Prince Castle DHB3PT-KFCCN User manual

520-501revA-EN
Building 5, No. 889 Kungang Road.,XiaoKunShan Town, Songjiang District, Shanghai, China, Zip Code 201614
Tel: [phone] www.princecastle.com
LIMITED WARRANTY
This product is warranted to be free from defects in material and/or
workmanship
for a period of 1 year from date of original installation, not to exceed 18 months
from the date of manufacture.
Any component which proves to be faulty in material and/or workmanship will be
replaced or repaired (at the option of Prince Castle, Inc.) without cost to the
customer for parts and labor. This warranty covers on location service (i.e. trip
charges and or mileage). Travel mileage is limited to 100 miles (200 Kilometers)
round trip (one trip warranty) from an authorized service agency or its sub-
service
agency.
This warranty is subject to the following exceptions/conditions:
• Use of any non-genuine Prince Castle parts voids this warranty.
• All labor to be performed during regular work hours. Overtime premium (the
incremental amount) will be charged to the customer.
• Damage caused by carelessness, neglect and/or abuse (e.g., dropping,
tampering or altering parts, equipment damaged in shipment, by fire, flood or
an act of God) is not covered under this warranty.
• All problems due to operation at voltages other than that specified on
equipment nameplates are not covered by this warranty. Conversion to correct
voltage is the customer’s responsibility.
• This equipment must be serviced by Prince Castle Authorized Service Agency
or a Prince Castle Service Technician during the warranty period.
Note: 520-120 wire frame and 520-202 tray is consumable, not covered under
this warranty.
TABLE OF CONTENTS
Safety Information.......................................................................2
Electrical Specification................................................................2
Product Identification.................................................................2
Installation...................................................................................3
Operation....................................................................................3
Cleaning......................................................................................4
Setting the Temperature.............................................................4
Calibrating Heater......................................................................5
Trouble Shooting.........................................................................6
Wiring Diagram...........................................................................6
Exploded View and Parts List.....................................................7
Operation
Manual
Holding Bin
DHB3PT-KFCCN
Display
Set point
UP arrow
Down arrow
Button 1、2、3
DHB3PT-KFCCN

DHB3PT-KFCCN
Safety Information
Electrical Specfication
Model No. Volts Watts Hz
DHB3PT-KFCCN 208-240 1717-2286 50
Product Identification
Important
Control panel
Power switch
Tray
Guide rail
Indicates information important to the proper operation of the
unit. Failure to observe may result in damage to the
equipment and/or severe bodily injury or death.
WARING
CAUTION
Indicates information important to the operation of the unit.
Failure to observe may result in damage to the equipment.
Prince Castle reserves the right to change specifications and product design without notice. Such revisions do not entitle the buyer to
corresponding changes, improvements, additions or replacements for previously purchased equipment.
Guide rail (3pcs)
Tray(3 pcs, use with Al bakery pans)
Pan cover (3 pcs, use with full size plastic pans)
This warning is not for EUROPEAN market:This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be
supervised to ensure that they do not play with the appliance.
This warning is only for EUROPEAN market only:This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall
not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order
to avoid a hazard.
WARING
To prevent an electric shock hazard, this device must be
bonded to equipment in close proximity with an
equipotential bonding conductor. This device is equipped
with a grounding lug for this purpose and is marked with
the following symbol.

DHB3PT-KFCCN
520-501 revA-EN
Operation
Installation
Remove the unit from the carton and inspect for signs of damage. If there is
damage to the unit:
• notify the carrier within 24 hours of delivery
• save carton and packaging materials for inspection purposes
• contact your local dealer, or if purchased directly, the Prince Castle Sales
Department at [phone] to arrange for a replacement
unit.
Verify that the following parts have been received.
• Three Trays、three Guide rails and 2 aluminum pan covers.
NOTE: When installing this unit, the ambient temperature at the
mounting site should not exceed 100°F.
Plug the power cord into the proper electrical receptacle. All electrical
connections must be in accordance with local electrical codes and any
other applicable codes.
2. Place the cooked food in food pans (optional) and
place the pans in the cabinet with intedned
accessories.
Allow 20minutes for heaters to
reach operating temperature.
Control panel will display “_ _ _
_” when unit is warmed up.
3. The three layers are separate control，if you
want to close one of three layers，Press and
hold the number button until the light is off.
4. Turn off the power switch when closing.
3
1. Turn power ON/OFF switch to ON position.

DHB3PT-KFCCN
Cleaning
WARNING
Before performing any maintenance, turn the power
switch to the OFF position and unplug the power cord
from the electrical receptacle.
CAUTION
NOTE: To reset all temperatures to the factory settings, turn the unit off, then press and hold the UP and DOWN Arrow buttons simultaneously while turning the
unit on. All temperatures will be reset to original factory settings.
This unit is not watertight. Do not clean with a water jet/jet spray. Do not
immerse the unit in water.
1. Turn the unit off and unplug the power cord from the electrical receptacle.
2. Remove the pan covers and pan racks. Wipe all parts and unit with a damp
cloth. DO NOT use a green Scotch Bright pad cleaner, ice or water.
Setting the Temperature
1. Press and hold the SET POINT button，until
show the set temperature.
95C
note：
a. a point beside upper shelf
light,show will change upper
heater temperature.
a point beside lower shelf
light, show will change
lower heater temperature.
b. which one of number button
flash show will change heater
temperature of the layer.
3. Press upper arrow button or lower arrow
button until show the temperature what you
want.
4. Press“1”button，save the changed.
2. Press SET POINT button，select the heater
which is you want to change.
90C
90C
4
Hot surface!

DHB3PT-KFCCN
520-501 revA-EN
5. If you want to adjust more the heaters
temperature, you can press SET POINT button to
select the next heater after set a heater
temperature.
Warning
Hot surfaces. Use caution when taking
temperature readings within the shelf.
Calibration Heater
Setting the Temperature（continued）
1. Press and hold Set Point and Up arrow
button，display will show the actual
temperature of the heater.
94C
6. Press "1" button to save these settings and exit
after completion.
2. Take a tempreature reading within the shelf
near the center of the heater surface.
Heater Center
Use a stand-alone
temperature meter(not
supplied)
3. Press the UP or DOWN arrow button until the
temperature displayed matches the reading obtained.
95C
4. Press“1”button to save the temperature
value and exit the Calibration mode。
5
NOTE: Allow sufficient amount of
time for temperatures to stabilize
before starting calibration.
Press the UP or DOWN Arrow
button until the desired shelf LED
and upper(U) or lower (L) heater
is selected.

DHB3PT-KFCCN
Trouble shooting
Wiring Diagram
6

DHB3PT-KFCCN
520-501 revA-EN
NO
PART
NUMBER
DESCRIPTION
Qty
NO
PART
NUMBER
DESCRIPTION
Qty
1
520-105
BASE
1
17
520-104
BASE FITTING PLATE
1
2
520-107
SUPPORT PLATE,RIGHT
1
18
547-067
SCREW
1
3
520-109
SUPPORT PLATE,LEFT
1
19
520-210
NYLON THERMAL
BARRIER STRIP
6
4
520-116
ALUMINIUM
PLATE(LARGE)
4
20
520-011
MAIN PCB
1
5
520-117
ALUMINIUM PLATE
(SMALL)
2
21
99432
BUSHING
1
6
520-118
STRAIN RELIEF FIXED
PLATE
1
22
542-164
GUARD SWITCH
1
7
520-110
MAIN PCB MOUNTING
PLATE
1
23
66-045
STRAIN RELIEF
1
8
78-233
POWER SWITCH
1
24
PM-123A
POWER CORD
1
9
520-103
TOP SUPPORT PLATE
1
*
197-232
FEET
4
10
520-114
HEATER PLATE APRON
2
*
542-432H
ROPE HEATER
6
11
520-119
SIDE PLATE
2
*
520-211
PAPER CARD
MOUNTING BOARD
1
12
520-115
SIDE PLATE MOUNTING
PLATE
2
*
520-120
WIRE FRAME
3
13
520-102
TOP COVER
1
*
520-201
TRAY
3
14
520-111
DISPLAY BOARD
MOUTING PLATE
1
15
520-010
DISPLAY BOARD
1
*
Not shown
16
520-012
Overlay
1
Exploded View and Parts List
7
