Siemens SIMATIC IM 151/CPU User manual

Important Notes, Contents
Product Overview 1
Addressing 2
ET 200S in the PROFIBUS
Network 3
Commissioning and Diagnostics 4
Functions of the IM 151/CPU 5
Technical Specifications 6
Cycle and Response Times 7
Getting Started 8
Configuration Frame and
Parameter Assignment Frame for
the ET 200S A
Instruction List B
Execution Times of the SFCs and
SFBs C
Migration of the IM 151/CPU D
Glossary, Index
Edition 05/2000
A5E00058783-01
ET 200S Interface Module
IM 151/CPU
Manual
This manual is part of the document package with the order
number: 6ES7 151-1AA00-8BA0
SIMATIC

OChapter
Index-2 ET 200S Interface Module IM 151/CPU
A5E00058783-01
!Danger
indicates that death, severe personal injury or substantial property damage will result if proper precau-
tions are not taken.
!Warning
indicates that death, severe personal injury or substantial property damage can result if proper precau-
tions are not taken.
!Caution
indicates that minor personal injury or property damage can result if proper precautions are not taken.
Note
draws your attention to particularly important information on the product, handling the product, or to a
particular part of the documentation.
Qualified Personnel
Only qualified personnel should be allowed to install and work on this equipment. Qualified persons
are defined as persons who are authorized to commission, to ground, and to tag circuits, equipment, and
systems in accordance with established safety practices and standards.
Correct Usage
Note the following:
!Warning
This device and its components may only be used for the applications described in the catalog or the
technical descriptions, and only in connection with devices or components from other manufacturers
which have been approved or recommended by Siemens.
This product can only function correctly and safely if it is transported, stored, set up, and installed cor-
rectly, and operated and maintained as recommended.
Trademarks SIMATIC, SIMATIC HMIand SIMATIC NETare registered trademarks of SIEMENS AG.
Some of other designations used in these documents are also registered trademarks; the owner’s rights
may be violated if they are used by third parties for their own purposes.
Safety Guidelines
This manual contains notices which you should observe to ensure your own personal safety, as well as
to protect the product and connected equipment. These notices are highlighted in the manual by a
warning triangle and are marked as follows according to the level of danger:
We have checked the contents of this manual for agreement with the hard-
ware and software described. Since deviations cannot be precluded entirely,
we cannot guarantee full agreement. However, the data in this manual are
reviewed regularly and any necessary corrections included in subsequent
editions. Suggestions for improvement are welcomed.
Disclaimer of LiabilityCopyright Siemens AG 1998 All rights reserved
The reproduction, transmission or use of this document or its contents is not
permitted without express written authority. Offenders will be liable for
damages. All rights, including rights created by patent grant or registration of
a utility model or design, are reserved.
Siemens AG
Bereich Automatisierungs- und Antriebstechnik (A&D)
Geschäftsgebiet Industrie-Automatisierungsysteme (AS)
Postfach 4848, D- 90327 Nürnberg SiemensAG 2000
Technical data subject to change.
Siemens Aktiengesellschaft

iii
ET 200S Interface Module IM 151/CPU
A5E00058783-01
Important Information
Purpose of the Manual
This manual supplements the ET 200S Distributed I/O System manual. It
describes all the functions of the IM 151/CPU interface module. The manual does
not deal with general ET 200S functions. You will find descriptions of these in the
ET 200S Distributed I/O System manual (see also the section entitled ”Delivery
Package”).
The information contained in this manual and in the ET 200S Distributed I/O
System manual will enable you to operate the ET 200S with the IM 151/CPU
interface module as a DP slave on the PROFIBUS-DP or in a stand-alone
configuration.
Target Group
The manual describes the hardware of the IM 151/CPU interface module and is
aimed at configuration engineers, commissioning engineers and maintenance
personnel who use the ET 200S with PLC functionality.
It consists of chapters containing instructions and reference chapters.
Delivery Package
This delivery package (order number 6ES7 151-1AA00-8BA0) consists of three
manuals, with contents as follows:
IM 151/CPU Interface Module
Installing and wiring the
ET 200S
Commissioning and
diagnostics of the ET 200S
Technical specifications of
the IM 151, digital and
analog electronic modules,
process-related modules
Order numbers for the
ET200S
ET 200S Distributed I/O
System ET 200S Motor Starters
Installing and wiring motor
starters
Commissioning and
diagnostics of motor
starters
Technical specifications of
motor starters
Order numbers for motor
starters
IM 151/CPU addressing
ET 200S with IM 151/CPU in
the PROFIBUS network
Commissioning and
diagnostics of the
IM 151/CPU
Technical specifications of
the IM 151/CPU
 List of STEP 7 instructions

Important Information
iv ET 200S Interface Module IM 151/CPU
A5E00058783-01
Applicability
This manual is valid for the IM 151/CPU interface module with the order numbers
6ES7 151-7AA00-0AB0 and 6ES7 151-7AB00-0AB0 as well as the components of
the ET 200S specified in the ET 200S Distributed I/O System manual.
This manual contains a description of the components that were valid at the time
the manual was published. We reserve the right to enclose a Product Information
bulletin containing up-to-date information about new components and new versions
of components.
Standards, Certificates and Approvals
The ET 200S distributed I/O system is based on EN 50170, Volume 2, PROFIBUS.
The ET 200S distributed I/O system fulfills the requirements and criteria of
IEC 1131, Part 2 and the requirements for obtaining the CE marking. CSA, UL and
FM certifications have been obtained for the ET 200S.
Shipbuilding certification has been applied for.
You will find detailed information on these standards, certificates and approvals in
the ET 200S Distributed I/O System manual.
Position in the Information Landscape
In addition to the ET 200S manuals, you will also need the manual for the DP
master used and the documentation for the configuration and programming
software used (see the list in Appendix A of the ET 200S Distributed I/O System
manual).
Note
You will find a detailed list of the contents of the ET 200S manuals in Section 1.2
of this manual.
We recommend that you begin by reading this section so as to find out which parts
of which manuals are most relevant to you in helping you to do what you want to
do.

Important Information
v
ET 200S Interface Module IM 151/CPU
A5E00058783-01
Aids to Finding Information
You can quickly access specific information in the manual by using the following
aids:
At the beginning of the manual you will find a comprehensive table of contents
and lists of the figures and tables in the manual.
The sections of the chapters in the manual contain subheadings that allow you
to gain a quick overview of the contents of the section.
You will find a glossary in the appendix at the end of the manual. The glossary
contains definitions of the main technical terms used in the manual.
At the end of the manual you will find a detailed index that enables you to find
the information you require quickly and easily.

Important Information
vi ET 200S Interface Module IM 151/CPU
A5E00058783-01

vii
ET 200S Interface Module IM 151/CPU
A5E00058783-01
Contents
1 Product Overview
1.1 What Is the IM 151/CPU Interface Module? 1-2. . . . . . . . . . . . . . . . . . . . . . . . .
1.2 Guide to the ET 200S Manuals 1-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 Addressing
2.1 Slot-Oriented Addressing 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.2 User-Defined Addressing 2-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3 Data Transfer with the DP Master 2-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.4 Accessing the Intermediate Memory in the IM 151/CPU 2-8. . . . . . . . . . . . . .
3 ET 200S in the PROFIBUS Network
3.1 ET 200S in the PROFIBUS Network 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2 Setting the PROFIBUS Address 3-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3 Network Components 3-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.4 Functions via the Programming Device/OP 3-9. . . . . . . . . . . . . . . . . . . . . . . . .
3.5 Direct Communication 3-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4 Commissioning and Diagnostics
4.1 Configuring the IM 151/CPU 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.2 Resetting the Memory of the IM 151/CPU 4-4. . . . . . . . . . . . . . . . . . . . . . . . . .
4.3 Commissioning and Startup of the ET 200S 4-7. . . . . . . . . . . . . . . . . . . . . . . . .
4.4 Diagnostics Using LEDs 4-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.5 Diagnostics via Diagnostic Address with STEP 7 4-11. . . . . . . . . . . . . . . . . . . .
4.6 Slave Diagnosis 4-14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.6.1 Station Status 1 to 3 4-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.6.2 Master PROFIBUS Address 4-18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.6.3 Manufacturer ID 4-19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.6.4 Module Diagnosis 4-20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.6.5 Module Status 4-21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.6.6 Structure of the Station Diagnosis 4-22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.7 System Status List (SSL) 4-24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Contents
viii ET 200S Interface Module IM 151/CPU
A5E00058783-01
5 Functions of the IM 151/CPU
5.1 Data for the PROFIBUS-DP 5-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.2 The Mode Selector and LEDs 5-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.3 Force 5-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.4 Memory Module 5-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.5 Clock 5-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.6 Blocks 5-13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.7 Parameters 5-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.8 Parameterization of the Reference Junction for the Connection of
Thermocouples 5-18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.9 Removal and Insertion of Modules During Operation 5-20. . . . . . . . . . . . . . . . .
5.10 Switching Power Modules Off and On During Operation 5-22. . . . . . . . . . . . . .
6 Technical Specifications
6.1 Technical Specifications of the IM 151/CPU 6-2. . . . . . . . . . . . . . . . . . . . . . . . .
7 Cycle and Response Times
7.1 Cycle time 7-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.2 Response Time 7-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.3 Interrupt Response Time 7-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8 Getting Started
8.1 Step 1: Installing the ET 200S/IM 151/CPU and S7-300 8-4. . . . . . . . . . . . . .
8.2 Step 2: Wiring the ET 200S/IM 151/CPU and S7-300 8-5. . . . . . . . . . . . . . . . .
8.3 Step 3: Commissioning the ET 200S/IM 151/CPU 8-6. . . . . . . . . . . . . . . . . . .
8.4 Step 4: Configuring the IM 151/CPU for Stand-Alone Operation 8-7. . . . . . . .
8.5 Step 5: Programming the IM 151/CPU 8-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8.6 Step 6: Test Run 8-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8.7 Step 7: Upgrading the IM 151/CPU and Commissioning the S7-300 8-11. . . .
8.8 Step 8: Configuring the IM 151/CPU as a DP Slave and the S7-300 as a
DP Master 8-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8.9 Step 9: Programming the IM 151/CPU and the S7-300 8-15. . . . . . . . . . . . . . .
8.10 Step 10: Commissioning and Test Run of the IM 151/CPU and S7-300 8-17.
A Configuration Frame and Parameter Assignment Frame for the ET 200S
A.1 Structure of the Configuration Frame (SKF) A-2. . . . . . . . . . . . . . . . . . . . . . . . .
A.2 Structure of the Configuration Frame (AKF) A-4. . . . . . . . . . . . . . . . . . . . . . . . .
A.3 Structure of the Parameter Assignment Frame A-6. . . . . . . . . . . . . . . . . . . . . .

Contents
ix
ET 200S Interface Module IM 151/CPU
A5E00058783-01
B Instruction List
B.1 Address Identifiers and Parameter Ranges B-2. . . . . . . . . . . . . . . . . . . . . . . . .
B.2 Abbreviations B-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B.3 Tab B-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B.4 Examples of Addressing B-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B.5 Execution Times with Indirect Addressing B-7. . . . . . . . . . . . . . . . . . . . . . . . . . .
B.5.1 Example of Memory-Indirect, Area-Internal Addressing B-9. . . . . . . . . . . . . . .
B.5.2 Example of Register-Indirect, Area-Internal Addressing B-10. . . . . . . . . . . . . . .
B.5.3 Example of Memory-Indirect, Area-Crossing Addressing B-11. . . . . . . . . . . . . .
B.5.4 Example of Addressing Via Parameters B-12. . . . . . . . . . . . . . . . . . . . . . . . . . . .
B.6 Bit Logic Instructions B-13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B.7 Logic Instructions with Parenthetical Expressions B-15. . . . . . . . . . . . . . . . . . . .
B.8 ORing of AND Operations B-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B.9 Logic Instructions with Timers and Counters B-17. . . . . . . . . . . . . . . . . . . . . . . .
B.10 Logic Instructions with the Contents of Accumulator 1 B-18. . . . . . . . . . . . . . . .
B.11 Logic Instructions with Condition Code Bits B-19. . . . . . . . . . . . . . . . . . . . . . . . .
B.12 Edge-Triggered Instructions B-25. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B.13 Setting/Resetting Bit Addresses B-26. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B.14 Instructions Directly Affecting the RLO B-27. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B.15 Timer Instructions B-28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B.16 Counter Instructions B-29. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B.17 Load Instructions B-30. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B.18 Load Instructions for Timers and Counters B-32. . . . . . . . . . . . . . . . . . . . . . . . . .
B.19 Transfer Instructions B-33. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B.20 Load and Transfer Instructions for Address Registers B-35. . . . . . . . . . . . . . . .
B.21 Load and Transfer Instructions for the Status Word B-36. . . . . . . . . . . . . . . . . .
B.22 Load Instructions for DB Numbers and DB Length B-36. . . . . . . . . . . . . . . . . . .
B.23 Fixed-Point Math Instructions (16 Bits) B-37. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B.24 Fixed-Point Math Instructions (32 Bits) B-38. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B.25 Floating-Point Math Instructions (32 Bits) B-39. . . . . . . . . . . . . . . . . . . . . . . . . . .
B.26 Addition of Constants B-39. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B.27 Addition via the Address Register B-40. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B.28 Comparison Instructions with Integers (16 Bits) B-40. . . . . . . . . . . . . . . . . . . . . .
B.29 Comparison Instructions with Integers (32 Bits) B-41. . . . . . . . . . . . . . . . . . . . . .
B.30 Comparison Instructions (32-Bit Real Numbers) B-42. . . . . . . . . . . . . . . . . . . . .
B.31 Shift Instructions B-43. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Contents
xET 200S Interface Module IM 151/CPU
A5E00058783-01
B.32 Rotate Instructions B-44. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B.33 ACCU Transfer Instructions, Incrementing, Decrementing B-45. . . . . . . . . . . . .
B.34 Program Display and Null Operation Instructions B-45. . . . . . . . . . . . . . . . . . . .
B.35 Data Type Conversion Instructions B-46. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B.36 Complement Formation B-47. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B.37 Block Call Instructions B-48. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B.38 Block End Instructions B-49. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B.39 Exchanging Data Blocks B-49. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B.40 Jump Instructions B-50. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B.41 Instructions for the Master Control Relay (MCR) B-52. . . . . . . . . . . . . . . . . . . . .
C Execution Times of the SFCs and SFBs
C.1 System Functions (SFCs) C-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
C.2 System Function Blocks (SFBs) C-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
D Migration of the IM 151/CPU
D.1 Differences to Selected S7-300 CPUs D-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
D.2 Porting the User Program D-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Glossary
Index
