Pro's Kit MA-1003MA User manual

MA-1003MA （AC 110V-120V 60Hz）
MA-1003MF ( AC 220V-240V 50Hz )
Desk Type Magnifier Lamp
Certificate Number: TW98/12323QA
寶工實業股份有限公司
PROKIT’S INDUSTRIES CO., LTD.
http://www.prokits.com.tw
E-mail: [email protected]
User’s Manual
1st Edition,2009
©2009 Copy Right by Prokit’s Industries Co., Ltd
Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 - TestEquipmentDepot.com

DeskTypeMagnifierLamp Desk Type Magnifier Lamp
Desk Type Magnifier Lamp
MA-1003 MA / MA-1003MF
Thank you very much for purchasing Pro’skit Desk Type
Magnifier Lamp. The Desk Type Magnifier Lamp is ideal for
precise work in home, office and workshop as well as a lot of
other important places. Before using the Magnifier Lamp,
please read the following instructions.
1. Specification:
1) Complies with CE safety standards
2) Lens material: glass ∅ 100mm (4”)
3) Diopter: 3 diopter (1.75X) / 12diopter (4.00X)
4) Light source: T4 G10q 12W circular fluorescent lamp
5) Voltage: AC 110~120V 60 Hz / AC220-240V AC 50Hz
6) Supplied with electronic ballast
7) Product size: Base: 18*15cm,Height37.0cm
2. How to use:
1) Before use, remove all packing from around the lamp.
2) Put the lamp on the horizontal table.
3) Insert the plug into a conveniently located electrical
socket.
4) Switch on using the ON/OFF switch located on the surface
of the base.
5) To place the head in the desired position.
3. Replacing the Tube:
1) Always switch off, remove the plug from the mains supply and
allow the lamp to cool before changing the tube.
2) Rotate the head so you can see the underside. Using a
suitable screwdriver remove
the five small screws that secures the diffuser to the head of the
lamp.
3) Remove the diffuser and place safely to one side.
4) Remove the tube from the head and gently unplug the 4-pin
connector-discard the
old tube safely.
5) Gently push-fit the 4-pin connector onto the new tube
ensuring it is pushed on fully.
6) Position the new tube into the head, replace the diffuser and
tighten the 5 screws to
hold it in place.
4. Caution for safe using:
1) Indoor use only.
2) Environment temperature: -20°C~40°C.
3) Humidity: ≤95%.
4) Never disassemble the magnifier lamp unless you are a
qualified electrician.
5) Plug must be taken out while repairing the magnifier lamp.
6) Never leave the lens unattended in direct sunlight or where
light can shine through it.
This constitutes a fire hazard.
