Pro-Elec PEL01350 User manual

1
Solar Road Stud Light
Model: PEL01350
Please read these instructions carefully before use and retain for future reference.
IMPORTANT SAFETY INFORMATION
• Avoid locations of high temperature or humidity.
• The lamp is rated at IP65 for external use.
WHAT’S INCLUDED
• Lamp assembly.
• User manual.
• The road stud can be either bolted to the surface or afxed using epoxy adhesive.
• Ensure the surface and the base of the stud are clean before applying adhesive.
Allow at least 8 hours for the adhesive to cure fully.
INSTALLATION
OPERATION
• Allow at least 8hrs for the battery to fully charge initially.
CLEANING & MAINTENANCE
• Clean the unit only with a damp cloth. Do not use any chemicals, abrasives or
solvents that could damage the casing or lens.
NOTE: the lamp does not light except in low ambient light levels.
• When the ambient light falls below a preset level the LEDs will illuminate
constantly.

2
INFORMATION ON WASTE DISPOSAL FOR CONSUMERS OF
ELECTRICAL & ELECTRONIC EQUIPMENT.
When this product has reached the end of its life it must be treated as Waste Electrical & Electronic
Equipment (WEEE). Any WEEE marked products must not be mixed with general household waste,
but kept separate for the treatment, recovery and recycling of the materials used. Contact your local
authority for details of recycling schemes in your area.
Made in China. PR2 9PP
Man Rev 1.0
SPECIFICATION
Solar panel: 2V, 0.25W
Battery: 1 x Ni-MH 700mAh rechargeable.
LED: 6 Epistar white
Working time: up to 72 hours.
Dimensions: L105 x W95 x H23mm.
Load bearing: 20 tons.
