo
Manufacturer Information
Model
Serial Number
Rated Voltage of Use
Rated Frequency of Use
Year of manufacturing
Accumulated Installed Wattage
Picture 1: Serial Number Sign
2.2 Use of the Instruction Manual
The correct assembly and adjustment of the machine is vital to the safety of the user and the machine’s
life span. For this reason, the installation, alteration, replacement or extension of the ironing table
should only be performed by qualified personnel.
Under no circumstances is interventions allowed in the machine, unless it’s for the planned
maintenance by an unauthorized engineer.
If you remain uncertain regarding the correct assembly of the machine even after reading the
instructions, contact the manufacturer or an authorized representative before starting the operation of
the machine.

Instruction Manual
5
2.3 Technical Description
Ironing table with heating and suction and blowing.
This unique ironing table can transform itself within 3 minutes. You can have one ironing table with 2
switchable ironing surfaces.
It is ergonomic and runs very silently with a powerful suction and blowing system.
Suitable for workshops, ateliers and domestic use.
Available in models:
TAILOR - Heating and suction
TAILOR S+B - Heating suction and blowing
2.4 Technical Characteristics
Model
Tailor
Tailor S+B
Working surface (DOB)
Working surface (FL)
110x38cm
115x45cm
110x38cm
115x45cm
Height adjustment
85cm
85cm
Heating power
1kW
1kW
Suction power
0.27HP
0.27HP
Blowing power
NO
0.27HP
Power Supply
230V-1ph-50Hz
230V-1ph-50Hz
3. General rules and Warnings
3.1 General rules of using the Ironing Table
For the safe usage of your Ironing Table, please read the following operating instructions carefully, as
listed below:
Install, use and maintain the Ironing Table according to the instructions in this manual.
Otherwise, the manufacturer has no responsibility for the possible failed operation or safety.
Before connecting the power supply, check that the voltage corresponds to the voltage indicated
on the technical specifications.
Connect the machine only to a power supply that meets the minimum required frequency and is
properly grounded. Do not leave the Ironing Table while it is operating and is on power without
supervision.
Use the Ironing Table ONLY for the intended purpose in accordance with the current instruction
manual and only with the accessories that are provided or that are intended for this specific
Ironing Table. The manufacturer is not liable for any damages resulting from misuse or wrong
use of the Ironing Table.
DO NOT touch the power supply with wet hands.
Do not clean the Ironing Table with corrosive or other damaging materials/chemicals.
Never use the Ironing Table to support any other machine or structure.
It is strictly prohibited to do any kind of welding or alterations on the Ironing Table or its
parts.
It is strictly prohibited to remove any protective device/guards.
It is strictly prohibited to intervene in the control units/circuit boards of the Ironing Table.
It is strictly forbidden to do any modification to the technical specifications of the machine
(electrical or mechanical) by third persons.

Instruction Manual
6
Please contact your dealer or the manufacturer for any malfunction or further information
requests
3.2 Warning marks placed on the Ironing Table
The following attention marks are placed on each ironing table:
The operator of the system has the obligation to inform himself regarding the dangers which may occur
during usage, so that he/she can avoid them or minimize their occurrence as best as he/she is able to.
4. Electrical Connection
For the electrical connection and above all for the power supply, please follow carefully the instructions
of the wiring diagram (enclosed) as well the warning signs symbols attached on the machine. In case
you have purchased a single phase machine 230V, connect the machine to the power into the socket
230V/16A. The connection should be done with 3-phase 3Χ1,5 mm (1 phase, 1 neutral, 1 grounded). The
power should be provided with a fuse 10Α.
CAUTION! For your own safety, pay attention to all the warning labels (yellow colored) that are placed
on the machine. The manufacturer bears no liability for any damages or accidents due to faulty
supplying network or to not specified personnel.
5. Activation Instructions
For the instructions mentioned in the current section please see the below image (picture 2).
Picture 2: Switches placed on Tailor
Turn on the main switch No 01.
2
1
3

Instruction Manual
7
Whenever you want to use the suction just press the foot pedal.
Adjust the steam quantity of the steam generator in proportion to the suction performance of
the table, in order to avoid steam liquidation on the working surface. The refined fabrics require
small quantity of steam, while the gross fabrics require big quantity of steam.
The ironing buck’s heating is activated when you press switch No 02 to position I.
6. How to change the working surface from DOB to FL surface and vice versa.
For the instructions mentioned in the current section please see the below images (picture 3).
Image 1: Disconnect the plug No 04 Image 2: Knob No 05
Image 3: Place the surface into the holes No 06 Image 4: Connect the plug No 04
Picture 3: Images for explaining the change of the working surface from DOB to FL surface and vice
versa:
Disconnect the plug No 04 (image 1).
Unscrew the knob No 05 to the left (image 2).
Pick up slightly, pull out and remove the placed surface.
Place the new surface into the suitable holes No 06 (Image 3).
Screw the knob No 05 to the right (image 2).
Connect the plug No 04 (image 4).
7. Additional Instructions
In case the table disposes a Vario iron system (optional):
Hook the steam iron from the balancer and adjust the distance of the steam iron from the
working surface (approximately 5cm). After you have finished ironing, unhook the steam iron
from the balancer and put it on the iron rest mat.
In case your table disposes a blowing system of air:
Push with the foot pedal.
Pull up the lever No 03 (see the picture 2 on page 6).
Keep your foot on the pedal. Since you do not push the foot pedal, the function reverts to the
suction.
5
4
4
6

Instruction Manual
8
8. Maintenance
Make sure that the covers of the table and the ironing buck remain clean, in order to have high
performance of suction and blowing air. Wash periodically the blue polyester fabric and the
foam blue in the washing machine (30-40 οC). In case you use felt molletone instead of blue
foam, do not wash it in the washing machine, but wash it by hand. Replace them regularly, in
order to keep high suction and blowing performance.
Clean the dust of the fan wheel/impeller at least 2-3 times per year.
Clean periodically and grease the arm’s as well as the buck’s bearings.
Clean periodically the internal parts of the table as well as the electronic circuit by using
compressed air.
Keep the machine clean.
CAUTION!
Before doing maintenance work, please disconnect the machine from the electrical power supply.

Instruction Manual
9

Instruction Manual
10
TAILOR DOB, TAILOR FL- Spare parts list
Article nr.
Description
1
308-00-006
Switch ON-OFF 16A
2
302-22-054
Buck’s switch ON-OFF
3
192-38-003
Metallic Iron Rest
4
107-01-002
Silicon iron rest
5
304-01-036
Perforated plate F1
6
304-01-037
Wire mesh F1
7
304-01-038
Felt molletone F1
8
304-01-040
Fabric cover F1
9
302-38-009
Cable for heating element
10
306-03-011
4-pole safety plug
11
302-38-011
Safety thermostat 110°C
12
302-38-012
Thermostat 90°C
13
302-38-013
Heating element 800W 230V
14
192-38-014
192-38-014-1
Perforated plate for TAILOR DOB
Perforated plate for TAILOR FL
15
302-01-032
Cover’s rail
16
302-01-035
Spring with clips
17
302-26-015
302-38-017
Wire mesh for TAILOR DOB
Wire mesh for TAILOR FL
18
302-01-031
302-38-007
Felt molletone for TAILOR DOB
Felt molletone for TAILOR FL
19
302-38-019
302-38-006
Fabric cover for TAILOR DOB
Fabric cover for TAILOR FL
20
102-38-009
Blowing system
21
192-38-021
Spill tray
22
302-38-022
Fabric cover for spill tray
23
305-01-009
Handle of blowing operating lever
24
192-38-024
Foot pedal base
25
192-38-025
Vacuum’s foot pedal
26
302-26-026
Vacuum button pedal MV45
27
192-38-027
Ironing table base
28
302-38-028
Terminal block
29
302-38-029
Capacitor of motor Tailor
30
302-26-043
Motor 0.27HP TAILOR
31
302-02-014
Regulator Alignment adjusting leg

Instruction Manual
11

Instruction Manual
12
For any advice about the operation of the machine or the spare parts, please contact the dealer you
have purchased the machine from or us directly at:
14th km Thessaloniki –Kilkis, 57200 Liti, Thessaloniki, Greece
Tel.: [phone] Fax: [phone]
E-mail: [email protected]
All specifications have been made to the best of our knowledge.
Primula S.A preserves the right to make changes to the system and its parts without prior notice.
TECHNICAL ASSISTANCE
