Pro-face CA2-ISOALL422-01 User manual

RS-232C/422 Isolation Unit
Installation Guide
Thank you for purchasing Pro-face's RS-232C/422 Isolation Unit (CA2-ISOALL232-
01/CA2-ISOALL422-01). This unit is designed to utilize the GP/GLC unit's serial inter-
face connector (Dsub25-pin), and electrically separates the serial interface signal from
the GP/GLC unit's chassis.
Essential Safety Precautions
WARNINGS
•To avoid an electric shock, prior to connecting this unit to the
display's serial interface, confirm that the display's power sup-
ply is completely turned OFF, via a breaker, or similar unit.
•Do not modify this unit. Doing so may cause a fire or an elec-
tric shock.
•Do not use this unit in an environment where flammable gases
are present, since operating this unit may cause an explosion.


General Safety Precautions
•Do not allow water, liquids, metal or charged particles to enter inside
this unit, since they can cause either a unit malfunction or an electri-
cal shock.
•Do not use or store this unit in direct sunlight, or in excessively dusty
or dirty environments.
•Do not store or use this unit where strong jolting or excessive vibra-
tion can occur.
•Do not store or use this unit where chemicals (such as organic sol-
vents, etc.) and acids can evaporate, or where chemicals and acids are
present in the air.

Package Contents
Please check that the following items are included in your package.


Isolation Unit
CA2-ISOALL232-01 (RS-232C Type) or CA2-ISOALL422-01 (RS-422 Type)


Installation Guide (this guide)


Attachment Ties (2)
CE Marking
The CA2-ISOALL232-01 and CA2-ISOALL422-01 are a CE marked, EMC compliant
products.
These units conform to EN55011 Class A and EN61000-6-2 directives.
For detailed CE marking information, please contact your local distributor.
Compatible Models
The following GP/GLC Series units are compatible with the Isolation Unit. (As of July,
2002)
GP70 Series GP77R Series / GP2000 Series GLC Series / Others
GPH70-LG41-24VP*1 GP377R-TC11-24V GLC100-LG41-24V
GPH70-SC41-24VP*1 GP377R-TC41-24V GLC100-SC41-24V
GP370-LG21-24VP GP577R-SC41-24VP GLC150-BG41-RSFL-24V
GP370-LG41-24VP GP577R-TC41-24VP GLC300-TC41-24V
GP370-SC21-24VP GP2301H-LG41-24V*1 GLC2300-LG41-24V
GP370-SC41-24VP GP2301H-SC41-24V*1 GLC2300-TC41-24V
GP37W2-BG41-24V GP2401H-TC41-24V*1 GLC2400-TC41-24V
GP570-BG11-24V GP2300-LG41-24V GLC2600-TC41-24V
GP570-LG21-24V GP2300-TC41-24V FGW-SE41-24V
GP570-SC21-24VP GP2301-LG41-24V GPH70-AP232-O
GP570-TC21-24VP GP2301-SC41-24V GP2000H-AP232
GP675-SC11 GP2400-TC41-24V
GP675-TC41-24VP GP2500-LG41-24V
GP377-LG11-24V GP2500-TC11
GP377-LG41-24V GP2500-TC41-24V
GP377-SC11-24V GP2501-SC11
GP377-SC41-24V GP2501-TC11
GP2600-TC11
GP2600-TC41-24V
*1 The Isolation unit cannot be attached directry to these GP models. To attach the Isolation
unit, either create your own cable, or use Digital’s separately sold Conversion
Adaptor(GPH70-AP232-O/GP2000H-AP232).

2.1 General
Unit mm:[in.]
1External Drawings and Dimensions
15[0.5
9]
83[3.27]
55[2.17]
2Specifications
Item Description
Input Voltage 5V (supplied from display)
Power Consumption 1.25W or less
Voltage Endurance AC1,000V 20mA for 1minute
(When attached to display)
Insulation Resistance
10MΩor hi
g
her at DC500V
(When attached to display)
Isolation resistance beween display and Device/PLC is 1MΩ
Item Description
Coolin
g
Method Natural air circulation
Wei
g
ht 65
g
[0.14lb] or less
External Dimensions W83mm[3.27in]×H55mm[2.17in]×D15mm[0.59in]
2.2 Structural

3.1 RS-232C Type
3Serial Interface Specifications
The RS-232C type (CA2-ISOALL232-01) Dsub 25-pin connector's pin assignments are
as follows.
Pin # Si
g
nal
Name Condition Si
g
nal
Direction
1 FG Frame ground -
2 SD Send data Output
3 RD Receive data Input
4 RS Request send Output
5 CS Clear send Input
6 DR Data Set Ready Input
7 SG Signal ground -
8 CD Carrier detect Input
9-13 NC No connection -
14 VCC +5V±5% output 0.15A Output
15-16 NC No connection -
17 RI Ring Indicate Input
18-19 NC No connection -
20 ER Enable receive Output
21-25 NC No connection -
Recommended Connector :Dsub25pin plug XM2A-2501 <made by OMRON>
Recommended Cover :Dsub25pin cover XM2S-2511 <made by OMRON>
Jack Screws XM2Z-0071 <made by OMRON>
Recommended Cable :CO-MA-VV-SB5PX 28AWG
<made by HITACHI Cable Ltd.>
Use rough metric type M2.6 x 0.45 p threads used to secure the
cable's set screws.

3.2 RS-422 Type
The RS-422 type (CA2-ISOALL422-01) Dsub 25-pin connector's pin assignments are
as follows.
Recommended Connector :Dsub25pin plug XM2A-2501 <made by OMRON>
Recommended Cover :Dsub25pin cover XM2S-2511 <made by OMRON>
Jack Screws XM2Z-0071 <made by OMRON>
Recommended Cable :CO-MA-VV-SB5PX 28AWG
<made by HITACHI Cable Ltd.>
Use rough metric type M2.6 x 0.45 p threads used to secure the
cable's set screws.
4Isolation Unit Connection Precaution
Since attaching the isolation unit can cause cabling problems, or put stress on the inter-
face connector, Pro-face recommends the purchase of the optional interface cable (CA1-
EXCBL/D25-01). When this cable is used, please attach the Attachment Ties provided
in the Isolation Unit's package.
Pin # Si
g
nal
Name Condition Si
g
nal
Direction
1 FG Frame ground -
2-6 NC No connection -
7 SG Signal ground -
8 NC No connection -
9 TRMX Termination -
10 RDA Receive data A Input
11 SDA Send data A Output
12-13 NC No connection -
14 VCC +5V±5% output 0.15A Output
15 SDB Send data B Output
16 RDB Receive data B Input
17 NC No connection -
18 CSB Clear send B Input
19 ERB Enable receive B Output
20 NC No connection -
21 CSA Clear send A Input
22 ERA Enable receive A Output
23-25 NC No connection -

Digital Electronics Corporation
8-2-52 Nanko Higashi, Suminoe-ku, Osaka
559-0031, Japan
URL : http://www.pro-face.com/
Note
Please be aware that Digital Electronics Corpora-
tion shall not be held liable by the user for any dam-
ages, losses, or third party claims arising from the
uses of this product.
